Dell Safeguard 5242LR Manuel utilisateur

Dell-Restricted-Confidential

Dell™ Safeguard 5242LR

Getting Started Guide

Regulatory Model Number: 1RK32-0B2

Dell-Restricted-Confidential

This guide contains proprietary information protected by copyright. The software described in this guide is furnished under a software license or

nondisclosure agreement. This software may be used or copied only in accordance with the terms of the applicable agreement. No part of this

guide may be reproduced or transmitted in any form or by any means, electronic or mechanical, including photocopying and recording for any

purpose other than the purchaser’s personal use without the written permission of Dell Inc.

The information in this document is provided in connection with Dell products. No license, express or implied, by estoppel or otherwise, to any

intellectual property right is granted by this document or in connection with the sale of Dell products. EXCEPT AS SET FORTH IN THE TERMS AND

CONDITIONS AS SPECIFIED IN THE LICENSE AGREEMENT FOR THIS PRODUCT, DELL ASSUMES NO LIABILITY WHATSOEVER AND DISCLAIMS ANY

EXPRESS, IMPLIED OR STATUTORY WARRANTY RELATING TO ITS PRODUCTS INCLUDING, BUT NOT LIMITED TO, THE IMPLIED WARRANTY OF

MERCHANTABILITY, FITNESS FOR A PARTICULAR PURPOSE, OR NON-INFRINGEMENT. IN NO EVENT SHALL DELL BE LIABLE FOR ANY DIRECT,

INDIRECT, CONSEQUENTIAL, PUNITIVE, SPECIAL OR INCIDENTAL DAMAGES (INCLUDING, WITHOUT LIMITATION, DAMAGES FOR LOSS OF PROFITS,

BUSINESS INTERRUPTION OR LOSS OF INFORMATION) ARISING OUT OF THE USE OR INABILITY TO USE THIS DOCUMENT, EVEN IF DELL HAS BEEN

ADVISED OF THE POSSIBILITY OF SUCH DAMAGES. Dell makes no representations or warranties with respect to the accuracy or completeness of

the contents of this document and reserves the right to make changes to specifications and product descriptions at any time without notice.

Dell does not make any commitment to update the information contained in this document.

If you have any questions regarding your potential use of this material, contact:

Dell Inc.

Attn: LEGAL Dept

5 Polaris Way

Aliso Viejo, CA 92656

Refer to our web site (software.dell.com) for regional and international office information.

Dell-Restricted-Confidential

Safeguard 5242LR Getting Started Guide

Updated - 6/3/15

232-002785-50 Rev A

Dell-Restricted-Confidential

Patents

This product is protected by U.S. Patents. For more information, go to http://software.dell.com/legal/patents.aspx.

Trademarks

Dell, the Dell logo, SonicWALL, and all other SonicWALL product and service names and slogans are trademarks of Dell Inc. Other trademarks

and trade names may be used in this document to refer to either the entities claiming the marks and names or their products. Dell disclaims any

proprietary interest in the marks and names of others.

Legend

CAUTION: A CAUTION icon indicates potential damage to hardware or loss of data if instructions are not followed.

WARNING: A WARNING icon indicates a potential for property damage, personal injury, or death.

IMPORTANT NOTE, NOTE, TIP, MOBILE, or VIDEO: An information icon indicates supporting information.

This product contains third-party components.

For third-party license information, go to http://software.dell.com/legal/license-agreements.aspx.

Source code information for open-source components is available at http://opensource.dell.com.

Dell-Restricted-Confidential

Dell Secure Mobile Access 6200/7200 Getting Started Guide

Introduction to the Safeguard 5242LR

This section describes the items shipped with the Dell Safeguard 5242LR appliances and provides front and rear illustrations of

them.



Dell-Restricted-Confidential

Safeguard 5242LR package contents

Before you begin the setup process, verify that your package contains the following items:

1One Safeguard 5242LR appliance

2One rack mounting kit

3One RJ45 to DB9 console cable

4One Ethernet cable

5Two power cords *

6One Dell Safeguard Safeguard 5242LR Getting Started Guide

*The included power cord(s) are approved for use only in specific countries or regions. Before using a power cord, verify that it is

rated and approved for use in your location. The power cords are for AC mains installation only. See Safety and regulatory

information on page 45 for minimum power cord rating and additional safety information.

添付の電源コードに関して

電気安全を確保するために、弊社製品にご使用いただく電源コードは必ず製品同梱の電源コードをご使用ください。この電源コードは他の製

品では使用できません。



Dell-Restricted-Confidential

Figure 1. Package contents

If any items are missing from your package, contact Support at https://support.software.dell.com.



Dell-Restricted-Confidential

Safeguard 5242LR front panels

2.5” HDD * 4

LCD Controls



Dell-Restricted-Confidential

Safeguard 5242LR back panels

Redundant Power Supply

Console Port

Display Port

USB 3.0 & eSATA Ports LED Indicators

Management Port

SFP+ Ports

Gigabit Ports

Dell-Restricted-Confidential

Preparing to deploy the Safeguard 5242LR

This section provides an overview of single-homed and dual-homed network architecture and discusses firewall settings and other

information you need about components of your network to successfully deploy the Safeguard 5242LR.

•Network architecture

•Preparing for the installation

•About installation and de
