Directed Electronics 4103 Series Manuel utilisateur

This product is intended for installation by a professional

installer only! Attempts to install this product by a per-

son other than a trained professional may result in severe

damage to a vehicle’s electrical system and components.

N4103 2012 01

Installation Guide

Keyless Entry Remote Start

4103, 4-button series

Bitwriters with a date code of 6a or older require an IC

upgrade (p/n 998M). Some Bitwriters with a date code of

6B do not require the IC upgrade, refer to tech tip # 1112

for more information.

Bitwriter®, Code Hopping™, Doubleguard®, ESP™, Fail-

Safe®, Ghost Switch™, Learn Routine™, Nite-Lite®, Nuisance

Prevention® Circuitry, Revenger®, Silent Mode™, Soft Chirp®,

Stinger®, Valet®, Vehicle Recovery System®, VRS®, and Warn

Away® are all Trademarks or Registered Trademarks of Direct-

ed Electronics.

The Bitwriter®(p/n

998U) requires chip

version 2.7 or newer to

program this unit.

Contents

Warning! Safety first ....................................................................................................................... 4

Wiring diagram.............................................................................................................................. 5

Wiring connections ......................................................................................................................... 5

Main Harness (H1), 9-pin connector ............................................................................................ 5

Door Lock - 3 pin connector........................................................................................................ 6

Heavy Gauge Relay (H2), 6-pin connector ................................................................................... 6

Satellite harness - 4-pin connector................................................................................................ 6

Remote Start harness (H3) 5-pin connector ................................................................................... 6

Tach Learning ................................................................................................................................. 7

Virtual Tach .................................................................................................................................... 7

Neutral safety switch interface .......................................................................................................... 8

Testing the neutral safety switch................................................................................................... 8

Remote start shutdown diagnostics .................................................................................................... 9

Remote programming ...................................................................................................................... 9

Programming system features.......................................................................................................... 10

Feature menus .............................................................................................................................. 11

Menu 1 ................................................................................................................................. 11

Menu 2 ................................................................................................................................. 13

Red 4-pin port, Bitwriter/ESP2 or D2D programming.................................................................. 14

Bitwriter only options ..................................................................................................................... 15

Bitwriter feature descriptions..................................................................................................... 15

Basic remote functions ................................................................................................................... 16

Reset and deletion......................................................................................................................... 17

Troubleshooting: Keyless entry ........................................................................................................ 17

Troubleshooting: Remote start ......................................................................................................... 17

Warning! Safety ﬁrst

The following safety warnings must be observed at all times:

• Due to the complexity of this system, installation of this product must only be performed by an authorized

Directed Electronics dealer.

• When properly installed, this system can start the vehicle via a command signal from the remote control.

Therefore, never operate the system in an area that does not have adequate ventilation.

The following precautions are the sole responsibility of the user; however, authorized Directed Electronics

dealers should:

• Never use a test light or logic probe when installing this unit. Always use a multimeter.

• Never operate the system in an enclosed or partially enclosed area without ventilation (such as a garage).

• When parking in an enclosed or partially enclosed area or when having the vehicle serviced, the remote

start system must be disabled using the installed toggle switch. It is the user’s sole responsibility to prop-

erly handle and keep out of reach from children all remote controls to assure that the system does not

unintentionally remote start the vehicle.

USER MUST INSTALL A CARBON MONOXIDE DETECTOR IN OR ABOUT THE LIVING AREA ADJACENT TO THE VEHICLE. ALL

DOORS LEADING FROM ADJACENT LIVING AREAS TO THE ENCLOSED OR PARTIALLY ENCLOSED VEHICLE STORAGE AREA MUST

REMAIN CLOSED AT ALL TIMES.

Use of this product in a manner contrary to its intended mode of operation may result in property damage,

personal injury, or death. Except when performing the Safety Check outlined in this installation guide,

(1) Never remotely start the vehicle with the vehicle in gear, and (2) Never remotely start the vehicle with the

keys in the ignition. The user is responsible for having the neutral safety feature of the vehicle periodically

checked, wherein the vehicle must not remotely start while the car is in gear. This testing should be performed

by an authorized Directed Electronics dealer in accordance with the Safety Check outlined in this product

installation guide. If the vehicle starts in gear, cease remote start operation immediately and consult with the

user to ﬁx the problem immediately.

After the remote start module has been installed, test the remote start module in accordance with the Safety

Check outlined in this installation guide. If the vehicle starts when performing the Neutral Safety Shutdown

Circuit test, the remote start unit has not been properly installed. The remote start module must be removed

or properly reinstalled so that the vehicle does not start in gear. All installations must be performed by an

authorized Directed Electronics dealer.

OPERATION OF THE REMOTE START MODULE IF THE VEHICLE STARTS IN GEAR IS CONTRARY TO ITS IN-

TENDED MODE OF OPERATION. OPERATING THE REMOTE START SYSTEM UNDER THESE CONDITIONS

MAY RESULT IN PROPERTY DAMAGE OR PERSONAL INJURY. IMMEDIATELY CEASE THE USE OF THE UNIT

AND REPAIR OR DISCONNECT THE INSTALLED REMOTE START MODULE. DIRECTED ELECTRONICS WILL

NOT BE HELD RESPONSIBLE OR PAY FOR INSTALLATION OR REINSTALLATION COSTS.

IMPORTANT! This product is designed for fuel-injected, automatic transmission vehicles only. Installing it in a

standard transmission vehicle is dangerous and is contrary to its intended use.

Wiring diagram

Control Button

(Valet Switch)

Door Lock/unlock

Harness

Side View

Antenna

LED (Programming

indicator)

Parking light jumpers

Primary Harness Remote Start Harness

Heavy

Gauge

Relay

Side View

Satellite Harness

Red 4-pin port, Bitwriter/ ESP2 or D2D

4x03

Wiring connections

Main Harness (H1), 9-pin connector

H1/1 LIGHT GREEN

BLACK

(-) 200mA FACTORY ALARM DISARM

H1/2 GREEN/WHITE (-) 200mA FACTORY ALARM REARM

H1/3 YELLOW (+) IGNITION OUT (TO ALARM)

H1/4 WHITE/BLUE (-) ACTIVATION INPUT

H1/5 ORANGE (-) 500mA GROUND WHEN LOCKED/ANTI-GRIND OUTPUT

H1/6 BROWN (-) 200mA HORN OUTPUT

H1/7 RED/WHITE (-) 200mA TRUNK RELEASE OUTPUT

H1/8 BLACK GROUND

H1/9 WHITE (+/-) LIGHT FLASH OUTPUT

Door Lock - 3 pin connector

1LIGHT BLUE (-) UNLOCK

2EMPTY NOT USED

3GREEN (-) LOCK

Heavy Gauge Relay (H2), 6-pin connector

H2/1 PINK OUTPUT TO PRIMARY IGNITION CIRCUIT

H2/2 PURPLE OUTPUT TO STARTER CIRCUIT

H2/3 ORANGE OUTPUT TO ACCESSORY CIRCUIT

H2/4 RED (+) 30A HIGH CURRENT 12V INPUT

H2/5 PINK/WHITE OUTPUT TO SECOND IGNITION/ACCESSORY CIRCUIT

H2/6 RED (+) 30A HIGH CURRENT 12V INPUT

Satellite harness - 4-pin connector

1BLUE (-) 200mA STATUS OUTPUT

2ORANGE (-) 200mA ACCESSORY OUTPUT

3PURPLE (-) 200mA STARTER OUTPUT

4PINK (-) 200mA IGNITION OUTPUT

Remote Start harness (H3) 5-pin connector

H3/1 BLACK/WHITE (-) NEUTRAL SAFETY SWITCH INPUT

H3/2 VIOLET/WHITE TACHOMETER INPUT WIRE

H3/3 BROWN (+) BRAKE SHUTDOWN INPUT WIRE

H3/4 GRAY (-) HOOD PIN SWITCH SHUTDOWN WIRE

H3/5 BLUE/WHITE (-) 200 mA 2ND STATUS/REAR DEFOGGER

Tach Learning

To learn the tach signal:

1. Start the vehicle with the key.

2. Within 5 seconds, press and hold the Valet (Control) button.

3. After 3 seconds the system LED will light constant when the tach signal is learned.

4. Release the Valet (Control) button.

Important: This unit can learn the tachometer with the analog

input or through D2D using an interface module. The unit con-

ﬁrms which source is used.

When programming tach learning with:

• Analog, the parking lights ﬂash one time

• D2D inerface module, the parking lights ﬂash twice

If the tachometer input on the system is connected to the vehicle, the D2D tachometer input will be ignored.

Virtual Tach

Note: Virtual tach is not recommended for diesel vehicles.

To program Virtual Tach:

1. After the install is complete, remote start the car.

2. If the car does not start on the ﬁrst attempt, let the remote start attempt again.

3. Once the car starts, let it run until the parking lights come on.

4. When the parking lights come on, shut off the remote start with the remote - that’s it! Virtual Tach is pro-

grammed.

Virtual Tach handles disengaging the starter motor during remote starting – it does not address over-rev. If

the customer wants to have the over-rev protection capability, the tach wire must be connected. This may

involve more installation shop charges than initially quoted.

Important: If the Virtual Tach mode over cranks or

doesn't crank the vehicle long enough to start and run

the car, use the Bitwriter to add or subtract the starter

output time. You can adjust the output time in incre-

ments of 50msec of the learned time using the Bitwriter.

Neutral safety switch interface

Some vehicles do not have an electrical neutral safety switch, but instead have a mechanical neutral safety

switch that interrupts the starter wire when the vehicle is in any drive gear. The remote start must be interfaced

before the neutral safety switch , to provide protection from starting in gear. However, some vehicles combine

the column shift and the neutral safety switch into one mechanical part, and in this case you will not be able

to interface the remote start before the neutral safety switch.

Important: You must complete the remote start system installation before doing the follow-

ing test. Ensure that the remote start system is functioning normally. This includes connect-

ing to the brake as a shut-down.

Testing the neutral safety switch

1. Make sure there is adequate clearance to the front and rear of the vehicle because it may move slightly.

2. Make sure the hood is closed and there are no remote start shut-downs active.

3. Set the emergency brake.

4. Turn the key to the “run” position, this releases the shifter.

5. Place the car in drive (D).

6. Place your foot directly over the brake pedal, but do not depress it. Be ready to step on the brake if the

starter engages.

7. Activate the remote start system.

8. If the starter engages, immediately depress the brake to shut the remote start system down. If the

starter does not engage, no additional safety

system is required.

If the starter engages and the vehicle is a General Motors product or Dodge Dakota pickup, refer to

www.

directechs.com

for Document 1008 under the Resource tab. For an alternative shut-down method

which prevents the starter from engaging. If the vehicle is not a General Motors product or a Dodge

Dakota pickup, please call Directed Electronics Technical Support for an alternative shut-down method.

Do not return the vehicle to the customer until this feature is properly installed!

Remote start shutdown diagnostics

If the remote start activates but fails to stay running, the remote start module has the ability to inform you of

what may have caused the remote start failure. Before performing shutdown diagnostics it is important that

you let the remote start shut off on its own i.e. let it attempt to start 3 times then shut down, if this is not done

the unit will report the shutdown you used to shut off the remote start.

Note: Shutdown diagnostics does not report if the vehicles factory immobilizer is causing the problem.

To perform shutdown diagnostics:

1. With the ignition Off, press and hold the Valet button

2. Turn the ignition On and then back Off while holding the Valet button.

3. Release the Valet button.

4. Press and release the Valet button. The status LED ﬂashes to report the last shutdown for one minute or

until the ignition is turned on, as shown in the following table:

Status LED Flashes Shutdown Mode

1 ﬂash Runtime expired

2 ﬂashes Over-rev shutdown

3 ﬂashes Low or no RPM

4 ﬂashes Transmitter shutdown (or optional push button)

5 ﬂashes (-) Hood shutdown (H3/4 GRAY)

6 ﬂashes (+) Shutdown (H3/3 BROWN)

7 ﬂashes Neutral safety shutdown (H3/1BLACK/WHITE)

8 ﬂashes Wait-to-start timed out

Remote programming

1. Turn key to the ON position

2. Within 5 seconds, press and release Valet button one time.

3. Within 5 seconds, press and hold the Valet button. The LED will ﬂash one time and the horn honks to

conﬁrm entry into remote programming.

4. Press the

AUX

button ( or the single button ) on the remote control.

5. The horn honks to conﬁrm the remote has been programmed.

6. Release the Valet button, and turn the key to the Off position.

7. The horn sounds one long honk to conﬁrm that remote programming has been exited.

The programming routine exits if any of the following occurs:

• The ignition is turned off

• There is no activity for 30 seconds

• The Valet button is pressed too many times

Programming system features

The System Features Learn Routine dictates how the unit operates. It is possible to access and change most of

the feature settings using the Control button.

1. Turn the ignition on, then off.

2. Select a Menu. Press and hold the Valet button. The number of LED ﬂashes and horn honks indicates the

menu number. A single LED ﬂash and honk indicates menu 1. Two LED ﬂashes and 2 honks indicates

menu 2.

3. When the desired menu LED ﬂashes and honks are heard, release the Valet button.

4. Select a Feature. Press and release the Valet button the number of times corresponding to the feature you

wish to change. Then press and hold one more time to select the feature. The LED ﬂashes and the horn

honks to indicate which feature is selected.

5. Program the Feature. While holding the Valet button, you can program the feature using the remote

control.

For features with only two options;

AUX

= option 1 while

AUX

= option 2.

For features with more than two options;

AUX

selects the options in ascending order. The LED ﬂashes and the

horn honks indicating which option is selected.

Once a feature is programmed:

• Other features can be programmed within the same menu

• Another menu can be selected

• The learn routine can be exited if programming is complete

To access another feature in the same menu:

1. Press and release the Valet button the number of times necessary to advance from the feature you just

programmed to the next one you want to program.

2. Then press the Valet button once more and hold it.

To select another menu:

1. Press and hold the Valet button.

2. After 3 seconds, the unit advances to the next menu and the LED ﬂashes and the horn honks, indicating

which menu has been accessed.

The learn routine exits if any of the following occurs:

• The ignition is turned On

• There is no activity for 30 seconds

• The Valet button is pressed too many times

Autres manuels pour 4103 Series

Table des matières

Autres manuels Directed Electronics Démarreur à distance

Directed Electronics

Directed Electronics ProStart CT-5472TW Manuel utilisateur

Directed Electronics

Directed Electronics AS-6870TW-FM Manuel utilisateur

Directed Electronics

Directed Electronics Ready Remote 23927 Manuel utilisateur

Directed Electronics

Directed Electronics Rattler 259D Manuel utilisateur

Directed Electronics

Directed Electronics Avital 4113 Manuel utilisateur

Directed Electronics

Directed Electronics Valet 712T Manuel utilisateur

Directed Electronics

Directed Electronics PS-3655E-FM Manuel utilisateur

Directed Electronics

Directed Electronics CT-3271 Manuel utilisateur

Directed Electronics

Directed Electronics Avital G3000 7/01 Manuel utilisateur

Directed Electronics

Directed Electronics G4311A-AM15 AM15 Manuel utilisateur

Directed Electronics

Directed Electronics Xpresskit CANMAX400 Manuel utilisateur

Directed Electronics

Directed Electronics 3000 Manuel utilisateur

Directed Electronics

Directed Electronics Failsafe 103T Manuel utilisateur

Directed Electronics

Directed Electronics AVITAL 4003 Manuel utilisateur

Directed Electronics

Directed Electronics READY REMOTE 24921 Manuel utilisateur

Directed Electronics

Directed Electronics AS-1271 Manuel utilisateur

Directed Electronics

Directed Electronics AutoCommand 25622 Guide de démarrage rapide

Directed Electronics

Directed Electronics ONE-WAY FM AUTOMATIC/MANUAL TRANSMISSION Manuel utilisateur

Directed Electronics

Directed Electronics SmartStart 5000-series Manuel utilisateur

Directed Electronics

Directed Electronics Viper 7652V Manuel utilisateur

Directed Electronics

Directed Electronics AutoCommand 28624T Manuel utilisateur

Directed Electronics

Directed Electronics Smart start Manuel utilisateur

Directed Electronics

Directed Electronics SmartStart 5000-series Manuel utilisateur

Directed Electronics

Directed Electronics Python 1601 Manuel utilisateur

Manuels Démarreur à distance populaires d'autres marques

AstroStart

AstroStart 803U Manuel utilisateur

Durite

Durite 0-649-20 Manuel

EINHELL

EINHELL BT-PS 1000 Manuel

Linear

Linear ACCESS AK-21 Caractéristiques techniques

Soundstream

Soundstream TARANTULA RS.2 Manuel utilisateur

Jaycar Electronics

Jaycar Electronics MB3752 Manuel utilisateur

Ultra Start

Ultra Start 72 Series Manuel utilisateur

ADS

ADS FLASHLOGIC FLRSVW1 Manuel utilisateur

Selecta

Selecta JS012 Manuel utilisateur

Black Widow Security

Black Widow Security BW RAS 400 Manuel utilisateur

Vector

Vector Power City DK080706 Supplément

Code Alarm

Code Alarm CA-535 Manuel utilisateur

Ozito

Ozito OJS-800 Manuel utilisateur

Profi-Partner

Profi-Partner 46387 Manuel utilisateur

EZ STARTER

EZ STARTER EZ-45 Manuel utilisateur

Viper

Viper 4204 Manuel utilisateur

Essex Electronics

Essex Electronics KE-1701 Manuel utilisateur

EINHELL

EINHELL EGS 3600 Manuel
