DSE DX Series Feuille d'instructions
CONFIGURATION MANUAL
Video recorders DX Series
Page: 1 Page: 1
DSE SRL - ITALY - WWW.DSE.EU
Video recorders DX Series
AHD DVR cameras, analog, IP
Operative manual
for the installer and for the user
How to use the GUI screen. How to set the programming options.
CONFIGURATION MANUAL
Video recorders DX Series
Page: 2 Page: 2
DSE SRL - ITALY - WWW.DSE.EU
Contents of this handbook
The DX series VCRs range is designed to allow the management and the recording of CCTV cameras AHD technology, traditional analog
and IP. It is assumed that the DVR has been connected correctly according to the installation instructions. For convenience it will refer to
commands by using the mouse.
Switching on the DVR
After having prepared the connections and installed on the hard disk as explained in the installation manual it is possible to proceed to
the first ignition. Connect the power plug, the DVR will start automatically.
CONFIGURATION MANUAL
Video recorders DX Series
Page: 3 Page: 3
DSE SRL - ITALY - WWW.DSE.EU
Configuration Wizard (wizard)
At the first start the DVR offers a wizard to enable the connection to the server CLOUD and quickly configure any IP cameras.
It is, however, also it CARRIED operations directly in the DVR configurations as will be explained later.
The setup wizard is proposed at every start until you select "DO NOT SHOW MORE '"
If necessary, you can always reopen the wizard with the button on the taskbar
Enable cloud server is always recommended to facilitate web access operations.
CONFIGURATION IP CAMERAS
The second step of the wizard only occurs if you have chosen, in the multi-technology options (see below), a combination of inputs
providing for the management of IP cameras and allows you to match the network cameras to the DVR channels. ATTENTION: The
"intelligent" configuration proposed by the wizard is not active on these. Choose SETUP MANUAL.
The configuration dialog can also be called simply by clicking on a black box to a non-configured IP camera.
CONFIGURATION MANUAL
Video recorders DX Series
Page: 4 Page: 4
DSE SRL - ITALY - WWW.DSE.EU
The search window and IP camera setup consists of two sections. The upper part is used to list the available cameras on the network,
while the lower part is the DVR channels
CONFIGURATION MANUAL
Video recorders DX Series
Page: 5 Page: 5
DSE SRL - ITALY - WWW.DSE.EU
To the right are the control buttons. At the top you can choose the communication protocol: you can leave all or specify the ONVIF
standard protocol that is supported by this DVR / NVR. Press the Search button to search all onvif camera devices that can be listed in the
left window.
In the lower window shows all channels on the DVR. Only those marked with IPC will accept the connection of IP cameras while others
are reserved for local cameras. Choose one of the IPC DVR canli the bottom window and a network camera from the upper window.
Double click or press ADD. The camera will be connected to the selected channel and its data will appear in the fields below in the
window. As a rule, the DVR is able to set itself consistently all the connection data, but you can edit them manually. In particular you may
need to modify the video stream to be used (if the camera will support more than one) and enter your log in credentials.
Clicking APPLY the configuration will be saved. E 'can move a camera between the digital channels of the NVR with the up / down
arrows and delete it with the DELETE button. The second DELETE button clears all channels configured to start the configuration. If you
want you can quickly load all the cameras in free online channels of DVR QUICK SET button and then make any changes.
With the COPY button, you can copy some data on all cameras without having to manually set (typically useful for setting user
name and password). The configuration of the cameras takes effect after you press the APPLY button.
CONFIGURATION MANUAL
Video recorders DX Series
Page: 6 Page: 6
DSE SRL - ITALY - WWW.DSE.EU
Log-in
After starting the DVR presents the subdivision screen 4/8/16 quadrants depending on the version
Clicking with the right mouse button you can appear and disappear TASKBAR with buttons at the bottom of the screen
The DVR control is password protected to prevent unauthorized access. To log-in click of a command button in the taskbar any
The DVR factory credentials
CONFIGURATION MANUAL
Video recorders DX Series
Page: 7 Page: 7
DSE SRL - ITALY - WWW.DSE.EU
USERNAME: admin PASSWORD: Leave
blank
E 'can customize password and user name in the user configuration.
If you enter incorrect credentials 3 times the DVR beeps. After 5 times the DVR hangs and no longer accepts commands before 30
minutes have passed or that a restart takes place
If you lose your password please contact our customer service.
CONFIGURATION MANUAL
Video recorders DX Series
Page: 8 Page: 8
DSE SRL - ITALY - WWW.DSE.EU
Checking the DVR for viewing live
This section of the manual describes how to use the controls on the DVR in the LIVE Vision.
Upon starting the DVR it is proposed the simultaneous multi-vision camera with screen division in 4, 9 or 16 frames, depending on the
model in question.
If at this stage the camera images do not appear in the boxes to check connections and power supplies to check the video signal
presence. Refer to the installation manual.
TASKBAR
Clicking with the right mouse button you can appear and disappear TASKBAR with the buttons at the bottom of the screen.
With the exception of the 3 leftmost OSD buttons, and PLAYBACK GUIDE which will be described later, all the remaining buttons relate to
live view and are described in this chapter.
CONFIGURATION MANUAL
Video recorders DX Series
Page: 9 Page: 9
DSE SRL - ITALY - WWW.DSE.EU
ICONS OF CHANNEL STATE
Each camera pane shows the overlays provided in configuration and some icons that reveal the input status as per the following table
Icon
Description
Video offline or
absent
Recording in
progress
Blindness camera in
progress
Motion
detection
activated
Audio playback
MULTIVISION CONTROL
To bring a camera full screen just double click on it. With a new double click to return to the multiple vision. You can select different
screen layout options with the right-most button in the taskbar.
DIGITAL ZOOM
The DVR DH series are equipped with a very advanced zoom function that allows you to easily zoom in the particular interest in both live
viewing and playback. The digital zoom function works only in full screen view of a single camera. To zoom drag the mouse in the
camera frame to fit around a particular interest. Then just click on the track pane. To turn off the display double click again.
ACTIVATE AUDIO
The default audio playback of the individual channels is disabled. To unmute, click the icon of the channel speaker
PTZ CONTROL
To control a motorized camera must first set the control parameters in the configuration menu (see below).
CONFIGURATION MANUAL
Video recorders DX Series
Page: 10 Page: 10
DSE SRL - ITALY - WWW.DSE.EU
To enable auditing, click the PTZ button in the taskbar
It opens the control panel for motorized cameras speed dome
●CHANNEL - You should select the camera to be controlled
●SPEED '- La 1 to 8 of the speed control allows you to choose the speed of movement.
●DIRECTION ARROWS - Used to move the camera in all directions
●ZOOM / FOCUS / IRIS - Lens Remote control
●SETTINGS - Accesses the PRESET / TOUR / PATTERN control window that allows you to schedule automatic camera movements.
The setting of these functions may not be effective due to the imperfect homogeneity of the protocols, it is always better to set these
movements in the camera setup menu.
●PTZ MOUSE - Activate the control of the camera movements acting directly on the image with the mouse. It is a type of very intuitive
and direct command that allows it to move in one direction simply by clicking on the corresponding image edge. You can also zoom with
the mouse wheel. The command of the PTZ with the mouse makes it possible to avoid the superimposition of the control mask.
Note that the command of the PTZ with the mouse can also be activated with the MOUSE PTZ button in the taskbar
With the OTHER button PAG. PTZ control browsing other pages.
