1. Product Overview

The DR-N video recorders have been developed for professional video surveillance and incorporate in one unit of

digital video recorder hard drive, a multiplexer, and a web server.

1.1 Product Features

• Possibility of connecting 4 (DR-N4), 8 (DR-N8) or 16 (DR-N16) cameras in both color and B / W

• 1 independent audio input for each camera

• H264 Video compression with configurable quality

• ADPC audio compression

• Hexaplex - The unit can not stop recording in case of live viewing, playback, backup, control and remote

access

• PAL Resolution: Selectable D1: 704x576 / HD1: 704x288 / CIF: 352x288

• Frame rate PAL viewing live: real-time 25 f / sec per channel

• Frame rate PAL recording: configurable up to 25 f / sec per channel

• Continuous recording, alarm or on an hourly basis

• Mouse control with on-screen graphic interface

• Playback search by time or event (alarm, motion

• Intelligent Motion detection with programmable area and sensitivity

• Management of air not shown for privacy surveillance in the workplace.

• 4 (DR-N4 / 8) and 16 (DR-N16) alarm inputs and 1 alarm output to external devices

• 1 Hard disk SATA II max. 2TB capacity (DR-N16: 2 HDD only)

• Video / audio backup to USB2.0 storage devices, including USB sticks, external HDD and DVD + RW

recorders, DVD + R, and DVD-R

• Ethernet interface for remote access via web browser, remote alarm notification, remote control speed dome,

tele programming and updating firmware remotely.

• PTZ control capability of speed dome cameras multiprotocol (with SD series cameras use Pelco D). alarm

preset recall.

• Access from mobile devices: iPhone, iPad, Blackberry, 3G / 3.5G phones

• Access via PDA with support for Windows Mobile, Symbian, Android.

• Free App for remote access with advanced features (full screen, PTZ control of speed dome cameras etc).

• Mapping of the gates of automatic UPnP router

• Remote access via the Internet with the video ID

• Menu in Italian (Multilingual programmable)

• Enter password to ensure a high degree of safety.

USER MANUAL

DIGITAL VIDEO DR-N4 / 8/16

Page: - 3 - Page: - 3 - Page: - 3 -

DSE srl - ITALY - WWW.DSE.EU

1.2 Specifications

DR-N4 DR-N8 DR-N16

video Format PAL / NTSC / SECAM

video Compression H.264 baseline

audio Format G.726 ADPCM Mono 8Kx16bit

video Inputs 4 BNC 8 BNC 16 BNC

audio Inputs 4 RCA 8 RCA 16 RCA

alarm inputs 4 NO / NC 4 NO / NC 16 NO / NC

alarm outputs 1 1 1

video Resolution CIF 352x288 Half D1

704x288

D1 704x576

CIF 352x288 Half D1

704x288

D1 704x576

CIF 352x288 Half D1

704x288

D1 704x576

Frame rate display 25 f / sec channel 25 f / sec per channel 25 f / sec per channel 25 f / sec channel 25 f / sec per channel 25 f / sec per channel

Total recording frame rate D1: 100 f / sec HalfD1:

100 f / sec CIF: 100 f /

sec

D1: 50 f / sec HalfD1:

100 f / sec CIF: 200 f /

sec

D1: 100 f / sec HalfD1:

200 f / sec CIF: 400 f /

sec

Recording Mode Schedule, manual, alarm, motion detection

Masks privacy Yes Yes Yes

HDD 1 SATA HDD

Max. 2TB

1 SATA HDD

Max. 2TB

2 SATA HDD

Max. 2TB

Network port RJ45 10 / 100M RJ45 10 / 100M RJ45 10/100 /

1000M

USB2 port Mouse / Portable HDD / Flash Drive / DVD Burner

RS485 port Protocol Pelco P / D, Samsung, Panasonic etc.

video Backup AVI format, MP4, H264

Supply 12VDC power supply provided

Absorption 10-15W

Temperature - 10 + 40 ° C

Humidity 10% -90% RH

Dimensions mm. 315x224x52 315x224x52 435x340x55

USER MANUAL

DIGITAL VIDEO DR-N4 / 8/16

Page: - 4 - Page: - 4 - Page: - 4 -

DSE srl - ITALY - WWW.DSE.EU

2. controls, connections and remote control

2.1 Front controls

DR-DR-N4 and N8

DR-N16

1 Alphanumeric keys and multivision

They are used to select a camera to display full screen. The multivision button (

) is used to divide the

screen into quadrants to display multiple cameras simultaneously. In the DR-N8-N16 model and DR for space reasons

some buttons control 2 channels: for example, the 1/11 button selects the camera 1 if pressed once and 11 when

pressed two times consecutively.

2 MENU button

Press this button to display the programming menu of the DVR

3 ESC button

Press this button to display or hide the menu bar and system information, or to exit the menu in which you entered.

4 REC button

Pressing this button starts manual recording stops again pressed again. Manual recording is used to record regardless

of the automatic settings that are set in DVR.

USER MANUAL

DIGITAL VIDEO DR-N4 / 8/16

Page: - 5 - Page: - 5 - Page: - 5 -

DSE srl - ITALY - WWW.DSE.EU

5 button BACKUP

Pressing this button on the screen window that allows you to examine for films of interest and saving on external media

such as USB keys etc ..

6 Play / Pause ( )

Press this button to open the search function that lets you search and play back the recorded movies. Also it used to

pause the movie playback.

7 Button PTZ

This button is used to control the movement of Speed Dome cameras connected to the RS485 serial port. Once you

have selected with the mouse or keyboard to control the camera, press this button to open the control panel that

appears on the screen.

8 Button left / right / up / down ( ◄, ►, ▲, ▼)8 Button left / right / up / down ( ◄, ►, ▲, ▼)8 Button left / right / up / down ( ◄, ►, ▲, ▼)

In PTZ control, press these buttons to move the camera. In other situations. press this button to move the cursor or

click on a particular window.

9 ENTER button

This button is used in many cases to confirm the data.

10 Light POWER

Indicator light for ignition.

11 Light HDD

Indicator light for switched to the hard disk.

12 IR Receiver

It receives the signal sent to it from the remote control. Avoid obstacles that can interfere in the signal direction.

13 Front Tray (DR-N16 ONLY)

Accesses the pull-out drawer for removable disk.

14 Button NO ALARM14 Button NO ALARM

Pressing this button will access the alarm source screen to silence any kind of alarm or buzzer.

USER MANUAL

DIGITAL VIDEO DR-N4 / 8/16

Page: - 6 - Page: - 6 - Page: - 6 -

DSE srl - ITALY - WWW.DSE.EU

2.2 Connections

DR-N4

DR-N8

DR-N16

1 USB port

Connect an external USB device like a USB stick, an external HDD or a DVD burner. The maximum current that the

VCR is able to provide to the USB device, if this is not provided with their own autonomous power supply is 500 mA.

This port only supports drives with FAT32 file system.

2 Port MOUSE

It allows to connect the mouse to the VCR. The mouse is not required for use of the device but faster and more

convenient to use than the front buttons, and we recommend that you always connect if the position of the DVR allows

you to use it.

3 (DR-N16 only) - auxiliary video output connector (CALL OUT)

USER MANUAL

DIGITAL VIDEO DR-N4 / 8/16

Page: - 7 - Page: - 7 - Page: - 7 -

DSE srl - ITALY - WWW.DSE.EU

BNC connector to connect a secondary external monitor said CALL. The monitor said no CALL visualises the menu,

but only images from the cameras. Compared to the main output monitor it has an independent display showing

programming and can cycle the cameras and bring up specific cameras according to alarm events.

3 (DR-N4 only) - Audio output connector (AUDIO OUT)

This RCA connector allows you to connect an external audio speakers to play the sound live or recorded. In DR-N8 /

16 models this output is also available, but is included in the audio cable supplied.

4 Audio Input Connectors (AUDIO IN)

The DR VCRs include one audio input for each camera to record audio along with the video. In the model DR-N4 I audo The DR VCRs include one audio input for each camera to record audio along with the video. In the model DR-N4 I audo The DR VCRs include one audio input for each camera to record audio along with the video. In the model DR-N4 I audo

the inputs are composed of 4 RCA connectors and serve to connect the audio inputs from the cameras or from external

microphones. In the model DR-N8, for reasons of space, the RCA connectors for audio are not directly placed on the microphones. In the model DR-N8, for reasons of space, the RCA connectors for audio are not directly placed on the microphones. In the model DR-N8, for reasons of space, the RCA connectors for audio are not directly placed on the

DVR but are on a cable supplied separately to connect to the D-SUB connector labeled Audio. This cable also allows

you to connect an external speaker to play back the recorded audio (AUDIO OUT). In the model DR-N16 They are you to connect an external speaker to play back the recorded audio (AUDIO OUT). In the model DR-N16 They are you to connect an external speaker to play back the recorded audio (AUDIO OUT). In the model DR-N16 They are

supplied separately to the well 2 adapters and cables are located on the DVR 2 D-SUB ports. The AUDIO IN port 1-8

allows to connect the microphones from 1 to 8 and the speaker output. The AUDIO 9-16 allows you to connect

microphones of the remaining cameras.

5 Video Input Connectors (1-16)

Connect cameras to these BNC connectors. If the cable has RCA connectors use special adapters RCA / BNC

6 main video output connector (MAIN OUT)

BNC connector for connecting the analog type main external monitor. It display all the windows even if the video signal

is absent and provides access to the programming menu.

7 Ethernet RJ45 socket

10/100 Ethernet connection for remote access from a PC.

8 VGA connector

VGA connector for connecting a computer to type PC monitor. And 'possible to directly connect a monitor with a VGA

cable. This replica output exactly the analog BNC output named MAIN. The DR series VCRs support maximum

1440x900 resolution in 4: 3 and 16: 9 If you have set an unsupported resolution on your monitor so there is precluded

the display can restore the 800x600 VGA resolution by pressing the ESC + 2 keyboard and 2 + ESC

Terminal block 9 inputs / alarm outputs and serial ports

This terminal allows you to connect different types of devices.

ALARM INPUTS - As alarm inputs are intended sensors or external contacts capable of generating alarm and start ALARM INPUTS - As alarm inputs are intended sensors or external contacts capable of generating alarm and start

recording ( ALARM IN).recording ( ALARM IN).

ALARM OUTPUT - The alarm outputs allow to connect external devices, such as acoustic, flashing alarms, lighting, etc. ALARM OUTPUT - The alarm outputs allow to connect external devices, such as acoustic, flashing alarms, lighting, etc.

to operate in case of alarm ( ALARM OUT).to operate in case of alarm ( ALARM OUT).

USER MANUAL

DIGITAL VIDEO DR-N4 / 8/16

Page: - 8 - Page: - 8 - Page: - 8 -

DSE srl - ITALY - WWW.DSE.EU

PORT RS485 - The serial port is used to send commands to motorized speed dome cameras ( RS485).PORT RS485 - The serial port is used to send commands to motorized speed dome cameras ( RS485).PORT RS485 - The serial port is used to send commands to motorized speed dome cameras ( RS485).

10 ON / OFF

switching on and off switch.

11 Power connector

Connect the power supply 12VDC.

12 Cooling Fan

Fan for the cooling of the hard disk.

13 HDMI Video output (DR-N16 only)

The only DR-N16 model includes another type of HDMI video output to connect a TV-like monitor.

2.3 Remote Control

The remote is a standard accessory with the DVR to facilitate the user. You can perform all the functions with the

remote control at a distance instead of going to select the front panel. The effective distance is about 10 meters

without any obstacle.

The DR-N keyboard also has only the essential buttons for operation, while several additional functions are only

available using the mouse or remote control.

Below a picture of the remote control whose design can be different depending on the model.

commands

Most of the buttons on the remote replication the keys on the DVR keyboard. There are also the following

additional functions:

1 - Play / Paua ( 1 - Play / Paua ( )To search for movies, play, and pause

2 - Stop () Stop playback 2 - Stop () Stop playback

3/4/5/11 - Moving - Motion arrows in all directions 3/4/5/11 - Moving - Motion arrows in all directions

6 - Menu / ESC - Press to open the programming menu and to exit 6 - Menu / ESC - Press to open the programming menu and to exit 6 - Menu / ESC - Press to open the programming menu and to exit 6 - Menu / ESC - Press to open the programming menu and to exit

USER MANUAL

DIGITAL VIDEO DR-N4 / 8/16

Page: - 9 - Page: - 9 - Page: - 9 -

DSE srl - ITALY - WWW.DSE.EU

7 - Log in - Press to log-in and log-out 7 - Log in - Press to log-in and log-out 7 - Log in - Press to log-in and log-out 7 - Log in - Press to log-in and log-out

8 - Numerical buttons (1-9, 0, 10+) cameras and inserting texts Selection 8 - Numerical buttons (1-9, 0, 10+) cameras and inserting texts Selection 8 - Numerical buttons (1-9, 0, 10+) cameras and inserting texts Selection

9 - Fast Backward ( 9 - Fast Backward ( )Fast backward playback

10 - Fast Forward ( 10 - Fast Forward ( )fast forward

12 - Enter 13 - Scan - Starts and stops the cyclical scanning 12 - Enter 13 - Scan - Starts and stops the cyclical scanning

14 - Audio ON / OFF 14 - Audio ON / OFF 14 - Audio ON / OFF 14 - Audio ON / OFF

15 - Multivision Change the screen division. 15 - Multivision Change the screen division.

16 - REC Start manual recording16 - REC Start manual recording

Any other buttons on the remote control other than those described have no application of these models.

USER MANUAL

DIGITAL VIDEO DR-N4 / 8/16

Page: - 10 - Page: - 10 - Page: - 10 -

DSE srl - ITALY - WWW.DSE.EU

3. Installation

3.1 Basic Connections

Before turning on the VCR is necessary to arrange the connections with the peripheral units which we explain

below.

•Connect cameras

The cameras are connected to the BNC Video IN (channel 1 ... 16). If the cable you have available has RCA

connectors you must use a RE-BNCRCA1 adapter. The inputs support a standard analog video signal 1

Vp-p 75 Ohm.

•Connect the main monitor

A classic CRT or LCD monitor or a TV can be connected to the MAIN OUT with BNC attack. It 'also possible

to connect a PC to the VGA monitor. In DR-N16 model it is also possible to connect a TV monitor to the

HDMI output.

Without monitor the DVR can run but you can not control it.

•hard disk installation

Because the DVR is capable of recording, you need to install the hard drive inside the equipment. Before

installation make sure the hard drive is the SATA type 3.5 " Then install the hard disk as follows: installation make sure the hard drive is the SATA type 3.5 " Then install the hard disk as follows: installation make sure the hard drive is the SATA type 3.5 " Then install the hard disk as follows:

1. Turn off the appliance open the VCR by removing the 1. Turn off the appliance open the VCR by removing the
