DTSystems CDT 1000 PLUS Manuel utilisateur

CDT

PLUS

Series

Electronic Dog Trainer

Owner’s Manual

• CDT 1000 PLUS

• CDT 2000 PLUS

Manufactured by:

TABLE OF CONTENTS

• Table of Contents ....................................... 3

• Introduction ................................................ 4

• Package Contents ...................................... 5

• Model Features .......................................... 5

• Parts & Functions ....................................... 6

• Charging the Batteries................................ 10

• Turning ON and OFF.................................. 11

• Testing ....................................................... 12

• Programming the Collar.............................. 13

• Properly Fitting the Collar ........................... 14

• Setting Intensity Levels............................... 15

• Maintenance............................................... 16

• Important Safety Notes............................... 17

• Warranty..................................................... 18

• FCC/IC/CE Compliance.............................. 19

• Contact Information .................................... 20

Congratulations and thank you for purchasing our

Cabela’s Exclusive Alpha Dog Series CDT PLUS

Training Collar with “Add-On” capability. The Cabela’s

Alpha Dog Series represents the absolute latest

technological advancement in the Electronic Dog

Training World. It offers Maxx-Range™, the industry’s

only internally woven antenna in the collar. With up to

a 1200 yard range, they are perfect for hunting, basic

obedience and professional training. The Cabela’s

Alpha Dog Series collars feature sixteen levels of

stimulation intensity. Easy one hand operation allows

for maximum control and safety. Each model includes

both Constant and Momentary “Nick” stimulation. Our

Positive Vibration feature is also available (CDT 2000

PLUS). The collars are 100% waterproof and can be

worn even when the dog is submerged. The Cabela’s

Alpha Dog Series Training Collar is durable, safe and

very humane when used correctly. The automatic

safety shut-off feature stops the stimulus on both the

transmitter and the receiver to prevent accidental or

prolonged stimulation. Thanks again for choosing

D.T. Systems to help bring out the best in your best

friend!

INTRODUCTION

IMPORTANT NOTE:

Please read this owner’s manual in its entirety before

operating this unit. Should you have any questions

about our collars or their operation please contact

our Customer Service department (see back page

for address and phone number information).

PACKAGE CONTENTS

• Transmitter

• Collar Receiver

• Antenna for the Transmitter

• Rechargeable NiMH Batteries for both the Collar

and Transmitter (already installed)

• Battery Charger

• Splitter Cable for simultaneous charging

• Test Light

• Owner’s Manual

MODEL FEATURES

CDT PLUS Series

• Digital Technology

• Up to 1200 yard (2/3 mile) range

• Expandable to 2- or 3-dog system with CDT PLUS

Add-On collar units (sold separately)

• Lightweight, waterproof collar

• Weather resistant transmitter

• 16 adjustable intensity levels of Momentary (‘Nick’)

Stimulation and Continuous Stimulation

• MAXX-Range™ Internal Antenna System in collar

belt

• Rechargeable NiMH battery system

• Gentle Touch System™ Extra Mild Stimulation

• Built in safety shut-off system

• Positive Vibration (CDT 2000 PLUS only)

Transmitter

PARTS & FUNCTIONS

Button #2*

(Vib.+Stim.)

Battery

Charging

Receptacle

Intensity Dial

Collar Selecting

Switch

Momentary ‘Nick’

Stimulation

Continuous

Stimulation

Red LED Indicator

Light

Button #1*

(Vibration)

*The CDT 1000 PLUS will not

have the #1 or #2 buttons.

Lanyard Loop

Transmitter Antenna

Transmitter Indicator Light

When one of the buttons on the transmitter is pushed,

the Red LED light will turn on to indicate that the

transmitter is being operated. When the battery needs

charging, the Red LED light will blink rapidly after

pressing any transmitter button. The Red LED light

will stay on solid while plugged into the charger.

PARTS & FUNCTIONS

Intensity Selection Dial

The intensity selection dial can be set

from level 1 to level 16 to find the

exact stimulation level for your dog

(see page 15).

Transmitter Antenna

Always check that the antenna is securely fastened to

the transmitter before each use. Hand tighten only.

Use care when attaching antenna. Over-tightening

may cause damage to the antenna or antenna mount.

Momentary and Continuous Stimulations

Pressing the upper button will make the collar give a

Momentary (or ‘Nick’) Stimulation. Pressing the lower

button gives a Continuous Stimulation. These buttons

are the same on every model of the CDT PLUS series.

Collar Selecting Switch

Switching between collar units can be controlled by

moving the Collar Selection Switch to the desired unit.

Vibration Buttons (CDT 2000 PLUS only)

Pressing the button on the left (#1) of the transmitter

will make the collar vibrate only. Pressing the button

on the right (#2) of the transmitter will make the collar

vibrate only for half a second, and then adds simulta-

neous Continuous Stimulation to the Vibration.

Battery Charging Receptacle

After charging, always cover the jack with the rubber

plug to prevent foreign particles from getting inside.

PARTS & FUNCTIONS

CAUTION

If your collar belt is too long , we recommend looping the

excess collar belt back around through the buckle. We

DO NOT recommend cutting the collar belt. Cutting the

collar belt too much will drastically reduce the range of

your collar unit. However, the collar belt can be cut up to

about 3 inches without affecting the range too much.

Collar Belt with MAXX-Range™ Antenna

The embedded collar antenna is woven into the collar

belt, and runs along the entire length of the belt. This

antenna wraps around your dog’s neck and will give

your collar unit 360˚of signal reception no matter

which way your dog is facing.

Collar Receiver

Charging

Receptacle

LED Indicator Light

ON/OFF Button

Contacts

Collar Belt with

MAXX-Range™

Antenna

PARTS & FUNCTIONS

Collar LED Indicator Light

When the Collar Receiver is turned on, the Red LED

light will flash steadily once every two seconds to

indicate that the unit is active. The Red LED light

changes to a rapid flash when the battery is in need of

charging. The Red LED light stays lit while plugged

into the charger.

Contacts

Contacts should fit snugly against the dog’s neck to

ensure good contact with the skin. For more

information on the proper fit of the collar, see page 14.

Battery Charging Receptacle

The battery charging receptacle is located on the side

of the Collar Receiver facing the dog’s neck. After

charging, always close the jack with the rubber plug to

prevent foreign particles from getting inside

NOTE

The collar unit is still waterproof even if water gets into the

charging receptacle. However, if water should get in, we

recommend rinsing out the charging receptacle and allow-

ing it to dry, especially after use in salt water. This will

prevent premature corrosion in the metal pins inside that

make contact with the charger plug.

CHARGING THE BATTERIES

All CDT PLUS Series units are equipped with

rechargeable Nickel Metal Hydride (NiMH) batteries.

NiMH batteries are not memory sensitive and do not

require depletion before recharging.

The batteries come partially charged from the factory.

However, it is recommended that the batteries are

given a full charge (about 12 hours) before initial use.

Remember - Always keep batteries away from

flammable substances (especially when charging).

When storing the unit for long periods, remember to

regularly give the batteries a full charge (12 hours)

and test your unit once every 4 to 6 weeks.

Battery Charging Procedure

1. Make sure the unit is off.

2. Plug the charger into a

standard electrical outlet.

3. Connect the splitter cable to

the charger and plug the

ends into the appropriate

units (small end in transmitter, large end in collar).

4. Charge the batteries for up to 12 hours. This can be

done either separately or simultaneously.

5. After charging, disconnect the battery charging

cables from the receptacles, securely replace the

rubber battery receptacle covers, and test unit.

WARNING: DO NOT CHARGE WHILE UNIT IS WET!
