All-in-one Touch POS Terminal

EC-1519I3

User Manual

Overview

Thank you for purchasing the EC-1519I3 all-in-one touch POS terminal, EC-Line is

committed to continuously improve product quality and provide better after-sales service.

In order to take full advantage of our devices, we strongly recommend that you take the

time to read this manual before going into software installation.

Note: Information in this manual may change without prior notice.

1. Safety Information

Before plug in the product, please make sure the power you provide meets the

power requirements (such as voltage, frequency); Make sure the ground terminal of

the power outlet is working properly.

Lightning may damage this product. During lightning storms, unplug the network

cable, power cable and any other connections.

Turn off power before connecting any devices (except USB devices) to the terminal.

Do not attempt to open the chassis. You may be hurt by electric shock. For service,

call your place of purchase.

Do not spill liquid on the terminal. Do not place any objects into the ventilation

holes of this product. It may cause short-circuit of the internal components and

cause a fire or electric shock.

After the computer is stored below temperature of 10 °C, please place the machine

in room temperature (10 - 35 °C) in the original packing for at least two hours to

allow the terminal to restore to room temperature before operation. This is to avoid

condensation that might bring electrical damage.

Keep the terminal clean, dry, and away from dust, moisture and direct sunlight.

Do not use harsh chemicals or strong cleaning solvents to clean the monitor screen.

Wipe it clean with a soft terry cloth applied with a mild solution

Do not share the same power outlet with high power electrical appliances keep

distance from high level magnetic interference.

Do not the use sharp pointed objects to work with the touch screen to avoid damage

to the screen?

When the following occurs:

Liquid gets inside the POS terminal;

Accidental physical damage;

POS terminal produces a burning smell;

Immediately disconnect the power supply, unplug the power cord, and contact a

qualified service technician.

2. Electromagnetic compatibility statement

FCC NOTICE

This device complies with Part 15 of FCC Rules. Operations are subject to the

following two conditions: (1) this device may not cause harmful interference, and (2)

this device must accept any interference received, including interference that may

cause undesired operation.

EUROPEAN COMMUNITY (CE) MARK OF CONFORMITY

This product is in conformity with the protection requirements of EU Council

Directive 89/336/EEC on the approximation of the laws of the Member States

relating to electromagnetic compatibility. Logic Controls cannot accept

responsibility for any failure to satisfy the protection requirements resulting from a

non-recommended modification of the product. This product has been tested and

found to comply with the limits for Class A Information Technology Equipment

according to CISPR 22 / European Standard EN 55022.The limits for Class A

equipment were derived for commercial and industrial environments to provide

reasonable protection against interference with licensed communication equipment.

Installation Guide

1. Appearances

2. Power On/Off

3. Rear Panel I/O Connectors

At the rear panel of the EC-1519I3 is a row of external I/O device connectors

Detailed as follows:

1 COM4: For connection to serial devices DB9 port

2 COM3: For connection to serial devices DB9 port

3 COM1: For connection to serial devices RJ45 port

4 MIC: Microphone Input

5 LINE OUT: Stereo phone jack audio output

6 LAN: RJ-45 Ethernet connection to Giga-bit LAN

7 USB2.0: Connection to USB 2.0 devices (compatible with USB 1.1

devices)

8USB3.0: Connection to USB3.0 devices (compatible with USB 2.0

devices)

9VGA: VGA signal output for connection to external monitor

10 HDMI: Digital image/sound transmission interface

11 12V DC IN: Connection to 12V DC Power Supply

12 POWER: ON/OFF

Specification

Model name

EC-1519I3

Type

15”All In One Touch POS Terminal

Colour

Black

Material

Magaluma

Optional Peripherals

ISO Trick 1/2/3 Magnetic Stripe Reader

Customer Display: VFD

Second Screen(9.7”,12”,15”)

WIFI

Bluetooth

SSD (32G,64G,128G)

Motherboard

Main Board

ITX- Intel Sharkbay

CPU

4th Generation Intel® Core™ i3 Processors (3M Cache,

1.70 GHz or UP)

BIOS

AMI BIOS

RAM Support

DDR3L 4GB,

Storage

SSD 64G

Network Support

Realtek 8111E Gigabit Ethernet

Audio

Realtek ALC662 HD

Main Display

LCD Size

15” LED-LCD

Viewing Angle

left/right ＋80°~－80°

up/down ＋70°~－70°

Brightness

450cd /㎡

Resolution

XGA 1024×768 @ 60Hz

Touch Screen

Type

5 wire resistive touch panel

Touch Interface

USB

I/O Ports

I/O port

DC IN*1

HDMI*1

POWER BUTTON*1

COM*2(DB9)

USB2.0*4

LAN*1

USB3.0*2

LINE*1

MIC*1

Power LED*1

Operating Temperature

0 ℃to 40℃

Storage Temperature

-20℃to 60℃

SIZE

450*245*400mm

Package: Carton Box with

Foam Packaging

NW: 6.1KG

GW:7.8.KG

Power Consumption

50W（MAX）

EMC/ Product Safety

FCC Class A / CE Mark / LVD / CCC

OS Support

Windows 7/8 or up

Accessory

Power adaptor, power cable, CD for driver

Driver’s installation

Under Windows 7 system, open the CD > EC1519 & EC1219 > Windows 7 in sequence:

/Audio driver Audio-64bit_Win7_Win8_Win81_Win10_R279.exe(X64)

/Chipset driver SetupChipset.exe

/Graphic driver 7_8.1_10 win32_153339（X86）/7_8.1_10 win64_153339（X64）

/LAN driver LAN_32&64 Win7_7078_01212013

/Touch driver Touch-ForSingleTouchDevice（Resistive）/Touch-ForPCAP（Capacitance）

/USB3.0 driver USB3.0

/RAID driver STOR_Win7_8_8.1_12.9.0.1001.exe

Windows 8 OS，open the CD > EC1519 & EC1219 > Windows 8 in sequence:

/Audio driver Audio\ Win8_R273

/Chipset driver Chipset\INF_allOS_10.0_Baytrail.exe

/Graphic driver J1900-Win7-8-64_153330.exe（X64）/ J1900-Win8-32_153330.exe（X86）

/LAN driver Lan\ setup.exe

/Touch driver Touch-ForSingleTouchDevice（Resistive）/Touch-ForPCAP（Capacitance）

/USB3.0 driver USB3.0\IntelUSB_3.0_3.0.2.54

Intel Sideband Fabric driver Intel Sideband\Fabric Setup.exe

/RAID driver STOR_Win7_8_8.1_12.9.0.1001.exe

Windows 8.1 OS dirver，open the CD > EC1519 & EC1219 > Windows 8.1 in sequence:

/Audio driver Audio\ Win8_R273

/Chipset driver Chipset\INF_allOS_10.0_Baytrail.exe

/Graphic driver J1900-Win7-8-64_153330.exe（X64）/ J1900-Win8-32_153330.exe（X86）

/LAN driver Lan\win8

/Touch driver Touch-ForSingleTouchDevice（Resistive）/Touch-ForPCAP（Capacitance）

/USB3.0 driver USB3.0\IntelUSB_3.0_3.0.2.54

Intel Sideband Fabric driver Intel Sideband\Fabric Setup.exe

/RAID driver STOR_Win7_8_8.1_12.9.0.1001.exe

Windows10 OS dirver，open the CD > EC1519 & EC1219 > Windows 10 in sequence:

/Audio driver Audio\Audio-64bit_Win7_Win8_Win81_Win10_R279.exe

/Chipset driver Chipset\ SetupChipset.exe

/Graphic driver GFX_Win7_8.1_10_64_15.33.41.4338\ Setup.exe

/LAN driver Lan\ setup.exe

/Touch driver Touch-ForSingleTouchDevice（Resistive）/Touch-ForPCAP（Capacitance）

/USB3.0 driver USB3.0\IntelUSB_3.0_3.0.2.54

/RAID driver STOR_Win7_8_8.1_12.9.0.1001.exe

Intel Sideband Fabric driver Intel Sideband\Fabric Setup.exe

Troubleshooting

1. Terminal does not boot

If the terminal cannot boot after pressing the power switch check that the

power cable is connected to the power socket. If the terminal power light still

remains off, the fan does not operate, and there is no BIOS beeping sound, it

might be the power supply problems.

a) Check the power adapter is plugged in correctly to the power outlet.

b) Check the connection between the terminal and the power adapter, and

then re-boot the system.

c) If the terminal is working in high temperature environment that causes the

terminal automatically shut down in protection mode, please disconnect the

power of the machine. Wait until environment temperature has dropped

then restart.

d) If the terminal does not boot after a sudden power failure or illegal

shutdown, unplug the adapter from the terminal, and press the power

button several times. Then plug in the adapter and boot again.

e) If the adapter light blinks or go off, unplug the adapter immediately and do

not plugged in again. Contact with our products service center.

2. The terminal automatically restart (or shutdown)

If terminal is frequently automatic shutdown or auto-boot during operation (or

boot up),

a) Check the power supply is connected properly; make sure the plug is not
