Dell™ PowerEdge™

19x0 and 29x0 Systems

Installing a SATA

Optical Drive

Notes, Cautions, and Warnings

NOTE: A NOTE indicates important information that helps you make better use of

your computer.

CAUTION: A CAUTION indicates potential damage to hardware or loss of data if

instructions are not followed.

WARNING: A WARNING indicates a potential for property damage, personal

injury, or death.

____________________

Information in this document is subject to change without notice.

Reproduction of these materials in any manner whatsoever without the written permission of Dell Inc.

is strictly forbidden.

Trademarks used in this text: Dell and the DELL logo are trademarks of Dell Inc.

Other trademarks and trade names may be used in this document to refer to either the entities claiming

the marks and names or their products. Dell Inc. disclaims any proprietary interest in trademarks and

trade names other than its own.

August 2008 P/N N974G Rev. A00

Installing a SATA Optical Drive 3

Installing a SATA Optical Drive

These instructions apply to Dell™ PowerEdge™ systems to which a SATA

optical drive is being added, or in which an existing PATA or IDE optical drive

is being replaced by a SATA optical drive.

WARNING: Only trained service technicians are authorized to remove the system

cover and access any of the components inside the system. Before you begin this

procedure, review the safety instructions that came with the system.

Removing an Existing Optical Drive – All Systems

Turn off the system and attached peripherals, and disconnect the system

from the electrical outlet.

Remove the bezel. See "Removing the Bezel" in your

Hardware Owner’s

Manual

Remove the system cover. See "Opening the System" in your

Hardware

Owner’s Manual

PowerEdge 1950 systems only:

Disconnect and remove the SAS controller

daughter card. See "Removing a SAS Controller Daughter Card" in your

Hardware Owner’s Manual

Disconnect the data and power cables from the back of the optical drive.

PowerEdge 2900 and 1900 systems only:

Perform the following steps. See

your

Hardware Owner’s Manual

for specific step instructions.

Disconnect the SAS cable from the SAS controller and pull the cable

away from the center fan bracket.

Remove the center fans and the center fan bracket.

Release the spring latch at the top of the peripheral bay and remove

the optical drive from the front of the bay.

For systems with a drive tray, release the blue tab at the back of the tray

and slide the drive tray out of the system.

4Installing a SATA Optical Drive

Preparing the Optical Drive Tray – PowerEdge 2970, 2950, and 1950

For PowerEdge 2970 and 2950 systems, the optical drive tray that shipped

with the system is used for the SATA optical drive. If you are replacing an

existing IDE optical drive, you must remove the old drive and interposer card

from the drive carrier and install the new SATA drive in the same carrier.

On PowerEdge 1950 systems, the existing optical drive tray must be replaced

with the drive tray provided with the SATA drive installation kit.

The PowerEdge 2900 and 1900 systems do not require optical drive trays.

Replacing a PowerEdge 2950 or 2970 Optical Drive

NOTE: If you are replacing an existing optical drive, do not reuse the interposer

board attached to the old drive.

Pull outward on the interposer board release tab at the back of the drive

tray to release the interposer board connected to the optical drive. See

Figure 1-1.

Pull the interposer board connector from the optical drive connector and

rotate the interposer board outward to detach the board from the tray.

Pull outward again on the interposer board release tab and simultaneously

pull up on the left side of the optical drive to separate the drive from the

tray.

Attach the SATA optical drive to the tray by lowering the right side of the

drive onto the right side of the tray. See Figure 1-1.

Lower the left side of the drive into the tray and press the drive down to

lock it into place.

The pins on the carrier fit into the corresponding holes in the side of the

drive.

Installing a SATA Optical Drive 5

Figure 1-1. Replacing the Optical Drive in a PowerEdge 2950 or 2970 System

Replacing a PowerEdge 1950 Optical Drive

NOTE: The replacement drive tray provided in the installation kit must be used with

PowerEdge 1950 systems. If you are replacing an existing optical drive, do not reuse

the interposer board attached to the old drive.

Spread the side rails of the replacement drive tray and insert the back end of

the SATA optical drive into the tray until the pins on the carrier align with the

holes in the side of the drive. Release the rails to attach the drive to the tray.

See Figure 1-2.

1 optical drive 2 interposer release latch

3 interposer 4 SATA cable

5 SATA power cable 6 carrier latch

7 optical drive carrier

6Installing a SATA Optical Drive

Figure 1-2. Installing a SATA Optical Drive in a PowerEdge 1950 Drive Tray

Installing the SATA Optical Drive – PowerEdge 1950

Insert the optical drive tray into the system until it is fully inserted and

locked into position.

Connect the SATA cable (the end with the branching power cable) to the

back of the optical drive.

Connect the branching power cable to the power supply connector.

NOTE: You may need to replace the existing power cable with a cable

provided in the optical drive kit.

Route the SATA cable to the SATA_A connector on the system board.

Route the cable through the power cable cutout in the fan bracket and

follow the power cable routing to the power supply bays.

Bend the cable toward the chipset shroud and insert the cable into the

cable path on top of the chipset shroud. See Figure 1-3.

Connect the cable to the SATA_A connector on the system board.

1 optical drive 2 SATA cable

3 SATA power cable 4 carrier latch

5 optical drive carrier

Installing a SATA Optical Drive 7

Figure 1-3. SATA Cable Routing in the PowerEdge 1950

Reinstall the SAS controller daughter card and reconnect the SAS cable.

See "SAS Controller Daughter Card" in your Hardware Owner’s Manual.

Close the system. See "Closing the System" in your

Hardware Owner’s

Manual

Reconnect the system to power and turn on the system and attached

peripherals.

Installing the SATA Optical Drive – PowerEdge 2970 or 2950

Insert the optical drive tray into the system until it is fully inserted and

locked into position.

Connect the SATA cable (the end with the branching power cable) to the

back of the optical drive.

Connect the branching power cable to the power supply connector.

1 SATA data cable 2 SATA_A connector on system board

3 chipset shroud 4 system fans

5 SATA power cable 6 optical drive

8Installing a SATA Optical Drive

Remove the cooling shroud. See "Removing the Cooling Shroud" in your

Hardware Owner’s Manual

Remove the cable retention bracket from the right interior wall of the

chassis by pushing the blue release latch and sliding the bracket toward the

front of the system until the bracket detaches from the chassis slots.

Route the SATA cable in the cable channel in the right wall of the chassis

and replace the cable retention bracket over the cable. See Figure 1-4.

Route the SATA cable along the top of the cable retention bracket to the

central riser.

Bend the cable behind the central riser and connect the cable to the

SATA_B connector on the system board.

Figure 1-4. SATA Cable Routing in the PowerEdge 2950 and 2970

1 SATA_B connector on system board 2 cable retention bracket

3 SATA data cable 4 SATA power cable

5 optical drive

Installing a SATA Optical Drive 9

Replace the cooling shroud. See "Installing the Cooling Shroud" in your

Hardware Owner’s Manual

Close the system. See "Closing the System" in your

Hardware Owner’s

Manual

Reconnect the system to power and turn on the system and attached

peripherals.

Installing the SATA Optical Drive – PowerEdge 2900 and 1900

If the mounting screws are not attached to the drive, install them now.

Align the mounting screws with the bay slide slots and insert the optical

drive into the optical drive bay until the spring latch engages.

Connect the SATA cable to the back of the optical drive.

Use the appropriate power cable provided in the optical drive kit and

connect one end to the optical drive and the other to the power supply as

follows:

– For a PowerEdge 2900 system, connect to the CD/TBU connector on

the system backplane. See Figure 1-5.

– For a PowerEdge 1900 system, connect to an available power supply

cable.

Replace the center fan bracket. See "Replacing the Center Fan Bracket" in

your

Hardware Owner’s Manual

Replace the fans in the center fan bracket.

Route the SATA cable to the system board over the top of the fan bracket

and connect the cable to the SATA connector on the system board. See

Figure 1-5.

– For a PowerEdge 2900, use the SATA_B connector.

– For a PowerEdge 1900, use the SATA_D connector.

10 Installing a SATA Optical Drive

Figure 1-5. SATA Cable Routing in a PowerEdge 2900 or 1900

Reconnect the cables to the SAS controller daughter card.

Close the system. See "Closing the System" in your

Hardware Owner’s

Manual

Reconnect the system to power and turn on the system and attached

peripherals.

1 optical drive 2 SATA power cable

3 SATA data cable 4 SATA connector on system board

5 SATA power connector on SAS

backplane (PowerEdge 2900 only)
