Elkay DSBS130UVPC Manuel

Table of Contents

Declaraon of Conformity 2

Associaon 2

Recommendaons for Safeguarding the

Environment 3

Explanaon of Warning/Safety Icons 3

Introducon 4

Components Guide 5

Product Specicaons 6

Before You Begin – Requirements for

Installaon 7

Mounng Dimensions 7

Operang Environment 8

Water 8

Electrical 8

Tools You Will Need 9

Unpacking the Kit 9

What’s in the Kit 10

Installing the Machine 11

Operang the Keypad 16

Roune Maintenance 17

Troubleshoong 20

Replacement Parts 23

NOTICE: Read the instrucons in this manual and retain for future reference.

Installaon and

Maintenance

Manual

ENERGY

SAVING

DSBS130UVPC DSBSH130UVPC

DSBS130UVPC and DSBSH130UVPC

Installaon and Maintenance Manual

Declaraon of Conformity

D.M. 174

rosso 032 c

Materials compliant for contact with drinking water

This unit is intended for the dispensing of drinking water, and so the materials that enter into direct contact with

water meet the criteria for food-grade components pursuant to the current legislaon. In addion, the unit is

manufactured in compliance with Italian Ministerial Decrees 174 of 04/06/2004 and 25 of 02/07/2012.

Electrical safety

This water cooler is designed, manufactured and marketed in compliance with:

 the safety objecves of the Low Voltage Direcve 2006/95/EC;

 the protecon requirements of the Electromagnec Compability Direcve 2004/108/EC.

The electrical safety of the product is ensured only when it is properly connected to an ecient, legally

compliant grounding circuit.

UL standard for safety of drinking water coolers, ANSI/UL 399, Issued: 2008/08/22, Ed: 7, Rev: 2013/10/18

CSA standard for refrigeraon equipment, CSA C22.2 No. 120, Issued: 2013/03/01, Ed: 4

Associaon

D.M. 174

rosso 032 c

Internaonal Awards

2015 - BEST PROMOTION OF HEALTH AND HYDRATION

EUROPEAN AQUA AWARDS 2015, ROME

2015 - BEST ENVIRONMENTAL PRACTICE

EUROPEAN AQUA AWARDS 2015, ROME

2014 – BEST PROMOTION OF HEALTH AND HYDRATION

EUROPEAN AQUA AWARDS 2014, BUDAPEST

2013 – BEST PRODUCT INNOVATION

EUROPEAN AQUA AWARDS 2013, BERLIN

2012 – BEST ENVIRONMENTALLY FRIENDLY PRACTICE

EUROPEAN AQUA AWARDS 2012, ISTANBUL

1000003719 (Rev. A - 02/2017)

Recommendaons for Safeguarding the Environment

Packaging materials

D.M. 174

rosso032 c

The packaging materials are 100% recyclable. Please follow the local guidelines on waste disposal.

For safety reasons keep the packaging material out of the reach and sight of children.

Scrappage

D.M. 174

rosso 032 c

The DSBS130UVPC and DSBSH130UVPC water coolers are made using recyclable material.

These units are marked in compliance with European Direcve 2002/96/EC on Waste Electrical and

Electronic Equipment (WEEE). By ensuring that the product is scrapped correctly, you will help to

prevent potenal negave consequences for the environment and for health. This symbol indicates

that the product should not be treated as domesc waste but should be taken to a dedicated recycling

center for electrical and electronic equipment. Immediately prior to scrapping, cut o the power cable.

For more informaon on the treatment, recovery and recycling of this product, please contact

the appropriate local oce, the waste disposal service or the reseller from which the product was

purchased.

These products contain no CFCs or HFCs, which contribute to global warming.

They are the rst water coolers on the American market to use natural refrigerant.

The refrigerang system is lled with R134a: a natural gas that does not contribute to global warming

and that allows for substanal Energy Savings.

Explanaon of Warning/Safety Icons

NOTICE: Indicates an instrucon which, if not followed, could result in damage to product or property

or poor product performance.

CAUTION: Indicates an instrucon which, if not followed, could result in minor or moderate injury.

WARNING: Indicates an instrucon which, if not followed, could result in serious injury or death.

DSBS130UVPC and DSBSH130UVPC

Installaon and Maintenance Manual

Introducon

The DSBS130UVPC and DSBSH130UVPC coolers bring contemporary style and state-of-the-art technology

to commercial water dispensers. DSBS130UVPC and DSBSH130UVPC oer light, compact and powerful

performance made enrely from stainless steel.

 Mulple dispensing opons: cold sll water, cold sparkling water, room temperature sll water and/or hot

water.

 Natural materials throughout: stainless steel, aluminum

 Internal components made enrely of stainless steel

 DRY COOLING technology: a noiseless, low maintenance, and innovave cooling system which allows for great

performance and compact size

 Made enrely of stainless steel

 An-bacterial UV lamp at dispensing point ensures water delivery pure of microbiological contaminants

NOTICE: Due to rigorous tesng, product may reasonably be expected to contain traces of sanizing

soluon.

1000003719 (Rev. A - 02/2017)

Components Guide

Keypad

Drip tray

Power buon

Water inlet

CO2inlet

Power cord

Thermostat

Cold sparkling

dispenser

Room

temperature sll

dispenser

Cold sll

dispenser

DSBS130UVPC

DSBSH130UVPC

DSBS130UVPC keypad DSBSH130UVPC keypad

ENERGY

SAVING

ENERGY

SAVING

Keypad

Drip tray

Boiler switch

Power buon

Water inlet

CO2inlet

Power cord

Thermostat

ENERGY

SAVING

Cold sparkling

dispenser

Hot dispensers Cold sll

dispenser

DSBS130UVPC and DSBSH130UVPC

Installaon and Maintenance Manual

Product Specicaons

Specicaon DSBS130UVPC DSBSH130UVPC

Cooling capacity gal/h (lt/h) 1.5 (5.7)

32 6 oz. cups/h

1.5 (5.7)

32 6 oz. cups/h

Cold water temperature* 42°F – 50°F

(5.5°C – 10°C)

42°F – 50°F

(5.5°C – 10°C)

Cooling technology Aluminium fusion block heat

exchanger

Aluminium fusion block heat

exchanger

Condensaon Venlated Venlated

Adjustable cooling thermostat Yes Yes

Refrigerant gas HFC R134a HFC R134a

Pump Professional booster pump Professional booster pump

Max hot water temperature - 185°F (85°C)

Hot water tank capacity gal (lt) - 0.265 (1)

Heater waage - 1000W

Inlet water pipe ø 1/4" ø 1/4"

Power 110V - 60Hz 110V - 60Hz

Power consumpon 200W - 2A 1130W - 9.4A

Working room temperature Min 41°F – Max 107.6°F

(Min 5°C – Max 42°C)

Min 41°F – Max 107.6°F

(Min 5°C – Max 42°C)

UNIT WEIGHT lb (kg) 67.5

(30.6)

67.5

(30.6)

SHIPPING WEIGHT lb (kg) 72

(32.6)

Dimensions W x D x H

in (mm)

10.26 x 19.23 x 16.44

(261 x 488 x 418)

10.26 x 19.23 x 16.44

(261 x 488 x 418)

Dispensing area height in (mm)

10.99 (279) 10.99 (279)

Packaging dimensions

W x D x H

in (mm)

14.45 x 23.74 x 27.3

(367 x 603 x 694.4)

14.45 x 23.74 x 27.3

(367 x 603 x 694.4)

Dispensing Supply opon (sparkling, cold

and room temperature water)

Supply opon (sparkling, cold

and hot water)

Push buons Stainless steel push buons Stainless steel push buons

Materials All robust stainless steel parts All robust stainless steel parts

* rated at a room temp. of 77°F and inlet water temp. of 68°F

1000003719 (Rev. A - 02/2017)

Before You Begin – Requirements for Installaon

Mounng Dimensions

Width

18.3” (465mm)

Depth

23.2” (589mm)

Height

20.5” (520.7mm)

Height

28" (711mm)

Height

12.75"

(324mm)

Depth

3.88" (99mm)

Diameter

8" (203mm)

Width

3.25" (83mm)

Footprint:

10.3” wide x 19.2” deep

261mm x 488mm

DSBS130UVPC DSBSH130UVPC

Over counter (includes 4" clearance on sides and back)

Under counter

Water lter

CO2 cylinder (typical, 20 pound)

Width

18.3” (465mm)

Depth

23.2” (589mm)

Height

20.5” (520.7mm)

Footprint:

10.3” wide x 19.2” deep

261mm x 488mm

DSBS130UVPC and DSBSH130UVPC

Installaon and Maintenance Manual

Operang Environment

 Install the machine in a clean, dry, well-venlated room. It is designed to funcon correctly in environments

with a temperature of 16°C to 32°C – Climac Class N, (between 61°F and 90°F).

 Check that the water cooler is level, that it is on a surface that can support its weight and in an environment

suitable for its size and use.

 Do not place the machine near a source of heat.

 To guarantee adequate venlaon, leave at least 4" (100 mm) of space around the unit.

 Take care not to damage the cooling uid circuit. It is essenal to ensure that the tubes of the refrigerant

circuit are not damaged.

 The unit is not intended for use by children.

 Keep the areas surrounding the unit dry to avoid the risk of people slipping.

 The unit must not be cleaned with a water jet.

Water

 Always connect the water cooler to a water main that supplies drinking water only.

 Use of 1/4’’ diameter connecons is recommended.

 Turn o the main water inlet tap if the unit is not to be used for a long period.

Electrical

 Check that the voltage shown on the serial number plate corresponds to the voltage being

supplied at the installaon site.

 Do not use extension cables or mulple-power sockets. The machine must be located

close enough to a standard power socket that the supplied power cable reaches without

stretching.

 Aer installaon, check that the machine is not standing on its power supply cable.

 Ensure that it is possible to disconnect the power supply either by removing the plug or via a two-pole circuit

breaker placed upstream of the plug.

 Before any maintenance or cleaning operaon is carried out, remove the plug from the socket or disconnect

the power supply.

 If the power cable is damaged, it must be replaced by the manufacturer, by its technical support service or by

a qualied technician.

 Do not posion other electrical equipment in the immediate vicinity of the water cooler.

1000003719 (Rev. A - 02/2017)

Tools You Will Need

Unpacking the Kit

Remove the front panel (labeled FRONT) and cover of the

wooden packing case.

Remove the cardboard box and the internal protecve

packaging by sliding them up and over the top.

Once you have unpacked the machine, check all components

to ensure that they are not damaged. Contact the carrier

immediately if there has been any damage during shipping.

NOTICE: Ensure that your machine is installed by a

qualied technician in compliance with the

manufacturer’s instrucons and the local safety

guidelines.

NOTICE: Only qualied technicians should access the internal components of your machine.

(2) 8" adjustable wrenches

(1) 10" adjustable pliers

(1) 12" adjustable wrench

(1) universal screwdriver

(1) 12" pipe cuer

(1) wire cung pliers

DSBS130UVPC and DSBSH130UVPC

Installaon and Maintenance Manual

What’s in the Kit

NOTICE: CO2 source is not included and must be supplied separately.

(1) DSBS130UVPC or DSBSH130UVPC

water cooler

(1) CO2

regulator

(1) external

water lter

(2) 3/8"–quick

connect connector

(1) supply hose 1/2 ips x 3/8

tube x 12” long

(1) water

shuto valve (1) water

pressure

regulator

(1) 10' coil CO2 tubing (natural)

1/4” OD

(1) 3/8” x 3/8”

quick connect

connector

(1) 10' coil water tubing (blue)

1/4” OD

(1) 10' coil water tubing (blue)

3/8” OD

PLUS

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels Elkay Distributeur d'eau

Elkay

Elkay LVRCGRNTLD B Series Manuel d'installation

Elkay

Elkay OFA25*2FJO Manuel d'installation

Elkay

Elkay EZOOTL Series Mode d’emploi

Elkay

Elkay EFA16 1E Series Manuel d'installation

Elkay

Elkay OFA25*1D Manuel d'installation

Elkay

Elkay ezH2O LBWD06BKK Manuel utilisateur

Elkay

Elkay LVRC8-BAC Series Manuel d'installation

Elkay

Elkay EMASMB Mode d’emploi

Elkay

Elkay Space-ette FD700-3 1J Series Manuel d'installation

Elkay

Elkay EFA25 2EJO Series Manuel d'installation

Elkay

Elkay LZ Series Manuel d'installation

Elkay

Elkay VRCHD8 Series Manuel d'installation

Elkay

Elkay EHFRA7FC A Series Mode d’emploi

Elkay

Elkay Deluxe EFHA8 1L Series Manuel d'installation

Elkay

Elkay EWTLA8K 1L Series Manuel d'installation

Elkay

Elkay LZWSRK -EZH2O Manuel d'installation

Elkay

Elkay ESWA8 1E Series Manuel d'installation

Elkay

Elkay Space-ette FD7005 1G Series Manuel d'installation

Elkay

Elkay EMASM Mode d’emploi

Elkay

Elkay OFAVR14*1 Manuel d'installation

Elkay

Elkay LZ Series'EZF4 1D Series Manuel d'installation

Elkay

Elkay OFA25 2FJO Series Manuel d'installation

Elkay

Elkay EMABFTL Instructions d'utilisation

Elkay

Elkay EZ Series Instructions d'utilisation

Manuels Distributeur d'eau populaires d'autres marques

Monarch Water

Monarch Water ULTIMATE MINI AQUA HE Manuel utilisateur

Haier

Haier HLM-109B Manuel utilisateur

abc

abc Fleck 5600SXT Manuel utilisateur

GE GXOF18G Mode d'emploi

Kenmore

Kenmore 625.385560 UltraFilter 650 Manuel utilisateur

Innova

Innova CEV+ Guide de démarrage rapide

Aries

Aries Hydra DI Manuel

GE GNCF02H Manuel utilisateur

ProFlo

ProFlo PFB Series Manuel utilisateur

Hydrotech

Hydrotech 89DF HIM Manuel utilisateur

A.O. Smith

A.O. Smith FREZYA 300S Manuel utilisateur

Frakco

Frakco Travelsoft RV 2400HD Manuel utilisateur

GE GXSF30V Mode d'emploi

Avanti

Avanti WD31EC Manuel utilisateur

Avanti

Avanti WD360 Manuel utilisateur

BRIO

BRIO CLCTTL520 Guide de l'utilisateur

3M HCD-1 Manuel utilisateur

Coway

Coway CHP-671L Manuel utilisateur
