M115 Wireless Installation Guide.book Page 1 Tuesday, July 2, 2013 5:50 PM !

Dell Mobile Projector

M115HD

Wireless Installation Guide

__________________

M115 Wireless Installation Guide.book Page 2 Tuesday, July 2, 2013 5:50 PM !

About Notes

NOTE: A NOTE indicates important information that helps you make better use of your

projector.

Information in this document is subject to change without notice.

Reproduction of these materials in any manner whatsoever without the written permission of Dell Inc. is strictly forbidden

Trademarks used in this text: Dell and the DELL logo are trademarks of Dell Inc.; Microsoft, Windows 7, and Windows Vista are

trademarks or registered trademarks of Microsoft Corporation in the United States and/or other countries.

Other trademarks and trade names may be used in this document to refer to either the entities claiming the marks and names or

their products. Dell Inc. disclaims any proprietary interest in trademarks and trade names other than its own.

August 2013 Rev. A00

M115 Wireless Installation Guide.book Page 3 Tuesday, July 2, 2013 5:50 PM

Wireless Installation Instruction

NOTE: Your computer must have the following minimum system requirements:

Operating System:

• Windows

Microsoft Windows XP Home or Professional

Service pack 2 (32-bit recommended),

Windows Vista 32-bit or 64-bit, Windows 7

Home or Professional 32-bit or 64-bit, and

Windows 8 32-bit or 64-bit

• MAC

MacBook and above, MacOS 10.5 and above

Minimum Hardware:

a) Intel Dual Core 1.8 MHz or greater

b) 256 MB of RAM required, 512 MB or more

recommended

c) 10 MB of available hard-disk space

d) nViDIA or ATI graphic card with 64 MB

VRAM or above

e) Ethernet adapter (10 / 100 bps) for an

Ethernet connection

f) A supported WLAN adapter for a WLAN

connection (any NDIS-compliant 802.11b

or 802.11g or 802.11n Wi-Fi device)

Web browser:

Microsoft Internet Explorer 6.0 or 7.0

(recommended) or 8.0, Firefox 2.0, Safari 3.0

and above

NOTE: The wireless dongle is not

shipped with your M115HD projector.

You can purchase it on the Dell website

at www.dell.com.

Wireless dongle

FCC ID:

SUZ-WU5205C

FCCID:

SUZ-WU5205C

FCCID:

SUZ-WU5205C

M115 Wireless Installation Guide.book Page 4 Tuesday, July 2, 2013 5:50 PM !

Wireless Installation Instruction

Enable Wireless on the Projector 3 Press the Menu button on your

projector control panel or remote

Install the optional wireless dongle. control.

2 Connect the power cord with AC

adapter to the wall outlet and press the

power button.

NOTE: Use , , and

buttons to navigate and to select.

4 Select the input source as USB.

M115 Wireless Installation Guide.book Page 5 Tuesday, July 2, 2013 5:50 PM !

The Wireless Guide Screen shown below

appears:

5 Take note of the Wireless Network

(SSID), IP Address, and Access Code.

You will need this information to log in

in later.

Wireless Installation Instruction

Install the Dell Projector Connection

Manager on Your Computer

6 Connect your computer to the

M115HD wireless network.

NOTE:

a) Your computer must have wireless

network function to detect the

connection.

b) When you connect to the M115HD

wireless network, you will lose wireless

connectivity with other wireless networks.

M115 Wireless Installation Guide.book Page 6 Tuesday, July 2, 2013 5:50 PM !

Wireless Installation Instruction

NOTE: It is recommended that all

proxies are turned off. (In Microsoft®

Windows 7: Click Control Panel J

Internet Options JConnections J

LAN Settings)

7 "Dell Projector Connection Manager" is

required if used for wireless display.

Please download and install the

software for first-time use. If it is

already installed, skip Step 7 - 12.

NOTE: You only need to install the "Dell

Projector Connection Manager" once.

8 Open the Internet browser on your

computer. You will be automatically

directed to the M115HD Web

Management web page.

NOTE: If the web page does not load

automatically, enter the IP address

(default IP address is 192.168.100.10) in

the browser's address bar.

9 The M115HD web management page

opens. For first-time use, click

Download.

M115 Wireless Installation Guide.book Page 7 Tuesday, July 2, 2013 5:50 PM !

Wireless Installation Instruction

10 Select the appropriate operating

system, and then click Download.

NOTE: You may choose to save the file

and install it at a later time. To do this,

click Save.

NOTE: If you are unable to install the

application because of inadequate

rights on the computer, please contact

your network administrator.

12 The installation software will launch.

Follow the on-screen instructions to

complete setup.

11 Click Run to proceed with the

installation.

M115 Wireless Installation Guide.book Page 8 Tuesday, July 2, 2013 5:50 PM !

Wireless Installation Instruction

Launch the Dell Projector Login

Connection Manager 14 Login with the Access Code (see Step

5), then click OK.

13 Once the installation is complete, the

program will launch automatically. Or

you can double-click the icon on

the desktop to start the application.

M115 Wireless Installation Guide.book Page 9 Tuesday, July 2, 2013 5:50 PM !

Wireless Installation Instruction

Understanding the Buttons

After a successful log in, the following screen

appears:

Minimize Click to minimize the

button application.

Close Click to exit the

button application.

2 Controls Toolbar

Informat Click to display SSID, IP,

ion and Access Code

information.

Item Description

1StatusBar

Settings Click to activate the

application settings.

mode

Click to activate the

share mode (4-in-1 split

screen).

(this feature is not

supported in the

M115HD)

Display Click to change the

mode display mode.

Start Click to start projection.

M115 Wireless Installation Guide.book Page 10 Tuesday, July 2, 2013 5:50 PM !

Wireless Installation Instruction

Item Description Using the Settings

2 Pause Click to pause

projection.

Click to display the settings menu.

Stop Click to stop projection. RESOLUTION—Allows you to setup the

resolution.

Audio

Click to toggle audio

projection On/Off.

(this feature is not

supported in the

M115HD)
