Installation Manual

MMI-20020979, Rev AB

May 2015

Micro Motion® Gas Density Meters (GDM)

Fiscal gas density measurement

Safety and approval information

This Micro Motion product complies with all applicable European directives when properly installed in accordance with the

instructions in this manual. Refer to the EC declaration of conformity for directives that apply to this product. The EC declaration of

conformity, with all applicable European directives, and the complete ATEX Installation Drawings and Instructions are available on

the internet at www.micromotion.com or through your local Micro Motion support center.

Information affixed to equipment that complies with the Pressure Equipment Directive can be found on the internet at

www.micromotion.com/documentation.

For hazardous installations in Europe, refer to standard EN 60079-14 if national standards do not apply.

Other information

Full product specifications can be found in the product data sheet. Troubleshooting information can be found in the transmitter

configuration manual. Product data sheets and manuals are available from the Micro Motion web site at

www.micromotion.com/documentation.

Return policy

Micro Motion procedures must be followed when returning equipment. These procedures ensure legal compliance with

government transportation agencies and help provide a safe working environment for Micro Motion employees. Failure to follow

Micro Motion procedures will result in your equipment being refused delivery.

Information on return procedures and forms is available on our web support system at www.micromotion.com, or by phoning the

Micro Motion Customer Service department.

Emerson Flow customer service

Email:

•Worldwide: [email protected]

•Asia-Pacific: [email protected]

Telephone:

North and South America Europe and Middle East Asia Pacific

United States 800-522-6277 U.K. 0870 240 1978 Australia 800 158 727

Canada +1 303-527-5200 The Netherlands +31 (0) 704 136 666 New Zealand 099 128 804

Mexico +41 (0) 41 7686 111 France 0800 917 901 India 800 440 1468

Argentina +54 11 4837 7000 Germany 0800 182 5347 Pakistan 888 550 2682

Brazil +55 15 3413 8000 Italy 8008 77334 China +86 21 2892 9000

Venezuela +58 26 1731 3446 Central & Eastern +41 (0) 41 7686 111 Japan +81 3 5769 6803

Russia/CIS +7 495 981 9811 South Korea +82 2 3438 4600

Egypt 0800 000 0015 Singapore +65 6 777 8211

Oman 800 70101 Thailand 001 800 441 6426

Qatar 431 0044 Malaysia 800 814 008

Kuwait 663 299 01

South Africa 800 991 390

Saudi Arabia 800 844 9564

UAE 800 0444 0684

Contents

Chapter 1 Planning ...........................................................................................................................1

1.1 Installation checklist .......................................................................................................................1

1.2 Best practices .................................................................................................................................2

1.3 Recommended sample flow rate ....................................................................................................3

1.4 Power requirements .......................................................................................................................4

1.5 Installation requirements for the thermo-well pocket .................................................................... 5

1.6 Recommended installations for gas density applications ................................................................6

1.7 Perform a pre-installation meter check .........................................................................................14

Chapter 2 Mounting .......................................................................................................................16

2.1 Mount the meter in the pipeline ...................................................................................................16

2.2 Connect the gas bypass lines ........................................................................................................18

2.3 Rotate the electronics on the meter (optional) .............................................................................20

2.4 Rotate the display on the transmitter (optional) ...........................................................................20

2.5 Post-installation check ................................................................................................................. 22

Chapter 3 Wiring ........................................................................................................................... 23

3.1 Available output terminals and wiring requirements .................................................................... 23

3.2 Hazardous area output wiring ...................................................................................................... 23

Chapter 4 Grounding ......................................................................................................................32

Contents

Installation Manual i

Contents

ii Micro Motion® Gas Density Meters

1 Planning

Topics covered in this chapter:

•Installation checklist

•Best practices

•Recommended sample flow rate

•Power requirements

•Installation requirements for the thermo-well pocket

•Recommended installations for gas density applications

•Perform a pre-installation meter check

1.1 Installation checklist

□Verify the contents of the product shipment to confirm that you have all parts and

information necessary for the installation.

Part Quantity

Micro Motion® Gas Density Meter (GDM) 1

Accessories kit:

-M20 to 1/2-inch NPT adapter (if applicable)

-1/2-inch NPT blanking plug

-2.5 mm hex key

Aluminum sleeve 1

Silicon fluid 1

Thermo-well pocket kit (if applicable) 1

Calibration certificate 1

Safety instructions booklets 2

Micro Motion Product Documentation DVD 1

□Make sure that all electrical safety requirements are met for the environment in

which the meter will be installed.

□Make sure that the local ambient and process temperatures and process pressure

are within the limits of the meter.

□Make sure that the hazardous area specified on the approval tag is suitable for the

environment in which the meter will be installed.

□If installing the meter in a hazardous area, confirm that you have the required safety

barriers or galvanic isolators for your installation.

□Make sure that you will have adequate access to the meter for verification and

maintenance.

Planning

Installation Manual 1

□Make sure that the process gas meets the recommended characteristics regarding

composition, temperature, and pressure for your installation.

□Verify that you have all equipment necessary for your installation. Depending on

your application, you may be required to install additional parts for optimal

performance of the meter.

□Follow recommended best practices for installing the GDM to account for the

effects of density, temperature, and pressure equilibrium.

1.2 Best practices

The following information can help you get the most from your meter.

•Handle the meter with care. Follow local practices for lifting or moving the meter.

•Ensure that the process gas is clean and dry.

•Do not use gases incompatible with the materials of construction. To prevent

corrosion of the sensing element, the process gas should be compatible with

Ni-Span-C.

•Do not expose the meter to excessive vibration (greater than 0.5 g continuously).

Vibration levels in excess of 0.5 g can affect the meter accuracy.

•Perform a Known Density Verification (KDV) check of the meter prior to installing

the meter in your system.

•Installing the meter in a bypass configuration allows you to remove the meter for

servicing or calibration without affecting the main pipeline.

•Install the meter in a thermo-well pocket to ensure the temperature of the sample

gas is equal to that of the pipeline gas. Micro Motion thermo-well pocket kits are

available for purchase.

•Minimize the length and volume of the input sample pipe to ensure an optimal

meter response time. Use 6 mm (1/4 in) instrument tubing and low-volume inlet

filters.

•Control gas flow with a needle valve mounted before or after the meter, depending

on the installation.

•Install an external coalescing filter in the sample gas inlet pipework to minimize

condensate and dust contamination.

•Verify that the filters in your system are not causing any excessive flow restrictions.

•Verify that the pressure of the process gas is approximately equal to the pipeline

pressure.

•Do not exceed more than a 10% reduction of the cross-sectional area at the point of

insertion in the pipeline to ensure minimal effect on pressure.

•Ensure that the meter and associated pipework are pressure-tested to 1½ times the

maximum operating pressure after installation.

•Install thermal insulation to the meter and the inlet and bypass-loop pipeline to

maintain temperature equilibrium between the sample and pipeline gases. Do not

insulate the transmitter (electronics) and maintain a nominal 1-in clearance

between the insulation and the transmitter housing.

Planning

2Micro Motion® Gas Density Meters

1.3 Recommended sample flow rate

Use the smallest acceptable flow rate for the process gas passing through the meter. This

ensures a sample gas flow rate that is representative of the main flow with regard to the

proportions of different gas constituents.

Micro Motion recommends a gas flow rate of 5 ±1 l/hr (0.176 ±0.35 ft3/hr), although a flow

rate between 1 to 10 l/hr (0.035 to 0.35 ft3/hr) is acceptable.

At flow rates greater than 10 l/hr (0.35 ft3/hr), the density reading can become slightly

unstable and may introduce a small density error. For natural gas with a typical application

density of approximately 0.06 g/cm3 (60 kg/m3), a pressure differential of approximately

1.66 mbar (0.67 in WC) is required to maintain a flow rate of 5 l/hr (0.176 ft3/hr) .

Pressure drop through the meterFigure 1-1:

Volume of gas in meter = 40 cm3

3.5

2.5

1.5

0 2 4 6 8 10

Flowrate (lt/hr)

Recommended

operating

flow rate

Volume of gas in meter = 2.44 in3

1.2

1.0

0 0.05 0.1 0.15 0.2 0.25 0.3 0.35

Flowrate (ft3/hr)

Pressure drop (mbar)

Pressure drop (inch WC)

Recommended

operating

flow rate

Planning

Installation Manual 3

1.4 Power requirements

Following are the DC power requirements to operate the meter:

•24 VDC, 0.45 W maximum

•Minimum 22.8 VDC with 1000 m (3280 ft) of 0.20 mm2 (18 AWG) power-supply

cable

•At startup, power source must provide a minimum of 0.5 A of short-term current at

a minimum of 19.6 V at the power-input terminals.

Power cable recommendations

Minimum wire gauge (AWG per feet)Figure 1-2:

300 600 900 1200 1500 1800 2100 2400 2700 3000

Distance of Installation (ft)

22.8V

24V

AWG

Minimum Wire Gauge

Planning

4Micro Motion® Gas Density Meters

Minimum wire area (mm2 per meter)Figure 1-3:

0.000

0.050

0.100

0.150

0.200

0.250

0.300

0.350

0.400

0.450

0.500

0.550

0.600

0.650

0.700

0.750

0.800

0.850

0.900

100 200 300 400 500 600 700 800 900 1000

Minimum Wire Area (mm2)

Distance of Installation (m)

Minimum Wire Area (mm2)

22.8V

24V

1.5 Installation requirements for the thermo-well

pocket

Installation of the GDM in a thermo-well pocket helps maintain temperature equilibrium

between the sample gas and pipeline gas. Micro Motion provides thermo-well pocket

installation kits for purchase. Contact your local sales representative or Micro Motion

Customer Support at [email protected] for more information.

A thermo-well pocket installation requires the following, before you can mount and

connect the GDM:

1. Create an aperture in the pipeline to receive the pocket (see Figure 1-4 for the pocket

dimensions).

Important

Micro Motion recommends that you do not exceed more than a 10% reduction of the cross-

sectional area at the point of insertion to ensure minimal effect on pressure. Follow local

practices and guidelines for welding in hazardous areas, if applicable.

2. Install and weld the pocket in place. Be sure to follow local practices and guidelines

for welding in hazardous areas, if applicable.

Planning

Installation Manual 5

Micro Motion thermo-well pocket dimensionsFigure 1-4:

6.00

(152.30)

Ø3.94

(100.00)

1.59

(40.30)

2.83

(72.00)

Dimensions in inches

(mm)

1.6 Recommended installations for gas density

applications

Micro Motion recommends specific installations for the GDM depending on the gas

density application – as defined by international standards, ISO 5167 and AGA 3. This

information is provided for your reference only.

1.6.1 Installation in an orifice plate metering system

The orifice plate metering system is a widely used method for accurate flow measurement

of natural gas. The orifice meter is a differential pressure device in which the orifice plate

causes a pressure drop between the upstream and downstream sides. The flow rate is

determined from the dimensions of the system (as defined by international standards ISO

5167 and AGA 3), and from measurements of differential pressure and fluid density.

Planning

6Micro Motion® Gas Density Meters

Table des matières

Autres manuels Emerson Instrument de mesure

Emerson

Emerson MRLDS-250 Mode d'emploi

Emerson

Emerson Rosemount 3410 Series Manuel utilisateur

Emerson

Emerson Daniel 3812 Manuel utilisateur

Emerson

Emerson CSI 2140 Manuel utilisateur

Emerson

Emerson EC2-XC645CX Schéma de câblage

Emerson

Emerson Rosemount Analytical FCLi Manuel utilisateur

Emerson

Emerson Rosemount Oxymitter DR Manuel utilisateur

Emerson

Emerson Nelson CM-1 Manuel utilisateur

Emerson

Emerson R&S SGT100A Manuel utilisateur

Emerson

Emerson Daniel Ultrasonic 3410 Series Manuel utilisateur

Emerson

Emerson Rosemount 3410 Series Manuel de programmation

Emerson

Emerson Rosemount WPG: Rosemount SPG Manuel utilisateur

Emerson

Emerson Daniel 3410 Series Manuel utilisateur

Emerson

Emerson Rosemount X-Stream Series Manuel utilisateur

Emerson

Emerson Aventics R412018223 Manuel utilisateur

Emerson

Emerson TopWorx 4310 Manuel utilisateur

Emerson

Emerson Daniel 3410 Series Manuel utilisateur

Emerson

Emerson Daniel 3814 Manuel de programmation

Emerson

Emerson ROSEMOUNT 485 Annubar Pak-Lok Manuel utilisateur

Emerson

Emerson PACSystems IPC 2010 Manuel utilisateur

Emerson

Emerson Rosemount CT5800 Manuel utilisateur

Emerson

Emerson ROSEMOUNT370XA Manuel utilisateur

Emerson

Emerson 2130 RBM Consultant Pro Manuel utilisateur

Emerson

Emerson 6888i Manuel utilisateur

Manuels Instrument de mesure populaires d'autres marques

Suaoki

Suaoki D40 Manuel utilisateur

Elster

Elster BK-G1.6 Manuel utilisateur

Endress+Hauser

Endress+Hauser Deltabar FMD71 Manuel

Duratool

Duratool D03128 Manuel utilisateur

Vega

Vega VEGAPULS 65 Manuel utilisateur

Tonghui

Tonghui TH2618B Manuel utilisateur

Tenmars

Tenmars TM-801 Manuel utilisateur

MSR

MSR 145 Manuel utilisateur

TPS

TPS WP-82 Manuel utilisateur

ELMETRON

ELMETRON CP-511 Manuel utilisateur

PCB Piezotronics

PCB Piezotronics 003C30 Manuel utilisateur

Tenma

Tenma 72-10465 Manuel utilisateur

Endress+Hauser

Endress+Hauser Proline Promag 50 Caractéristiques techniques

Siemens

Siemens SITRANS F Coriolis FCT030 Manuel de la liste des pièces

KLINGER

KLINGER CMF V Series Manuel utilisateur

EXFO

EXFO FTB-2 Manuel d'exploitation et d'entretien

Keysight

Keysight M8290A Manuel utilisateur

ADTEK

ADTEK MW-5 Manuel utilisateur
