EMP-Centauri MS13/13+32EEU-14 Manuel utilisateur

Instruction Manual

MS13/13+32EEU-14

MS13/13+40EEU-14

MS13/13+52ECU-13

MS13/13+60ECU-13

Dear Customer,

congratulations on the purchase of the EMP-Centauri product. Before its installation and putting into

operation, read carefully the entire operation manual. Keep the purchase and rework if any) records for

future need.

1) Field of Application, Warranty

The product is designed for the distribution of satellite & terrestrial including cable) TV and radio signals. Its

main purpose is to allow connecting of multiple user to the common antenna SMATV).

The manufacturer provides for E.LITE CLASS products extended 4 four) years warranty from the date of

purchase, see details in EMP-Centauri’s General trade conditions, published at manufacturer’s website

www.emp-centauri.cz.

It is prohibited to dismantle the product and make any interventions in it. Repairs or any interventions in the

product may be performed only by EMP-Centauri company, or other companies authorized by EMP-

Centauri.

2) Technical Specifications

Products are cascadable multiswitches for distribution of terrestrial and satellite signals from 3 satellite

positions 12 polarities) to up to 60 users, depending on model. Satellite trunk lines are active and exhibit

small gain. Terrestrial trunk line is passive.

Terrestrial band can be switched passive / active for all user’s outputs. The insertion loss in satellite band is

sloped to compensate increasing loss of coaxial cables.

The multiswitch is DC supplied from connected satellite receivers, DC2.1 socket for external power 12V is

connected to all satellite inputs. DC pass is provided through the TERR line.

Specification MS13/13+32

EEU 14

MS13/13+40

EEU 14

MS13/13+52

EEU 13

MS13/13+60

EEU 13

Number of Trunk Lines 13 12 x SAT, 1 x TERR)

Number of User Outputs 32 40 52 60

Frequency Range SAT 950–2150 MHz, TERR 40–840 MHz

Insertion Loss – User Outputs* SAT 5–0 dB, TERR 0 / 30 dB SAT 8–0 dB, TERR 5 / 32 dB

Insertion Loss – Trunk Lines* SAT 1 dB gain, TERR 4 dB

Isolation – User Outputs min) 20 dB

Isolation – Trunk Lines min) 25 dB

Maximum Input level** SAT 100 dBuV, TERR 100 dBuV active, 110 dBuV passive

1 of 4

Specification MS13/13+32

EEU 14

MS13/13+40

EEU 14

MS13/13+52

EEU 13

MS13/13+60

EEU 13

Max. Level at User Outputs** SAT 100 dBuV, TERR 95 dBuV

Current drawn 70 mA per user output)

Dimensions w,d,h) 37.5 x 35.0 x 6.5 cm 37.5 x 45.0 x 6.5 cm

Temperature Range −25 – +50 °C

Notes: * average values; SAT: range of loss from low to high frequencies, TERR: switchable active / passive

** according to EN 50083-3/35dB IMA3 SAT), EN 50083-3/60dB IMA3 TERR)

3) Product Takeover

Make sure that the product is not damaged and following accessories are enclosed:

•power supply 12V

•75 Ω loads for the impedance matching of unused outputs 12 pcs for 32 & 40 outputs models,

20 pcs for 52 & 60 outputs models)

•plastic mounting foots for 35 mm DIN rail 3 pcs)

In the case of damage or missing accessories please contact your dealer.

4) Product Storing and Installation

We recommend the device to be installed and serviced by the qualified technician.

The product must not be stored and installed:

•in the place with excessive humidity

•in the place with dropping or splashing water,

•in the place with excessive dust pollution, mechanical vibrations or impacts

•in the place out of temperature limits specified in the section 2) Technical Specifications

•close to heat sources radiators or air ventilators, direct sunshine etc.)

•in the reach of children

Use the apparatus only in moderate climates not in tropical climate).

Fix the product firmly on a wall or another hard and inflammable surface with screws and dowels. The

product shall be in no case held only by the connected cables.

Further instructions:

•ensure the free space at least 10 cm around the product for the sufficient air circulation

•do not cover the product with curtains etc.)

•do not place any containers with liquids vases, glasses etc.) or naked flame sources lighted

candle etc.) on the product or near the product

5) Product Connection

Connect the product in accordance with this manual and valid regulation in you country. Use high quality 75 Ω

coaxial cable designed for satellite reception. The coaxial cables shall not be broken, the minimum bending

radius should be 5 cm. Mount the F connectors screw, crimp or compress type) on the ends of coaxial cables

Connect the F connectors into the F sockets of product and fasten them with an appropriate force.

•Connect input F sockets marked “A” – “D”, “TERR” with outputs of preceding device in the

2 of 4

cascade LNB/antenna, amplifier, cascadable multiswitch)

•Connect output F sockets marked “A” – “D”, “TERR” with inputs of following device in the cascade

cascadable multiswitch, amplifier) or with 75 Ohm terminators DC-blocked)

•Connect output F sockets marked “1”, “2”, “3”… with wall sockets or receivers or terminate them

with 75 ohm terminators*

•Connect connector marked with protective earth symbol with protective bonding conductor

•Connect DC2.1 socket marked “DC 12V” with power supply

* Termination is not required if terrestrial reception is not used.

6) Product Settings

Turn the knob “ACTIVE PASSIVE” to switch between active and passive mode of terrestrial band.

Each connected satellite receiver must be properly set up to have access to all connected LNBs. Follow

instruction manual for satellite receiver or TV set. The most common styles of setup are shown in the table:

SAT SYSTEM LNB) Setting style 1 Setting style 2 Setting style 3

A DiSEqC 1.0: 1 of 4 DiSEqC 1.0: A committed: AA

B DiSEqC 1.0: 2 of 4 DiSEqC 1.0: B committed: AB

C DiSEqC 1.0: 3 of 4 DiSEqC 1.0: C committed: BA

7) Safety

Due to security reasons the product and wiring in which the product is connected, must be grounded

properly. Use the terminal identified with the appropriate symbol to ground the product. Make sure the

antennas are properly protected against lightning.

The product should be disconnected from the wiring immediately if it gets into contact with liquids dropping

water, spilled drinks etc.).

8) Product Maintenance

The maintenance operation is especially cleansing of the product. Use only dry cloth to clean the product

and do not use any liquid agents.

Coaxial cables installed outdoors should be replaced once in a few years. Unscrew all F connectors and

clean connector contacts, resp. shorten the coaxial cable by approx. 2 cm, every 2 years.

9) Symbols Explanation

Certificate of conformity Protective earth

According to EU directive, electric and electronic devices which are identified by one of the

following symbols must not be disposed of together with municipal waste. When disposing

of the old device, use local waste collection and separation systems.

3 of 4

10) Wiring Example

More wiring examples are shown at the manufacturer’s website.

4 of 4

11) Contact

Manufacturer: EMP-Centauri s.r.o.

5. kvetna 690

339 01 Klatovy 4

Czech Republic

tel: +420) 376 323 813 sales)

tel: +420) 376 323 853 tech. support)

[email protected]

www.emp-centauri.cz

TERR ANTENNA

LNB

(QUATTRO)

LNB

(QUATTRO)

LNB

(QUATTRO)

MS13/13+40EEU 14 PA12

13x cable

MS13/13+40EEU 14

13x cable

MS13/13+40EEU 14

13x DC blocked load 75 Ω

PA12
