Eden 96212EDAMZ Manuel utilisateur

18 NOZZLES VARIABLEWIDTH OSCILLATING SPRINKLER

Base

Oscillator tube

Spray nozzles (18)

Nozzle Switches On/O

Sliding tabs

Plastic nozzle heads :

Adjustable range control :

Coverage Max :

96212EDAMZ

Attach your garden hose to the sprinkler.

Use the range sliding tabs to select desired rectangular watering distance. (Fig 1 )

Turn water ow control knob to regulate water pressure. (Fig 2)

Press On/O switchable nozzles for wide to narrow spray path.(Fig 3)

Turn on the faucet and check to see how the coverage is working. Make adjustments to suit your needs.

Yes

4499 sq ft (418 m²)

(Based on 40PSI / 2.76Bar)

Flow control

Hose connection

Inlet lter

Cleaning pin

Get To Know Your Sprinkler

Usage

Specications

If your sprinkler begins to display irregular water pressure or is clogged due to dirt buildup, do the following

maintenance task.

Remove your hose from your sprinkler.

Notice a small inlet lter from the hose-end of the

oscillator, remove it and run under water to remove

the dirt (Fig. 4).

Maintenance + Care

Storage Tips

To ush, connect the oscillator to a faucet.

Turn on the faucet and while the water continues

running, spin the tube gently back and forth for few

minutes (Fig. 5)

Remove the cleaning pin from the opposite end of

the oscillator (Fig. 6).

3. Use the provided cleaning pin to clear any clogs

from the spray nozzles while running water in

step 2 (Fig. 7).

Drain the sprinkler after use. DO NOT allow water to

freeze in the sprinkler (Fig. 8).

Fig. 8

Fig. 7

Fig. 1 Fig. 2 Fig. 3

Fig. 4

inlet lter

Fig. 6

cleaning pin

spray nozzles

cleaning pin

spray nozzles

6. 5.

Use this manual to familiarize yourself with the various parts and components, the use, handling and features of the

sprinkler. Save this manual for future reference.

Fig. 5 hose-end

tube

Think of the best coverage design for the watering

without wasting water resources before placing the

sprinkler in the location where you want to water.

Drain any water from the sprinkler after use. This

will preserve the unit for longer lasting use.

Place the sprinkler in a dry warm storage area until

it is required.

Water only when necessary, preferably in the

morning as this will minimize water loss through

evaporation. To obtain deep root growth,water

deeply but do not water often. Watering every

second day will provide for better water coverage.

Using a timer can be helpful in reducing waste.

Watch water application to avoid water run-o.

Fig. 7

2 Extra stainless steel

lter washers for a

leak-free seal

m CAUTION m

-For outdoor use with cold water only

-Do not spray near electrical connections

-When not in use, rinse the tool with water to remove most of the dirt, dry your tool, and store indoors

18 NOZZLES

VARIABLEWIDTH

OSCILLATING SPRINKLER

96212EDAMZ

• Coverage up to 4499 sq. ft. ( 418m² )

(Based on 40 PSI / 2.76 Bar)

• 18 Clog resistant nozzles

• Six switchable (on/o) spray nozzles for easy width adjustment

• Water ow control

• Sliding tabs allow for simple range adjustment

• Needle plug for nozzle cleaning

UNLOCK LOCK

Secure twist-and-lock

mechanism prevents

accidental disconnection

A B C D

Quick and easy connections to 5/8-inch and

1/2-inch garden hoses, sprinklers, nozzles, and/or

any other garden watering tools

UNLOCK

LOCK

The Quick Connect Adapter (2 pcs) and Hose

Connector with Water Stop (1 pc) simplify your

watering experience. Simply attach the

connector at the end of your hose. Then,

connect the adapters to your watering tools.

Interchange various tools in a snap without

turning o the water as the adapter will stop

the water ow. No more kinking or hose

twisting as the adapter allows the hose to

swivel 360 degrees.

mWARNING: This product can expose you to chemicals including styrene, which is known to the

State of California to cause cancer. For more information go to www.P65Warnings.ca.gov
