Elegoo NEPTUNE 3 PRO Manuel utilisateur

User Manual for

NEPTUNE 3 PRO

3D Printer

Pictures are only for illustration purpose, please take actual product as standard.

Thank you for choosing ELEGOO product!

For your convenience, please read this instruction manual carefully before use, the cautions and

tips in this manual can help you better avoid incorrect installation and use.

For questions or problems not covered in this manual, please contact us at this email address:

[email protected].

ELEGOO team is always ready to provide you with quality service.

To give you a better experience of our products, you can also gain knowledge of the operation of the

equipment in the following ways：

1.The instruction manual: You can find the relevant operating instructions and videos on how to

operate the machine in the TF Card.

2.ELEGOO official website: www.elegoo.com You can go to our official website to find the relevant

operating instructions for the machine and contact information.

Cautions

1. Do not place the printer in vibrating or other unstable environments, as the shaking of the machine

will affect the print quality.

2. Do not touch the nozzle and heatbed when the printer is working to prevent high-temperature

scald and personal injury.

3. After printing, please take advantage of the residual temperature of the nozzle and clean the

filaments on the nozzle with the help of tools. Do not touch the nozzle directly with your hands during

cleaning to avoid scald.

4. Please do product maintenance frequently, and regularly clean the printer body with a dry cloth to

wipe away dust and sticky print material under the situation of power off.

5. 3D printers contain high-speed moving parts, so be careful not to get your hands caught.

6. Children must be supervised by adults when using the machine to avoid personal injury.

7. In case of emergency, please cut off the power directly.

Contents

Machine Parameters ----------------------------------------------------

Machine Structure Diagram --------------------------------------------

Packing List ----------------------------------------------------------------

Machine Installation ------------------------------------------------------

Operation Screen Introduction ----------------------------------------

Auto Leveling -------------------------------------------------------------

Model Test ------------------------------------------------------------------

Resume Printing Description ------------------------------------------

Software Installation -----------------------------------------------------

Online Print ----------------------------------------------------------------

Troubleshooting Guide -------------------------------------------------

Circuit wiring --------------------------------------------------------------

Machine Parameters

Print Parameters

Print Principle: FDM（Fused Deposition Modeling）

Build Size: 225X225X280(mm³)

Print Precision: ±0.1mm

Nozzle Diameter: 0.4mm

Print Speed: 30~180mm/s（60mm/s is recommanded）

Temperature Parameters

Ambient Enviroment Temperature: 5°C~40°C

Maximum Temperature of Nozzl: 260°C

Maximum Temperature of Hotbed: 100°C

Software Parameters

Slicer Software: Cura

Input Format: STL、OBJ

Output Format: Gcode

Connection Type: TF Card、USB Wire

Power Supply Parameters

Power Input: 100-120V/220-240V

Power Output: 24V

Physical Parameters

Machine Size: 475*445*515mm

Net Weight: 8.1kg

X-axis limit

switch

Lead Screws T8

Rigid Coupling

Filament tube

Filament holder

Filament detector

switch

X-axis belt

tensioner

Type-B interface

TF Card

slot

Touch screen

Timing Pulley

X-axis

stepper

Z-axis

stepper

Y-axis

stepper

Power Switch

Y-axis belt

tensioner

Build platform

Nozzle kit

Machine Structure Diagram

ELEGOO 3D Printer

01 02

03 04 05 06 07

08 09

Fasteners

Tools

Packing List

（HM5*45）4pcs

（PM4*20）5pcs

（PM4*8） 1pcs

（HM4*M3*3) 1pcs

(1.5 / 2.0 / 2.5 / 3.0 / 4.0)

4（HM5*45）4pcs

4.0

① ②

2.5

Machine Installation

The TF card of the machine comes with an installation instruction video.

（PM4*20）3pcs

③ ④

3.0

（PM4*20）2pcs

Filament detector installation:

R-shaped buckle fixing:

（PM4*8） 1pcs

（HM4*M3*3) 1pcs

2.5

⑤

Please adjust the voltage

to match the local

voltage before use.

Filament detector switch

X-axis limit

switch

X-axis

stepper

Z-axis

stepper
