Directed Electronics Failsafe 103T Manuel utilisateur

Model 103T

Owner's Guide

Limited Lifetime

Consumer Warranty

For a period of one calendar year from the date of purchase of this auto-security

device, Directed Electronics, Inc. promises to the ORIGINAL PURCHASER to repair or

replace (with a comparable reconditioned model), free of cost, any electronic control

module which proves to be defective in workmanship or material under normal use,

SO LONG AS THE SYSTEM WAS SOLD, INSTALLED, AND SERVICED BY A PROFESSIONAL

AUTO INSTALLER, AND REMAINS IN THE CAR IN WHICH THE SYSTEM WAS ORIGINALLY

INSTALLED. If warranty service is necessary you must have a clear copy of your sales

receipt containing all of the information shown on the following page.

After the first calendar year, from the date of purchase of this auto-security device,

Directed Electronics, Inc., promises to the ORIGINAL PURCHASER to repair or replace

(with a comparable reconditioned model) any electronic control module which proves

to be defective in workmanship or material under normal use FOR A CHARGE OF

$45.00, SO LONG AS THE SYSTEM WAS SOLD, INSTALLED, AND SERVICED BY A PRO-

FESSIONAL AUTO INSTALLER, AND REMAINS IN THE CAR IN WHICH THE SYSTEM WAS

ORIGINALLY INSTALLED. If warranty service is necessary you must have a clear copy

of your sales receipt containing all of the information shown on the following page.

This warranty contains the entire agreement relating to warranty and supersedes all

previous and contemporaneous representations or understandings, whether written or

oral. IN ANY EVENT, DEI IS NOT LIABLE FOR THE THEFT OF THE VEHICLE AND/OR ITS

CONTENTS.

This warranty is void if the product has been damaged by accident, unreasonable use,

neglect, improper service or other causes not arising out of defects in materials or

construction. This warranty is nontransferable and does not apply to any unit that

has been modified or used in a manner contrary to its intended purpose and does not

cover batteries. The unit in question must be returned to the manufacturer, postage

prepaid. This warranty does not cover labor costs for the removal, diagnosis, trou-

bleshooting or reinstallation of the unit. For service on an out-of-warranty product a

flat rate fee by model is charged. Contact your authorized dealer to obtain the ser-

vice charge for your unit.

These systems are a deterrent against possible theft. Directed Electronics, Inc. is not

offering a guarantee or insuring against the theft of the automobile or its contents

and disclaims any liability for the theft of the vehicle and/or its contents. Directed

Electronics does not authorize any person to create for it any other obligation or lia-

bility in connection with this security system.

TO THE MAXIMUM EXTENT ALLOWED BY LAW, ANY AND ALL WARRANTIES ARE EXCLUD-

ED BY THE MANUFACTURER AND EACH ENTITY PARTICIPATING IN THE STREAM OF COM-

MERCE THEREWITH. THIS EXCLUSION INCLUDES BUT IS NOT LIMITED TO THE EXCLU-

SION OF ANY AND ALL WARRANTY OF MERCHANTABILITY AND/OR ANY AND ALL WAR-

RANTY OF FITNESS FOR A PARTICULAR PURPOSE AND/OR ANY AND ALL WARRANTY OF

NON-INFRINGEMENT OF PATENTS, IN THE UNITED STATES OF AMERICA AND/OR

ABROAD. NEITHER THE MANUFACTURER OR ANY ENTITIES CONNECTED THEREWITH

SHALL BE RESPONSIBLE OR LIABLE FOR ANY DAMAGES WHATSOEVER, INCLUDING BUT

NOT LIMITED TO ANY CONSEQUENTIAL DAMAGES, INCIDENTAL DAMAGES, TOWING,

REPAIR, REPLACEMENT, DAMAGES FOR LOSS OF TIME, LOSS OF EARNINGS, COMMERCIAL

LOSS, LOSS OF ECONOMIC OPPORTUNITY AND THE LIKE. NOTWITHSTANDING THE

ABOVE, MANUFACTURER DOES OFFER A LIMITED WARRANTY TO REPLACE OR REPAIR

THE CONTROL MODULE AS DESCRIBED ABOVE. Some states do not allow limitations on

how long an implied warranty will last or the exclusion or limitation of incidental or

consequential damages. This warranty gives you specific legal rights, and you may

also have other rights which vary from state to state.

IMPORTANT NOTE:

This product warranty is automatically void if its date code or serial number is

defaced, missing, or altered. This warranty will not be valid unless you have com-

pleted the warranty card and mailed it to Directed Electronics, Inc. within 10 days

after purchase to the address listed on the warranty registration card.

Make sure you have all of the following information from your dealer:

A clear copy of the sales receipt, showing the following:

■Date of purchase

■Your full name and address

■Authorized dealer's company name and address

■Type of system installed

■Year, make, model and color of the automobile

■Automobile license number

■Vehicle identification number

■All security options installed on automobile

■Installation receipts

Table of Contents

Limited Lifetime Consumer Warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . i

What Is Included. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2

Important Information. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3

Product Description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3

System Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4

Keypad Illumination . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4

PIN Code Security . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4

Operation as a Stand-Alone Starter Kill . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

Arming . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

Disarming. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6

Trigger Sequence (optional) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6

Panic Mode (optional). . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7

Valet Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7

Operation as an ESP Interface . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8

Disarming the ESP System . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8

Panic Mode. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

Valet Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

Arming With Entry Delay . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10

Glossary of Terms . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10

Quick Reference Guide (Removable). . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11

What Is Included

■103T Control Module

■103T Keypad (see diagram below) with 4-Pin Keypad Harness

■8618 Failsafe Starter Kill Relay

■5-Pin Main Harness

■2-Pin LED Interface Harness

■3-Pin Data Interface Harness

Important Information

The 103T Digital Failsafe Starter Kill is designed to be used as

either a stand-alone passive/active starter kill or as an interface to

DEI’s ESP systems that use 3-pin data ports. The 103T features an

illuminated dash-mounted keypad, code-protected emergency

override, and Valet® code protection.

When used as a stand-alone starter kill, the 103T prevents the

starter from cranking whenever the system is armed. You can con-

trol the 103T’s basic functions from the dash-mounted keypad.

Simply enter coded key sequences to control the starter kill func-

tions.

The 103T can also be used as a serial controller for any of DEI’s ESP

systems. The ESP system LED can be plugged into the 103T’s key-

pad port, so that the LED on the keypad functions as the main sys-

tem LED. When connected to an ESP system, the 103T can be used

to control such features as Panic, Valet Mode and emergency over-

ride.

Product Description

System Features

Pressing any button will illuminate the keypad. The illumination

will time out 5 seconds after the last key is pressed.

A personalized PIN code must be established to operate the

various functions of the 103T. A PIN code can range from 1 to 10

digits. Any digit may be repeated. The default PIN code from the

factory is 1234.

To program a new, personalized PIN code:

1. Make sure the system is disarmed or in Valet Mode.

2. Turn on the ignition.

3. Enter the existing PIN code and the press . The LED will

flash once. EXAMPLE: To enter the factory default PIN code of

1234:

■Press for 1.

■Press for 2.

■Press for 3.

■Press for 4.

■Press to enter the code.

PIN Code Security

Keypad Illumination

4. Within 5 seconds, enter the new PIN code followed .

The LED will flash twice.

5. Within 5 seconds, enter the new PIN code again followed by

. The LED will light solidly for 1 second.

The new PIN code has been programmed. The programming mode is

exited if the ignition is turned off or if there is no activity for more

than 5 seconds. If the PIN code programming mode is exited before

a new PIN code is set, the unit will default to the existing PIN code.

Operation as a

Stand-Alone Starter Kill

When armed, the 103T will interrupt the starter wire when any

attempt is made to start the vehicle. The 103T can be passively or

actively armed. Passive arming occurs automatically 15 seconds

after the ignition is turned off.

To actively arm the unit:

1. Press .

2. Press (labeled ARM on the keypad). The system will

arm immediately.

The LED will flash steadily to indicate that the system is armed.

Arming

The system may be disarmed whether the ignition is on or off.

To disarm the system:

1. Enter your personalized PIN code followed by . The key-

pad is now disarmed.

■If the ignition is off, the unit will disarm, but the LED will

flash rapidly to indicate that the system will rearm in 15 seconds.

■If the ignition is on, the system will disarm and the LED will

turn off.

■If an error is made while entering the PIN code, simply press

to start over. If the PIN code is entered incorrectly

three times, the trigger sequence will begin.

■If the ignition is turned on before entering the PIN code, the

unit will honk the horn once (if connected). If the correct PIN

code is not entered within 5 seconds, the trigger sequence

will begin.

When disarming, if the correct PIN code is not entered in three

attempts or within 5 seconds after the ignition is turned on, the

unit will honk the horn (if connected) for 30 seconds. If the igni-

tion remains on, the unit will trigger again, up to four times. If the

unit has triggered four times, it will reset and trigger again if the

ignition is cycled. The unit will also trigger each time three errors

in PIN entry occur.

NOTE: When using the 103T as a stand-alone starter kill, the optional horn

honk feature must be installed in order for the trigger sequence to work.

Trigger Sequence (optional)

Disarming

If you are threatened in your vehicle, you can enter Panic Mode to

attract attention. Panic Mode will trigger the system and honk the

horn (if connected) for 30 seconds. The starter kill and state of the

system (armed or disarmed) are not affected by the Panic Mode

trigger sequence.

To enter Panic Mode:

1. Press .

2. Press (labeled PANIC on the keypad).

The same Panic Mode keypad sequence may be used to stop Panic

Mode at any time.

NOTE: When using the 103T as a stand-alone starter kill, the optional

horn honk feature must be installed in order for Panic Mode to work.

Valet®Mode prevents the system from arming and triggering. This

feature is useful when washing or servicing your vehicle.

To activate Valet Mode:

1. Make sure that the system is disarmed.

2. Press .

3. Press (labeled VALET on the keypad). The system has

now entered Valet Mode.

The same Valet Mode keypad sequence is used to deactivate Valet Mode.

NOTE: If an incorrect sequence of buttons is pressed while attempting to

exit Valet Mode, the system will ignore any new attempts to exit Valet

Mode for 5 seconds.

Valet Mode

Panic Mode (optional)

Table des matières

Autres manuels Directed Electronics Démarreur à distance

Directed Electronics

Directed Electronics 410 Manuel utilisateur

Directed Electronics

Directed Electronics CLIFFORD 1.3X Manuel utilisateur

Directed Electronics

Directed Electronics 3000 Manuel utilisateur

Directed Electronics

Directed Electronics SmartStart 5000-series Manuel utilisateur

Directed Electronics

Directed Electronics AutoCommand 40026 Manuel utilisateur

Directed Electronics

Directed Electronics 4103 Series Manuel utilisateur

Directed Electronics

Directed Electronics AutoCommand 40027 Manuel utilisateur

Directed Electronics

Directed Electronics CLIFFORD 1.3X Manuel utilisateur

Directed Electronics

Directed Electronics Python 1601 Manuel utilisateur

Directed Electronics

Directed Electronics AVITAL 4003 Manuel utilisateur

Directed Electronics

Directed Electronics Rattler 259D Manuel utilisateur

Directed Electronics

Directed Electronics SmartStart 5000-series Manuel utilisateur

Directed Electronics

Directed Electronics PS-4661TWE-FM Manuel utilisateur

Directed Electronics

Directed Electronics READY REMOTE 24926 Guide de démarrage rapide

Directed Electronics

Directed Electronics 553 Manuel utilisateur

Directed Electronics

Directed Electronics Avital G3000 7/01 Manuel utilisateur

Directed Electronics

Directed Electronics PS-4661TWE-FM Manuel utilisateur

Directed Electronics

Directed Electronics AutoCommand 41026 Guide de démarrage rapide

Directed Electronics

Directed Electronics READY REMOTE 24927 Guide de démarrage rapide

Directed Electronics

Directed Electronics Viper 5501 Manuel utilisateur

Directed Electronics

Directed Electronics G4311A-AM15 AM15 Manuel utilisateur

Directed Electronics

Directed Electronics Xpresskit Xpressparts Series Manuel utilisateur

Directed Electronics

Directed Electronics 210HV Manuel utilisateur

Directed Electronics

Directed Electronics Ready Remote 23927 Manuel utilisateur

Manuels Démarreur à distance populaires d'autres marques

AstroStart

AstroStart 803U Manuel utilisateur

Durite

Durite 0-649-20 Manuel

EINHELL

EINHELL BT-PS 1000 Manuel

Linear

Linear ACCESS AK-21 Caractéristiques techniques

Soundstream

Soundstream TARANTULA RS.2 Manuel utilisateur

Jaycar Electronics

Jaycar Electronics MB3752 Manuel utilisateur

Ultra Start

Ultra Start 72 Series Manuel utilisateur

ADS

ADS FLASHLOGIC FLRSVW1 Manuel utilisateur

Selecta

Selecta JS012 Manuel utilisateur

Black Widow Security

Black Widow Security BW RAS 400 Manuel utilisateur

Vector

Vector Power City DK080706 Supplément

Code Alarm

Code Alarm CA-535 Manuel utilisateur

Ozito

Ozito OJS-800 Manuel utilisateur

Profi-Partner

Profi-Partner 46387 Manuel utilisateur

EZ STARTER

EZ STARTER EZ-45 Manuel utilisateur

Viper

Viper 4204 Manuel utilisateur

Essex Electronics

Essex Electronics KE-1701 Manuel utilisateur

EINHELL

EINHELL EGS 3600 Manuel
