dji SPARK Manuel utilisateur
Main Screen
Connect* your DJI Spark to your iPhone/iPad! Then tap the Picture to start!
*you can connect directly to the spark wifi or use the DJI remote (WIFI or OTG connection)
Icons in the Main Screen:
Map View:
•View the last known drone position.
User Guide:
• Brings you to this user guide.
App Information:
•Provides you with information on the app version and other useful information.
Waypoint Mission:
•Shortcut to the Waypoint Mission Manager.
Piloting Screen
Fullscreen Mode
VR Mode
Waypoint Mission Manager
App Settings
Camera Settings
Camera Mode Switch
Shutter Button
Open Map View (see Spark Position / choose POI)
Controller Signal Level
Vision System State (On/Off)
Current Flight Mode
Take off / Landing Button
Return To Home Button
Back To Main Screen
Forward Anti-collision System State.
Important: The Forward Anti-collision system is active even in PRO MODE (without
the remote controller), BUT in this mode the Spark can fly faster than the reaction
time / brake distance that the Spark need to avoid forward collision
Right Info Panel
Controller* / Device / Spark GPS state + satellite number
Controller / Device / Spark battery level in percentage
*Only Inspire and M100 Remote Controllers have GPS
Left Info Panel
Drone Speed
Drone Altitude from Take off point
Drone Distance from Piloting Device
Camera Tilt slider
Radar - will show how the drone and the remote are oriented one respect
the other.
It appear on screen only when the drone distance is >20m (>65ft)
Flying Modes
With the remote controller currently you can fly in Atti/GPS Mode or switch to Sport Mode
Without the remote controller you can fly in Atti/GPS Mode, or in settings you can activate the
PRO MODE, that will allow you to fly your Spark Faster ( similar to remote controller Sport
Mode) and also will allow you to fly with out the 100m distance limitation.
IMPORTANT NOTE:
in PRO MODE the obstacle avoidance system will be ineffective because of the higher speed.
VR Mode
In this Mode you will have an immersive flight experience!! Enjoy the First Person View with any VR
headset (goggles)
You also have onscreen 2 Augmented Reality localizer, one will show you your Position, the other will
show you the position of the POI that you can choose on Map.
On screen you have all the information that you need! like distance,altitude,speed,video recording state
and all batteries level.
1 Batteries Level
2 Distance
3 Altitude
4 Video Recoding
State
5 Speed
If you need to look around you while you are wearing the Headset you can press the “C2 button” on the
remote to switch from the Drone point of view to Your point of view using the camera of your iPhone!
(View from the iPhone Camera)
Customise the VR view
The View is full customisable to fit all needs, you can adjust the eye width, the vertical position and the
dimension of the views
When the Drone is Landed follow on screen
instruction!
Move the left stick to left to enter edit Mode
Use the Right Stick to adjust vertical position and
eye-width
Use the Left stick to change View dimension and
confirm
-Press the “Fn button” to start/stop the Head-Tracking for camera Tilt
Ta p t h e r e d “ X” to return to close the VR view and go back to the normal piloting screen
AR Localizer
You have two Augmented Reality Localizer that will help you orient yourself on the Spark video
feed.
The green locator will always indicate your position, while the red one will show you the
Position and Distance of a Point of Interest that you can choose on Map.
GPS Error, compass error or barometer sensor error could affect the accuracy of the localizer
but will always be a great help to find your destination.
Localizers are available in normal mode, full screen and “VR” Mode
You can be switch localizers on/off in the settings.
Set the POI
To choose the POI, open the map view in
the piloting screen, then just tap the map
to set your POI.
Then adjust the Altitude of the POI with
the altitude picker on the left of the
screen (altitude is relative to take off
point)
Altitude Picker Tap to set the POI
Settings
General Settings
Here you can calibrate the Spark and choose some basic
settings such as measurement units (imperial / metric)
VR settings
Basic settings for VR view
RTH settings
Here you change the Altitude of the RTH also you can set the
FailSafe Behaviour
Flight Limit settings
Here you can set the Max altitude and distance for your
flight
Hardware Decoding Option
In setting you can choose hardware decoding ON/OFF, it’s recommended to keep it ON on all device with “A8” chip
or newer (iPhone 6/iPad Mini 4/iPad Air 2 or newer devices) this will reduce video latency also will reduce the over
heating/battery consumption of the device.
MFI Bluetooth Controller
As soon as you connect your MFI controller to your device via bluetooth the on-screen piloting pads will
disappear and you can start to use it!
Thumbsticks - move the Spark (piloting Mode2)
Directional pad - not used
L1 shoulder button - move camera up (pressure sensitive for the speed)
L2 shoulder buttons - move camera down (pressure sensitive for the speed)
R1 shoulder buttons - Start / Stop video recording
R2 shoulder buttons - Shot picture
X button - Start/Stop return home
Y button - switch from drone camere to iPhone camera in VR mode
B button - Head-traking ON/OFF in VR mode
A button - Start / Stop Landing
Autonomous Waypoint Navigation
Ta p t h e i c o n from the main screen of the app or from the piloting screen, to
access the Waypoint Mission Manager
From here you can access to your previous saved waypoint missions, or create a
new one
New mission
tap New Mission, to start to design your waypoint mission, you will enter to a map
view and you are already in “edit mode” to start to draw your mission route.
