EDELBROCK CAT-BACK EXHAUST SYSTEM

For 2007-2008 Toyota FJ Cruiser 2WD & 4WD

Catalog #5721

INSTALLATION INSTRUCTIONS

Please study these instructions carefully before installing your new Edelbrock Cat-Back Exhaust System. If you have any

questions, please contact our Technical Hotline at: 1-800-416-8628 , 7am - 5pm, Monday-Friday, Pacific Standard

Time or e-mail us at [email protected].

Suggested Tools for Installation:

❑3/8" ratchet and metric sockets ❑14mm, 15mm, and 17mm Wrenches

❑Jack and jackstands ❑Liquid penetrant and rubber lubricant

DISASSEMBLY

1. Raise and support vehicle.

2. Remove factory exhaust system from the flange

located behind the catalytic converter.

ASSEMBLY

1. Disconnect the fuel vapor return line from the vapor

canister located just above the rear-end housing. Place

the heat shield sleeve over return line and reconnect it

to the canister. NOTE: Since fuel lines contain harmful

vapors, this procedure should be done in a well

ventilated area clear of any open flames or extreme

heat. Safety glasses should also be worn when

performing this action.

2. Using the supplied 10mm bolts, lock washers, and flat

washers from the kit, install the I-pipe assembly #25-

3285 placing the hangers in the rubber isolators.

3. Using a 2-1/2” band clamp and hanger clamp assembly

#23-4107 from the kit, install muffler #25-55742.

NOTE: Only snug all clamps at this time for adjusment

later.

4. Install overaxle pipe assembly #25-3286.

WARNING!!!

Exhaust gas contains carbon monoxide, a deadly

invisible gas. Correct any leaks before driving!

IMPORTANT NOTE:

Proper installation is the responsibility of the installer. Improper installation will void warranty and may

result in poor performance and engine or vehicle damage.

KIT CONTENTS

Catalog #5716

Qty.Part # Description

❑1 25-3285 I-Pipe Assembly

❑1 25-3286 Overaxle Assembly

❑1 25-3298 Tailpipe Assembly

❑1 25-5582 Tailpipe Tip (Polished)

❑1 22-5721 Installation Kit

❑1 25-55742 Muffler

5. Using a 2-1/2” band clamp, install tailpipe assembly

#25-3298 placing the hanger in the rubber isolator.

6. Using a 2-1/2” band clamp, install tailpipe tip #25-

5582.

7. Working from the front of the system to the rear, adjust,

align, and tighten all the band clamps. Give adequate

clearance for fuel lines, brake lines, electrical wiring,

and the spare tire.

Edelbrock Corporation, 2700 California St., Torrance, CA 90503

Tech Line: (800) 416-8628 Office: (310) 781-2222

E-Mail: [email protected]
