DELTA DORE Tywatt EM.IC Manuel utilisateur

EM.IC

Consumption information transmitter

for double-service heat pump

2 3

1 - Installation

Install the EM.IC around 1.50 m off the ground.

2 - Mounting - connection

- Switch off the installation power supply

- Install the device around 1.50 m off the ground

to enhance radio propagation.

- Connect the power supply to terminals 1 and 2.

- To select the cabling suitable for your installation,

consult the specications contained

in the assembly instructions or in the specications

provided by the manufacturer of your heat pump

You can nd installation diagrams adapted

to your heat pump on the EM.IC page of

the www.deltadore.com site

1,50 m

Heat pump

20 cm 1

230V~

50 Hz

OFF

230V~

50 Hz

1 2 3

230V

50 Hz

...

4 5

3 - Pairing with an RT2012 system manager

4 - Pairing with the Tydom app

Your installation is equipped with a Tywatt

5400/5450, which is already paired with the

Tydom application - pair the EM.IC with the Tydom

application.

From the Tydom application, select

Settings > My home > My devices > Add a device >

Consumption > then select your previously paired

Tywatt with which you wish to pair the EM.IC and

follow the on-screen instructions.

>3s

2 43

... ... ... .. .. ..... .. ..

OFF

5 6

>3s

21 43

OFF

... ... ... .. .. ..... .. ..

Set the

system manager

to pending pairing.

Read the instructions

- Hold down the button for 3 seconds

until the LED ashes, then release.

- Briey press the button, the LED will ash quickly.

- Hold down the button for 3 seconds

until the LED ashes, then release.

- Briey press the button, the LED will ash quickly.

Check on

the system ma-

nager

that the pairing

was successful

Check that the LED on the EM.IC

is no longer ashing.

The products are now paired.

6 7

5 - Reset to factory settings

❶Hold down the receiver button for 10 seconds:

- after 3 seconds, the LED ashes slowly.

- after 7 seconds, the LED ashes quickly.

- press and hold the button until the LED goes

out.

❷Release.

All paired devices are now deleted.

RESET OK

>10s

3s 7s

... ... ...

OFF

.. .. ..... .. ..

Technical specications

- Power supply: 230 V~, 50 Hz,

- Consumption : 1 VA

- Class II insulation

- Type 1 action

- Rated impulse withstand voltage: 2500 V

- Ball test temperature: 75°C

- Storage temperature: -10°C / +70°C

- Operating temperature: 0°C / +55°C

- IP 44 with the supplied cable.

Vertical positioning of the product

- Dimensions: 54 x 140 x 25 mm

- X3D wireless remote control device:

868.7 MHz to 869.2 MHz

- Maximum wireless power < 10 mW

- Category 2 receiver

- Installation in an environment with normal pollution

levels

- Cable: 3 x 0.75 mm2(type H05VV-F)

Min. diameter: 6.5 mm.

Length: 1 m.

If the EM.IC is paired with the Tydom application,

begin by deleting the pairing via the Tydom

application.

03/23

www.deltadore.com
