Draytek VigorLTE 200n Manuel utilisateur

Intellectual Property Rights (IPR) Information

Copyrights

by copyright. No part may be reproduced, transmitted, transcribed, stored in

a retrieval system, or translated into any language without written permission

from the copyright holders.

Trademarks

The following trademarks are used in this document:

 Microsoft is a registered trademark of Microsoft Corp.

 Windows, Windows 95, 98, Me, NT, 2000, XP, Vista, 7, 8 and

Explorer are trademarks of Microsoft Corp.

 Apple and Mac OS are registered trademarks of Apple Inc.

 Other products may be trademarks or registered trademarks of

their respective manufacturers.

Safety Instructions and Approval

Safety

Instructions

 Read the installation guide thoroughly before you set up the router.

 The router is a complicated electronic unit that may be repaired

only be authorized and qualified personnel. Do not try to open or

repair the router yourself.

 Do not place the router in a damp or humid place, e.g. a bathroom.

 Do not stack the routers.

 The router should be used in a sheltered area, within a

temperature range of 0 to +40 Celsius.

 Do not expose the router to direct sunlight or other heat sources.

The housing and electronic components may be damaged by direct

sunlight or heat sources.

 Do not deploy the cable for LAN connection outdoor to prevent

electronic shock hazards.

 Keep the package out of reach of children.

 When you want to dispose of the router, please follow local

regulations on

nservation of the environment.

Warranty

We warrant to the original end user (purchaser) that the router will be free

from any defects in workmanship or materials for a period of two (2) years

from the date of purchase from the dealer. Please keep your purchase receipt

in a safe place as it serves as proof of date of purchase. During the warranty

period, and upon proof of purchase, should the product have indications of

failure due to faulty workmanship and/or materials, we will, at our discretion,

repair or replace the defective products or components, without charge for

either parts or labor, to whatever extent we deem necessary tore-store the

product to proper operating condition. Any replacement will consist of a new

or re-manufactured functionally equivalent product of equal value, and will

be offered solely at our discretion. This warranty will not apply if the product

is modified, misused, tampered with, damaged by an act of God, or subjected

to abnormal working conditions. The warranty does not cover the bundled or

licensed software of other vendors. Defects which do not significantly affect

the usability of the product will not be covered by the warranty. We reserve

the right to revise the manual and online documentation and to make changes

from time to time in the contents hereof without obligation to notify any

person of such revision or changes.

iii

VigorLTE 200n

LTE Router

Quick Start Guide

t .................................................................................................. 1

n ................................................................................................. 2

n ........................................................................................... 4

n ................................................................................................................... 4

-M

n ........................................................................................................... 5

n ........................................................................................ 6

e ................................................................................................. 9

Take a look at the package content. If there is anything missed or damaged, please contact

DrayTek or dealer immediately.

Vigor router Quick Start Guide

RJ-45 Ethernet Cable

2x LTE antenna

Power Adapter

LED

Status

Explanation

Off

rout

er is powered off.

Blinking The router is powered on and running

normall

The router is ready to access Internet.

Off

The rou

ter is not ready to access Internet.

Blinking

Slowly: The network connection is ready.

Quickly: The network connection is

establishing.

The LAN port is connected.

Blinking

The data is transmitting through the LAN port.

LTE device

is conne

cted and ready for use.

Off

LTE device is not detected, or has serious

problem (e.g., no SIM card, SIM pin error, SIM

deactivated, and etc.).

linking

Vigor

device

performs initial access

procedure

On SIM card is inserted into the slot and detected

by Vigor

device

linking

No SIM card in detected.

Wireless function is enabled.

Off

Wireless functio

is d

isabled.

Blinking

The data is transmitting via wireless

connection.

Blinks with one second cycle for two minutes.

The WPS function is

active.

Interface

Description

Factory Reset Restore the default settings. Usage: Turn on the router

(ACT LED is blinking). Press the hole and keep for more than

5 seconds. When you see the ACT LED begins to blink

rapidly than usual, release the button. Then the router will

restart with the factory default configuration.

SIM2/SIM1 SIM card slot(s).

P2-P1 Connecters for local network devices.

ON/OFF Power Switch.

PWR Connecter for a power adapter.

This section will guide you to install the router through hardware connection.

1. Install the SIM card into the card slot. The back plate of the SIM card slot must be

removed first and the direction of card notch must be on the left side.

After installing the SIM card, fasten the back plate again.

2. Connect to your computer with a RJ-45 cable.

3. Connect one end of the power cord to the power port of this device. Connect the other

end to the wall outlet of electricity.

4. Power on the router.

5. Check the power, LTE and LAN LEDs to assure network connections.

Note Remove the protective film from the router before use to ensure

ventilation.

-M

Vigor router has keyhole type mounting slots on the underside.

1. A template is provided on the Vigor router packaging box to enable you to space the

screws correctly on the wall.

2. Place the template on the wall and drill the holes according to the recommended

instruction.

3. Fit screws into the wall using the appropriate type of wall plug.

Note The recommended drill diameter shall be 6.5mm (1/4”).

4. When you finished about procedure, the router has been mounted on the wall firmly.

To access Internet, please finish basic configuration after completing the hardware

installation.

The Quick Start Wizard is designed for you to easily set up your router for Internet access.

You can directly access the Quick Start Wizard via Web Configurator.

1. Make sure your PC connects to the router correctly.

Note You may either simply set up your computer to get IP dynamically

from the router or set up the IP address of the computer to be the

same subnet as the default IP address of Vigor router

192.168.1.1.

2. Open a web browser on your PC and type http://192.168.1.1. A pop-up window will

open to ask for username and password. Please type “admin/admin” as the

Username/Password and click Login.

3. Now, the Main Screen will pop up.

4. Click Wizards>>Quick Start Wizard.

5. Enter the login password on the field of New Password and retype it on the field of

Confirm Password. Then click Next to continue.
