Preface

This publication, including all photographs, illustrations and software, is protected

any of the material contained herein, may be reproduced without written consent of

the author.

Version 1.1

Disclaimer

The information in this document is subject to change without notice. The

manufacturer makes no representations or warranties with respect to the contents

hereof and specifically disclaims any implied warranties of merchantability or fitness

for any particular purpose. The manufacturer reserves the right to revise this

publication and to make changes from time to time in the content hereof without

obligation of the manufacturer to notify any person of such revision or changes.

Trademark Recognition

Microsoft, MS-DOS and Windows are registered trademarks of Microsoft Corp.

MMX, Pentium, Pentium-II, Pentium-III, Celeron are registered trademarks of Intel

Corporation.

Other product names used in this manual are the properties of their respective owners

and are acknowledged.

Federal Communications Commission (FCC)

This equipment has been tested and found to comply with the limits for a Class B

digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to

provide reasonable protection against harmful interference in a residential installation.

This equipment generates, uses, and can radiate radio frequency energy and, if not

installed and used in accordance with the instructions, may cause harmful interference

to radio communications. However, there is no guarantee that interference will not

occur in a particular installation. If this equipment does cause harmful interference to

radio or television reception, which can be determined by turning the equipment off

and on, the user is encouraged to try to correct the interference by one or more of the

following measures:

− Reorient or relocate the receiving antenna.

− Increase the separation between the equipment and the receiver.

− Connect the equipment onto an outlet on a circuit different from that to which

the receiver is connected.

− Consult the dealer or an experienced radio/TV technician for help.

Shielded interconnect cables and a shielded AC power cable must be employed with

this equipment to ensure compliance with the pertinent RF emission limits governing

this device. Changes or modifications not expressly approved by the system's

manufacturer could void the user's authority to operate the equipment.

Declaration of Conformity

This device complies with part 15 of the FCC rules. Operation is subject to the

following conditions:

− This device may not cause harmful interference, and

− This device must accept any interference received, including interference

that may cause undesired operation.

Canadian Department of Communications

This class B digital apparatus meets all requirements of the Canadian Interference-

causing Equipment Regulations.

Cet appareil numérique de la classe B respecte toutes les exigences du Réglement

sur le matériel brouilieur du Canada.

About the Manual

The manual consists of the following:

Chapter 1

Introducing the Mainboard

Describes features of the mainboard,

and provides a shipping checklist.

Go to ⇒page 1

Chapter 2

Installing the Mainboard

Describes installation of mainboard

components.

Go to ⇒page 8

Chapter 3

Using BIOS

Provides information on using the BIOS

Setup Utility.

Go to ⇒page 28

Chapter 4

Using the Mainboard Software

Describes the mainboard software.

Go to ⇒page 52

Preface i

CHAPTER 1 1

Introducing the Mainboard 1

Introduction.................................................................................................1

Checklist.....................................................................................................2

Standard Items................................................................................................. 2

Features .....................................................................................................3

Choosing a Computer Case .......................................................................5

Mainboard Components .............................................................................6

CHAPTER 2 8

Installing the Mainboard 8

Safety Precautions......................................................................................8

Quick Guide................................................................................................8

Installing the Mainboard in a Case..............................................................9

Checking Jumper Settings..........................................................................9

Setting Jumpers ............................................................................................... 9

Checking Jumper Settings............................................................................. 10

Jumper Settings ............................................................................................. 10

Connecting Case Components........................................................................11

Front Panel Connector................................................................................... 13

Installing Hardware...................................................................................14

Installing the Processor.................................................................................. 14

Installing Memory Modules .......................................................................... 17

Installing a Hard Disk Drive/CD-ROM......................................................... 18

Installing a Floppy Diskette Drive................................................................. 20

Installing Add-on Cards................................................................................. 21

Connecting Optional Devices........................................................................ 23

Connecting I/O Devices............................................................................26

External Connector Color Coding ................................................................. 27

CHAPTER 3 28

Using BIOS 28

About the Setup Utility..............................................................................28

The Standard Configuration .......................................................................... 28

Entering the Setup Utility.............................................................................. 29

Updating the BIOS........................................................................................ 29

Using BIOS...............................................................................................30

Standard CMOS Features.............................................................................. 31

iii

Advanced BIOS Setup Option....................................................................... 33

Advanced Chipset Features Option ............................................................... 36

Integrated Peripherals.................................................................................... 38

Power Management Setup Option................................................................. 43

PNP/PCI Configurations................................................................................ 47

PC Health Status Option................................................................................ 48

Frequency/Voltage Control............................................................................ 49

Load Fail-Safe Defaults Option..................................................................... 50

Load Optimized Defaults Option................................................................... 50

Set Supervisor/User Password....................................................................... 51

Save & Exit Setup Option ............................................................................. 51

Exit Without Saving ...................................................................................... 51

CHAPTER 4 52

Using the Mainboard Software 52

About the Software CD-ROM ...................................................................52

Auto-installing under Windows 98/ME/2000/XP .......................................52

Running Setup............................................................................................... 53

Manual Installation....................................................................................55

Utility Software Reference ........................................................................55

Introducing the Mainboard

Thank you for choosing the L4S8A2 mainboard. The L4S8A2 mainboard is a

high–performance, enhanced function mainboard that supports Socket 478

Pentium 4 processors with system speeds up to 533MHz for high-end

business or personal desktop markets.

The mainboard incorporates the SiS648 Northbridge and SiS963 Southbridge

chipsets. The SiS648 Northbridge chipset provides a 12-level In-Order-Queue

to support maximum outstanding transactions on host up to 12. The memory

controller offers high-bandwidth up to 2.7GB/s under DDR333 in order to

sustain the bandwidth demand from the host processor, as well as the multi

I/O masters and AGP masters. While the SiS963 Southbridge integrates the

Universal Serial Bus 2.0 Host Controllers, 1394a and Audio Controller with AC

97 interface.

The L4S8A2 is designed to give customers an advanced, multimedia solution

at a very low cost. It is equipped with advanced full set of I/O ports, such as

dual channel IDE interfaces, a floppy controller, two high-speed serial port, an

EPP/ECP capable bi-directional parallel port connector, four USB (Universal

Serial Bus) connector, a PS/2 keyboard and mouse connectors. One AGP slot,

five PCI local bus slots and one communication and networking riser (CNR -

optional) slot provide expandability for add-on peripheral cards.

Note: SDRAM provides 800 MBps or 1 GBps data transfer depending on whether

the bus is 100 MHz or 133 MHz. Double Data Rate SDRAM (DDR SDRAM)

doubles the rate to 1.6 GBps or 2.7 GBps by transferring data on both the

rising and falling edges of the clock. DDR SDRAM uses additional power and

ground lines and requires 184-pin DIMM modules rather than the 168-pin

DIMMs used by SDRAM.

Compare the mainboard’s package contents with the following checklist:

Standard Items

• One mainboard

• One diskette drive ribbon cable (optional)

• One IDE drive ribbon cable

• One auto-install software support CD

• One I/O panel

• One cooling fan retention module

• This user’s manual

Processor The L4S8A2 mainboard uses a micro PGA 478-pin socket that

has the following features:

• Supports 400/533 MHz system bus

• Supports “Hyper-Threading” technology CPU

• Accommodates Pentium 4 processors at 1.5G/1.6G/1.7G…

2.5G and above

“Hyper-Threading” technology enables the operating system

into thinking it’s hooked up to two processors, allowing two

threads to be run in parallel, both on separate ‘logical’

processors within the same physical processor.

Chipset The SiS648 and SiS963 chipsets are based on an innovative

and scalable architecture with proven reliability and

performance. A few of the chipset’s advanced features are:

• Supports Intel Pentium 4 series CPU with data transfer

rate up to 533MHz

• Support 12 outstanding transactions and out-of-order

completion

• Supports 64-bit high performance DDR333/DDR266

Memory Controller

• Universal AGP v3.0 compliant and supports AGP 8X/4X

Interface with Fast Write Transaction

• Distributed arbitration strategy with long contiguous data

streaming up to 1GB/s

• PCI 2.2 specification compliance

• Integrated multi-threaded I/O link mastering with read

pipelined streaming

• Supports Ultra DMA 33/66/100/133

Additional key features include support for six USB 2.0 ports,

Fast Ethernet MAC controller, AC97 interface, advanced

power management, integrated DMA controller and keyboard

controller.

Memory • Supports DDR SDRAM up to 200/266/333 MHz memory

module

• Accommodates three unbuffered 2.5V 184-pin slots

• Each slot supports up to 1 GB with a total maximum

capacity of 3 GB

AGP The L4S8A2 includes an 8xAGP slot that provides eight times

the bandwidth of the original AGP specification. The AGP 3.0

(8xAGP) offers a significant increase in performance along

with feature enhancements to AGP2.0. This interface

represents the natural evolution from the existing AGP to meet

the ever-increasing demands placed on the graphic interfaces

within the workstation and desktop environments.

AC’ 97 Audio

Codec The AC’ 97 Audio codec is compliant with the AC’ 97 2.2

specification, and supports 18-bit ADC (Analog Digital

Converter) and DAC (Digital Analog Converter) resolution as

well as 18-bit stereo full-duplex codec with independent and

variable sampling rates. Further features include support for

four analog line-level stereo inputs.

Expansion

Options The mainboard comes with the following expansion options:

• Five 32-bit PCI slots

• One 8x/4x AGP slot

• A Communications Network Riser (CNR) slot (AC97

interface only) (optional)

• Two IDE connectors which support four IDE channels and

a floppy disk drive interface

The L4S8A2 supports Ultra DMA bus mastering with transfer

rates of 33/66/100/133 MB/sec.

Onboard LAN

(optional) RTL8201BL is a Fast Ethernet Phyceiver with an MII (Media

Independent Interface)/SNI (Serial Network Interface). It can

be used as a Network Interface Adapter, MAU, CNR, ACR,

Ethernet Hub, and Ethernet Switch.

It is incorporated in the chipset providing the mainboard with

10/100Mbps fast Ethernet controller and integrated Ethernet

PCI LAN capabilities.

Integrated I/O The mainboard has a full set of I/O ports and connectors:

• Two PS/2 ports for mouse and keyboard

• Two serial port (COM2 – optional)

• One parallel port

• Four USB ports

• One LAN port (optional)

• Audio jacks for microphone, line-in and line-out

BIOS

Firmware This mainboard uses Award BIOS that enables users to

configure many system features including the following:

• Power management

• Wake-up alarms

• CPU parameters

• CPU and memory timing

The firmware can also be used to set parameters for different

processor clock speeds.

Some hardware specifications and software items are subject to change

without prior notice.

There are many types of computer cases on the market. The mainboard

complies with the specifications for the ATX system case. Some features on

the mainboard are implemented by cabling connectors on the mainboard to

indicators and switches on the system case. Ensure that your case supports

all the features required. The mainboard can support one or two floppy

diskette drives and four enhanced IDE drives. Ensure that your case has

sufficient power and space for all the drives that you intend to install.

Most cases have a choice of I/O templates in the rear panel. Make sure that

the I/O template in the case matches the I/O ports installed on the rear edge

of the mainboard.

This mainboard has an ATX form factor of 305 x 190 mm. Choose a case that

accommodates this form factor.

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels ECS Carte mère

Manuels Carte mère populaires d'autres marques

DFI

DFI SD170 Manuel utilisateur

ASROCK

ASROCK ROMED8-2T Manuel utilisateur

Asus

Asus P2L97A Manuel utilisateur

Winmate

Winmate IC70 Manuel utilisateur

Asus

Asus MES-B Manuel utilisateur

Grantech

Grantech SYS8F377VGGA-3OMN Manuel utilisateur

Telit Wireless Solutions

Telit Wireless Solutions SL869-3DR Manuel utilisateur

Gigabyte

Gigabyte GA-9IVDT Manuel utilisateur

Texas Instruments

Texas Instruments ADS8372EVM Manuel utilisateur

Commell

Commell MS-C73 Manuel utilisateur

IBT Technologies

IBT Technologies MB860 Manuel utilisateur

Nvidia

Nvidia TEGRA DG-04927-001_V01 Manuel utilisateur

Biostar

Biostar M7VIT Bravo Instructions d'utilisation et d'installation

Intel

Intel D33217CK Manuel utilisateur

Asus

Asus F1A55-M LX PLUS R2.0 Manuel utilisateur

EPC

EPC EPC9147C Manuel utilisateur

Asus

Asus EX-B760M-V5 D4 Manuel utilisateur

EPOX

EPOX MU-8KHA0010 Manuel utilisateur
