Instruction Manual

Hidden CCD Camera VK-1321/PIR (B&W),

VKC-1338/PIR (Colour)

Contents

1. Safety Instructions ......................................................................................... 2

2. Description .................................................................................................... 3

3. Installation ..................................................................................................... 4

4. Wiring Instructions......................................................................................... 5

5. PIR Detector Board Installation and Descriptions ............................................ 6

6. Specications ................................................................................................ 9

7. Dimensional Drawings ................................................................................. 11

1. Safety Instructions

• Read these safety instructions and the operation manual rst before you install

and commission the camera.

• Keep the manual in a safe place for later reference.

• Contact your local dealer in case of malfunction.

• Protect your camera from contamination with water and humidity to prevent it

from permanent damage.

Never switch the camera on when it gets wet. Have it checked at an authorized

service center in this case.

• To disconnect the power cord of the cameras, pull it out by the plug.

Never pull the cord itself.

• Do not open the camera housing.

Maintenance and repair have to be carried out only by authorized service centers.

• Operate the camera only at a temperature range of -10°C to +50°C and at

a humidity of max. 90%.

• The camera is equipped with an automatic gain control (AGC) which increases

the sensitivity at low light levels.

Noisy pictures at these conditions are quite normal.

• Pictures including bright spotlights will cause perhaps vertical lines (smear) or

soft edges (blooming) on the monitor display. This happens most probably in

automatic shutter mode (AES).

This is not a defect but an effect caused by the CCD sensor.

• With darkened environment, and direct view into the IR lighting, is to be kept a

safety margin from >1m to the IR LEDs.

• Use only a mild detergent to clean the housing.

Never use dilution or gasoline for this can cause permanent damage to

the surface.

The cameras should never:

• be operated beyond the technical specications. This can lead to destruction.

• pointed with open iris towards the sun. (This can damage the sensor).

Note: This is a class A digital device. This digital device can cause harmful

interference in a residential area; in this case the user may be required

to take appropriate corrective action at his/her own expense.

2. Description

This B/W (Colour) HIDDEN CCD Camera uses high sensitive 1/3” interline transfer

CCD Image Sensor (CCD = Charge Coupled Device), and all state circuitry which

provides extremely long life and high reliability.

This Camera offers excellent image quality with low lag and high burn resistance,

and is not subject to distortions from magnetic elds.

Highly resistance to shock and vibration, and easy to install this Camera is a very

good choice for your B/W (Colour) CCTV system.

3. Installation

1. Secure the bracket to the wall with screws (included).

2. Attach the Camera Case to the bracket.

3. Adjust the vertical and horizontal angles by loosening screws (A&B) and

by turning the bracket vertically and horizontally.

4. Wiring Instructions

1. Connect the coaxial cable between the camera and the monitor using a 75ohms

coaxial cable.

2. Insert the AC plug into the AC power socket and the DC plug to the DC Jack.

Note: AC Adapter Sold separately (see Accessories)

Monitor to 24VDC

5. PIR Detector Board Installation and Descriptions

N.C.

JP2

VR2

VR1

N.O.

PULSE

Output Terminals

Pulse Count

Light Control

Recording Control

Time Adjustment

LED Selector

Sensitivity

Adjustment

Options Description

1. LED Selector

(3 pins: Top, Center, Bottom)

A. Top + Center w/black cap: Upon walk-testing:

Light blinking (disadvantages: Easy to identify

as a security system.)

B. Center + Low w/black cap: No light blinking

while detecting. (advantages: less obvious)

2. Sensitivity Adjustment A. To raise sensitivity: Turn clockwise to detect

longer distance and wider pattern.

B. To lower sensitivity: Turn counter clockwise

for detection in narrow areas.

3. Dwell Time Adjustment

Adjustable

from 2 to 40 sec.

For closure period of N.C/N.O relay connected to

an alarm panel, light control or recording control

of time lapse VCR, etc.

A. Max. time: Turn counter clockwise

B. Min. time: Turn clockwise

Top + Center pins of „J4” must be selected

to adjust the time setting.

High Low

„VR1”

Min. Max.

„VR2”

Options Description

4. Alarm control, Light

control or Recording

control (N.O or N.C)

(3 pins: Top, Center,

Bottom)

A. Top + Center w/black cap: Operate with „VR2”

to adjust time. (To set the relay output of the

Light control or Recording control, the time is

selected by individual preference or application.

B. Center + Bottom w/black jumper: Relay output

can be set for Security control panel for only

2 seconds.

Note: N.C./N.O. relay output current:

1A 125VAC, 2A 30VDC.

5. Pulse Control

Once or twice

4 pins: 2PAIRS w/jumper

connector

Position 1: Set to „ONCE” for instant reaction when

PIR detects someone: and either the

„alarm or Security control panel” or

„Recording control” will be triggered

immediately.

Position 2: Set to „Twice” when PIR detects

someone 2 times within 15 seconds.

6. Output Terminals

24 Hour/Anti-Tamper

N.C.: Normally Closed

A. For connection to: Security panel or

Light control CCTV

...etc.

B. With anti-tamper function for 24 hours.

N.O.: Normally Open Contacts

Note: Relay output current:

1A 125VAC, 2A 30VDC

7. Power: 12VDC

Standby Current: 3mA,

Working Current: 28mA

Caution:

The PIR is triggered by body movement,

excluding xed objects, however, do not place

in direct sunlight or reected sunlight.

N.C. N.O.

JP2

• Wide angle lens up to 100°, coverage areas to 30x30 feet

• Provide 64 beans in 3 layers

100° Top view

Side view

10 20 30 feet 10 20 30 feet

6. Specications

Model VK-1321/PIR VKC-1338/PIR

EDP No. 91989 91991

Automatic white balance

(AWB)

Supplied

Imager 1/3“ Sony Super HAD Interline Transfer CCD

Picture elements Approx. 440,000 (H) 752 x (V) 582

System CCIR CCIR/PAL

Synchronization Internal

Sensitivity

at 50% video signal

0.65Lux at F2.0 /

0.23Lux at F1.2

(VT measurement result)

5.6Lux at F2.0 /

2.0Lux at F1.2

(VT measurement result)

Horizontal resolution 600 TV lines 470 TV lines

Signal-to-noise ratio 48dB (AGC OFF)

Automatic gain control

(AGC)

Supplied

Automatic shutter

control (AES)

1/50 ~ 1/100,000sec.

Gamma correction 0.45

Lens F2.0/3.7mm pinhole

Horizontal angle of view 68°

External connections Video (BNC), 12VDC (DC socket)

Video output 1Vp-p, VBS, 75ohms 1Vp-p, CVBS, 75ohms

Supply voltage 12VDC ±10%

Power consumption 1.44watts 2.5watts

Temperature range -10° ~ +50°C

Housing Plastic

Mounting Wall mount (bracket included)

Colour Light grey

Dimensions See drawing

Weight 110g 125g

Accessories

EDP No. Description

70447 Plug-in Power Supply Unit 100-240VAC

77772 PSU 12VDC/0.5A, Regulated, Desktop

77779 Plug-in Power Supply Unit 230VAC/12VDC

Model VK-1321/PIR VKC-1338/PIR

EDP No. 91989 91991

Special features PIR sensor function.

NO/NC relay contact output (125VAC/1A, 30VDC/2A

resisitive), adjustable switching duration: 2 ~ 40sec.

sensor eld angles: 100° horizontal / 45° vertical,

detection range: up to 10m
