Digisol DG-GS1016D-A Manuel utilisateur

V1.1

2018-05-21

16 Port 10/100/1000Mbps Gigabit

DG-GS1016D-A

PORTS

2000 Mbps

Ethernet Unmanaged Switch

Company has an on-going policy of upgrading its products and it may be

possible that information in this document is not up-to-date.

Please check with your local distributors for the latest information.

No part of this document can be copied or reproduced in any form without

written consent from the company.

Trademarks:

DIGISOL is a trademark of DIGISOL SYSTEMS LTD. All other trademarks

are the property of the respective manufacturers.

Package Contents

The DG-GS1016D-A is a 10/100/1000Mbps Ethernet unmanaged switch. It

is designed to enhance network performance in a compact form factor. The

switch comes with 16x10/100/1000Mbps ports, offering solutions for

accelerating bandwidth needs of small Ethernet workgroups. The switch

uses store and forward packet-switching technology which offers reliable

data transfer and supports automatic MDI/MDI-X detection & auto

crossover for uplink ports which eliminates the need for cross over cables or

dedicated uplink ports. Any port can simply plug to a server or a switch, using

the usual straight through twisted-pair cable. This switch is ideal for network

connectivity for the SOHO/SME environment.

The following items should be present in your package:

DG-GS1016D-A Gigabit Ethernet Unmanaged Switch

DC Power Adapter (1 No.)

Quick installation guide

Make sure that the package contains above items. If any of the listed items is

damaged or missing, please contact your retailer immediately.

Product Overview

Product Features

Sixteen (16) RJ-45 Ports for 10BaseT,100BaseTX and 1000BaseT

connectivity.

Complies with IEEE802.3, IEEE802.3u and IEEE802.3ab standards.

Supports IEEE802.3x flow control for Full-duplex Mode and

backpressure for Half-duplex Mode.

Supports MDI/MDI-X auto crossover for each port.

Link & activity indicators for each port.

Supports Auto-Negotiation.

MAC Address Table: 8K

After installing the switch, you can check its status from the LED indicators on

the front panel shown below.

Network card for each PC or Server

Network cables min. Cat.5E UTP/STP for 1000Mbps

System Requirements

The following system requirements are recommended

Front View

LED Description

Following is the LED description:

Rear View

Ports 1 ~ 16: The switch has 16 x 10/100/1000Mbps ports for connecting

PC/Desktop or other network devices.

Power Switch is powered on.

LED Description

Port 1 - Port 16

(Link/Act)

OFF

ON (Steady Green)

Status

Switch is powered off.

ON (Steady Green)

Blinking Data packets transmitted/received.

A valid link is established.

OFF No link is established

Power Connection

Connecting Computers to the Switch

The switch features auto MDI/MDIX cross over detection function and

provides plug-and-play capability. Users can immediately use any of the

features of this product simply by plugging the network cables (RJ-45) into

the computers and the switch.

Uplink

All Ports can be used as an uplink port for connecting to another unit without

using crossover cable. When using the uplink port, you can extend the

distance to 100m for linking another switch or hub.

To prolong the operational life of your units

Do not place objects on top of any unit or stack.

Do not obstruct any vents at the sides of the case.

Plug the circle end of the power adapter firmly into the power port on the rear

side, and the other end into an electrical service outlet, then the device is

ready to use.

Limited Lifetime Warranty

[email protected]

1800 209 3444

Digisol is a Subsidiary of Smartlink Holdings Limited

www.digisol.com

1800 209 3444

[email protected]

L-7, Verna Industrial Estate,

Salcete, GOA - 403722

DIGISOL SYSTEMS LIMITED
