PARTS AND SERVICE MANUAL

FOR THE 23” INSERT FIREPLACE

MODEL NUMBER:

DFI2309

TABLE OF CONTENTS

OPERATION PAGE1

PARTS DRAWING PAGE 3

PARTSLIST PAGE4

WIRING DIAGRAM PAGE 5

LIGHT BULB REPLACEMENT PAGE 6

MAIN ON/OFF SWITCH REPLACEMENT PAGE 8

LOW HEAT ON/OFF SWITCH REPLACEMENT PAGE 9

HIGH HEAT ON/OFF SWITCH REPLACEMENT PAGE 10

FLAME MOTOR/FLAME ROD REPLACEMENT PAGE 11

HEATER ASSEMBLY REPLACEMENT PAGE 12

LIGHT HARNESS REPLACEMENT PAGE 13

POWER CORD REPLACEMENT PAGE 14

DFI2309

OPERATION

MAIN ON/OFF FLAME ON/OFF SWITCH

The ON/OFF switch supplies power to all unit functions. When this switch is in the ON

position the flame effect operates without heat.

LOW HEAT SWITCH

The LOW HEAT ON/OFF SWITCH supplies power to the heater fan and the heater

element. When the switch is in the ON position the heater operates on LOW.

HIGH HEAT SWITCH

The HIGH HEAT ON/OFF SWITCH supplies power to the heater fan and the heater

element, when the switch is in the ON position the heater operates on HIGH. The LOW

HEAT ON/OFF SWITCH must also be in the ON position for the high heat setting to

operate.

RESETTING THE TEMPERATURE CUTOFF SWITCH

The heater is protected with a safety device to prevent overheating. Should the heater

overheat, an automatic cut out will turn the heater off and it will not come back on

without being reset. It can be reset by switching the ON/OFF SWITCH to OFF and

waiting 5 minutes before switching the unit back on.

CAUTION

If you need to continuously reset the heater, unplug the unit and call your local dealer.

MAIN ON/OFF

HIGH HEAT

LOW HEAT

DFI2309

REMOTE CONTROL

The remote control has a range of approximately 50ft. (15.25m) it does not have to be

pointed at the fireplace and can pass through most obstacles (including walls). It is

supplied with one of 243 independent frequencies to prevent interference with other

units. The frequency designation is indicated on the back of the transmitter (FIGURE 3)

REMOTE CONTROL INSTALLATION

1. Plug fireplace cordset into the outlet located on the side of the receiver. (FIGURE 2)

2. Plug receiver into the wall outlet.

3. Install a 9 volt battery into the transmitter. (FIGURE 3)

NOTE

• Fireplace MAIN on/off switch must be in the

ON position prior to using the Remote Control.

• ON/OFF Remote Control may be used to

control most other electrical devices including

T.V.’s, stereos and lamps.

CAUTION

• For indoor use in dry areas only

• For use on electrical devices with 15 amp

resistive load or 1/3 HP inductive load

• 120 volt AC only

FIGURE 2

Receiver

Outlet

OPEN

Frequency

Code

Battery

Cover

FIGURE 3

DFI2309

REPLACEMENT PARTS

23” FIREPLACE INSERT

REPLACEMENT PART REPLACEMENT PART NO.

1. MAIN ON/OFF SWITCH 2800090100RP*

2. LOW HEAT ON/OFF SWITCH 2800090100RP*

3. HIGH HEAT ON/OFF SWITCH 2800090100RP*

4. CORDSET 4100090101RP

5. HEATER ASSEMBLY 2200490300RP

6. CUTOUT 2300270200RP

7. MIRROR 5900350100RP

8. LOGSET 0438200200RP

9. FLICKER MOTOR 2000220100RP

10.REFLECTOR ASSEMBLY 5900340100RP

11.LAMPHOLDER 4200120100RP

12.REMOTE CONTROL 6800050200RP

DFI2309

WIRING DIAGRAM

DFI2309

If unit was operating prior to servicing allow at least 10 minutes for light bulbs and

heating element to cool off to avoid accidental burning of skin.

Disconnect power before attempting any maintenance or cleaning to reduce the risk of

electric shock or damage to persons.

Light bulbs need to be replaced when you notice a dark section of the flame. There are

four bulbs under the log set which generate the flames and embers.

It is a good idea to replace all of the light bulbs at one time if they are close to the end of

their rated life. Group replacement will reduce the number of times you need to open

the unit to replace the light bulbs.

1. Remove the fireplace trim.

2. Remove the (2) outer screws from the log grate.

3. Slide the light assembly out of the insert by pulling the log grate

until the light assembly reaches the stop.

4. Remove the log set by lifting the log ember bed straight up.

5. Examine the bulb(s) to determine which bulb(s) require replacement.

6. Unscrew the bulbs counter clockwise.

7. Insert new bulbs.

8. Replace the log set into the insert.

9. Slide the light assembly back into the insert.

10.Install the two outer screws into the log grate.

11.Reinstall the fireplace trim.

Outer Screws

Light Assembly

Light Bulbs

Log Ember Bed

DFI2309

If unit was operating prior to servicing allow at least 10 minutes for light bulbs and

heating element to cool off to avoid accidental burning of skin.

Disconnect power before attempting any maintenance or cleaning to reduce the risk of

electric shock or damage to persons.

BULB REQUIREMENTS

Quantity 2 clear chandelier or candelabra bulbs with an E-12 (small) socket base, 60

watt rating.

DFI2309

If unit was operating prior to servicing allow at least 10 minutes for light bulbs and

heating element to cool off to avoid accidental burning of skin.

Disconnect power before attempting any maintenance or cleaning to reduce the risk of

electric shock or damage to persons.

TO REPLACE MAIN ON/OFF SWITCH

1. Remove the trim and firebox from mantel.

2. Remove the trim from firebox.

3. Remove the (2) screws located in the front middle of the top and the (2) screws at

the back of the top.

4. Locate the main on/off switch mounted in the exhaust panel and disconnect the

wiring clips and connections noting their original locations.

5. Depress the retainer clips on the rear of the switch and push the switch out of the

exhaust panel.

6. Properly orientate the new switch and connect all of the wiring clips and

connections.

7. Reassemble in the reverse order as above.
