Dji RS 3 MINI Manuel utilisateur

v1.0 2023.01

User Manual

Searching for Keywords

Search for keywords such as “battery” and “install” to find a topic. If you are

using Adobe Acrobat Reader to read this document, press Ctrl+F on Windows or

Command+F on Mac to begin a search.

Navigating to a Topic

View a complete list of topics in the table of contents. Click on a topic to navigate to

that section.

Printing this Document

This document supports high resolution printing.

Using this Manual

Legend

Important Hints and Tips

Read Before First Use

Read the following documents before using DJITM RS 3 Mini.

DJI RS 3 Mini Safety Guidelines

DJI RS 3 Mini Quick Start Guide

DJI RS 3 Mini User Manual

It is recommended to watch all the tutorial videos on the official website (https://www.dji.com/

rs-3-mini) or in the DJI Ronin app and read the Safety Guidelines before using for the first time.

Make sure to review the Quick Start Guide before using for the first time and refer to this user

manual for more information.

Download the Ronin App and Watch the Tutorial Videos

Scan the QR code to download the RONINTM app and watch the tutorial videos.

iOS 11.0 or above Android 7.0 or above

https://s.dji.com/guide22

Ronin App

Contents

Using this Manual 1

Legend 1

Read Before First Use 1

Download the Ronin App and Watch the Tutorial Videos 1

Introduction 3

DJI RS 3 Mini Diagram 4

Using for the First Time 5

Charging DJI RS 3 Mini 5

Attaching the Extended Grip/Tripod 5

Unlocking and Locking the Gimbal 6

Mounting the Camera 7

Balancing 11

Activating DJI RS 3 Mini 16

Connecting a Camera 17

Auto Tune 17

Operations 18

Button and Port Functions 18

Touchscreen 19

Ronin App Settings 24

Firmware Update 35

Grip and Built-In Battery 36

Safety Guidelines 36

Operation Modes 39

Maintenance 40

Specifications 40

Introduction

DJI RS 3 Mini is a professional single-handed 3-axis gimbal specifically designed for mirrorless

cameras. It is compatible with a wide range of mainstream cameras and lenses and supports a

tested payload of up to 2 kg (4.4 lbs). DJI RS 3 Mini boasts enhanced gimbal performance thanks

to the 3rd-Gen RS Stabilization Algorithm.

DJI RS 3 Mini weighs 850 g, which makes it lightweight for users to carry on the go. [1] The gimbal

can be switched between horizontal and vertical shooting without additional accessories. With

a 1.4-inch full-color touchscreen, users can calibrate the gimbal and set parameters. Users can

control the gimbal movement, shutter, recording, and camera focus using the onboard buttons.

DJI RS 3 Mini can be paired with mainstream mirrorless cameras via Bluetooth for wireless

camera control. With the NATO port, accessories such as the DJI RS Briefcase Handle can be

used. The grip has a built-in battery with a capacity of 2450 mAh, providing a maximum runtime

of up to 10 hours. [2]

After connecting to the Ronin app, easily control gimbal movement and parameter settings with

intelligent functions such as Panorama, Timelapse, and Track.

[1] The weight in Horizontal Shooting Mode is 850 g (1.8 lbs), and in Portrait Mode is 795 g (1.75 lbs)

with the quick-release plate attached (excluding both the extended Grip/Tripod and arm protector

and screw kit). The actual weight may vary depending on the manufacturing process.

[2] Measured with the equipment in a level and stationary state. The maximum runtime is for

reference only.

DJI RS 3 Mini User Manual

20. RSS Camera Control Port (USB-C)

21. NATO Port

22. Front Dial

23. Trigger

24. Safety Lock

25. Vertical Arm

26. Roll Arm

27. Safety Lock

28. Roll Motor

29. Roll Lock

DJI RS 3 Mini Diagram

1. Upper Quick-Release Plate

2. Lower Quick-Release Plate

3. Horizontal Arm

4. Roll Arm

5. Roll Motor

6. 1.4-inch Full-Color Touchscreen

7. Joystick

8. Camera Control Button

9. Grip (Built-in battery with 1/4"-20

screw hole)

10. Extended Grip/Tripod

11. Tilt Lock

12. Tilt Motor

13. Tilt Arm

14. Pan Motor

15. Pan Lock

16. Pan Arm

17. Power Port (USB-C)

18. Power Button

19. M Button

Attaching the Extended Grip/Tripod

Attach the extended grip/tripod to the gimbal, tighten and unfold the tripod and place the

gimbal on a level surface.

Using for the First Time

Charging DJI RS 3 Mini

Charge DJI RS 3 Mini through the power port (USB-C) using the charging cable (included) and a

USB adapter (not included). It is recommended to use a 5V-2A USB adapter. The battery can be

fully charged in approximately 2.5 hours. [1] Press the power button to check the battery level on

the screen when powered off.

[1] Tested in a 25° C (77° F) environment while using a 10W charger.

5V-2A

DJI RS 3 Mini User Manual

Unlocking and Locking the Gimbal

Each axis of the gimbal is equipped with a lock, which can lock the axes for convenient storage

and installation. The gimbal is packaged in the locked position. Toggle the tilt and roll lock to the

unlocked position. Adjust the gimbal position as shown and toggle the tilt and roll locks in the

locked position before mounting the camera.

•The tilt and roll axis of DJI RS 3 Mini have different locked positions, which can be

locked and stored according to the actual situation.

DJI RS 3 Mini User Manual

Mounting the Camera

Supported Cameras and Lenses

DJI RS 3 Mini has been rigorously tested to support a payload of 2 kg (4.4 lbs). Make sure the

combined weight of the camera, lens, and other accessories are within 2 kg (4.4 lbs). Refer

to the official DJI website (https://www.dji.com/support/compatibility) for the most updated

Ronin Series Compatibility List.

Mounting a Camera

Make sure to prepare the camera before mounting it to DJI RS 3 Mini. Remove the lens cap and

check that the battery and memory card are inserted in the camera.

1. Attach the Upper Quick-Release Plate

Attach the upper quick-release plate to the camera by tightening the screw. Note: use the

curved placement guide to secure the camera on the upper quick-release plate firmly.

•If the curved placement guide of the upper quick-release plate cannot be used to

firmly secure the camera, change the direction of the upper quick-release plate and

then install it.

2. Attach the Camera to the Gimbal

DJI RS 3 Mini supports horizontal shooting and vertical shooting. Follow the steps to install

the camera in horizontal and vertical shooting modes.

DJI RS 3 Mini User Manual

Horizontal Shooting

1. Loosen the lever ①on the lower quick-release plate.

2. Insert the upper quick-release plate with the camera attached into the lower quick-release

plate ②, as shown below.

3. Adjust the lower quick-release plate to an appropriate position according to the width of the

camera, and then tighten the lever ③.

•The position of the lower quick-release plate on the horizontal arm can be adjusted

according to the width of the camera. Loosen the red lever on the lower quick-release

plate and then move the lower quick-release plate.

•To remove the upper quick-release plate, loosen the gray lever on the lower quick-

release plate and press and hold the safety lock beside the lever.
