Digitus DN-95355 Manuel utilisateur

16/24 Port Fast Ethernet PoE

Switch, 1 Combo (RJ45+SFP)

and 1 RJ45 Gigabit Uplinks

Quick Installation Guide

DN-95355 - DN-95356

Table of Contents

1. Introduction ............................................................................. 2

2. Features ................................................................................... 3

3. Package Contents..................................................................... 3

4. Specifications ........................................................................... 3

5. Hardware Description .............................................................. 5

5.1 Front Panel......................................................................... 5

5.2 Rear Panel .......................................................................... 7

6. Installation the Switch.............................................................. 7

6.1 Desktop Installation ........................................................... 8

6.2 Rack-mountable Installation .............................................. 8

6.3 Turn on the switch ............................................................. 9

1. Introduction

DN-95355 PoE Switch is 16-port 10/100Mbps PoE + 1G Combo +

1GE PoE Switch.

DN-95356 PoE Switch is 24-port 10/100Mbps PoE + 1G Combo +

1GE PoE Switch.

The PoE ports can automatically detect and supply power to

IEEE802.3af/at compliant Powered Devices (PD).

The electrical power and data transmission on the same cable can expand

your network to the places where no power lines or outlets, where you

can install devices such as APs, IP cameras, or IP phones etc.

The PoE Switch provides a simple, cost- effective, and non-blocking

wire-speed performance with 11-inch metal shape for rack deployment

in office or department network application.

2. Features

1. 16/24x 10/100Mbps PoE RJ45 Ports

2. 1x 10/100/1000Mbps Combo Ports

3. 1x 10/100/1000Mbps RJ45 Port

4. Support VLAN and CCTV function

5. Complies with IEEE802.3af/at Power over Ethernet

6. Supports PoE Power up to 32W for each PoE port

7. Auto detect power device

8. Remote power and Data feeding up to 100m

9. Flow Control for Full Duplex operation and back pressure for Half

Duplex Operation

10. 16K MAC address, automatic address learning and address aging

11. Support Energy-Efficient Ethernet (EEE) function EEE802.3az

12. Support PD Alive function (the switch port is disconnected will

automatically connected)

3. Package Contents

1x PoE Switch

1x User Guide

1x Power Cord

Accessories (hanging ears x2, Rubber Feet x4, screw x8)

4. Specifications

Model DN-95355 DN-95356

PoE Port Port 1~16 Port 1~24

Standards and Protocols

IEEE802.3, IEEE802.3u, IEEE802.3ab,

IEEE802.3z, IEEE802.3x, IEEE802.3af,

IEEE802.3at

Network Media



10BASE-T:

UTP category 3,4,5 cable (≤100m),

100BASE-TX:

UTP category 5, 5e cable (≤100m),



1000BASE-T:

UTP category 5e, 6 cable (≤100m),



1000BASE-X: SMF, MMF SFP module

Transfer Method Store-and-Forward

Frame Forward Rate

10Base-T: 14881pps/Port

100Base-TX: 148810pps/Port



1000Base-T/X: 1488095pps/Port

Switching Capacity 7.2G 8.8G

Fan 1x Fan

Power Input AC: 100~240V, 50/60Hz

Packet Forwarding Rate 5.4Mpps 6.5Mpps

Packet Buffer

4Mbit

PoE Power on RJ45 Mode A 1/2(+),3/6(-)

PoE Power Output Voltage: 55V DC Power: 32W(Max)

PoE Power budget 185W

Dimensions (W x D x H) 280x180x44mm

Temperature

Operating Temperature:

0°C ~ 40°C (32 °F ~104°F)

Storage Temperature:

-40°C ~ 70°C (-40 °F ~158°F )

Humidity

Operating Humidity:

10% ~ 90% non-condensing

Storage Humidity:

5% ~ 90% non-condensing

5. Hardware Description

5.1 Front Panel

The Front Panel Consists of 16/24-Port 10/100M Auto-Negotiation

Ethernet RJ45 Ports, 1-Port Gigabit Combo Port and 1x 10/100/1000 RJ45

port. The LED indicators also on located on the panel.

DN-95355

1. Status indicators 2. Switch

3. 16x 10/100Mbps

PoE RJ45 Ports

4. 1x 10/100/1000Mbps Combo Ports

1x 10/100/1000Mbps RJ45 Ports

DN-95356:

1. Status indicators 2. Switch

3. 24x 10/100Mbps

PoE RJ45 Ports

4. 1x 10/100/1000Mbps Combo Ports

1x 10/100/1000Mbps RJ45 Ports

LED indicator:

LED Color Function

PWR Green

Off: No Power supply

Light: Indicates the switch has power

LNK/

ACT Green

Off: No device is connected to the

corresponding port.

Light: Indicates the link through that port is

successfully.

Blink: Indicates that the Switch is actively sending

or receiving data over that port.

PoE Orange

Off: No PoE powered device (PD) connected

Light: There is a PoE PD connected to be port,

which supply power successfully.

Blink: Indicates port abnormal power supply

Max Green

Off: PoE power is less than 80% of total power.

Light: PoE power above 80%.

DIP Switch

The DIP switch located on the left panel.

Default: the factory default mode, can normal communication between

port 1~18/1~26.

VLAN: 1-16/24 port can be isolated each other but 1-16/24 port can

connect to 17~18/25~26 port after open VLAN to stop broadcast storm

to increase forwarding rate of frame.

CCTV: Up to 250m PoE distance allows you to expand you network via

Ethernet cable but where you want to fix device such as IP Cameras.

Note:

After change the mode, there is no need to restart manually to make the

corresponding configuration take effect.

5.2 Rear Panel

The rear panel of the PoE Switch indicates an AC inlet power socket,

Grounding Column.

1. AC power socket 2. Grounding

6. Installation the Switch

This part describes how to install your Ethernet Switch and make

connections to it. Please follow the following instructions in avoid of

incorrect installation causing device damage and security threat.

Before cleaning the switch, unplug the power plug of the switch

first. Do not clean the switch with wet cloth or liquid;

Do not place the switch near water or any damp area. Prevent

water or moisture from entering the switch chassis;

Do not place the switch on an unstable case or desk. The switch

might be damaged severely in case of a fall;

Ensure proper ventilation of the equipment room and keep the

ventilation vents of the switch free of obstruction;

Make sure that the operating voltage is the same one labeled on

the switch;

Do not open the chassis while the switch is operating or when

electrical hazards are present to avoid electrical shocks

6.1 Desktop Installation

Install the Switch on a desktop, please attach these cushioning rubber

feet provided on the bottom at each corner of the Switch in case of the

external vibration. Allow adequate space for ventilation between the

device and the objects around it. The installation diagram is as follows:

6.2 Rack-mountable Installation

The switch is rack-mountable and can be installed on an EIA-11-inch

equipment rack. To do this, first, please install the mounting brackets on

the switch’s side panels (one on each side), secure them with the

included screws, and then use the screws provided with the equipment

rack to mount the switch on the 11-inch rack.

6.3 Turn on the switch

Plug in the negative connector of the provided power cord into the power

socket of the device, and the positive connector into a power outlet.

After the device is powered on, it begins the Power-On Self-Test. The

PWR LED indicator will light on all the time.

CE Mark Warning: This is a Class A product. In home environment, this

product may cause radio interference. In this case, the user may be

required to take appropriate measures.

Hereby Assmann Electronic GmbH, declares that the Declaration of

Conformity is part of the shipping content. If the Declaration of

Conformity is missing, you can request it by post under the below

mentioned manufacturer address.

www.assmann.com

Assmann Electronic GmbH

Auf dem Schüffel 3

58513 Lüdenscheid

Germany
