Directed Electronics 560T Manuel utilisateur

556600TT

➤

OOwwnneerr’’ssGGuuiiddee

lliimmiitteeddlliiffeettiimmeeccoonnssuummeerrwwaarrrraannttyy

For a period of one calendar year from the date of purchase of this auto-security device,

Directed Electronics, Inc. promises to the ORIGINAL PURCHASER to repair or replace

(with a comparable reconditioned model), free of cost, any electronic control module

which proves to be defective in workmanship or material under normal use, SO LONG

AS THE SYSTEM WAS SOLD, INSTALLED, AND SERVICED BY A PROFES-

SIONAL AUTO INSTALLER, AND REMAINS IN THE CAR IN WHICH THE SYS-

TEM WAS ORIGINALLY INSTALLED. If warranty service is necessary you must have

a clear copy of your sales receipt containing all of the information shown on the follow-

ing page.

After the first calendar year, from the date of purchase of this auto-security device,

Directed Electronics, Inc., promises to the ORIGINAL PURCHASER to repair or replace

(with a comparable reconditioned model) any electronic control module which proves to

be defective in workmanship or material under normal use FFOORRAACCHHAARRGGEEOOFF$$4455..0000,,

SO LONG AS THE SYSTEM WAS SOLD, INSTALLED, AND SERVICED BY A

PROFESSIONAL AUTO INSTALLER, AND REMAINS IN THE CAR IN WHICH

THE SYSTEM WAS ORIGINALLY INSTALLED. If warranty service is necessary you

must have a clear copy of your sales receipt containing all of the information shown on

the following page.

This warranty contains the entire agreement relating to warranty and supersedes all pre-

vious and contemporaneous representations or understandings, whether written or oral.

IN ANY EVENT, DIRECTED ELECTRONICS IS NOT LIABLE FOR THE THEFT

OF THE VEHICLE AND/OR ITS CONTENTS.

This warranty is void if the product has been damaged by accident, unreasonable use,

neglect, improper service or other causes not arising out of defects in materials or con-

struction. This warranty is nontransferable and does not apply to any unit that has been

modified or used in a manner contrary to its intended purpose and does not cover bat-

teries. The unit in question must be returned to the manufacturer, postage prepaid. This

warranty does not cover labor costs for the removal, diagnosis, troubleshooting or rein-

stallation of the unit. For service on an out-of-warranty product a flat rate fee by model is

charged. Contact your authorized dealer to obtain the service charge for your unit.

These systems are a deterrent against possible theft. Directed Electronics, Inc. is not offer-

ing a guarantee or insuring against the theft of the automobile or its contents and dis-

claims any liability for the theft of the vehicle and/or its contents. Directed Electronics

does not authorize any person to create for it any other obligation or liability in connec-

tion with this security system.

TO THE MAXIMUM EXTENT ALLOWED BY LAW, ANY AND ALL WAR-

RANTIES ARE EXCLUDED BY THE MANUFACTURER AND EACH ENTITY

PARTICIPATING IN THE STREAM OF COMMERCE THEREWITH. THIS

EXCLUSION INCLUDES BUT IS NOT LIMITED TO THE EXCLUSION OF ANY

AND ALL WARRANTY OF MERCHANTABILITY AND/OR ANY AND ALL WAR-

RANTY OF FITNESS FOR A PARTICULAR PURPOSE AND/OR ANY AND ALL

WARRANTY OF NON-INFRINGEMENT OF PATENTS, IN THE UNITED

STATES OF AMERICA AND/OR ABROAD. NEITHER THE MANUFACTURER

OR ANY ENTITIES CONNECTED THEREWITH SHALL BE RESPONSIBLE OR

LIABLE FOR ANY DAMAGES WHATSOEVER, INCLUDING BUT NOT LIMIT-

ED TO ANY CONSEQUENTIAL DAMAGES, INCIDENTAL DAMAGES, TOW-

ING, REPAIR, REPLACEMENT, DAMAGES FOR LOSS OF TIME, LOSS OF

EARNINGS, COMMERCIAL LOSS, LOSS OF ECONOMIC OPPORTUNITY

AND THE LIKE. NOTWITHSTANDING THE ABOVE, MANUFACTURER

DOES OFFER A LIMITED WARRANTY TO REPLACE OR REPAIR THE CON-

TROL MODULE AS DESCRIBED ABOVE. Some states do not allow limitations on

how long an implied warranty will last or the exclusion or limitation of incidental or con-

sequential damages. This warranty gives you specific legal rights, and you may also have

other rights which vary from state to state.

IIMMPPOORRTTAANNTTNNOOTTEE::

This product warranty is automatically void if its date code or serial number is defaced,

missing, or altered. This warranty will not be valid unless you have completed the war-

ranty card and mailed it to Directed Electronics, Inc. within 10 days after purchase to the

address listed on the warranty registration card.

Make sure you have all of the following information from your dealer:

A clear copy of the sales receipt, showing the following:

➤Date of purchase

➤Your full name and address

➤Authorized dealer's company name and address

➤Type of system installed

➤Year, make, model and color of the automobile

➤Automobile license number

➤Vehicle identification number

➤All security options installed on automobile

➤Installation receipts

ttaabblleeooffccoonntteennttss

lliimmiitteeddlliiffeettiimmeeccoonnssuummeerrwwaarrrraannttyy................................................................................ii

wwhhaattiissiinncclluuddeedd.....................................................................

.......................................22

iimmppoorrttaannttiinnffoorrmmaattiioonn......................................

............................................................22

system maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2

your warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3

fcc/id notice . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3

wwaarrnniinngg!!ssaaffeettyyffiirrsstt...............

.......................................................................................33

ttrraannssmmiitttteer

rffuunnccttiioonnss..........................................................................................

..........66

uussiinnggyyoouurrssyysstteemm.......................................................................

.................................77

remote start . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7

timer mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8

ppiittssttooppmmooddee..................................................

............................................................1100

lleeaarrnniinnggttrraannssmmiitttteerr.................

...................................................................................1111

ccooddeehhooppppiinngg®®rree--ssyynncchhrroonniizzee....................................................................................1122

glloossssaarryyoofftteerrmmss....................................................................................

....................1122

qquuiicckkrreeffeerreenncceegguuiiddee::.......................................................

.........................................1133

wwhhaattiissiinncclluuddeedd

➤Control Module

➤One 2-Button Transmitter

➤8-Pin Main H/1 Harness

➤6-Relay Wires

➤Shutdown Toggle Switch

➤Hood Pin Switch

iimmppoorrttaannttiinnffoorrmmaattiioonn

Congratulations on the purchase of your remote start system.

This system has been designed to provide years of trouble-free

operation. By carefully reading this owner's guide prior to using

your system, you will maximize the use of this system and its

features. Additional or replacement copies of this guide can be

printed by accessing the Directed Electronics internet website at

www.directed.com.

system maintenance

The system requires no specific maintenance. Your transmitter is

approximately one year under normal use. When the battery

begins to weaken, the operating range will be reduced.

➜

your warranty

Your warranty registration must be completely filled out and

returned within 10 days of purchase. Your product warranty

will not be validated if your warranty registration is not returned.

Please note that it is necessary to keep your proof of purchase.

fcc/id notice

This device complies with Part 15 of FCC rules. Operation is

subject to the following conditions: (1) This device may not

cause harmful interference, and (2) This device must accept any

interference received, including interference that may cause

undesirable operation.

Changes or modifications not expressly approved by the party

responsible for compliance could void the user's authority to

operate this device.

wwaarrnniinngg!!ssaaffeettyyffiirrsstt

The following safety warnings must be observed at all times:

➤When properly installed, this system can start the vehicle via

a command signal from the remote control transmitter.

Therefore, never operate the system in an area that does not

have adequate ventilation. The following precautions are the

sole responsibility of the user; however, the following recom-

mendations should be made to all users of this system:

➜

1. Never operate the system in an enclosed or partially

enclosed area without ventilation (such as a garage).

2. When parking in an enclosed or partially enclosed area

or when having the vehicle serviced, the remote start

system must be disabled using the toggle switch.

3. It is the user's sole responsibility to properly handle and

keep out of reach from children all remote control

transmitters to assure that the system does not uninten-

tionally remote start the vehicle.

4. TTHHEEUUSSEERRMMUUSSTTIINNSSTTAALLLLAACCAARRBBOONN

MMOONNOOXXIIDDEEDDEETTEECCTTOORRIINNOORRAABBOOUUTTTTHHEE

LLIIVVIINNGGAARREEAAAADDJJAACCEENNTTTTOOTTHHEE

VVEEHHIICCLLEE..

AALLLLDDOOOORRSSLLEEAADDIINNGGFFRROOMMAADDJJAACCEENNTT

LLIIVVIINNGGAARREEAASSTTOOTTHHEEEENNCCLLOOSSEEDDOORR

PPAARRTTIIAALLLLYYEENNCCLLOOSSEEDDVVEEHHIICCLLEE

SSTTOORRAAGGEE

AARREEAAMMUUSSTTAATTAALLLLTTIIMMEESSRREEMMAAIINNCCLLOOSSEEDD..

➤Use of this product in a manner contrary to its intended

mode of operation may result in property damage, personal

injury, or death. Except when performing the Safety Check

outlined in this user’s guide, (1) Never remotely start the

vehicle with the vehicle in gear, and (2) Never remotely start

the vehicle with the keys in the ignition. The user will be

responsible for having the neutral safety feature of the vehicle

periodically checked, wherein the vehicle must not remotely

start while the car is in gear. This testing should be performed

by an authorized Directed dealer in accordance with the

Safety Check outlined in this product installation guide. If

the vehicle starts in gear, cease remote start operation imme-

diately and consult with the Dealer to fix the problem imme-

diately.

➤After the remote start module has been installed, test the

remote start module in accordance with the Safety Check

outlined in this installation guide. If the vehicle starts when

performing the Neutral Safety Shutdown Circuit test, the

remote start unit has not been properly installed. The remote

start module must be removed or properly reinstalled so that

the vehicle does not start in gear. OOPPEERRAATTIIOONNOOFFTTHHEE

RREEMMOOTTEESSTTAARRTTMMOODDUULLEEIIFFTTHHEEVVEEHHIICCLLEE

SSTTAARRTTSSIINNGGEEAARRIISSCCOONNTTRRAARRYYTTOOIITTSSIINNTTEENNDDEEDD

MMOODDE

EOOFFOOPPEERRAATTIIOONN..OOPPEERRAATTIINNGGTTHHEE

RREEMMOOTTEESSTTAARRTTSSYYSSTTEEMMUUNNDDEERRTTHHEESSEECCOONNDDII--

TTIIOONNSSMMAAYYRREESSUULLTTIINNPPRROOPPEERRTTYYDDAAM

MAAGGEEOORR

PPEERRSSOONNAALLIINNJJUURRYY..IIMMMMEEDDIIAATTEELLYYCCEEAASSEETTHHEE

UUSSEEOOFFTTHHEEUUNNIITTAANNDDRREEPPAAIIRROORRDDIISSCCOONNNNEECCTT

TTHHEEIINNSSTTAALLLLEED

DRREEMMOOTTEESSTTAARRTTMMOODDUULLEE..

DDIIRREECCTTEEDDWWIILLLLNNOOTTBBEEHHEELLDDRREESSPPOONNSSIIBBLLEEOORR

PPAAYYFFOORRIINNSSTTAALLLLAATTIIOONNOORRRREEIINNSSTTAALLLLAATTIIOON

CCOOSSTTSS..

ttrraannssmmiitttteerrffuunnccttiioonnss

The receiver uses a computer-based learn routine to learn the

transmitter buttons.

Button

Press the button once to remote start the vehicle.

Button

Press the button once to remote stop the vehicle.

Buttons

and

These buttons when pressed simultaneously, engage timer mode.

The timer starts the engine every 3 hours (12-minute run time).

Button

Press the button once for Pit Stop mode (with engine

running).

Timer/Prog

Mode

LED

Stop

Start

and

Pit Stop

uussiinnggyyoouurrssyysstteemm

remote start

Press the button to remotely start your vehicle. This feature

makes it possible to warm up the engine, as well as adjust the

interior temperature of the vehicle with the climate control

system. If interior heating or cooling is desired, the climate

controls must be preset, and the fan blower must be set to the

desired level prior to remote starting the vehicle.

WWhheennyyoouuaarreerreeaaddyyttooddrriivveetthheevveehhiiccllee::

1. Insert the ignition key and turn it to the

ON (not the START) position.

2. Press the brake pedal.

While the vehicle is running during remote start operation, the

system will monitor the vehicle and will automatically shut down

the engine if the system receives any of the following shut-down

inputs:

nnoottee::If the brake pedal is pressed

before the key is in the ON posi-

tion, the engine will shut down.

nnoottee::(1) Never remotely start the vehicle with the vehi-

cle in gear, and (2) Never remotely start the vehicle with the

key in the ignition.

➜

Autres manuels pour 560T

Table des matières

Autres manuels Directed Electronics Démarreur à distance

Directed Electronics

Directed Electronics AutoCommand 25523T Manuel utilisateur

Directed Electronics

Directed Electronics Python G4203P Manuel utilisateur

Directed Electronics

Directed Electronics AutoCommand 41027T Guide de démarrage rapide

Directed Electronics

Directed Electronics Failsafe 103T Manuel utilisateur

Directed Electronics

Directed Electronics Python 1401 Manuel utilisateur

Directed Electronics

Directed Electronics Valet 562T Manuel utilisateur

Directed Electronics

Directed Electronics Viper Manuel utilisateur

Directed Electronics

Directed Electronics 440HP Manuel utilisateur

Directed Electronics

Directed Electronics VSM200 Manuel utilisateur

Directed Electronics

Directed Electronics Ready Remote 23926 Manuel utilisateur

Directed Electronics

Directed Electronics READY REMOTE 24926 Guide de démarrage rapide

Directed Electronics

Directed Electronics AutoCommand 41026 Guide de démarrage rapide

Directed Electronics

Directed Electronics PS-4661TWE-FM Manuel utilisateur

Directed Electronics

Directed Electronics PS-4461TWE-FM Manuel utilisateur

Directed Electronics

Directed Electronics Avital G3000 7/01 Manuel utilisateur

Directed Electronics

Directed Electronics SMARTSTART VSM200 Manuel utilisateur

Directed Electronics

Directed Electronics SmartStart 5000-series Manuel utilisateur

Directed Electronics

Directed Electronics CLIFFORD 1.3X Manuel utilisateur

Directed Electronics

Directed Electronics 7111A Manuel utilisateur

Directed Electronics

Directed Electronics 991 Manuel utilisateur

Directed Electronics

Directed Electronics ONE-WAY FM AUTOMATIC/MANUAL TRANSMISSION Manuel utilisateur

Directed Electronics

Directed Electronics PYTHON 413 Manuel utilisateur

Directed Electronics

Directed Electronics AutoCommand 28624T Manuel utilisateur

Directed Electronics

Directed Electronics ProSecurity RK20 Manuel utilisateur

Manuels Démarreur à distance populaires d'autres marques

AstroStart

AstroStart 803U Manuel utilisateur

Durite

Durite 0-649-20 Manuel

EINHELL

EINHELL BT-PS 1000 Manuel

Linear

Linear ACCESS AK-21 Caractéristiques techniques

Soundstream

Soundstream TARANTULA RS.2 Manuel utilisateur

Jaycar Electronics

Jaycar Electronics MB3752 Manuel utilisateur

Ultra Start

Ultra Start 72 Series Manuel utilisateur

ADS

ADS FLASHLOGIC FLRSVW1 Manuel utilisateur

Selecta

Selecta JS012 Manuel utilisateur

Black Widow Security

Black Widow Security BW RAS 400 Manuel utilisateur

Vector

Vector Power City DK080706 Supplément

Code Alarm

Code Alarm CA-535 Manuel utilisateur

Ozito

Ozito OJS-800 Manuel utilisateur

Profi-Partner

Profi-Partner 46387 Manuel utilisateur

EZ STARTER

EZ STARTER EZ-45 Manuel utilisateur

Viper

Viper 4204 Manuel utilisateur

Essex Electronics

Essex Electronics KE-1701 Manuel utilisateur

EINHELL

EINHELL EGS 3600 Manuel
