Dell PowerEdge M1000e Manuel utilisateur

Dell™ PowerEdge™ M1000e

Systems

Configuration Guide

Dell™ PowerEdge™ M1000e

Systems

Configuration Guide

Notes, Notices, and Cautions

NOTE: A NOTE indicates important information that helps you make better use of

your computer.

NOTICE: A NOTICE indicates either potential damage to hardware or loss of data

and tells you how to avoid the problem.

CAUTION: A CAUTION indicates a potential for property damage, personal injury,

or death.

____________________

Information in this document is subject to change without notice.

Reproduction of these materials in anymanner whatsoever without the written permissionof Dell Inc.

is strictly forbidden.

Trademarks usedinthis text:Dell, theDELL logo,PowerEdge,and DellOpenManage aretrademarks

of Dell Inc.; Microsoft, Windows, and Active Directory are either trademarks or registered trademarks

of Microsoft Corporation in the United States and/or other countries.

Other trademarks and trade names may be used in this document to refer to either the entities claiming

the marks and names or their products. Dell Inc. disclaims any proprietary interest in trademarks and

trade names other than its own.

August 2008

Contents 3

Contents

1 About Your System . . . . . . . . . . . . . . . . . . 7

System Overview . . . . . . . . . . . . . . . . . . . . . 7

System Control Panel Features . . . . . . . . . . . . . 10

LCD Module . . . . . . . . . . . . . . . . . . . . . . . 11

LCD Module Menus . . . . . . . . . . . . . . . . 12

Back-Panel Features . . . . . . . . . . . . . . . . . . 13

Blades . . . . . . . . . . . . . . . . . . . . . . . . . . 13

CMC Module . . . . . . . . . . . . . . . . . . . . . . . 16

CMC Daisy Chaining (Enclosure Stacking) . . . . 17

iKVM Switch Module . . . . . . . . . . . . . . . . . . 19

2 Initial System Configuration . . . . . . . . . . 21

Before You Begin . . . . . . . . . . . . . . . . . . . . 21

Power Requirements . . . . . . . . . . . . . . . . 21

Network Information . . . . . . . . . . . . . . . . 21

Initial Setup Sequence . . . . . . . . . . . . . . . . . 21

Configuring the CMC . . . . . . . . . . . . . . . . . . 22

Initial CMC Network Configuration . . . . . . . . 22

Logging in to the CMC Using the Web-Based

Interface . . . . . . . . . . . . . . . . . . . . . . 25

Adding and Managing CMC Users . . . . . . . . . 26

4Contents

Configuring iDRAC Networking Using the

Web-Based Interface . . . . . . . . . . . . . . . 27

Setting the First Boot Device for Servers . . . . . 28

Configuring and Managing Power . . . . . . . . . 28

Installing or Updating the CMC Firmware . . . . . 29

Configuring the Optional iKVM Switch Module . . . . 31

Enabling iKVM Access to the Dell CMC

Console . . . . . . . . . . . . . . . . . . . . . . . 31

Updating the iKVM Firmware . . . . . . . . . . . . 31

Tiering the Avocent iKVM Switch From an

Analog KVM Switch . . . . . . . . . . . . . . . . 32

Tiering the Avocent iKVM Switch From a

Digital KVM Switch . . . . . . . . . . . . . . . . . 33

Viewing and Selecting Servers . . . . . . . . . . 34

FlexAddress . . . . . . . . . . . . . . . . . . . . . . . 36

3 Configuring the I/O Modules . . . . . . . . . . 37

Overview . . . . . . . . . . . . . . . . . . . . . . . . . 37

Before You Begin . . . . . . . . . . . . . . . . . . . . 39

Network Information . . . . . . . . . . . . . . . . 39

Switch Modules . . . . . . . . . . . . . . . . . . . . . 39

Configuring a Switch Module Network Ethernet

Port Using the Web-Based Interface . . . . . . . 39

Cisco SFS M7000e Infiniband Switch Module . . . 40

PowerConnect M6220 Ethernet Switch

Module . . . . . . . . . . . . . . . . . . . . . . . 42

Cisco Ethernet Switch . . . . . . . . . . . . . . . 43

Brocade M4424 SAN I/O Module . . . . . . . . . 45

Contents 5

Pass-through Modules . . . . . . . . . . . . . . . . . 47

Ethernet Pass-through Module . . . . . . . . . . 47

Fibre Channel Pass-through Module . . . . . . . 49

6Contents

Configuration Guide 7

About Your System

System Overview

Your system can include up to 16 half-height blades (server modules), eight

full-height blades, or a mixture of the two blade types (see Figure 1-1,

Figure 1-2, and Figure 1-3). To function as a system, a blade is inserted into a

enclosure (chassis) that supports power supplies, fan modules, a Chassis

Management Controller (CMC) module, and at least one I/O module for

external network connectivity. The power supplies, fans, CMC, optional

iKVM module, and I/O modules are shared resources of the blades in the

enclosure.

8Configuration Guide

Figure 1-1. Blade Numbering – Half-Height Blades

12345678

910111213141516
