DFI ST2K Series Manuel utilisateur

ST2K Series

Rev. C

System Board

User’s Manual

935-ST2K01-600

41830305

This publication contains information that is protected by copyright.

No part of it may be reproduced in any form or by any means or

used to make any transformation/adaptation without the prior

written permission from the copyright holders.

This publication is provided for informational purposes only. The

manufacturer makes no representations or warranties with respect to

the contents or use of this manual and specifically disclaims any

express or implied warranties of merchantability or fitness for any

particular purpose.The user will assume the entire risk of the use or

the results of the use of this document. Further, the manufacturer

reserves the right to revise this publication and make changes to its

contents at any time, without obligation to notify any person or

entity of such revisions or changes.

Trademarks

Microsoft®MS-DOS®, WindowsTM, Windows®95 and Windows®98

are registered trademarks of Microsoft Corporation. Intel®, Pentium®

III and CeleronTM are registered trademarks of Intel Corporation.

Award is a registered trademark of Award Software, Inc. Other

trademarks and registered trademarks of products appearing in this

manual are the properties of their respective holders.

Caution

To avoid damage to the system:

• Use the correct AC input voltage range.....

To reduce the risk of electric shock:

• Unplug the power cord before removing the system chassis

cover for installation or servicing. After installation or servicing,

cover the system chassis before plugging the power cord.

Battery:

• Danger of explosion if battery incorrectly replaced.

• Replace only with the same or equivalent type recommend

the manufacturer.

• Dispose of used batteries according to the battery

manufacturer’s

instructions.

Joystick or MIDI port:

• Do not use any joystick or MIDI device that requires more than

10A current at 5V DC. There is a risk of fire for devices that

exceed this limit.

FCC and DOC Statement on Class B

This equipment has been tested and found to comply with the limits

for a Class B digital device, pursuant to Part 15 of the FCC rules.

These limits are designed to provide reasonable protection against

harmful interference when the equipment is operated in a residential

installation. This equipment generates, uses and can radiate radio

frequency energy and, if not installed and used in accordance with

the instruction manual, may cause harmful interference to radio

communications. However, there is no guarantee that interference

will not occur in a particular installation. If this equipment does cause

harmful interference to radio or television reception, which can be

determined by turning the equipment off and on, the user is

encouraged to try to correct the interference by one or more of the

following measures:

• Reorient or relocate the receiving antenna.

• Increase the separation between the equipment and the receiver.

• Connect the equipment into an outlet on a circuit different from

that to which the receiver is connected.

• Consult the dealer or an experienced radio TV technician for

help.

Notice:

1. The changes or modifications not expressly approved by the

party responsible for compliance could void the user's authority

to operate the equipment.

2. Shielded interface cables must be used in order to comply with

the emission limits.

Table of Contents

Chapter 1 - Introduction

1.1 Features and Specifications..................................................................................

1.2 Package Checklist.........................................................................................................

Chapter 2 - Hardware Installation

2.1 System Board Layout ...........................................................................................

2.2 System Memory...........................................................................................................

2.3 Jumper Settings for Clearing CMOS Data........................................

2.4 Jumper Settings for Wake-On-Keyboard/Mouse..................................

2.5 Jumper Settings for the Onboard LAN...............................................

2.6 Jumper Settings for the Boot Block Lock/Unlock........................

2.7 Ports and Connectors...........................................................................................

Chapter 3 - Award BIOS Setup Utility

3.1 The Basic Input/Output System.....................................................................

3.1.1 Standard CMOS Features..............................................................

3.1.2 Advanced BIOS Features................................................................

3.1.3 Advanced Chipset Features .......................................................

3.1.4 Integrated Peripherals..........................................................................

3.1.5 Power Management Setup.............................................................

3.1.6 PnP/PCI Configurations.....................................................................

3.1.7 System Health Monitor......................................................................

3.1.8 CPU Frequency Control...................................................................

3.1.9 Load Fail-Safe Defaults......................................................................

3.1.10 Load Optimized Defaults...............................................................

3.1.11 Set Supervisor Password................................................................

3.1.12 Set User Password...............................................................................

3.1.13 Save & Exit Setup..................................................................................

3.1.14 Exit Without Saving...............................................................................

Chapter 4 - Supported Softwares

4.1 Desktop Management Interface.....................................................................

4.2 Hardware Doctor Utility........................................................................................

4.3 Intel 810 INF Update Utility for Windows95/98....................

4.4 IDE, USB and Firmware Hub Patch Utility for Intel 810........

4.5 Intel 810 Graphics Drivers for Windows..............................................

4.6 SoundMAX Audio Drivers for Windows...............................................

4.7 Intel 82559 LAN Driver for Windows....................................................

4.8 Drivers and Utilities Installation Notes.....................................................

Appendix A - Using the Suspend to RAM

Function

A.1 Using the Suspend to RAM Function........................................................

Appendix B - System Error Messages

B.1 POST Beep.......................................................................................................................

B.2 Error Messages..............................................................................................................

Appendix C - Troubleshooting

C.1 Troubleshooting Checklist....................................................................................

Introduction

1.1 Features and Specifications

1.1.1 Features

Chipset

• Intel®810-E

Processor

The system board is equipped with Socket 370. It is also equipped

with a switching voltage regulator that automatically detects 1.30V

to 2.05V.

• Pentium®III FCPGA 133MHz FSB processor

• Pentium®III FCPGA 100MHz FSB processor

• CeleronTM PPGA and FCPGA 66MHz FSB processors

System Memory

• 16MB to 512MB memory using unbuffered DIMMs

• Two 168-pin DIMM sockets

• Uses x64 PC-100 SDRAM DIMM, 3.3V

Chapter 1 - Introduction

DIMMs

2MBx64

4MBx64

8MBx64

16MBx64

32MBx64

Memory Size

16MB

32MB

64MB

128MB

256MB

Introduction

Expansion Slot/Connector

The system board is equipped with a two-slot PCI Riser Card.

It is also equipped with a daughterboard docking connector. Refer to

“Daughterboard Docking Connector” in chapter 2 for more

information.

Onboard Graphics Features

• Graphics memory

- Shares 1MB of the system memory.This is fixed regardless of

the size of the system memory.

- Uses Dynamic Video Memory Technology (DVMT). This freely

changes in size because graphics memory is allocated from

the system memory according to current needs.

- 4MB onboard display cache

• Graphics controller

- 133MHz super AGP performance using 4MB display cache

memory

- 3D hyper pipelined architecture

- 2D hardware and motion video acceleration

- 9-bit precision hardware motion compensation

assistance for software MPEG2 decode

- Software DVD at 30fps

• Resolutions: up to 1600x1200 in 256 color at 75Hz refresh

• Software drivers

- Windows®95/98/ME

- Windows®2000

- Windows NT®4.0

Onboard Audio Features

• Supports Microsoft®DirectSound/DirectSound 3D

• 32-voice wavetable synthesis

• 3D positional audio effects

• AC’97 supported with full duplex, independent sample rate

converter for audio recording and playback

• Downloadable sound (DLS) level-1

• Headphone amplifier

Introduction

Onboard LAN Features

• Uses Intel 82559 fast ethernet controller

• Integrated IEEE 802.3 10BASE-T and 100BASE-TX compatible

PHY

• 32-bit PCI master interface

• Integrated power management functions

• Full duplex support at both 10 and 100 Mbps

• Supports IEEE 802.3u auto-negotiation

• Supports Wired for Management (WfM) feature

Compatibility

• Microsoft PC ’98 compliant

• VESA Display Power Management Signaling (DPMS)

• VESA DDC2B for Plug and Play monitors

• PCI 2.2, AMR 1.0 and AC ’97 compliant

ATX Double Deck Ports (PC 99 color-coded connectors)

• 2 USB ports

• 1 DB-9 serial port

• 1 DB-15 VGA port

• 1 DB-25 parallel port

• 1 mini-DIN-6 PS/2 mouse port

• 1 mini-DIN-6 PS/2 keyboard port

• 1 game/MIDI port

• 3 audio jacks: speaker-out, line-in and mic-in

• 1 RJ45 LAN port

Connectors

• 1 connector for 2 additional external USB ports

• 3 9-pin connectors for external serial ports

• 1 connector for external headphone/mic

• 1 connector for IrDA interface

• 2 IDE connectors

• 1 floppy connector

• 1 20-pin ATX power supply connector

• 1 Wake-On-LAN connector

• 1 Wake-On-Ring connector

• 3 connectors for CPU, chassis and second chassis fans

Introduction

• 1 opened chassis alarm connector

• 4 internal audio connectors (video-in, AUX-in, CD-in and TAD)

• 2 power connectors for touchscreen (optional)

• 1 connector for LCD interface board

PCI Bus Master IDE Controller

• Two PCI IDE interfaces support up to four IDE devices

• Supports Ultra ATA/66 hard drives

• PIO Mode 4 Enhanced IDE (data transfer rate up to 14MB/sec.)

• Bus mastering reduces CPU utilization during disk transfer

• Supports ATAPI CD-ROM, LS-120 and ZIP

IrDA Interface

The system board is equipped with an IrDA connector for wireless

connectivity between your computer and peripheral devices. It

supports peripheral devices that meet the IrDA or ASKIR standard.

USB Ports

The system board supports 4 USB ports. USB allows data exchange

between your computer and a wide range of simultaneously

accessible external Plug and Play peripherals. Refer to “Universal

Serial Bus Ports” in chapter 2 for more information.

BIOS

• Award BIOS, Windows®95/98 Plug and Play compatible

• Supports SCSI sequential boot-up

• Flash EPROM for easy BIOS upgrades (4Mbit)

• Includes NCR 810 SCSI BIOS

• Supports DMI 2.0 function

Desktop Management Interface (DMI)

The system board comes with a DMI 2.0 built into the BIOS. The

DMI utility in the BIOS automatically records various information

about your system configuration and stores these information in the

DMI pool, which is a part of the system board's Plug and Play

BIOS. DMI, along with the appropriately networked software, is

designed to make inventory, maintenance and troubleshooting of

computer systems easier. Refer to chapter 4 for instructions on using

the DMI utility.

Introduction

PCB

• 4 layers, FlexATX form factor

• 22.8cm (9") x 19cm (7.5")

Note:

The system board is designed to fit into a FlexATX chassis. It

provides PCI expansion by installing a two-slot PCI Riser Card.

You may also install the system board into a microATX chassis

but you will be confined to one PCI expansion slot only. Please

refer to “Expansion Slots” in chapter 2 for more information.

1.1.2 System Health Monitor Functions

The system board is capable of monitoring the following “system

health” conditions.

• Monitors processor/system temperature and overheat alarm

• One optional temperature sensor for user customization

• Monitors 5VSB/VBAT/1.5V/3.3V/5V/±12V/processor voltages

and failure alarm

• Monitors processor/chassis/second chassis fan speed, controls

processor/chassis fan speed and failure alarm

• Automatic fan on/off control

• Read back capability that displays temperature, voltage and fan

speed

• Opened chassis alarm

• Supports CeleronTM processor thermal diode output (real

processor temperature)

Refer to “System Health Monitor” in chapter 3 and “Hardware

Doctor Utility” in chapter 4 for more information.

1.1.3 Intelligence

Automatic CPU/Chassis Fan Off

The CPU and chassis fans will automatically turn off once the system

enters the Suspend mode.

Table des matières

Autres manuels DFI Carte mère

DFI

DFI LANParty UT ICFX3200-T2R/G Manuel utilisateur

DFI

DFI AL102 Manuel utilisateur

DFI

DFI NB72-SC Manuel utilisateur

DFI

DFI HD101-H81 Manuel utilisateur

DFI

DFI 586STC Manuel utilisateur

DFI

DFI AD73 Pro Manuel utilisateur

DFI

DFI SB331-D Manuel utilisateur

DFI

DFI ICX610-C621A-000G Manuel utilisateur

DFI

DFI RNO171 Manuel utilisateur

DFI

DFI CMS171 Manuel utilisateur

DFI

DFI ADS630-R680E Manuel utilisateur

DFI

DFI PW65-L Manuel utilisateur

DFI

DFI LanParty LT X38 series Manuel utilisateur

DFI

DFI AD77 INFINITY Manuel utilisateur

DFI

DFI G486VPC Manuel utilisateur

DFI

DFI G7B330-B Manuel utilisateur

DFI

DFI COM630-B Manuel utilisateur

DFI

DFI CMS630-W480E Manuel utilisateur

DFI

DFI DL310-C226 Manuel utilisateur

DFI

DFI 586STE Manuel utilisateur

DFI

DFI CA64-TN Manuel utilisateur

DFI

DFI G586OP Manuel utilisateur

DFI

DFI P2XBL D+ Manuel utilisateur

DFI

DFI G586SP Manuel utilisateur

Manuels Carte mère populaires d'autres marques

ASROCK

ASROCK ROMED8-2T Manuel utilisateur

Asus

Asus P2L97A Manuel utilisateur

Winmate

Winmate IC70 Manuel utilisateur

Asus

Asus MES-B Manuel utilisateur

Grantech

Grantech SYS8F377VGGA-3OMN Manuel utilisateur

Telit Wireless Solutions

Telit Wireless Solutions SL869-3DR Manuel utilisateur

Gigabyte

Gigabyte GA-9IVDT Manuel utilisateur

Texas Instruments

Texas Instruments ADS8372EVM Manuel utilisateur

Commell

Commell MS-C73 Manuel utilisateur

IBT Technologies

IBT Technologies MB860 Manuel utilisateur

Nvidia

Nvidia TEGRA DG-04927-001_V01 Manuel utilisateur

Biostar

Biostar M7VIT Bravo Instructions d'utilisation et d'installation

Intel

Intel D33217CK Manuel utilisateur

Asus

Asus F1A55-M LX PLUS R2.0 Manuel utilisateur

EPC

EPC EPC9147C Manuel utilisateur

Asus

Asus EX-B760M-V5 D4 Manuel utilisateur

EPOX

EPOX MU-8KHA0010 Manuel utilisateur

Ski-Doo

Ski-Doo Bombardier MPEM 219 700 090 Manuel utilisateur
