USER GUIDE

GPU WATER BLOCK

EK-Quantum

Vector² AMP/Trinity RTX 4090 ABP Set D-RGB

Please note the installation of the product is intended to be undertaken

by an adequately trained and experienced person. You are installing the

product at your own risk. If you are not properly trained or experienced

or feel unsure about the installation procedure, please refrain from

installing the product yourself and contact our tech support for

assistance. We disclaim our liability for any damages to the product as

well as incidental, consequential, or indirect damages incurred due to

improper or inappropriate installation.

Before you start using this product, please follow these basic guidelines:

Remove your graphics card from the computer for the safest

mounting process to prevent any possible damage to your

GPU or its circuit board (PCB).

The EK Fittings require only a small amount of force to screw

them ﬁrmly in place since the liquid seal is ensured by the

rubber O-ring gaskets.

The use of corrosion-inhibiting coolants is always

recommended for liquid cooling systems and mandatory for

nickel-plated water blocks!

Do not use pure distilled water!

For best results, EK recommends the use of EK-CryoFuel

coolants! To reach optimal performance, make sure to

thoroughly bleed the air out of your water block!

- 3 -

TABLE OF CONTENTS

BOX CONTENTS 4

WATER BLOCK DIMENSIONS 5

TECHNICAL SPECIFICATIONS AND WATER BLOCK PARTS 6

NICKEL PLEXI 6

PREPARING THE GRAPHICS CARD 7

REMOVING THE STOCK COOLER 7

ZOTAC GAMING GeForce RTX 4090 AMP Extreme AIRO 7

PREPARING THE WATER BLOCK FOR INSTALLATION 8

CUTTING AND PLACING THERMAL PADS 10

APPLYING THERMAL COMPOUND 11

ATTACHING THE WATER BLOCK 11

CUTTING AND PLACING THERMAL PADS 13

FITTINGS AND TUBING 15

INSERTING THE GRAPHICS CARD INTO THE CHASSIS 16

CONNECTING THE D-RGB LED STRIP 16

TESTING THE LOOP 17

WARRANTY 17

SUPPORT AND SERVICE 18

SOCIAL MEDIA 18

- 4 -

Thermal Grease (1 pc)

BOX CONTENTS

4 mm

8 mm

10 mm

EK-Loop Multi Allen Key

(1 pc)

Allen Key 2 mm (1 pc)Allen Key 2.5 mm (1 pc)

M2.5x8 AX1 Screw (1 pc)

M3x10 AX1 Screw (1 pc)

EK-Quantum Vector

AMP/Trinity RTX 4090

ABP Set D-RGB

M2.5x4 AX1 Screw (5 pcs)

Polyamid Washer M2.5 0.5mm

(7 pcs)

Standoff Ø4.5/2.5 (1 pc)EK Plug G1/4 (2 pcs)

EK-Plug Out Spludger Tool

(1 pc)

Standoff M2.5-M3 x 6.6mm

(1 pc)

Nut M2.5 (2 pcs)

Terminal OR - Vector214x1 mm

(2 pcs)

EAN: 106123

EAN: 106046

Thermal Pad G 2.0 mm

(1 pc) (3830046996794)

Thermal Pad G 1.0 mm

(2 pcs) (3830046996770)

Thermal Pad G 1.5 mm

(1 pc) (3830046996787)

120 mm

24 mm

120 mm

24 mm

120 mm

24 mm

M2.5x6 AX1 Screw (2 pcs)

6 mm

Thermal Pad F 1.0 mm

(3 pcs) (3830046996732)

120 mm

16 mm

Thermal Pad F 0.5 mm

(2 pcs) (3830046996725)

120 mm

16 mm

- 5 -

WATER BLOCK DIMENSIONS

272.5 mm

73.5 mm

124 mm

142.5 mm

155.5 mm

41 mm

35.5 mm

- 6 -

TECHNICAL SPECIFICATIONS AND WATER BLOCK PARTS

NICKEL PLEXI

- Dimensions: (L x H x W): 272.5 x 155 x 41 mm

- D-RGB LED count: 15

- D-RGB cable length: 50 cm

- D-RGB connector 3-pin 5V digital LED header

(Pinout: +5V | Data | Blocked | Ground)

Position EAN Description Quantity

1106107 Coldplate (Ni) 1

2106115 Coldplate ABP (Ni) 1

3106108 Top plate (Plexi) 1

4106133 Plexi insert 1

5104099 Stand out (Acetal) 1

6100663 EK - Badge 2

7103964 Mylar sticker 2

8106113 LED Cover (N.elox) 2

9106116 Top plate ABP (Plexi) 1

10 106119 Sideplate (N.elox) 1

11 104106 Terminal OR - 14 x 1 mm 4

12 103942 Terminal Badge 1

13 8208 Screw M3 x 8 7991DIN 2

14 9024 Screw M4 x 10 DIN7984 12

15 104414 OR - Active Backplate Terminal 1

16 105163 Disc magnet 3 x 2 mm 4

17 104086 Terminal Badge 1

18 8311 Screw M4 x 20 DIN7984 6

19 8201 Screw M3 x 10 DIN7991 2

20 104393 FC Terminal (Acetal) 1

21 104395 Terminal Plate 1

22 103986 Standoff M3.5-M2.5 x 11.3 mm 8

23 103988 Standoff M4-M2.5 x 3 mm 4

24 103987 Standoff M3.5-M2.5 x 3 mm 2

25 104093 Standoff M2.5-M3 x 6.6 mm 7

26 9013 Screw M4 x 8 DIN7984 11

27 104105 Screw AX1 M3 x 10 mm 7

28 106120 OR 144 x 2 mm 1

29 106121 OR 150 x 2 mm 1

30 106124 PCB cardboard 1

31 101556 LED D-RGB strip 500/300 mm 2

- 7 -

STEP 1

PREPARING THE GRAPHICS CARD

Phillips Head Screwdriver

REMOVING THE STOCK COOLER

ZOTAC GAMING GeForce RTX 4090 AMP Extreme AIRO

STEP 1

Using a Philips-head screwdriver, unscrew marked screws to detach

the stock cooler and retention bracket from the GPU PCB. After

removing, carefully unplug all the LEDs and FANs cables.

For this step, you will need:

STEP 2

Phillips Head Screwdriver

STEP 2

From the front side of the GPU PCB, additional two (2) screws must

be unscrewed to remove the I/O Bracket from the GPU PCB. Lastly,

unscrew four (4) backplate screws. Remove the Backplate.

Save the I/O Bracket for later use.

For this step, you will need:

RETENTION

BRACKET

I/O BRACKET

SCREWS

STOCK COOLER

BACK PL AT E

- 8 -

PREPARING THE WATER BLOCK FOR INSTALLATION

Allen Key 2.5mm

TERMINAL

BADGE

STEP 1

First, remove the terminal badge which is attached to the terminal

with two magnets. Under the badge, unscrew three (3) screws

M4 x 20 DIN7984. Additional seven (7) screws M3 x 10 AX1 need

to be removed (as shown in the image). Save the removed parts

for later use.

STEP 1

For this step, you will need:

Phillips Head Screwdriver

M3 x 10 AX1 SCREW

M4 x 20 DIN7984 SCREW

- 9 -

STEP 3

M2.5-M3 x 6.6 STANDOFF

M3.5-M2.5x11.3 STANDOFF

STEP 3

Unscrew seven (7) M2.5-M3 x 6.6 standoffs with the provided

tool (EK-Plug out Spludger Tool). Make sure not to unscrew the

M3.5-M2.5 x 11.3 standoffs! In case the M3.5-M2.5 x 11.3 standoffs

unscrew, carefully tighten it back with the 4 mm wrench. After

removing the standoffs, the PCB cardboard needs to be removed.

Save the removed parts for later use.

For this step, you will need:

EK-Plug Out Spludger Tool

PCB

CARDBOARD

STEP 2

Carefully remove the complete active backplate with the terminal.

Additional two (2) O-rings 14 x 1 mm needs to be removed.

ACTIVE BACKPLATE

TERMINAL OR

14 x 1 mm

- 10 -

CUTTING AND PLACING THERMAL PADS

STEP 1

The GPU water block comes with thermal pads that have to be cut

into smaller pieces to cover all the VRM components, such as COILs,

MOSFETs, and drivers.

Remove the protective foil from both sides of the thermal

pad before installation.

Replacement thermal pads:

Thermal Pad F 0.5 mm – (120 x 16 mm) EAN: 3830046996725

Thermal Pad F 1.0 mm – (120 x 16 mm) EAN: 3830046996732

Thermal Pad G 1.0 mm – (120 x 24 mm) EAN: 3830046996770

Thermal Pad G 1.5 mm – (120 x 24 mm) EAN: 3830046996787

Thermal Pad G 2.0 mm – (120 x 24 mm) EAN: 3830046996794

STEP 2

Once cut to the size, Thermal Pads should be placed on the PCB, as

shown in the picture.

STEP 2

Thermal Pad - 120 x 16 x 1.0 mm

STEP 1

Thermal Pad - 120 x 16 x 0.5 mm

F0.5

F1 F1

F0.5 F0.5

Thermal Pad G – 2.0 mm (120 x 24 mm)

120 mm

24 mm

2 mm

Thermal Pad G – 1.0 mm (120 x 24 mm)

120 mm

24 mm

1 mm

Thermal Pad F – 1.0 mm (120 x 16 mm)

120 mm

16 mm

1 mm

Thermal Pad F – 0.5 mm (120 x 16 mm)

120 mm

16 mm

0.5 mm

Thermal Pad G – 1.5 mm (120 x 24 mm)

120 mm

24 mm

1.5 mm
