DeLonghi DCH7993ER.BC Manuel utilisateur

IMPORTANT SAFEGUARDS

Danger!

Failure to observe the warning may result in life threatening

injury by electric shock.

- The appliance must not be placed im-

mediately under a xed power socket.

- Do not use the appliance near show-

ers, bathtubs, sinks, swimming pools,

etc.

- If the power cable is damaged, it must

be replaced by the manufacturer, an

authorised service centre or a qualied

electrician in order to eliminate all risk.

Important!

Failure to observe the warning could result in injury or

damage to the appliance.

- This appliance can be used by children

aged from 8 years and above and per-

sons with reduced physical, sensory or

mental capabilities or lack of experien-

ce and knowledge if they have been

given supervision or instruction con-

cerning use of the appliance in a safe

way and understand the hazards in-

volved. Children shall not play with the

appliance. Cleaning and user mainte-

nance shall not be made by children

without supervision.

- Children of less than 3 years should be

kept away unless continuously super-

vised.

- Children aged from 3 years and less

than 8 years shall only switch on/o

the appliance provided that it has been

placed or installed in its intended nor-

mal operating position and they have

been given supervision or instruction

concerning use of the appliance in a

safe way and understand the hazards

involved. Children aged from 3 years

and less than 8 years shall not plug

in, regulate and clean the appliance or

perform user maintenance.

CAUTION — Some parts of this

product can become very hot and

cause burns. Particular attention

has to be given where children

and vulnerable people are pre-

sent.

- ATTENTION: To avoid the safety sy-

stem resetting accidentally, this ap-

pliance must not be powered through

an external on/o device such as a

timer, or connected to a circuit which

is turned o and on regularly by the

energy supplier.

- Do not use the appliance in small

rooms when they are occupied by

persons that are not capable of leaving

the room, unless constant supervision

is provided.

Danger of burns!!

Failure to observe the warning could result in burns or scalds.

- WARNING: To avoid overhe-

ating, never under any cir-

cumstances cover the appliance

during operation as this would lead to

a dangerous rise in temperature.

Please note:

This symbol indicates recommendations and important

information for the user.

- Always use the appliance in an upright position.

- The use of extension leads is not recommended.

However if they cannot be avoided, follow the instruc-

tions accompanying the extension lead and never

exceed the power limit marked on the extension.

- The heater must be positioned at least 50 cm from furni-

ture or other objects.

- Do not use the appliance in rooms with a oor area of

less than 4m2.

- Before putting the appliance away, make sure it is com-

pletely o and unplugged from the mains socket. Wrap

the cable around the base.

Do not store in dusty atmospheres.

- Do not rest anything on the appliance.

- Do not use the appliance to dry laundry. Do not obstruct

the air intake and outlet grilles (danger of overheating).

- Do not use the appliance near walls, furniture, curtains,

etc.

Safety functions

-Safety device: the appliance is tted with a safety

device which switches it o in the event of accidental

overheating (e.g. obstruction of air intake and outlet

grilles, motor turning slowly or not at all).

To reset, unplug the appliance from the mains socket

for a few minutes, remove the cause of overheating

then plug in again. If the appliance doesn't work please

contact the De'Longhi Customer Service.

-Tip over safety device: a tip over safety device turns

the appliance o if it falls over or is positioned inappro-

priately in such a way as to jeopardise safety.

The appliance emits a beep and a dot ashes on the di-

splay. The appliance resumes operation a few seconds

after being placed in an upright position again.

Disposing of the appliance

The appliance must not be disposed of with hou-

sehold waste, but taken to an authorised waste se-

paration and recycling centre.

DESCRIPTION

(see g. 1)

A ON/STAND-BY button

B +/- adjustment buttons

C MODE button (selects the operating mode)

D “ECO plus”button

E Timer button

F Swing button

G Remote control receiver

H Remote control

I Indicator light

J Air intake grille

K Filter

USE

Installation

The appliance can be used on any horizontal surface.

Do not overload the electrical circuit. Avoid using the same

socket for other appliances.

Electrical connection

-Before plugging the appliance into the mains socket,

check that the mains power supply corresponds to the

value indicated on the rating plate and that the mains

power supply is adequate for the load.

- THIS APPLIANCE COMPLIES WITH DIRECTIVE 2004/108/

EEC ON RADIO INTERFERENCE SUPPRESSION.

Operation and use

- Plug into the mains socket.

- The appliance emits a beep. The indicator light (I) comes

on and remains lit while the appliance is powered.

- The appliance switches to stand-by. A dot ashing

on the display means the tip over device has been

activated. See paragraph:“Safety functions”.

- Press the ON/STAND-BY (A) to turn the appliance on.

It begins heating the room according to the current

settings.

- Press the MODE button (C) to select one of the following

operating modes:

-Fan

In this mode, only the fan operates and the appliance

does not heat the room.

-Freeze prevention

In this mode, the appliance keeps the room at a

temperature of 7°C to avoid freezing.

-Heating

In this mode, the desired temperature can be selected

by pressing the adjustment buttons + and – (B):

-Heating

Silent+

The appliance operates at minimum power, automati-

cally reducing energy consumption and noise level. The

tones emitted by the commands are lower than in other

modes for even more silent operation.

-Heating

The appliance operates at medium power.

-Heating

The appliance operates at high power to heat the room

rapidly.

“ECO plus” function

The“ECOplus”functionisavailableinHeating1,2and3modes

only.To activate the function, press the “ECO plus”button (D).

When this function is active the appliance automatically sets

the most appropriate power level to guarantee optimum

comfort while reducing energy consumption.

While the “ECO plus” function is active, the appliance may

switch automatically to a lower heating power than the one

displayed. This may happen a number of times in an hour.

- To distribute the air ow over a wider surface, press the

swing button (F) . The appliance starts swinging to

the right and left. To stop the appliance in the desired

position, simply press the swing button (F) again.

- To turn the appliance o, press the ON/STAND-BY

button (A). The display may visualize a countdown for

about 6 seconds.

Please note: Room temperature can be displayed in

either °C or °F. To change the unit of measurement for the

temperature, press the + button for a few seconds, then

release.

Digital 24 h timer

This function can be activated from any operating mode.

Auto-start: with the appliance in STAND-BY, press the timer

button (E) . The symbol is displayed together with

the time remaining before the appliance comes on.

To adjust the timer, use the adjustment buttons + and - (B),

then wait a few seconds for the setting to be memorised.

The stand-by light (I) is displayed together with the

symbol, indicating that the timer has been set. When the

programmed time is reached, the appliance comes on with

the settings used during the previous period of operation.

Auto-o: with the appliance on, press the timer button

(E). The symbol is displayed together with the time

remaining before the appliance goes o.

To set the timer, use the adjustment buttons + and - (B),

then wait a few seconds for the setting to be memorised.

The current settings are displayed again, together with the

symbol indicating that the timer has been set.

When the programmed time is reached, the appliance goes

o automatically. To go back to operation without the timer,

press the timer button (E) twice.

The timer symbol disappears from the display.

USING THE REMOTE CONTROL

The functions on the remote control are the same as those on

the appliance control panel.

For a description of the functions, see the“Operation and use”

section on the previous page.

Inserting or replacing the batteries

The remote control is powered

by a CR2032 lithium battery.

To operate the remote control,

pull and remove the plastic

strip under the battery cover.

To replace thebatteries,remove

the battery cover by sliding it as

shown in the gure.

When replacing the batteries,

make sure you respect the

polarity (see gure 2).

Replace the cover as shown in the gure.

Old batteries are harmful to the environment and must

be removed and disposed of in compliance with current

legislation.

MAINTENANCE

- Always unplug from the mains socket before cleaning.

- During the season when the appliance is in use, clean

the air intake and outlet grilles regularly using a vacuum

cleaner.

- To clean the lter, remove the rear grille by pulling it

outwards (g. 1).

Remove the dust lter which retains impurities in the air

drawn in from the room, blow on it lightly then replace

in the appliance.

- Never use abrasive powders or solvents to clean the

appliance.

TECHNICAL CHARACTERISTICS

Supply voltage See rating plate

Absorbed power “

Fig. 2

PROBLEM CAUSE SOLUTION

PF display and emits a beep Temperature sensor is not working

properly

Please contact Customer Service

Product doesn’t turn on Check that the plug is connected to the

outlet

Auto-start is on

Room temperature reaches the set

temperature

Plug in

Wait till time elapsed or press the but-

ton (E) twice to cancel the auto-start

and push the button (A)

Use the “+” button to increase the set

temperature

The appliance goes o unexpectedly Check that the plug is connected to the

outlet

The set temperature has been reached

or the time set on the timer has elapsed

Plug in

A dot is ashing and unit is o The tip-over switch has been activated Make sure the appliance is standing

upright on a at surface.

If the appli-

ance doesn’t work please contact Cus-

tomer Service

The display shows "Ht" blinking The internal temperature is too high.

The air intake or outlet grille is

obstructed

Check the appliance is correctly

positioned respecting the minum

distances from the wall, or objects, as

indicated on the instruction manual,

if not, position the appliance correctly

Remove the obstruction

Disconnect the plug from the outlet

and let the appliance cool down. After

few minutes plug the appliance again.

If the appliance doesn't work

please

contact Customer Service

TROUBLESHOOTING

Autres manuels DeLonghi Chauffage

DeLonghi

DeLonghi DCH4530 Manuel utilisateur

DeLonghi

DeLonghi HCO620FT Manuel utilisateur

DeLonghi

DeLonghi DCH5915ER Manuel utilisateur

DeLonghi

DeLonghi HCS Manuel utilisateur

DeLonghi

DeLonghi TRD40615ECA Manuel utilisateur

DeLonghi

DeLonghi Electric oil filled radiator Manuel utilisateur

DeLonghi

DeLonghi TRH0715 Manuel utilisateur

DeLonghi

DeLonghi KH770920CB Manuel utilisateur

DeLonghi

DeLonghi FAN HEATER Manuel utilisateur

DeLonghi

DeLonghi HFS70B Manuel utilisateur

DeLonghi

DeLonghi Dragon 4 Pro Manuel utilisateur

DeLonghi

DeLonghi 6507L Manuel d'instructions d'installation

DeLonghi

DeLonghi HVY1020 Mini Manuel utilisateur

DeLonghi

DeLonghi DFH232 Manuel utilisateur

DeLonghi

DeLonghi HWB5050T Manuel utilisateur

DeLonghi

DeLonghi HMP1500 Manuel d'instructions d'installation

DeLonghi

DeLonghi HVA Series Manuel utilisateur

DeLonghi

DeLonghi DCH5090ER Manuel utilisateur

DeLonghi

DeLonghi Heater Manuel utilisateur

DeLonghi

DeLonghi TRRSE Series Manuel utilisateur

DeLonghi

DeLonghi TRD40615E-6A Manuel utilisateur

DeLonghi

DeLonghi HOR KH590715 Manuel utilisateur

DeLonghi

DeLonghi HVF3031 Instructions de montage

DeLonghi

DeLonghi HOR KH770715CB Manuel utilisateur

Manuels Chauffage populaires d'autres marques

oventrop

oventrop Regucor Series Manuel utilisateur

Blaze King

Blaze King CLARITY CL2118.IPI.1 Manuel utilisateur

ELMEKO

ELMEKO ML 150 Manuel utilisateur

BN Thermic

BN Thermic 830T Manuel utilisateur

KING

KING K Series Mode d’emploi

Empire Comfort Systems

Empire Comfort Systems RH-50-5 Guide de démarrage rapide

Well Straler

Well Straler RC-16B Manuel utilisateur

EUROM

EUROM 333299 Manuel utilisateur

Heylo

Heylo K 170 Manuel utilisateur

Eterna

Eterna TR70W Manuel utilisateur

Clarke

Clarke GRH15 Mode d’emploi

IRSAP

IRSAP The Radiator Company Ovali Manuel utilisateur

Empire Heating Systems

Empire Heating Systems WCC65 Manuel utilisateur

Wetekom

Wetekom 92 86 43 Manuel utilisateur

Desa

Desa SPC170-F Manuel utilisateur

Watlow

Watlow Watrod Electric Tubular Heaters Manuel utilisateur

Haverland

Haverland ECO-DRY GPS Series Manuel de la liste des pièces

Stelpro

Stelpro ASILVC2060 Series Manuel utilisateur
