Dji OSMO MOBILE 6 Manuel utilisateur

User Manual 2022.09v1.0

Using this Manual

Legend

Important Hints and Tips

Before Use

Read the following documents before using DJITM OSMOTM Mobile 6:

1. Safety Guidelines

2. Quick Start Guide

3. User Manual

It is recommend to watch all tutorial videos on the official DJI website (www.dji.com/

osmo-mobile-6/video) or in the DJI Mimo app. Read the safety guidelines and quick start

guide before using for the first time. Refer to this user manual for more information.

Downloading the DJI Mimo App

Scan the QR code above to download the latest version of DJI Mimo app.

The iOS version of DJI Mimo is compatible with iOS v12.0 and later. The Android version

of DJI Mimo is compatible with Android v8.0 and later.

DJI Mimo App

https://s.dji.com/guide38

Searching for Keywords

Search for keywords such as “battery” and “install” to find a topic. If you are

using Adobe Acrobat Reader to read this document, press Ctrl+F on Windows or

Command+F on Mac to begin a search.

Navigating to a Topic

View a complete list of topics in the table of contents. Click on a topic to navigate to

that section.

Printing this Document

This document supports high resolution printing.

Contents

Using this Manual 2

Legend 2

Before Use 2

Downloading the DJI Mimo App 2

Introduction 4

Overview 4

Getting Started 5

Charging 5

Attaching the Phone 5

Using Osmo Mobile 6 8

On-board Features 8

Operating Mode 11

DJI Mimo App 12

Connecting to the DJI Mimo App 13

Camera View 13

Firmware Update 17

How to Update 17

Storage 17

Specifications 18

Introduction

Boasting 3-axis stabilization and a built-in extension rod, the lightweight Osmo Mobile 6

unlocks the full potential of your mobile phone. The foldable magnetic design makes

setup easier than ever, transportation and storage more convenient, and it can power

on automatically once unfolded. Osmo Mobile 6 can be operated in both portrait and

landscape, while the upright, underslung, side grip, and low position modes help capture

the perfect shot. Take content to the next level through DJI Mimo with ActiveTrackTM 5.0,

DynamicZoom, and Pano. The Story mode, Timelapse, and ShotGuides provide step-by-step

tutorials according to the scenario and help generate a video that can be shared on social

media.

Overview

1. Magnetic Phone Clamp 3

2. Magnetic Alignment

3. Pan Motor

4. Status Panel

5. Side Wheel

6. Joystick

7. 1/4"-20 UNC Port

8. Switch Button

9. Shutter/Record Button

10. Power/M Button

11. Tilt Motor

12. Roll Motor

13. M3×0.5 Screw Hole

14. Charging Port (USB-C)

15. Trigger

Osmo Mobile 6 is compatible with DJI OM Fill Light Phone Clamp and DJI Mic, which can

be purchased in the DJI Store.

Getting Started

Charging

To charge Osmo Mobile 6, connect a USB adapter (not included) to the charging port

using the power cable. The battery is fully charged when the battery level indicator turns

off on the status panel.

Charging time: approx. 1 hour 24 minutes (tested in the environment temperature of 25° C

when using a 10 W charger)

Max runtime: approx. 6 hours and 24 minutes (tested with the gimbal balanced and held

steadily. This value should be taken as a reference only)

Attaching the Phone

1. Unfold the gimbal as shown. Osmo Mobile 6 will power on automatically once unfolded.

Osmo Mobile 6 User Manual

2. Attach the magnetic phone clamp in the center of the phone. The magnetic phone

clamp can be stretched to adapt to the mobile phone width. The camera mark should

point towards the camera of the phone.

3. Align the marks on the phone clamp and the phone clamp mounting plate. Attach the

mobile phone to Osmo Mobile 6. Osmo Mobile 6 will stabilize once the gimbal mode

indicator lights up on the status panel.

The status indicator on the status panel will pulse red if the magnets are not aligned.

Adjust the position of the magnetic clamp in that case.

The anti-slip pads help to secure the mobile phone and the magnetic phone clamp. Attach

the anti-slip pad to the magnetic phone clamp as shown in the figure below and press

down firmly.

Magnetic Phone Clamp Tips

Make sure the direction of the magnet phone clamp is the same as shown in the figure above.

For optimal performance, make sure the magnetic phone clamp is in the middle of the mobile

phone, and the distance between the clamp arms is the same.

Osmo Mobile 6 User Manual

4. The built-in extension rod can be extended to up to 215 mm and the angle can be

adjusted from 0 to 90°.

M Button

When powered off

With the gimbal folded, press once or press and hold: check the

battery level

With the gimbal unfolded, press once: power on

When powered on

Press once: switch between gimbal modes

Press three times: enter standby mode (press any button to exit)

Press and hold: power off. Press and hold for 20 seconds to force

power off

Using Osmo Mobile 6

On-board Features

Status Panel

Displays the System Status Indicator, Battery Level Indicator, and Gimbal Mode.

System Status Indicator Descriptions

Blinking Pattern Descriptions

Pulses red Magnetic is not aligned

Solid yellow Bluetooth disconnected

Solid green Bluetooth connected

Pulses yellow or green Standby mode

Blinks red and green alternately Firmware updating/firmware update failed

Solid red Abnormal status detected

Battery Level Indicator Descriptions

Blinking Pattern Battery Level

Blinks red quickly ≤5%

Solid red 6%-19%

Solid yellow 20%-60%

Solid green >60%

Gimbal Mode

Follow: pan and tilt axes follow, where both the pan and tilt axes follow the movement

of the grip. Suitable for scenarios when moving up and down or on a slant.

Tilt Locked: only the pan axis follows, where only the pan axis follows the movement

of the grip. Suitable for scenarios such as arc shots or moving from left to right.

FPV: pan, tilt, and roll axes follow, where all three axes follow the movement of the

grip. Suitable for shooting the first-person view.

SpinShot: pan, tilt, and roll axes follow. The joystick can be used to control the roll axis

rotation. SpinShot enables footage to be shot while rotating the camera 360°. This is

suitable for shooting push, pull, and down.

Osmo Mobile 6 User Manual

Side Wheel

Press once: switch between focus and zoom

Rotate: control focus or zoom

Joystick

Move vertically and horizontally to tilt and pan the mobile phone.

The joystick control direction can be set in DJI Mimo. Use the

joystick to navigate through settings on the Quick Settings page.

Shutter/Record Button

Press once: take a photo or start or stop recording.

Press and hold: for burst shooting when in photo mode.

Switch Button

Press once: switch between front and rear cameras.

Press twice: switch between landscape and portrait mode.

Press three times: switch between photo and record mode. The

feature can be set to control Quick Settings in DJI Mimo.

Trigger

Press once to start or stop ActiveTrack 5.0 (requires used with

Mimo).

Press twice to recenter the gimbal. When using ActiveTrack 5.0,

the gimbal will recenter to the center of the camera view.

Press once, and then press and hold to adjust the follow speed

to fast mode, release to exit.

Press and hold to enter lock mode. In lock mode, the gimbal will

not follow the handle movements. Release to exit lock mode.

Charging Port (USB-C)

Charge Osmo Mobile 6 by connecting a USB adapter to this port.

1/4"-20 UNC Port

The 1/4"-20 UNC port can be used to attach a tripod.

Osmo Mobile 6 User Manual

M3×0.5 Screw Hole

Used to mount counterweights. Counterweights should be used

if a camera lens or microphone is mounted on the mobile phone.

Make sure the total weight of these accessories is less than 290 g.

Combination Operation

Press the switch button, shutter/record button, and trigger simultaneously for more than

one second to reset the Bluetooth name and connection and reconnect.

Osmo Mobile 6 will be powered off automatically if there is no operation for three

minutes in standby mode.
