DFI NB72-SC Manuel utilisateur

NB72-SC

NB72-SR

Rev. B+

System Board

Users Manual

50020142

This publication contains information that is protected by copyright.

No part of it may be reproduced in any form or by any means or

used to make any transformation/adaptation without the prior

written permission from the copyright holders.

This publication is provided for informational purposes only. The

manufacturer makes no representations or warranties with respect to

the contents or use of this manual and specifically disclaims any

express or implied warranties of merchantability or fitness for any

particular purpose. The user will assume the entire risk of the use or

the results of the use of this document. Further, the manufacturer

reserves the right to revise this publication and make changes to its

contents at any time, without obligation to notify any person or

entity of such revisions or changes.

rademarks

Windows® 98, Windows® 98 SE, Windows® ME, Windows® 000

and Windows NT® 4.0 are registered trademarks of Microsoft

Corporation. Intel® and Pentium® 4 are registered trademarks of

Intel Corporation. Award is a registered trademark of Award

Software, Inc. Other trademarks and registered trademarks of

products appearing in this manual are the properties of their

respective holders.

Caution

To avoid damage to the system:

 Use the correct AC input voltage range.

To reduce the risk of electric shock:

 Unplug the power cord before removing the system chassis

cover for installation or servicing. After installation or servicing,

cover the system chassis before plugging the power cord.

Battery:

 Danger of explosion if battery incorrectly replaced.

 Replace only with the same or equivalent type recommend by

the manufacturer.

 Dispose of used batteries according to the battery

manufacturers instructions.

Joystick or MIDI port:

 Do not use any joystick or MIDI device that requires more than

10A current at 5V DC. There is a risk of fire for devices that

exceed this limit.

FCC and DOC Statement on Class B

This equipment has been tested and found to comply with the limits

for a Class B digital device, pursuant to Part 15 of the FCC rules.

These limits are designed to provide reasonable protection against

harmful interference when the equipment is operated in a residential

installation. This equipment generates, uses and can radiate radio

frequency energy and, if not installed and used in accordance with

the instruction manual, may cause harmful interference to radio

communications. However, there is no guarantee that interference

will not occur in a particular installation. If this equipment does cause

harmful interference to radio or television reception, which can be

determined by turning the equipment off and on, the user is

encouraged to tr y to correct the interference by one or more of the

following measures:

 Reorient or relocate the receiving antenna.

 Increase the separation between the equipment and the receiver.

 Connect the equipment into an outlet on a circuit different from

that to which the receiver is connected.

 Consult the dealer or an experienced radio TV technician for

help.

Notice:

1. The changes or modifications not expressly approved by the

party responsible for compliance could void the user's authority

to operate the equipment.

. Shielded interface cables must be used in order to comply with

the emission limits.

Notice

This users manual contains detailed information about the system

board. If, in some cases, some information doesnt match those

shown in the multilingual manual, the multilingual manual should

always be regarded as the most updated version. The multilingual

manual is included in the system board package.

To view the users manual, insert the CD into a CD-ROM drive. The

autorun screen (Main Board Utility CD) will appear. Click Users

Manual.

System Board

This users manual is for the NB7 -SC and NB7 -SR system boards.

The differences between these boards are shown below.

NB72-SC NB72-SR

(Supports RAID)

Promise controller

RAID IDE connectors

RAID LED connector

Table of Contents

C apter 1 - Introduction

1.1 Features and Specifications..................................................................................

1. Package Checklist.........................................................................................................

C apter 2 - Hardware Installation

.1 System Board Layout ..........................................................................................

. System Memory...........................................................................................................

.3 Jumper Settings for Clearing CMOS Data........................................

.4 Jumper Settings for Wake-On-Keyboard/Mouse..................................

.5 Jumper Settings for Wake-On-USB Keyboard................................

.6 Jumper Settings for Selecting the CPUs Front Side Bus......

.7 Jumper Settings for USB 4................................................................................

.8 Por ts and Connectors...........................................................................................

C apter 3 - Award BIOS Setup Utility

3.1 The Basic Input/Output System.....................................................................

3.1.1 Standard CMOS Features.............................................................

3.1. Advanced BIOS Features..............................................................

3.1.3 Advanced Chipset Features ......................................................

3.1.4 Integrated Peripherals.........................................................................

3.1.5 Power Management Setup............................................................

3.1.6 PnP/PCI Configurations....................................................................

3.1.7 PC Health Status...................................................................................

3.1.8 CPU Frequency Control..................................................................

3.1.9 Load Fail-Safe Defaults.....................................................................

3.1.10 Load Optimized Defaults..............................................................

3.1.11 Set Supervisor Password...............................................................

3.1.1 Set User Password..............................................................................

3.1.13 Save & Exit Setup.................................................................................

3.1.14 Exit Without Saving..............................................................................

Introduction



C apter 4 - Supported Softwares

4.1 Desktop Management Interface.....................................................................

4. Hardware Doctor..........................................................................................................

4.3 Intel 845 INF Update Utility for Windows 98/ 000/ME...

4.4 Audio Drivers and Software Application...............................................

4.5 Microsoft DirectX 8.0 Driver.............................................................................

4.6 Drivers and Utilities Installation Notes.....................................................

Appendix A - Using t e Suspend to RAM

Function

A.1 Using the Suspend to RAM Function........................................................

Appendix B - System Error Messages

B.1 POST Beep.......................................................................................................................

B. Error Messages..............................................................................................................

Appendix C - Troubles ooting

C.1 Troubleshooting Checklist....................................................................................



Introduction

1.1 Features and Specifications

1.1.1 Features

C ipset

 Intel® 845 chipset

- Intel® 8 845 Memory Controller Hub (MCH)

- Intel® 8 801BA I/O Controller Hub (ICH )

Processor

The system board is equipped with Socket 478 for installing a

Pentium® 4 processor.

 Intel® Pentium® 4 processor (478-pin)

 400MHz system data bus

System Memory

 Three 168-pin PC SDRAM DIMM sockets

 Suppor ts 3GB system memory

- Uses 64Mbit, 1 8Mbit, up to 1.5GB using 56Mbit or up to

3GB using 51 Mbit technology, PC-133 PC SDRAM DIMM

 Supports ECC function

Chapter 1 - Introduction

DIMMs

MBx64/x7

4MBx64/x7

8MBx64/x7

Memory Size

16MB

3 MB

64MB

DIMMs

16MBx64/x7

3 MBx64/x7

64MBx64/x7

Memory Size

1 8MB

56MB

51 MB

Introduction



Expansion Slots

The system board is equipped with 1 AGP slot, 4 dedicated PCI

slots and 1 shared PCI/CNR slot.

The AGP slot only supports 1.5V AGP 4x (1066MB/sec. bandwidth)

add-in cards. AGP is an interface designed to support high

performance 3D graphics cards for 3D graphics applications. It

handles large amounts of graphics data with the following features:

 Pipelined memory read and write operations that hide memor y

access latency.

 Demultiplexing of address and data on the bus for nearly 100

percent efficiency.

CNR (Communication and Networking Riser) is an interface that

supports multi-channel audio, V.90 analog modem, phone-line based

networking or 10/100 Ethernet based networking riser board.

Onboard Audio Features

 18-bit stereo full-duplex codec with independent variable sam-

pling rate

 High quality differential CD input

 True stereo line level outputs

Compatibility

 Microsoft PC 98 compliant

 PCI . , CNR 1.0 A type and AC 97 compliant

 Intel AGP version .0

ATX Double Deck Ports (PC 99 color-coded connectors)

 Two USB ports

 Two NS16C550A-compatible DB-9 serial ports

 One SPP/ECP/EPP DB- 5 parallel port

 One mini-DIN-6 PS/ mouse port

 One mini-DIN-6 PS/ keyboard port

 One game/MIDI port

 Three audio jacks: line-out, line-in and mic-in



Introduction

Connectors

 One connector for additional external USB por ts

 One connector for IrDA interface

 Two IDE connectors

 Two RAID IDE connectors (NB7 -SR)

 One floppy drive interface supports up to two .88MB floppy

drives

 Three ATX power supply connectors

 One Wake-On-LAN connector

 One Wake-On-Ring connector

 CPU, system and second fan connectors

 One opened chassis alarm connector

 Two internal audio connectors (CD-in and TAD)

ATA RAID - Redundant Array of Inexpensive Disk (NB72-SR)

 RAID 0 (striping) or RAID 1 (mirroring) - RAID 0 and RAID 1

cannot coexist

 Two independent IDE channels support up to 4 drives (UDMA

modes 33/66/100 or EIDE)

 Supports PIO modes 0/1/ /3/4, DMA modes 0/1/ and

UDMA modes 0/1/ /3/4/5

PCI Bus Master IDE Controller

 Two PCI IDE interfaces support up to four IDE devices

 Supports ATA/33, ATA/66 and ATA/100 hard drives

 PIO Mode 4 Enhanced IDE (data transfer rate up to 14MB/sec.)

 Bus mastering reduces CPU utilization during disk transfer

 Supports ATAPI CD-ROM, LS-1 0 and ZIP

IrDA Interface

The system board is equipped with an IrDA connector for wireless

connectivity between your computer and peripheral devices. It

supports peripheral devices that meet the IrDA or ASKIR standard.

USB Ports

The system board supports 4 USB ports. Two onboard USB ports

are located at the ATX double deck ports of the board. The J16

connector on the system board allows you to connect the optional

Introduction



3rd and 4th USB ports. These optional USB por ts, which are

mounted on a card-edge bracket, will be provided as an option.

USB allows data exchange between your computer and a wide

range of simultaneously accessible external Plug and Play peripherals.

BIOS

 Award BIOS, Windows® 98/ 000/ME Plug and Play compatible

 Supports SCSI sequential boot-up

 Flash EPROM for easy BIOS upgrades

 Supports DMI .0 function

Desktop Management Interface (DMI)

The system board comes with a DMI .0 built into the BIOS. The

DMI utility in the BIOS automatically records various information

about your system configuration and stores these information in the

DMI pool, which is a part of the system board's Plug and Play

BIOS. DMI, along with the appropriately networked software, is

designed to make inventory, maintenance and troubleshooting of

computer systems easier. Refer to chapter 4 for instructions on using

the DMI utility.

1.1.2 System Healt Monitor Functions

The system board is capable of monitoring the following system

health conditions.

 Monitors CPU/system temperature and overheat alarm

 Monitors 5VSB/VBAT/3.3V/5V/±1 V/CPU voltages and failure

alarm

 Monitors the fan speed of the CPU fan, system fan and second

fan; and failure alarm

 Automatic system fan and second fan on/off control

 Read back capability that displays temperature, voltage and fan

speed

 Opened chassis alarm

Refer to the PC Health Status section in chapter 3 and the

Hardware Doctor section in chapter 4 for more information.

Autres manuels pour NB72-SC

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels DFI Carte mère

DFI

DFI SB332-C Manuel utilisateur

DFI

DFI 945G-TMGF Manuel utilisateur

DFI

DFI PR810-C622 Manuel utilisateur

DFI

DFI PT332-DRM Manuel utilisateur

DFI

DFI CP900-B Manuel utilisateur

DFI

DFI CT132-BR Manuel utilisateur

DFI

DFI G586IPV Manuel utilisateur

DFI

DFI LR102 SERIES Manuel utilisateur

DFI

DFI CS650-C246 Manuel utilisateur

DFI

DFI P2XBL D+ Manuel utilisateur

DFI

DFI Infinity NF series Manuel utilisateur

DFI

DFI ADS630-R680E Manuel utilisateur

DFI

DFI NS80-EA Manuel utilisateur

DFI

DFI SB336-Ni Manuel utilisateur

DFI

DFI GIC68-D Manuel utilisateur

DFI

DFI 586ITOX Manuel utilisateur

DFI

DFI CR101-D Manuel utilisateur

DFI

DFI G5M300-P Manuel utilisateur

DFI

DFI HD630-H81 Manuel utilisateur

DFI

DFI WL051 Manuel utilisateur

DFI

DFI SD631-C236 Manuel utilisateur

DFI

DFI LanParty UT nF3 Ultra-D Manuel utilisateur

DFI

DFI LanParty DK P35 series Manuel utilisateur

DFI

DFI AK74-SC Manuel utilisateur

Manuels Carte mère populaires d'autres marques

ASROCK

ASROCK ROMED8-2T Manuel utilisateur

Asus

Asus P2L97A Manuel utilisateur

Winmate

Winmate IC70 Manuel utilisateur

Asus

Asus MES-B Manuel utilisateur

Grantech

Grantech SYS8F377VGGA-3OMN Manuel utilisateur

Telit Wireless Solutions

Telit Wireless Solutions SL869-3DR Manuel utilisateur

Gigabyte

Gigabyte GA-9IVDT Manuel utilisateur

Texas Instruments

Texas Instruments ADS8372EVM Manuel utilisateur

Commell

Commell MS-C73 Manuel utilisateur

IBT Technologies

IBT Technologies MB860 Manuel utilisateur

Nvidia

Nvidia TEGRA DG-04927-001_V01 Manuel utilisateur

Biostar

Biostar M7VIT Bravo Instructions d'utilisation et d'installation

Intel

Intel D33217CK Manuel utilisateur

Asus

Asus F1A55-M LX PLUS R2.0 Manuel utilisateur

EPC

EPC EPC9147C Manuel utilisateur

Asus

Asus EX-B760M-V5 D4 Manuel utilisateur

EPOX

EPOX MU-8KHA0010 Manuel utilisateur

Ski-Doo

Ski-Doo Bombardier MPEM 219 700 090 Manuel utilisateur
