DG‐GS4600SSERIES
24/48PortAccessLayer3Switchwith10GUplinks
INSTALLATIONGUIDE
V1.1
2012‐06‐15
As our products undergo continuous development the specifications are subject to change without prior notice
Installation Guide
2
Content
1.1 OVERVIEW..........................................................................................1-1
1.2 INTRODUCTION TO PRODUCT................................................................1-1
1.2.1 Product Overview .................................................................................1-1
1.2.2 Features and Benefits ..........................................................................1-2
1.3 PHYSICAL SPECIFICATIONS..................................................................1-3
1.4 DESCRIPTION OF HARDWARE ...............................................................1-4
1.4.1 Front Panel............................................................................................1-4
1.4.2 Back Panel.............................................................................................1-5
1.4.3 DC Power/PoE Power Input .................................................................1-6
1.4.4 Status LEDs...........................................................................................1-7
1.4.5 Front Panel Interface Description........................................................1-8
1.4.6 DG-SA-GS4600-EM-2XFP/ DG-SA-GS4600-EM-2SFP+ /
DG-SA-GS4600-EM-2SFP Extended Module Description...........................1-9
2.1 INSTALLATION NOTICE.........................................................................2-1
2.1.1 Environmental Requirements ..............................................................2-1
2.1.2 Installation Notice.................................................................................2-4
2.1.3 Security Warnings ................................................................................2-4
2.2 INSTALLATION PREPARATION...............................................................2-5
2.2.1 Verify the Package Contents................................................................2-5
2.2.2 Required Tools and Utilities.................................................................2-5
2.3 INSTALLATION GUIDE ..........................................................................2-6
2.3.1 Installing the Switch .............................................................................2-6
2.3.2 Connecting Console.............................................................................2-7
2.3.3 SFP Transceiver Installation ................................................................2-7
2.3.4 DG-SA-GS4600-EM-2XFP Extended Module Installation...................2-8
2.3.5 DG-SA-GS4600-EM-2SFP+ extended module Installation.................2-8
2.3.6 DG-SA-GS4600-EM-2SFP Extended module Installation...................2-9
2.3.7 Copper Cable/Fiber Cable Connection ...............................................2-9
2.3.8 AC Power Supply Connection ...........................................................2-10
2.3.9 DC Power Supply Connection ........................................................... 2-11
2.3.10 PoE Power Supply Connection........................................................2-12
Introduction
1-1
Chapter 1 Introduction
1.1 Overview
DG-GS4600S series switches are ethernet switch. DG-GS4600S series switches are
intelligent network management switch used by the network environment which needs the
high performance, the bigger port density and the convenient installation.
DG-GS4600S series switches include the type are as follows:
Name Type Description
DG-GS4652S 44 copper ports ＋4 Combo ports ＋2 10Gb
extended cards ＋DC power
DG-GS4652SP 44 copper ports ＋4 Combo ports ＋2 10Gb
extended cards ＋PoE
DG-GS4628S 20 copper ports ＋4 Combo ports ＋2 10Gb
extended cards ＋DC power
DG-GS4628SP 20 copper ports ＋4 Combo ports ＋2 10Gb
extended cards ＋PoE
1.2 Introduction to Product
1.2.1 Product Overview
DG-GS4600S series switches include DG-GS4652S, DG-GS4652SP,
DG-GS4628S and DG-GS4628SP switches. The difference is DG-GS4652S implements
48V DC input, DG-GS4652SP supplies 48 ports for exporting PoE power supply, and the
max output power of each port is 15W. DG-GS4628S and DG-GS4628SP supply the
consistent signal interface, the difference is DG-GS4628S implements 48V DC input,
Introduction
1-2
DG-GS4628SP supplies 24 ports for exporting PoE power supply, and the max output
power of each port is 15W.
1.2.2 Features and Benefits
Various Interfaces
DG-GS4652S and DG-GS4652SP provide 44 fixed 1000Mb fiber ports, 4 1000Mb
COMBO ports (1000Mb fiber SFP ports/1000Mb copper ports) and 2 10Gb slots with 2
ports.
DG-GS4628S and DG-GS4628SP provide 20 fixed 1000Mb copper ports, 4 1000Mb
COMBO ports (1000Mb fiber SFP ports/1000Mb copper ports) and 2 10Gb slots with 2
ports.
Secure Power Supply
DG-GS4600S series switches provide DC power backup, support 220V AC input,
48V DC input or 220V AC, 48V DC input simultaneously.
Support 10Gb Ethernet
10Gb Ethernet which adopts full-duplex technology instead of low-speed, half-duplex
CSMA/CD protocol, is a big leap in the evolution of Ethernet. 10Gb Ethernet can be
deployed in star or ring topologies. DG-GS4600S series switches provide broad
bandwidth and powerful processing capacity. It is suitable for metropolitan networks and
wide area networks. Using DG-GS4600S series switches, users can simplify network
structures and reduce cost of network construction.
Networking Protocols
DG-GS4600S series switches support 802.1d/w/s, 802.1Q, 802.1p, 802.3ad, 802.3x,
GVRP, DHCP and SNTP etc; support IPv6 protocol. All these protocols supported enable
DG-GS4600S series switches to meet the requirements of complex network
constructions.
Note: For DG-GS4600S-28F-DC and DG-GS4600S-28F, v4 unicast route only
support static RIP, multicast route only support IGMP snooping, not support multicast
route protocol; v6 unicast route only support static RIPng, multicast only support
MLDv1/v2 snooping, not support multicast route protocol.
ACL
DG-GS4600S series switches support comprehensively ACL policies. The traffic can
be classified by source/destination IP addresses, source/destination MAC addresses, IP
protocols, TCP/UDP, IP precedence, time ranges and ToS. And various policies can be
conducted to forward the traffic. By implementing ACL policies, users can filter the virus
packets such as “Worm.Blaster”, “Worm.Sasser” and “Red Code” etc. DG-GS4600S
Introduction
1-3
series switch also support IEEE802.1x port based access authentication, which can be
deployed with RADIUS, to ensure the port level security and block illegal users.
QoS
DG-GS4600S series switches fully support DiffServ Module. Users can specify a
queue bandwidth on each port. WDRR/SP/SWDRR scheduling is also supported.
DG-GS4600S series support the port trust. Users can configure trusted CoS, DSCP, IP
precedence and port priority. User can also modify packet’s DSCP and COS values. The
traffic can be classified by port, VLAN, DSCP, IP precedence and ACL table. User can
also modify packet’s DSCP and IP precedence values. Users can specify different
bandwidths for voice/data/video to customize different qualities of service.
3D-SMP Ready
DG-GS4600S series are up to the mustard of Self-defending security region
management strategy. It is supported interaction with some security system such as
firewall, IDS, etc. It can defense the virus and aggress effectively from the extranet and
internet. Thus enhance the security and stability of the network-wide.
Perfect Web Management.
DG-GS4600S series support SNMP, In-band and Out-of band Management, CLI
and WEB interface and RMON. It can mail the correlative sensitive information to the
administrator abide by SMTP protocol. DG-GS4600S series support SSH protocol, ensure
the configuration management security of the switch.
1.3 Physical Specifications
Item DG-GS4628S/
DG-GS4628SP
DG-GS4652S / DG-GS4652SP
Dimension
(W * H * D)
（mm）
440×324×44
Weight <6kg
Fixed ports 20 100/1000Base-TX auto
negotiation ethernet ports
4 1000Mb Combo ports
2 interfaces with extended
card
44 100/1000Base-TX auto negotiation
ethernet ports
4 1000Mb Combo ports
2 interfaces with extended card
Management
p
orts
1 Console port
Introduction
System
power
DG-GS4600S series support AC/DC power input:
AC input:
The rating voltage range: 100V~240V AC; 50/60HZ
The max voltage range: 90V~264V AC; 47HZ～63HZ
DC input:
48V DC input, -48V～-60V/DC; 2.5A
Output
power supply
of PoE
Support Support
The max
Power
Consumption
35W (without PoE) 65W (without PoE)
Fan Support automatic timing
Operating
Temperature
0℃~50℃
Relative
Humidity
10％~90％
Table 1-1 Physical Specifications
1.4 Description of Hardware
1.4.1 Front Panel
DG-GS4628S and DG-GS4628SP Ethernet switches provide 20 100/1000Base-TX
auto negotiation ehternet ports, 4 1000Mb Combo ports, 6 function indicators and 1
Console port.
Fig 1-2 Front Panel of DG-GS4628S
1-4
Introduction
Fig 1-3 Front Panel of DG-GS4628SP
DG-GS4652S/ DG-GS4652SP series Ethernet switches provide 44
100/1000Base-TX auto negotiation ehternet ports, 4 1000Mb Combo ports, 6 function
indicators and 1 Console port.
Fig 1-5 Front Panel of DG-GS4652S
Fig 1-6 Front Panel of DG-GS4652SP
1.4.2 Back Panel
DG-GS4628S, DG-GS4628SP supplies 2 plug-in interfaces, 1 48V DC input power
interface, 1 input power interface of PoE and 1 220V input power interface.
Fig 1-8 Back Panel of DG-GS4628S
Fig 1-9 Back Panel of DG-GS4628SP
Back Panel of DG-GS4652S is same with DG-GS4628S, it supplies 2 plug-in
interfaces, 1 48V input power interface, 1 input power interface of PoE and 1 220V input
power interface.
1-5
Introduction
Fig 1-11 Back Panel of DG-GS4652S
Fig 1-12 Back Panel of DG-GS4652SP
1.4.3 DC Power/PoE Power Input
DG-GS4600S supports AC/DC input power backup and PoE output power. pin-outs
signal of DC power and PoE power are distributed as below:
Fig 1-13 Pin-outs Distribution of DC Input and PoE Power Input for DG-GS4600S
DC power has 3 pin-outs:
PIN1: GND Ground connection
PIN2: -48V DC power cathode input
PIN3: 0V DC power positive electrode input
PoE has 5 pin-outs:
PIN1: GND Ground connection
PIN2: -52V DC power cathode input
PIN3: -52V DC power cathode input
PIN4: 0V DC power positive electrode input
PIN5: 0V DC power positive electrode input
1-6
Introduction
1-7
1.4.4 Status LEDs
LEDs of DG-GS4600S show the corresponding state.
In mainboard of DG-GS4628S/ DG-GS4628SP/ DG-GS4652S/ DG-GS4652S/
DG-GS4652SP the LEDs include two parts, one is 24/48 1000M interface LEDs, they
show each port state at RJ45 plug-in, each port corresponds a LED with double colors.
Table 1-2 Port LEDs
LED Status Description
On PoE power output
Off no PoE power output
Red
Blink Send or receive the data
On Port in link state
Off Port not in link state
Green
Blink Send or receive the data
The other is system LEDs, they are used to show the work status of the system at the
right of front panel.
Table 1-3 System LEDs
Panel
Symbol Status Description
On (Green) Power is operating normally
PWR
Off Power is abnormally
On (Green, blink) System is loading
DIAG On (Green) System is operating normally
On (Green) System is malfunctioning
ALM Off System is operating normally
On (Green) System is using DC power
RPS Off System does not use DC power
On (Green) Port1 of M1 is at link state
On (Green,
Blink)
Port1 of M1 is receiving or sending the data
M1-1
Off Port1 of M1 is not at link state
Introduction
1-8
On (Green) Port2 of M1 is at link state
On (Green,
Blink)
Port2 of M1 is receiving or sending the data
Off Port2 of M1 is not at link state
M1-2
On (Orange) Port2 of M1 is not at link state, but M1 is in
place
On (Green) Port1 of M2 is at link state
On (Green,
Blink)
Port1 of M2 is receiving or sending the data
M2-1
Off Port1 of M2 is not at link state
On (Green) Port2 of M2 is at link state
On (Green,
Blink)
Port2 of M2 is receiving or sending the data
Off Port2 of M2 is not at link state
M2-2
On (Orange) Port2 of M2 is not at link state, but M2 is in
place
1.4.5 Front Panel Interface Description
DG-GS4600S series switches provide RJ-45 1000Mb copper port and the interface
of SFP 1000Mb fiber transceivers.
Each interface description is shown in the following:
Table 1-4 DG-GS4600S interface description
Port mode Spec
RJ-45 port 10/100/1000Mbps auto negotiation
MDI/MDI-X cable mode auto negotiation
5 kinds of UTP: 100 m
Ce manuel convient aux modèles suivants
3
Table des matières
Autres manuels Digisol Changer
Digisol
Digisol DG-GS1016D-A Manuel utilisateur
Digisol
Digisol DG-GS4526P Manuel utilisateur
Digisol
Digisol DG-GS1528HP/C Guide de démarrage rapide
Digisol
Digisol DG-CS4616F Manuel utilisateur
Digisol
Digisol DG-GS1008PF Manuel utilisateur
Digisol
Digisol DG-GS1510HPEV2 Manuel utilisateur
Digisol
Digisol DG-GS4528SE Manuel de programmation
Digisol
Digisol DG-GS4900 SERIES Manuel utilisateur
Digisol
Digisol DG-GS4824F Manuel utilisateur
Digisol
Digisol DG-CS4554F Manuel utilisateur
Digisol
Digisol DG-GS4826S Manuel de programmation
Digisol
Digisol DG-GS1510PL Manuel utilisateur
Digisol
Digisol DG-FS1510HPE Manuel utilisateur
Digisol
Digisol DG-GS1528HP/C Manuel utilisateur
Digisol
Digisol DG-GO4300 Series Manuel utilisateur
Digisol
Digisol DG-FS4526E Manuel de programmation
Digisol
Digisol DG-GS4600SE2 Series Manuel utilisateur
Digisol
Digisol DG-GS1528 Manuel utilisateur
Digisol
Digisol DG-GS4900SE Series Manuel utilisateur
Digisol
Digisol DG-GS1550 Manuel de programmation
