T80 Universal Transmitter
S80 Intelligent Sensors
ELECTRO-CHEMICAL DEVICES
Presented by:
January 2012
T80 Universal Transmitter
One Transmitter
for Multiple
Measurements
pH
ORP
ORP
Dissolved Oxygen
ll Specific Ions
Conductivity
Resistivity
Turbidity
T80 Universal Transmitter
Easy to Use
Membrane Switch
Navigation
Simple Menu
Structure
Structure
Soft Key Menu
Choices
Easy to read 2 ¾”
x 1 ½” LCD Display
T80 Universal Transmitter
Inputs:
ny S80 Intelligent Sensor
ny standard pH sensor
with solution ground using
the optional T80 input card.
Outputs:
4-20 m
MODBUS RTU on 24 VDC
MODBUS RTU on 24 VDC
and 110/220 V C
instruments
Optional H RT® 7
Optional 3 larm Relays
Power requirements:
Loop Powered
24 VDC @ 250 mW
minimum
110/220 V C
S80 Intelligent Sensors
New but Familiar
Digital Communication
with Transmitter
Sensor Type
Serial Number
Process Variable
Process Variable
Temperature
Calibration Data
Waterproof, IP68
rated Industrial
Detachable Cable
Connection
S80 Intelligent Sensors
6 Point dvantage
1. Intelligent Sensor
2. Common Configuration
for all Measurements
3. pplication Specific
Cartridges
Cartridges
4. Economic and Easily
Replaceable Cartridges
5. Submersible and
Retractable designs
6. pplication Specific
Materials of
Construction
T80 Home Display
Three Home Screens
Data Screen
Process Variable
% 4-20 m range
Temperature
mV Screen
Raw mV signal from
Raw mV signal from
the sensor
% 4-20 m range
Temperature
Graphical Screen
3 choices, Line, Bar,
Gauge
Process Variable
% 4-20 m range
T80 Main Menu
Press any Key Twice,
except the Screen Key,
within 1 second to
enter the Main Menu
C L = Calibration
CONFIG=Configuration
CONFIG=Configuration
INFO = Information
SIM = Simulation
HOLD = Output Hold
Function
Toggles ON/OFF
Freezes the 4-20 m
and alarm relays
T80 Calibration
New Sensor?
YES- Erases all 3
Calibration registers
NO- Saves to top register
uto Calibration
Two point Cal
utomatically recognizes
the Calibration Solution
the Calibration Solution
Standardize
Single point adjustment
Manual
User entry of the Offset
and Slope for sensor
Temperature
Temperature djustment
T80 uto Calibration
The Easy to use T80
prompts the user
through the calibration.
Press UTO and Cal 1
and the T80 waits for a
stable reading and then
Suggests the value of the
Suggests the value of the
Calibration Standard
ccept the value (YES)or
enter a different value
(NO)
Continue to the next
solution (YES) or end the
calibration (NO).
