Dell PowerEdge M1000e Manuel utilisateur

Dell PowerEdge M1000e, M915, M910, M820, M710HD,

M710, M620, M610x, M610, M520, and M420

Getting Started Guide

Regulatory Model: BMX01, DWHH, HHB, FHB, and QHB

Regulatory Type: DWHH Series, HHB Series, FHB Series, and QHB

Series

Notes, Cautions, and Warnings

NOTE: A NOTE indicates important information that helps you make better use of your computer.

CAUTION: A CAUTION indicates either potential damage to hardware or loss of data and tells you how to avoid the

problem.

WARNING: A WARNING indicates a potential for property damage, personal injury, or death.

Trademarks used in this text: Dell™, the Dell logo, Dell Precision™, OptiPlex™, Latitude™, PowerEdge™, PowerVault™,

PowerConnect™, OpenManage™, EqualLogic™, Compellent™, KACE™, FlexAddress™, Force10™and Vostro™are trademarks of Dell

Inc. Intel®, Pentium®, Xeon®, Core®and Celeron®are registered trademarks of Intel Corporation in the U.S. and other countries. AMD®

is a registered trademark and AMD Opteron™, AMD Phenom™and AMD Sempron™are trademarks of Advanced Micro Devices, Inc.

Microsoft®, Windows®, Windows Server®, Internet Explorer®, MS-DOS®, Windows Vista®and Active Directory®are either trademarks

or registered trademarks of Microsoft Corporation in the United States and/or other countries. Red Hat®and Red Hat®

Enterprise Linux®are registered trademarks of Red Hat, Inc. in the United States and/or other countries. Novell®and SUSE®are

registered trademarks of Novell Inc. in the United States and other countries. Oracle®is a registered trademark of Oracle Corporation

and/or its affiliates. Citrix®, Xen®, XenServer®and XenMotion®are either registered trademarks or trademarks of Citrix Systems, Inc. in

the United States and/or other countries. VMware®, Virtual SMP®, vMotion®, vCenter®and vSphere®are registered trademarks or

trademarks of VMware, Inc. in the United States or other countries. IBM®is a registered trademark of International Business Machines

Corporation.

2012 - 06

Rev. A00

Installation And Configuration

WARNING: Before performing the following procedure, review the safety instructions that came with the blade

server or enclosure.

Unpacking The System

Unpack your blade server or enclosure and identify each item.

Installing The Rails And Enclosure

Figure 1. Installing the Enclosure in the Rack

Assemble the rails and install the enclosure in the rack, following the safety instructions and the rack installation

instructions provided with the enclosure.

Installing A Sleeve In The Enclosure

NOTE: This procedure applies only to PowerEdge M420.

A sleeve includes up to four quarter-height blades to function as a system. Depending on your order, the sleeve may

ship with the blades preinstalled.

CAUTION: Exercise utmost care when installing or removing the sleeve to prevent damage to the internal

components. To ensure protection for the electronic components inside, follow the Electrostatic Discharge (ESD)

guidelines.

Figure 2. Installing a Sleeve

NOTE: Before you install or remove a sleeve from the enclosure, ensure that the top slot of the sleeve (Blade a) is

empty. You can install a blade in the top slot (Blade a) after you install the sleeve in the enclosure.

Remove the orange cover from the sleeve handle. Slide the sleeve into the enclosure and lift the sleeve handle to the top

position to secure the sleeve in the enclosure.

NOTE: To ensure optimal thermal performance, do not replace the cover on the sleeve handle after the sleeve is

installed in the enclosure. Reinstall the cover only if the sleeve is not installed in the enclosure.

Installing A Quarter-Height Blade In A Sleeve

CAUTION: Install a blade blank in all empty blade slots to maintain proper thermal conditions.

Slide the blade into the sleeve and rotate the blade handle upward to secure the blade in the sleeve.

Figure 3. Installing a Quarter-Height Blade

Installing A Full Or Half-Height Blade

CAUTION: Install a blade blank in all empty blade slots to maintain proper thermal conditions.

Figure 4. Installing a Half-Height Blade

NOTE: The above figure shows installation of a half-height blade. The procedure for installing a full-height blade is

identical to installing a half-height blade.

Beginning at the top, slide the blades into the enclosure from left to right. When the blade is securely installed, the blade

handle returns to the closed position.

Connecting The CMC And iKVM Modules

Figure 5. Connecting the Modules

Connect the serial cable and network cable(s) from the management system to the CMC module. If a second optional

CMC module is installed, connect it as well.

Connect the keyboard, mouse, and monitor to the optional iKVM module.

Connecting The System To Power

Figure 6. Connecting Power to the System

Connect the system’s power cables to the system power supplies.

CAUTION: To prevent the power cables from being disconnected accidentally, use the plastic clip on each power

supply to secure the power cable to the power supply, and use the strap to secure the power cable to the strain-

relief bar.

CAUTION: For AC power supply, do not plug the power cables directly into a power outlet; you must use a PDU. For

optimal system functionality, a minimum of three power supplies are required.

Plug the other end of the power cables of the AC power supplies into a power distribution unit (PDU). For DC power

supplies, plug the other end of the power cables to a branch-protected DC power source.

NOTE: The power supply units must have the same maximum output power.

NOTE: AC and DC power supplies cannot be mixed in an enclosure.

Turning On The Enclosure

Figure 7. Enclosure Power Button

Press the power button on the enclosure. The power indicator should light.

Turning On The Blades

Figure 8. Turning on a Blade

Press the power button on each blade, or power on the blades using the systems management software.

Complete The Operating System Setup

If you purchased a preinstalled operating system, see the documentation associated with the operating system. To

install an operating system for the first time, see the installation and configuration documentation for your operating

system. Be sure the operating system is installed before installing hardware or software not purchased with the system.

NOTE: See dell.com/ossupport for the latest information on supported operating systems.

Dell Software License Agreement

Before using your system, read the Dell Software License Agreement that came with your system. You must consider

any media of Dell-installed software as BACKUP copies of the software installed on your system’s hard drive. If you do

not accept the terms of the agreement, call the customer assistance telephone number. For customers in the United

States, call 800-WWW-DELL (800-999-3355). For customers outside the United States, visit support.dell.com and select

your country or region from the bottom of the page.

Other Information You May Need

WARNING: See the safety and regulatory information that shipped with your system. Warranty information may be

included within this document or as a separate document.

• The Owner’s Manual provides information about system features and describes how to troubleshoot the system

and install or replace system components. This document is available online at support.dell.com/manuals.

• For the Owner’s Manuals and Installation Guides for Dell EqualLogic hardware, go to support.equallogic.com.

• The rack documentation included with your rack solution describes how to install your system into a rack, if

required.

• Any media that ships with your system that provides documentation and tools for configuring and managing your

system, including those pertaining to the operating system, system management software, system updates, and

system components that you purchased with your system.

NOTE: Always check for updates on support.dell.com/manuals and read the updates first because they often

supersede information in other documents.

NOTE: When upgrading your system, it is recommended that you download and install the latest BIOS, drivers, and

systems management firmware on your system from support.dell.com.

Obtaining Technical Assistance

If you do not understand a procedure in this guide or if the system does not perform as expected, see your

Owner’s

Manual

. Dell offers comprehensive hardware training and certification. See dell.com/training for more information. This

service may not be offered in all locations.

NOM Information

The following information is provided on the device described in this document in compliance with the requirements of

the official Mexican standards (NOM):

Importer: Dell Inc. de México, S.A. de C.V.

Paseo de la Reforma 2620 -11º Piso

Col. Lomas Altas

11950 México, D.F.

Model number: BMX01

Supply voltage: 100 V CA to 240 V CA or –(48–60) V DC

Frequency: 50 Hz/60 Hz or N/A

Current consumption: 16 A (x6) or 75 A (x6)

Model number: FHB

Supply voltage: 12 V DC

Current consumption: 75 A

Model number: HHB

Supply voltage: 12 V DC

Current consumption: 37 A

Model number: QHB

Supply voltage: 12 V DC

Current consumption: 35 A

Technical Specifications

NOTE: For additional specifications, see your system

Owner's Manual

Power — Blades

Coin-cell battery 3 V CR2032 Lithium coin cell

Power — Enclosure

AC/DC power supply (per power supply module)

Wattage 2360 W and 2700 W

Connector IEC C20

Heat dissipation 1205 BTU/hr (maximum)

Maximum inrush current Under typical line conditions and over the entire system

ambient operating range, the inrush current may reach

55 A per power supply for 10 ms or less.

System Voltage Requirements

NOTE: This system is also designed to be connected to

IT power systems with a phase to phase voltage not

exceeding 230 V.

43 A, 200 V AC to 240 V AC, 50 Hz/60 Hz (2360 W power

supply)

16 A, 100 V AC to 240 V AC, 50 Hz/60 Hz (2700 W power

supply)

DC/DC power supply (per power supply module)

Wattage 2700 W

Connector Molex # 394260002 at PSU end,

mating connector Molex # 39422-0012

Heat dissipation 1205 BTU/hr (maximum)

Maximum inrush current Under typical input voltage conditions and over the

entire system ambient operating range, the inrush

current may reach 120 A per power supply for 10 ms or

less.

System Voltage Requirements 75 A, 48 V DC to 60 V DC

NOTE: Heat dissipation is calculated using the power

supply wattage rating.

Physical — Blades

PowerEdge M915

Height 38.5 cm (15.2 inch)

Width 5 cm (2 inch)

Depth 48.6 cm (19.2 inch)

Weight (maximum) 12.7 kg (28 lb)

PowerEdge M910

Height 38.5 cm (15.2 inch)

Width 5 cm (2 inch)

Depth 48.6 cm (19.2 inch)

Weight (maximum) 13.1 kg (29 lb)

Physical — Blades

PowerEdge M820

Height 38.5 cm (15.2 inch)

Width 5 cm (2 inch)

Depth 48.6 cm (19.2 inch)

Weight (maximum) 14.5 kg (31.9 lb)

PowerEdge M710 and M610x

Height 38.5 cm (15.2 inch)

Width 5 cm (2 inch)

Depth 48.6 cm (19.2 inch)

Weight (maximum) 11.1 kg (24.5 lb)

PowerEdge M710HD and M620

Height 18.9 cm (7.4 inch)

Width 5 cm (2 inch)

Depth 48.6 cm (19.2 inch)

Weight (maximum) 7.4 kg (16.3 lb)

PowerEdge M610

Height 18.9 cm (7.4 inch)

Width 5 cm (2 inch)

Depth 48.6 cm (19.2 inch)

Weight (maximum) 5.2 kg to 6.4 kg (11.5 lb to 14.0 lb)

PowerEdge M520

Height 18.9 cm (7.4 inch)

Width 5 cm (2 inch)

Depth 48.6 cm (19.2 inch)

Weight (maximum) 6.4 kg (14.1 lb)

PowerEdge M420

Sleeve

Height 39.5 cm (15.6 inch)

Width 5 cm (2 inch)

Depth 44.3 cm (17.4 inch)

Weight 3 kg (6.61 lb)

Blade

Height 9.75 cm (3.8 inch)

Width 5 cm (2 inch)

Depth 45.8 cm (18 inch)
