Dodge 2009 Charger Manuel utilisateur

CHARGER

2009

QUICK REFERENCE GUIDE

175470_09_Charger_QRG_101408.indd 6 4/24/09 1:28:22 PM

MANUAL CLIMATE CONTROLS

AIR RECIRCULATION

 Use recirculation for maximum A/C operation.

 For window defogging turn the recirculation off.

 Recirculation is not allowed in defrost, ﬂoor, defrost/ﬂoor

(mix) modes.

ADJUSTABLE PEDALS

 

move toward or away from the driver.

 

forward to move the pedals away from the driver and push the

button rearward to move the pedals toward the driver.

DRIVER POWER SEAT ADJUSTMENT

 

the outboard side of the seat,

controls seatback adjustment.

 

forward/back, up/down, and

tilt adjustment.

UNIVERSAL CONSUMER INTERFACE – iPod®

 ®can be plugged into the vehicle’s audio system, using

the provided cable, through a connector located in the glove

box. Refer to Owner’s Manual for operation.

Rotate

Blower

Control

Rotate

Temp.

Control

Push

A/C

Button

Push

Rear Window

Defroster

Button

Rotate

Mode

Control

Recirc.

Recline

Switch

Pedal

Adjust

Seat

Switch

175470_09_Charger_QRG_101408.indd 2 4/24/09 1:28:02 PM

AUTOMATIC TEMPERATURE CONTROLS

AUTOMATIC OPERATION

 Turn the mode control to the AUTO position and the blower

control to either LO AUTO or HIGH AUTO position.

 Select the desired temperature by rotating the

temperature control for the driver or passenger.

 The system will maintain the set temperature automatically.

AIR CONDITIONING (A/C)

 If the air conditioning button is pressed while in the AUTO

mode, the indicator light may ﬂash three times to indicate the

air conditioning is being controlled automatically.

AIR RECIRCULATION

 Use recirculation for maximum A/C operation.

 For window defogging, push the recirculation off.

 If the recirculation button is pressed while in the AUTO mode,

the indicator light may ﬂash three times to indicate the cabin

air is being controlled automatically.

WIND BUFFETING

  

percussion sound. If buffeting occurs with the rear windows

open, adjust the front and rear windows together.

 

sunroof opening, or adjust any window. This will minimize

the buffeting.

Rotate

Blower

Control

Rotate

Driver

Temp.

Control

Push

A/C Button

Push Rear

Window

Defroster

Button

Rotate

Passenger

Temp.

Control

Rotate

Mode

Control

Push

Air Recirc.

Button

175470_09_Charger_QRG_101408.indd 3 4/24/09 1:28:06 PM

FUEL CAP

LOOSE GAS CAP MESSAGE

 



 

 

tightening the gas cap, see your dealer.

TIRE PRESSURE MONITORING SYSTEM (TPMS)

 

Monitoring Light will illuminate and an audible chime will sound.

 

inﬂate to the recommended cold pressure value, shown on the placard

located in the driver’s door opening. The TPMS display should not be

used as a tire pressure gauge when adjusting your tire pressure.

  

recognized. The vehicle may need to be driven for up to 20 minutes

above 15 mph (25 km/h) before the light will turn off.

 

Temperature changes can affect tire pressures causing the TPMS light

to turn on. Colder temperatures will decrease tire pressure and

warmer temperatures will increase tire pressure.

 

Refer to your Owner’s Manual.

OIL CHANGE INDICATOR

MESSAGE

  

Required) appears and a single chime sounds, it is time for your

next required oil change.

RESETTING LIGHT AFTER SERVICING

 

 

 

VEHICLE FEATURES

175470_09_Charger_QRG_101408.indd 4 4/24/09 1:28:09 PM

CLOCK SETTING

NON-TOUCH-SCREEN RADIOS

 

the TUNE/SCROLL control knob to set the hours.

 



set the minutes.

 

TOUCH-SCREEN RADIOS

 

 

 

(Navigation Radio Only).

 

button or the hour backward button.

 

button or the minute backward button.

 

  

uconnect™phone

 ™phone is a voice-activated, hands-free, in-vehicle,

communications system. uconnect™phone allows you to dial a

phone number with your cellular phone using voice commands.

 ™phone allows pairing a cellular phone equipped with

the Bluetooth®Hands-Free Proﬁle, Version 0.96 or higher. See

the www.dodge.com/uconnect website for supported phones.

Refer to your Owner’s Manual for further information.

ELECTRONIC VEHICLE INFORMATION CENTER

(EVIC) CONTROLS

 The EVIC features a driver interactive display that is located

in the instrument cluster. Pressing the controls on the steering

wheel allows the driver to select vehicle information and

Personal Settings.

VEHICLE FEATURES

175470_09_Charger_QRG_101408.indd 5 4/24/09 1:28:11 PM

Headlight

Switch

Turn Signals/Wipers/Washer/

High Beam Lever

Electronic Vehicle

Information Center

(EVIC) Controls and Display

Speed

Control

Lever

INSTRUMENT PANEL

Remote

Audio Controls

175470_09_Charger_QRG_101408.indd 7 4/24/09 1:28:27 PM

INSTRUMENT PANEL

Electronic Vehicle

Information Center

(EVIC) Controls and Display

Speed

Control

Lever

Climate

Controls Heated

Seat

Switch

Heated

Seat

Switch

Audio System

(Touch-Screen

Radio Shown)

Upper Switch Panel

Hazard Warning Flasher

Electronic Stability Program

INSTRUMENT PANEL

Remote

Audio Controls

175470_09_Charger_QRG_101408.indd 8 4/24/09 1:28:33 PM

INSTRUMENT PANEL

Heated

Seat

Switch

Audio System

(Touch-Screen

Radio Shown)

KEY FOB



 

 

twice within ﬁve seconds to unlock all the doors.

  

  

 

PANIC ALARM

 

  

time to turn the panic alarm off.



  twice within ﬁve seconds to open

the trunk.

REMOTE START

  

Pressing the REMOTE START button a third time shuts the engine off.

 

the ignition and turn to the ON/RUN position.

 

unless the ignition key is placed in the ON/RUN position.

 

consecutive timeouts.

EXPRESS DOWN WINDOW FEATURE

 

  

front windows to the desired level.

VEHICLE FEATURES

Remote

Start

Lock

Unlock

Trunk

Slide to

Release Key

Emergency

Key

175470_09_Charger_QRG_101408.indd 9 4/24/09 1:28:42 PM

HEADLIGHT SWITCH



  

and the second detent for headlights.

 

 

on or off based on ambient light levels.

FOG LIGHTS

  

switch once to turn the fog lights on. Push the switch a second time

to turn the fog lights off. Fog lights will not operate when high

beams are on.

  

lights are on.

DIMMER CONTROL

  

dim the instrument panel lights and prevent the interior lights from

illuminating when a door is opened.

  

instrument panel lights when the parking lights or headlights are on.

  

brighten the odometer and radio displays when the parking lights

or headlights are on. Refer to your multimedia or navigation user

manual for display dimming.

 

interior lights.

VEHICLE FEATURES

Rotate

Headlight

Switch

AUTO

Push Fog

Lights

Rotate

Dimmer

175470_09_Charger_QRG_101408.indd 10 4/24/09 1:28:47 PM

SPEED CONTROL LEVER

CRUISE ON/OFF

 

  will appear on the instrument cluster

to indicate the Speed Control is on.

 

SET

 

desired speed.

ACCEL/DECEL

 



 

or decrease the set speed approximately 1 mph (2 km/h).

CANCEL

  

speed and maintain the set speed memory.

 

speed memory.

RESUME

 

up and release.

Mist (Push

to First Detent)

Push ON/OFF

Button

175470_09_Charger_QRG_101408.indd 11 4/24/09 1:28:52 PM
