Drive KA 1200N Manuel utilisateur

nimbo lightweight

posterior safety roller

KA 1200N, KA 2200N, KA 3200N,

KA 4200N, KA 5200N

www.drivemedical.com

two year limited

warranty

Your Drive brand product is warranted to be free of

defects in materials and workmanship for two years

from the date of the original consumer purchase.

This device was built to exacting standards and

carefully inspected prior to shipment. This Two

Year Limited Warranty is an expression of our

confidence in the materials and workmanship of

our products and our assurance to the consumer of

dependable service.

In the event of a defect covered by this warranty, we

will, at our option, repair or replace the device.

This warranty does not cover device failure due to

owner misuse or negligence, or normal wear and

tear. The warranty does not extend to non-durable

components such as rubber accessories, casters, and

grips, which are subject to normal wear and need

periodic replacement.

If you have a question about your Drive device or

this warranty, please contact an authorized

Drive dealer.

Drive is a trademark of Medical Depot, Inc.

Port Washington N.Y. 11050 USA Made in China

EU Authorized Representative

Drive International, LLC

Globe Lane - Stockport

DUKINFIELD SK16 4RE, GB

user instructions

1. Remove Nimbo from carton.

2. To unfold the Nimbo, pull handgrips and cross

brace in opposite directions. Continue to unfold

until the push pins “click” into place.

3. To install the legs, match the leg numbers with the

corresponding frame numbers. Depress the push

pins on the legs and slide into the frame. When

locked into position, the push pins will “CLICK”

through the frame.

4. Adjust height of walker by pressing push pins on

each leg and slide leg to desired position.

FIGUREA

INCORRECTPUSHPINSCORRECTPUSHPINS

FRONT

OF

WALKER

1. Lift and position knob (A) to set front wheels in

either the swivel or locked position.

maintenance and care

1. Inspect the Roller regularly. Tighten the nuts

and bolts as necessary. If a product needs service

or replacement parts, contact an authorized Drive

dealer.

2. To clean the Roller, use warm water with a mild

detergent. Wipe clean with a soft, dry cloth.

FIGUREC

PICTUREINDICATES

UNLOCKEDPOSITION

OVERRIDE

BRACKET

user information

2. To fold the Nimbo, face it from the open end,

depress the push pins, tilt walker so that it rests

on its rear legs only and push the front legs toward

the rear legs.

3. To override the one-directional feature of the rear

wheels, lift up aluminum pin and insert into

override bracket

FIGUREB
