TECHNICAL GUIDEBOOK—

INSIDE THE OPTIPLEX FX130 THIN CLIENT

DELL

OPTIPLEX

FX130

™

TABLE OF CONTENTS

O V E R V IE W

OPTIPLEX FX130 FRONT AND BACK VIEWS 3

DETAILED ENGINEERING SPECIFICATIONS: SYS TEM C OMPONENT DET A IL S 4

POWER D E TAILS 5

AUD IO & COMMU NICATIO NS NETWO RK ADAP TE R 6

BIOS D E F AULTS 7

SERVICE, SUPP OR T, AN D SOFTWAR E 8

REGULATORY CO MPLIANCE A ND ENVIRO NMENTAL 8

DELL™ OPTIPLEX™ FX130 TECHNICAL GUIDEBOOK 1.0

FRONT AND BACK VIEW

Front Back

Number Name Number Name

1Power Button 6USB 2.0 Connectors (4)

2Network Activity Indicator LED 7DVI-I

3Audio Line Out 8PS/2

4Microphone 9Power Connector

5Network Connector 10 Kensington Lock

DELL™ OPTIPLEX™ FX130 TECHNICAL GUIDEBOOK 1.0

Processor CPU / Chipsets VIA Eden ULV 1GHz/VIA VX855

Memory RAM 1GB DDR2 RAM

OS Support Linux (DeTOS)

Data Storage DOM 1GB DOM

Display

Resolution Up to 1600x1200 at 32 bit color

Video Memory Up to 512MB frame buer using system memory

Display Data Control Integrated VX855

Storage x 1 (50 pins CF socket by daughter board, x1 (2*22

pins IDE port for DOM), support UDMA, DMA, PIO

I/O Physical

USB (2.0)

Front x 2

Rear x 2

PS/2 x 1 (For keyboard, mouse, or optional PS/2 splitter

cable)

Video

x 1 DVI-I or

X 1 VGA with included adapter or

X 1 DVI-D + x 1 VGA with optional adapter

Audio

Mic-In x 1 3.5 mm jack

Line-Out x 1 3.5 mm jack

Speaker X 1 (Built-in 1 W internal speaker)

Networking LAN x 1 (RJ-45, 10/100/1000 Base-T)

WLAN Option (Internal USB header for WLAN module)

Environment

Temperature

Operation 32° to 95° F (0° to 35° C)

Storage -4° to 140° F (-20° to 60° C)

Relative Humidity 20% to 80% non-condensing

Power Power Supply 36W, DC 12V/3A external power adapter

Mounting

Foot Stand Vertical or Horizontal Vertical

VESA Bracket (wall mount vertical only) Metal mounting kit for VESA standard (Optional)

Security Kensington Lock Yes

Physical

Characteristics

Chassis Housing Plastic and metal

Dimension /

Weight

Thin Client 36 (W) x 156 (H) x 122 (D) mm / Net Weight : 0.68

Packing : Single Box 83 (W) x 232 (H) x 205 (D) mm / Gross Weight : 1.5

Packing : Carton 662 (W) x 265 (H) x 355 (D) mm / Gross Weight :

20 KG, 12 boxes in one carton

DETAILED ENGINEERING SPECIFICATIONS

DELL™ OPTIPLEX™ FX130 TECHNICAL GUIDEBOOK 1.0

POWER DETAILS

AC Parameters

External Power Adapter Dimensions 110.9 mm (L) x 51.9 mm (W) x 33 mm (H)

Power Supply Wattage 36W

AC input Voltage Range 100-240 V

AC input current (max) 2A

AC input Frequency 47HZ/63HZ

Average Eciency >=78%

Typical Eciency (Active PFC) 84.8%

DC Parameters

+12.0v output 3A

Max total power 36W

BTUs/h (based on PSU max wattage) 123 BTU

Compliance

1watt requirement Yes

Blue Angel Compliant No

Climate Savers / 80Plus Compliant No

FEMP (CECP) Standby Power Compliant No

E Star Compliant No

3.0v CMOS battery (Type and estimated battery life)

Brand Type Voltage Composition Life

KTS CR-2302

with wire

3V Lithium Continuous Discharge Under 15 kΩ Load to 2.0V End-Voltage.

23±3C Standard 1000 Hrs. Minimum Value 800h

0±3C Standard 850 Hrs. Minimum Value 680h

DELL™ OPTIPLEX™ FX130 TECHNICAL GUIDEBOOK 1.0

AUDIO

COMMUNICATIONS - NETWORK ADAPTER (NIC)

Integrated via 1708s High Denition Audio

High Denition Stereo support No

Number of Channels 2

Number of Bits / Audio resolution 16 and 24-bit resolution

Sampling rate (recording/playback) Support 44.1K/48K/96K/192 kHz sample rates

Signal to Noise Ratio 98 dB DAC outputs, 90 dB for ADC inputs

Analog Audio N/A

Dolby Digital N/A

THX N/A

Digital out (S/PDIF) N/A

Audio Jack Impedance

Microphone In 30K ohm

Headphone Out 50~65 ohm

Internal Speaker Power Rating 1Watt (peak) / 0.5Watt (average)

PCI Rea lt e k 81 10 sc E t h e r net L AN 10/1 00 /10 00

External Connector Type RJ45

Data Rates supported 10/100/1000 Mbps

Controller Details

Controller bus architecture PCI interface

Integrated memory N/A

Data transfer mode (example Bus-Master DMA) N/A

Power consumption (full operation per data rate connection speed) 538mW (Max.)

Power consumption (standby operation) 227mW (Max.)

IEEE standards compliance (example 802.1P) 802.3

Hardware Certications (example FCC, B, GS mark…) N/A

Boot ROM Support EEPROM (located in SPI)

Network Transfer Mode (example Full Duplex, Half Duplex)

Network Transfer Rate (example 10BASE-T (half-duplex) 10 Mbps

10BASE-T (full-duplex) 20 Mbps

100BASE-TX (half-duplex) 100 Mbps

100BASE-TX (full-duplex) 200 Mbps

1000BASE-T (full-duplex) 2000 Mbps

10 Mb (full/half-duplex)

100 Mb (full/half-duplex)

1000 Mb (full-duplex)

DELL™ OPTIPLEX™ FX130 TECHNICAL GUIDEBOOK 1.0

COMMUNICATIONS NETWORK ADAPTER (NIC) (CONTINUED)

PCIE Realtek 8111DL-GR Ethernet LAN 10/100/1000 (continued)

Management Capabilities

Operating Temperature 0° C to 70° C (32° F to 158° F)

Operating Humidity 20% to 80% (non-condensing)

Manageability (examples WOL, PXE) WOL, PXE 2.1

Management Capabilities Alerting N/A

System conguration

Integrated NIC Enable

USB Controller Enable

Serial Port N/A

SATA Operation N/A

SMART Reporting N/A

Diskette Drive N/A

Miscellaneous Devices Enable (Front USB, Rear USB, PXE)

Drives (IDE—0)

Video

Primary Video EGA/VGA

Performance

Multiple Core Support N/A

Intel® SpeedStep™ N/A

C States Control N/A

Limit CPUID Value Disable

HyperThread control Enable

Virtualization Support

Virtualization N/A

VT for Direct I/O N/A

Security

Administrator Password Not set

System Password Not set

Password Changes Enable

TPM Security N/A

CPU XD Support Enable

Computrace® N/A

SATA-0 Password N/A

BIOS DEFAULTS

DELL™ OPTIPLEX™ FX130 TECHNICAL GUIDEBOOK 1.0

BIOS DEFAULTS CONTINUED

Power Management

AC Recovery Power O

Auto On Time Disable

Deep Sleep Control N/A

Fan Control Override N/A

Wake on LAN Enable

Maintenance

Service Tag Set by the factory

Asset Tag Optional User Entry

SERR Message N/A

Number Lock LED Enable

USB Emulation Enable

Keyboard Errors Default—No Error

POST HotKeys Enable

Fast Boot Thorough

SERVICE AND SUPPORT

NO T E: For m or e d e t ail s o n D e ll Se rvic e Pla n s pleas e t o go to : ww w.d ell .com/se rvic e/se rvice_ p l a ns

3 Year Warranty1 Standard

ProSupport Optional

1 For a copy of our guarantees or limited warranties, please write Dell USA L.P., Attn: Warranties, One Dell Way, Round Rock, TX 78682. For more

information, visit www.dell.com/warranty.

2 Service may be provided by third-party. Technician will be dispatched if necessary following phone-based troubleshooting. Subject to parts

availability, geographical restrictions and terms of service contract. Service timing dependent upon time of day call placed to Dell. U.S. only.

SOFTWARE

VMware View Ready Yes

Citrix HDX Ready Yes

REGULATORY COMPLIANCE AND ENVIRONMENTAL

Product related conformity assessment and regulatory authorizations including Product Safety, Electromagnetic Compatibility

(EMC), Ergonomics, and Communication Devices relevant to this product may be viewed at www.dell.com/

regulatory_compliance. The Regulatory Datasheet for this product is located at http://www.dell.com/regulatory_compliance.
