User Manual: Elo
®
PayPoint for Windows
UM600039 Rev B, Page 6 of 33
4. Barcode scanner
The register has a built in barcode scanner that scans 1-D barcodes. When the register is in
cashier view, the barcode scanner will be on the right of the register display head.
5. Customer-facing display
The register base is equipped with a customer-facing display. As a cashier rings up customer
orders, the customer facing display will display each order.
6. Side USB port
This USB port can be used to charge your mobile device or to connect additional POS
peripherals (e.g. handheld 2D barcode scanner). This port will support USB 3.0 power output.
7. Receipt printer (built-in)
The register is equipped with a built-in receipt printer that is located on the register base.
8. Cash drawer
The register is equipped with a cash drawer for storing cash, coins, and checks.
9. Cash drawer lock
Use the key that comes with the Elo PayPoint for Windows Register to lock / unlock the cash
register. When cash drawer is locked, cash drawer will not open even when it is commanded to.
10.Printer head release button
Press this release button to release the printer head cover. For more information on how to
change printer paper on the register, refer to the “Printer Maintenance” section of Chapter 8.
11.Check compartment slot
The cash drawer is designed with a slot for slipping checks into the cash drawer.
12.Power button
Press the power button to turn on / off the register (set by default). The power button is
equipped with an LED that displays:
- Solid White light when the register is on.
- Solid red light when the register is off but plugged in to the wall.
- No light when the register is off and not plugged in to the wall.
13.Speaker (built-in)
The register is equipped with a built-in speaker.
