Cartridge Care and Cleaning: Dell™PowerVault™110T SDLT 320 Tape Drive User's

Guide

•Appearance of SDLT Tapes •Cleaning the Tape Mechanism •Caring for Tape Cartridges

Appearance of SDLT Tapes

From the outside, the Super DLTtape™cartridge looks very similar to the DLTtape IV cartridges. The basic geometry, write protection switch, and label space are unchanged

from the DLTtape IV cartridge. This simplifies the integration of Super DLTtape into existing operating environments and into automated tape libraries.

The Super DLTtape cartridge is easy to recognize; it has a different color than the DLTtape IV cartridge and contains a distinctive pattern molded into the shell. The Super

DLTtape cartridge has a keying feature to ensure you can not load it into previous generation DLTtape systems.

Cleaning the Tape Mechanism

When to Use the Cleaning Cartridge

SuperDLTtape drives do not require regular preventative cleaning due to improvements in the design. Do not clean your drive unless required. Your backup software or the

yellow Cleaning Required light (LED) notify you if you need to clean the drive. The location of the yellow Cleaning Required LED is shown in Figure 1.

Figure 1. Front Panel LEDs

Compatibility

The SDLT cleaning cartridge is for use in Super DLTtape drives, autoloaders, and libraries only.

Capacity

Each SDLT cleaning cartridge is good for 20 uses. Use one of the attached labels to keep track of the number of uses.

Loading a Cleaning Cartridge

To load a cleaning cartridge, follow these steps:

1. Insert the cleaning cartridge (with the front slide label slot facing outward) fully into the drive until the drive engages the cartridge and begins to take up the cleaning

media.

The green In Use light will blink and the cleaning cycle will begin automatically.

When the cleaning cycle completes the cartridge automatically ejects from the drive and the yellow Cleaning Required light shuts off.

2. Remove the cartridge, place it back into a plastic case, and mark the label after each cleaning.

For additional details about using cleaning cartridges in autoloaders and libraries, refer to the owner's manual for that product.

Cleaning Cartridge Care



1

Drive

Density

LED

(Amber)

2

Drive

Status

LED

(Green)

3

Cleaning

Required

LED

(Yellow)

4

Eject

Button

NOTE: On the last cleaning, the cleaning cartridge will not eject. Use the Eject button on the front of the drive to eject the expired cleaning cartridge and dispose of

the cartridge.

lProtect cartridges from shock, vibration and magnetic fields.

lAvoid exposure to direct sunlight, heat and moisture.

lStore cleaning cartridges vertically.

lNever touch the tape or tape leader. Dust and oils from your skin will contaminate the tape and affect performance.

lAlways visually inspect a media cartridge before placing it in the drive. If damage is apparent, do not use the cartridge.



Caring for Regular (Non-cleaning) Tape Cartridges

lAlways keep each tape cartridge in its protective plastic case when it is not in the tape drive.

lWhen carrying tape cartridges in their cases, always orient the cases so that the grooves in the cases interlock. This prevents the cases from slipping apart and falling.

lNever stack the tape cartridges in a stack of more than five.

lWhen placing tape cartridges in archival storage, stand each tape cartridge vertically.

lDo not carry cartridges loosely in a box or any other container. Allowing cartridges to hit together exposes them to unnecessary physical shock.

lAlways observe the proper environmental conditions for the storage of tape cartridges. Refer to the cartridge reference card supplied with each cartridge. The ambient

operating environment for the tape cartridge is:

lIf storage or transportation of a tape cartridge have exposed it to conditions outside the ambient values above, "condition" the tape cartridge to its operating environment

for a 24-hour period.

lDo not place cartridges on or near devices that may produce magnetic fields such as computer monitors, motors, or video equipment. Such exposure can alter or

erase data on the tape.

lNever apply adhesive labels or adhesive notes on the top, side, or bottom of a tape cartridge. Only use the user slide-in type label provided with each cartridge and

slide it over the label slot on the cartridge.

lDo not touch or allow direct contact with tape or tape leader. Dust or natural skin oils can contaminate the tape and impact tape performance.

lDo not expose the tape cartridge to moisture or direct sunlight.

lDo not insert any cartridge that has been dropped into tape drive without a thorough visual inspection. A dropped cartridge may have dislodged, loosened, or damaged

internal components.

lAvoid unnecessary opening of the cartridge door; this may expose the tape to contamination or physical damage.

lDo not use graphite pencils, water-soluble felt pens, or other debris-producing writing instruments on your labels. Never erase a label—replace it.

lMake sure you place the unused cartridge labels in the protective box so that you do not inadvertently pick them up along with the cartridge during subsequent usage.

(A static electricity charge on a cartridge may cause a label to cling to the cartridge.) A label that is accidentally inserted into the drive along with a cartridge can

prevent the hub reel and drive gear from meshing.

lMaintain clean operating, working, and storage environments.

lFollow all tape cartridge handling instructions that accompany your cartridges or tape drive.

Back to Contents Page

CAUTION: Ensure that only one label is stuck to the label area of the cartridge. Never use nonstandard labels, and never stick anything to the cartridge

other than in the label area.

Temperature

10°Cto40°C(50°Fto104°F)



Relative Humidity

20% to 80% (non-condensing)

Back to Contents Page

SCSI Connectors: Dell™PowerVault™110T SDLT 320 Tape Drive User's Guide

Figure 1 shows the location of the two 68-pin SCSI connectors available from the back of the Dell PowerVault 110T SDLT 320 tape drive, external model.

Figure 2 shows the location of the SCSI port available from the back of the Dell PowerVault 110T SDLT 320 tape drive, internal model.

Figure 1. Location of SCSI Connectors on Back of External Drive

Figure 2. Location of SCSI Port on Back of Internal Drive



1

SCSI ID

Selector

2

SCSI

Connectors (2)

3

Fan

4

Power

Connector

5

Power Switch



1

Power

Connector

(4-pin)

2

Controller

Diag Port

(8-pin)

(Diagnostic

use only; not

for customer

use)

3

Configuration

Jumper (Not

for customer

use) (8-pin)

4

Loader

Connector

RS-422

(8-pin)

5

SCSI ID

Jumper

Block

(10-pin)

6

TERMPWR

Block

(4-pin)

7

SCSI Port

(68-pin)

Back to Contents Page

Contacting Dell: Dell™PowerVault™110T SDLT 320 Tape Drive User's Guide

To contact Dell electronically, you can access the following websites:

lwww.dell.com

lsupport.dell.com (technical support)

lpremiersupport.dell.com (technical support for educational, government, healthcare, and medium/large business customers, including Premier, Platinum, and Gold

customers)

For specific web addresses for your country, find the appropriate country section in the table below.

NOTE: Toll-free numbers are for use within the country for which they are listed.

When you need to contact Dell, use the electronic addresses, telephone numbers, and codes provided in the following table. If you need assistance in determining which
