DFI P5XV3 Manuel utilisateur

P5XV3

Rev. A+

System Board

User’s Manual

34880114

This publication contains information that is protected by copyright.

No part of it may be reproduced in any form or by any means or used

to make any transformation/adaptation without the prior written

permissionfromthecopyrightholders.

This publication is provided for informational purposes only. The

manufacturer makes no representations or warranties with respect to

the contents or use of this manual and specifically disclaims any express

orimpliedwarrantiesofmerchantabilityorfitnessforanyparticularpurpose.

Theuser will assume the entire risk of the use or the results of theuseof

thisdocument.Further,the manufacturerreserves therightto revisethis

publicationandmakechangestoitscontentsatanytime,withoutobligation

to notify any person or entity of such revisions or changes.

Trademarks

Microsoft®MS-DOS®, WindowsTM and Windows®95 are registered

trademarks of Microsoft Corporation. Intel and Pentium are registered

trademarks of Intel Corporation. Cyrix, 6x86, 6x86L and 6x86MX are

registered trademarks of Cyrix Corporation. AMD, K5 and K6 are

registeredtrademarksofAdvancedMicroDevices,Inc. IBMisaregistered

trademark of International Business Machine Corporation. Award is a

registered trademark of Award Software, Inc. Other trademarks and

registered trademarks of products appearing in this manual are the

properties of their respective holders.

Caution:

Danger of explosion if battery incorrectly replaced.

Replace only with the same or equivalent type recommended by the

manufacturer.

Dispose of used batteries according to the battery manufacturer’s

instructions.

FCC and DOC Statement on Class B

This equipment has been tested and found to comply with the limits

for a Class B digital device, pursuant to Part 15 of the FCC rules.

These limits are designed to provide reasonable protection against

harmful interference when the equipment is operated in a residential

installation. This equipment generates, uses and can radiate radio

frequency energy and, if not installed and used in accordance with

the instruction manual, may cause harmful interference to radio

communications. However, there is no guarantee that interference

will not occur in a particular installation. If this equipment does cause

harmful interference to radio or television reception, which can be

determined by turning the equipment off and on, the user is

encouraged to try to correct the interference by one or more of the

following measures:

•Reorient or relocate the receiving antenna.

•Increase the separation between the equipment and the receiver.

•Connect the equipment into an outlet on a circuit different from

that to which the receiver is connected.

•Consult the dealer or an experienced radio TV technician for

help.

Notice:

1. The changes or modifications not expressly approved by the

party responsible for compliance could void the user's authority

to operate the equipment.

2. Shielded interface cables must be used in order to comply with

the emission limits.

Table of Contents

Chapter 1 - Introduction

1.1 Features and Specifications...................................................................

1.2 Package Checklist....................................................................................... 7

Chapter 3 - Award BIOS Setup Utility

3.1 The Basic Input/Output System........................................................

3.1.1 Standard CMOS Setup.......................................................

3.1.2 BIOS Features Setup.............................................................

3.1.3 Chipset Features Setup.......................................................

3.1.4 Power Management Setup................................................

3.1.5 PNP/PCI Configuration.......................................................

3.1.6 Load Fail-Safe Settings..........................................................

3.1.7 Load Optimal Settings..........................................................

3.1.8 Integrated Peripherals...........................................................

3.1.9 Supervisor Password............................................................

3.1.10 User Password.........................................................................

3.1.11 IDE HDD Auto Detection................................................

3.1.12 Save & Exit Setup...................................................................

3.1.13 Exit Without Saving................................................................

Chapter 2 - Hardware Installation

2.1 System Board Layout .............................................................................

2.2 Installation Steps..........................................................................................

2.2.1 Installing System Memory........................................................

2.2.2 Installing a Processor..................................................................

2.2.3 Setting the Jumpers on the System Board..................

2.2.4 Installing Expansion Cards......................................................

2.2.5 Connecting the Ribbon Cables and Wires of the

Ports and Connectors..............................................................

2.2.6 Installing the System Board....................................................

Appendix B - System Error Messages

B.1 POST Beep.........................................................................................................................

B.2 Error Messages................................................................................................................ 72

Appendix C - Troubleshooting

C.1 Troubleshooting Checklist...................................................................................... 75

Chapter 4 - Supported Softwares

4.1 Desktop Management Interface......................................................................

4.2 System Health Monitor Utility............................................................................

4.3 Drivers.....................................................................................................................................

Appendix A - Identifying Processors

A.1 Intel Processors...............................................................................................................

A.2 Cyrix Processors............................................................................................................

A.3 AMD Processors...........................................................................................................

P5XV3 System Board User’s Manual

Introduction

CHAPTER

Introduction

1.1 Features and Specifications

1.1.1 Features

Chipset

•VIAApollo VP3 AGP system chipset

Processor

The system board is equipped with a 321-pin ZIF socket (Socket

7). This socket is designed for easy removal of an old processor

and easy insertion of an upgrade processor. The system board is

also equipped with a switching voltage regulator that supports

2.0V to 3.5V core voltage for various processors.

•Intel Pentiumprocessor with MMXTM technology-166/200/

233MHz

•Intel Pentium90/100/120/133/150/166/200MHz

•Cyrix6x86L PR120+/PR133+/PR150+/PR166+ and

6x86MX-PR166/PR200

•AMDK5 PR90/PR100/PR120/PR133/PR166

•AMDK6-166, K6-200, K6-233 and future K6 processors

System Memory

The system board supports 8MB to 256MB of memory. It is

equipped with two DIMM and two SIMM sockets. The 168-pin

DIMM sockets use x64 EDO (60/70ns) or SDRAM (10/12/13ns),

3.3V. The 72-pin SIMM sockets use EDO or FPM, 60/70ns, x32

DRAM, 5V.

Level 2 Cache Memory

•512KB or 1MB pipeline burst, direct map write-back cache

installed on the system board.

Expansion Slots

The system board is equipped with 1 dedicated AGP slot, 3

dedicated PCI slots, 2 dedicated 16-bit ISA slots and 1 shared PCI/

ISA slot. All PCI and ISA slots are bus masters.

P5XV3 System Board User’s Manual

Desktop Management Interface (DMI)

The system board comes with a DMI 2.0 built into the BIOS. The

DMI utility in the BIOS automatically records various information

about your system configuration and stores these information in

the DMI pool, which is a part of the system board's Plug and Play

BIOS. DMI, along with the appropriately networked software, is

designed to make inventory, maintenance and troubleshooting of

computer systems easier. Refer to Chapter 4 for instructions on

using the DMI utility.

Onboard I/O

•Two NS16C550A-compatible DB-9 serial ports

•One SPP/ECP/EPP DB-25 parallel port

•One floppy drive interface supports up to two 2.88MB floppy

drives

•One mini-DIN-6 PS/2 mouse port

•One mini-DIN-6 PS/2 keyboard port

PCI Bus Master IDE Controller

•Two PCI IDE interfaces support up to four IDE devices

•Ultra DMA/33 supported (Synchronous Ultra DMA mode -

data transfer rate up to a maximum of 33MB/sec.)

•PIO Mode 3 and Mode 4 Enhanced IDE (data transfer rate up

to 16.6MB/sec.)

•Bus mastering reduces CPU utilization during disk transfer

•ATAPI CD-ROM supported

•LS-120 and ZIP supported

IrDA Interface

The system board is equipped with an IrDA connector for wireless

connectivity between your computer and peripheral devices. It

supports infrared peripheral devices that meet the ASKIR or

HPSIR standard.

USB Ports

The system board is equipped with two USB ports. USB allows

data exchange between your computer and a wide range of

simultaneously accessible external Plug and Play peripherals.

Introduction

BIOS

•Award BIOS, Windows95 Plug and Play compatible

•Flash EPROM for easy BIOS upgrades

ATX Power Supply Connector

The system board is equipped with an ATX power supply

connector. Using an ATX power supply, you can either shut down

your computer by pressing the Power button located on the front

bezel of your computer or by executing the Shut Down

command under the Windows95 operating system. Your system

will then enter the “Soft Off” state.

To power-on your system automatically, enable “Resume On Alarm”

in the Power Management Setup of the Award BIOS (Chapter 3).

This will allow you to set the date and time you would like your

system to power-on.

1.1.2 Technology

AGP (Accelerated Graphics Port)

The system board is equipped with 1 AGP slot. AGP is an

interface designed to support high performance 3D graphics cards.

It utilizes a dedicated pipeline to access system memory for

texturing, z-buffering and alpha blending; delivering up to 533MB/

sec. bandwidth for 3D graphics applications. AGP in this Intel

Pentiumprocessor based system board will deliver faster and

better graphics with your PC.

SDRAM (Synchronous Dynamic Random Access Memory)

The system board supports unbuffered SDRAM memory. SDRAM

is a DRAM technology that uses the clock on the chip to

synchronize with the CPU clock so that the timing of the memory

chips and the timing of the CPU are synchronized. This saves time

during transmission of data, subsequently increasing system

performance.

P5XV3 System Board User’s Manual

Ultra DMA/33 Bus Master IDE

Synchronous Ultra DMA mode provides data transfer rate up to a

maximum of 33MB/sec, which is twice the data transfer rate of

Enhanced IDE or ATA-2. This enables the CPU to operate more

efficiently when handling simultaneous events.

ACPI (Advanced Configuration and Power Interface)

The system board is designed to meet the ACPI specification. ACPI

has energy saving features that enables PCs to implement Power

Management and Plug-and-Play with operating systems that support

OS Direct Power Management.

PC ‘97 Compliant

The system board is PC ’97 compliant. This will optimize your PC

system to run Windows95 and Windows NTand future

versions of these operating systems.

1.1.3 Intelligence

Monitors Processor Temperature and Overheat Alarm

The system board is able to detect the temperature of the

processor. An alarm will sound in case of processor overheat. Refer

to Chipset Features Setup (Chapter 3) and System Health

Monitor Utility (Chapter 4).

Monitors Processor/AGP Fan Speed and Failure Alarm

The system board is able to detect the fan speed (RPM-

Revolutions Per Minute) of the processor and AGP fans, and alerts

you to attend to any irregularity that may damage your system.

Refer to Chipset Features Setup (Chapter 3) and System Health

Monitor Utility (Chapter 4).

Monitors Power Voltages and Failure Alarm

The system board is able to detect the output voltage of the power

supply. An alarm will sound warning you of voltage irregularity.

Refer to Chipset Features Setup (Chapter 3) and System Health

Monitor Utility (Chapter 4).

Table des matières

Autres manuels DFI Carte mère

DFI

DFI CR100-CRM Manuel utilisateur

DFI

DFI AL170 Manuel utilisateur

DFI

DFI P5BV3+/e Manuel utilisateur

DFI

DFI K6XV3+/66 Manuel utilisateur

DFI

DFI G5C900-B Manuel utilisateur

DFI

DFI CS35-EC Manuel utilisateur

DFI

DFI NS70-EC Manuel utilisateur

DFI

DFI CA230-BF Manuel utilisateur

DFI

DFI C586VX Manuel utilisateur

DFI

DFI PB50-ZX Manuel utilisateur

DFI

DFI HM101-QM87 Manuel utilisateur

DFI

DFI nF2 U400SG-AGF Manuel utilisateur

DFI

DFI LANPARTY UT X58 t3eh8 Manuel utilisateur

DFI

DFI PT880-ALE Manuel utilisateur

DFI

DFI SD101-Q170 Manuel utilisateur

DFI

DFI CA64-BC Manuel utilisateur

DFI

DFI CW35-TC Manuel utilisateur

DFI

DFI NB78-BC Manuel utilisateur

DFI

DFI CS551 Manuel utilisateur

DFI

DFI PB50-V3 Manuel utilisateur

DFI

DFI Blood-Iron LanParty Bi 785G-M35 Manuel utilisateur

DFI

DFI ADS310-R680E/Q670E Manuel utilisateur

DFI

DFI SB336-Ni Manuel utilisateur

DFI

DFI AL102 Manuel utilisateur

Manuels Carte mère populaires d'autres marques

ASROCK

ASROCK ROMED8-2T Manuel utilisateur

Asus

Asus P2L97A Manuel utilisateur

Winmate

Winmate IC70 Manuel utilisateur

Asus

Asus MES-B Manuel utilisateur

Grantech

Grantech SYS8F377VGGA-3OMN Manuel utilisateur

Telit Wireless Solutions

Telit Wireless Solutions SL869-3DR Manuel utilisateur

Gigabyte

Gigabyte GA-9IVDT Manuel utilisateur

Texas Instruments

Texas Instruments ADS8372EVM Manuel utilisateur

Commell

Commell MS-C73 Manuel utilisateur

IBT Technologies

IBT Technologies MB860 Manuel utilisateur

Nvidia

Nvidia TEGRA DG-04927-001_V01 Manuel utilisateur

Biostar

Biostar M7VIT Bravo Instructions d'utilisation et d'installation

Intel

Intel D33217CK Manuel utilisateur

Asus

Asus F1A55-M LX PLUS R2.0 Manuel utilisateur

EPC

EPC EPC9147C Manuel utilisateur

Asus

Asus EX-B760M-V5 D4 Manuel utilisateur

EPOX

EPOX MU-8KHA0010 Manuel utilisateur

Ski-Doo

Ski-Doo Bombardier MPEM 219 700 090 Manuel utilisateur
