Eden 94154EDAMZ Manuel utilisateur

94154EDAMZ

Spray Range tabs (2) control the length of

the watering area

360° adjustable radius neck controls spray direction

Note: If you are not using the

Quick Connect System,

simply connect the sprinkler

directly to the hose.

20 clog-resistant spray nozzles for even watering

4-WAY ADJUSTABLE MINI OSCILLATING SPRINKLER

WITH TELESCOPING TRIPOD

18.7”

(47.5cm)

Spray Width tabs (2) control

the width of the watering area

Tripod

length

Water ow control knob

adjusts the overall watering area

Place the tripod in the area where you

want to water. Open the latches to

release the legs. Push down on the

tripod legs until the legs are well seated

in the ground.

Step 1

Step 2

Attach the Extension Tube to the tripod, then

connect the sprinkler head to the top of the

Tripod or Extension Tube (do not overtighen).

Step 3

Use the Quick Connect to easily connect and disconnect the sprinkler from the hose.

Connect the Product Adapter to the base of the sprinkler. Attach the lockable Quick Connect

to the end of the hose, then simply snap in the hose to the sprinkler to begin using.

63.7”

(162cm)

43.7”

(111cm)

Premium Quick Connect

Starter Set

ts standard garden

hoses and watering tools

Sliding tabs control

the width

(up to 59ft. (18m))

Width Control

Allow simple incremental angle

adjustments without moving the

sprinkler and hose.

360° Rotation Adjustment

Allows adjustment of

overall watering area.

Water Flow Control

Push down tabs

control the length

(up to 36.1ft.(11m))

Range Control

WARNING: This product can expose you to chemicals including styrene which is

known to the State of California to cause cancer. For more information go to

www.P65Warnings.ca.gov.

UNLOCK LOCK

Secure twist-and-lock

mechanism prevents

accidental disconnection

A B C D

Quick and easy connections to 5/8-inch and

1/2-inch garden hoses, sprinklers, nozzles, and/or

any other garden watering tools

UNLOCK

LOCK

The Premium Quick Connect with Shut O Valve Set will simplify your watering experience.

Simply attach the connector at the end of your hose. Then connect the adapters to your

watering tools. Interchange various tools with a snap without turning o the water as the shut

o valve of the connector will stop the water ow. No more kinking or hose twisting as the

connector allows you to swivel your hose 360 degrees.

Made in Taiwan

www.edengarden.com

-For outdoor use with cold water only

-Do not spray near electrical connections

-When not in use, rinse the tool with water to remove most of the dirt, dry your tool, and store indoors

CAUTION
