Dell™SP2008WFPFlatPanelMonitor
Notes, Notices, and Cautions




Information in this document is subject to change without notice.
©2007DellInc.Allrightsreserved.
Reproduction in any manner whatsoever without the written permission of Dell Inc. is strictly forbidden.
Trademarks used in this text: Dell, the DELL logo, Inspiron, Dell Precision, Dimension, OptiPlex, Latitude, PowerEdge, PowerVault, PowerApp, and Dell OpenManage are trademarks of Dell
Inc;Microsoft, Windows, and Windows NT areregisteredtrademarksofMicrosoftCorporation;Adobe is a trademark of Adobe Systems Incorporated, which may be registered in
certain jurisdictions.ENERGYSTAR is a registered trademark of the U.S. Environmental Protection Agency. As an ENERGY STAR partner, Dell Inc. has determined that this product
meets the ENERGY STAR guidelines for energy efficiency.
Other trademarks and trade names may be used in this document to refer to either the entities claiming the marks and names or their products. Dell Inc. disclaims any
proprietary interest in trademarks and trade names other than its own.
Model SP2008WFP
June 2007 Rev. A00


About Your Monitor
Front View
Back View
Side View
Bottom View
Monitor Specifications
Cleaning Your Monitor
Using Your Monitor Stand
Attaching the Stand
Organizing Your Cables
Using the Tilt
Removing the Stand
Setting Up Your Monitor
ConnectingYourMonitor
Installing the Webcam Application
Using the Front Panel
Using the OSD
Setting the Optimal Resolution
Using the Dell Soundbar (Optional)

Solving Problems
Troubleshooting Your Monitor
General Problems
Product Specific Problems
USB Problems
Troubleshooting Your Soundbar

Appendix
Safety Instruction
FCC Notice (U.S. Only) and Other Regulatory Information
Contacting Dell

NOTE: A NOTE indicates important information that helps you make better use of your computer.
NOTICE: A NOTICE indicates either potential damage to hardware or loss of data and tells you how to avoid the problem.

CAUTION: A CAUTION indicates a potential for property damage, personal injury, or death.

Great user manuals database on UserManuals.info

Back to Contents Page



About Your Monitor

Dell™SP2008WFPFlatPanelMonitor

Front View

Back View

Bottom View

Side View

Monitor Specifications

Cleaning Your Monitor



Front View

Back View

Video input select

OSD menu / select button

Brightness & Contrast / Down (-) button

Auto-Adjust / Up (+) button

Power button (with power light indicator)

Webcam

MIC

Great user manuals database on UserManuals.info



Bottom View

NOTE: You can use this connector only after you connect the USB cable to the computer and the USB upstream connector on the monitor.

Side View

VESA mounting holes (100mm) (Behind

attached base plate)

Use to mount the monitor.

Barcode serial number label

Refer to this label if you need to contact Dell for technical support.

Security lock slot

Use a security lock with the slot to help secure your monitor.

Dell Soundbar mounting brackets

Attach the optional Dell Soundbar.

Regulatory rating label

List the regulatory approvals.

Stand removal button

Press to release the stand.

Cable management hole

Help organize cables by placing them through the hole.

Power connector

Insert the power cable.

Dell Soundbar

power connector

Connect the power cord for the Soundbar (optional).

DVI connector

Connect your computer DVI cable.

VGA connector

Connect your computer VGA cable.

USB upstream

connector

Connect the USB cable that came with your monitor to the monitor and the

computer. Once this cable is connected you can use the USB connectors on the side

andbottomofthemonitor.

USB connector

Connect your USB devices.

Great user manuals database on UserManuals.info

Monitor Specifications

Power Management Modes

IfyouhaveVESA'sDPM™compliancedisplaycardorsoftwareinstalledinyourPC,themonitorautomaticallyreducesitspowerconsumptionwhennotinuse.

This is referred to as Power Save Mode. The monitor automatically resumes functioning when the computer detects input from the keyboard, mouse, or other

input devices. The following table shows the power consumption and signaling of this automatic power saving feature:



Activate the computer and the monitor to gain access to the OSD.

* Zero power consumption in OFF mode can only be achieved by disconnecting the main cable from the monitor.

Pin Assignments

15-pin D-Sub Connector

USB connectors (downstream)

Left side



Right side



VESA Modes

Horizontal Sync

Vertical Sync

Video

Power Indicator

Power Consumption

Normal operation (with Dell Soundbar and USB active)

Active

Blue

75 W (maximum)

Normal operation

Active

Blue

38 W (typical)

Active-off mode

Inactive

Blanked

Amber

Less than 2 W

Switch off

Off

Less than 1 W

NOTE: The OSD only functions in the normal operation mode. One of the following messages appears when the “menu”or “plus”

buttons are pressed when in

Active-off mode.

1. Auto Detect (Analog Input)

In Power Save Mode

Press Computer Power Button

or Any Key on Keyboard or Move Mouse

1. Auto Detect (Digital Input)

In Power Save Mode

Press Computer Power Button

or Any Key on Keyboard or Move Mouse

2. Analog Input

In Power Save Mode

Press Computer Power Button

or Any Key on Keyboard or Move Mouse

3. Digital Input

In Power Save Mode

Press Computer Power Button

or Any Key on Keyboard or Move Mouse

This monitor is ENERGY STAR®-compliant as well as TCO '99 power management compatible.

Great user manuals database on UserManuals.info

The following table shows pin assignments in the D-Sub connector:

24-pin Digital-only DVI Connector

NOTE: Pin 1 is at the top right.

The following table shows pin assignments in the DVI connector:

Universal Serial Bus (USB) Interface

USB ports:

Pin Number

Monitor Side of the 15-pin Side Signal Cable

Video-Red

Video-Green

Video-Blue

GND

Self-Test

GND-R

GND-G

GND-B

DDC +5V

GND

DDC data

H-sync

V-sync

DDC clock

Signal Assignment

T.M.D.S. Data 2-

T.M.D.S. Data 1-

T.M.D.S. Data 0-

T.M.D.S. Data 2+

T.M.D.S. Data 1+

T.M.D.S. Data 0+

T.M.D.S. Data 2 Shield

T.M.D.S. Data 1 Shield

T.M.D.S. Data 0 Shield

No Connect

DDC Clock

+5V Power

T.M.D.S. Clock Shield

DDC Data

Self-Test

T.M.D.S. Clock +

No Connect

Hot Plug Detect

T.M.D.S. Clock -

This monitor supports High-Speed Certified USB 2.0 interface.



Data Rate

PowerConsumption

High speed

480 Mbps

2.5W(Max.,eachport)

Full speed

12 Mbps

2.5W(Max.,eachport)

Low speed

1.5 Mbps

2.5W(Max.,eachport)

Great user manuals database on UserManuals.info

l1 upstream -rear

l4 downstream -2 on rear; 2 on left side

Plug and Play Capability

You can install the monitor in any Plug and Play-compatible system. The monitor automatically provides the computer system with its Extended Display

Identification Data (EDID) using Display Data Channel (DDC) protocols so the system can configure itself and optimize the monitor settings. Most monitor

installations are automatic; you can select different settings, if desired.

NOTE: USB2.0capabilityrequires2.0-capablecomputer.

NOTE: The USB interface of the monitor works ONLY when monitor is powered ON (or in Power Save Mode). Switching your monitor OFF and then ON

would re-enumerate its USB interface; attached peripherals may take a few seconds to resume normal functionality.

General

Model number

SP2008WFP

Flat Panel

Screen type

Active matrix -TFT LCD

Screen dimensions

20.1 inches (20.1-inch viewable image size)

Preset display area:

Horizontal

433.44 mm (17.06 inches)

Vertical

270.9 mm (10.67 inches)

Pixel pitch

0.258 mm

Viewing angle

160°(vertical)typ,160°(horizontal)typ

Luminance output

300 CD/m ²(typ)

Dynamic contrast ratio

2000 to 1 (typ)

Faceplate coating

ARC-Glare (2H)

Backlight

CCFL (4) edgelight system

Response Time

2ms typical (Grey to Grey)

Webcam -MIC Specifications

Lens

Field of view

66.5 degree +/-5 %

Focus mode

FixedFocus

Focus area

49cm~Infinity

Focusing

distance(normal

mode)

1100 mm

Image Sensor

Active array size

2.0 mega-pixel

Video specification

Video frame rate

1600 x 1200 (UXGA) -up to 10 frames per second

640 x 480 (VGA) and below -up to 30 frames per second

Image flip

Horizontally

Digital zoom

Audio Specification

Microphone type

Dual Microphone

Interface

USB 2.0 high Speed

Power Supply

5.0 volts+-5%

Webcam -MIC System Requirements

The following are the minimum system requirements for Webcam - MIC feature:

Intel®Pentium®4 or AMD®equivalent processor running at 1.8 GHz or higher (Recommended: Intel Pentium 4, 2.8 GHz with Hyper-Threading enabled)

Microsoft®Windows®XP Service Pack 2 or Windows Vista

256 MB RAM (512 MB RAM or higher recommended)

580 MB free hard disk space

Great user manuals database on UserManuals.info

Available USB 1.1 port or a USB 1.1 hub with external power supply (USB 2.0 required for maximum frame rate and resolution)

CD-ROM/DVD-ROM drive for software installation

Monitor Resolution

Horizontal scan range

30 kHz to 83 kHz (automatic)

Vertical scan range

56Hzto76Hz(automatic)

Optimal preset resolution

1680 x 1050 at 60 Hz

Highest preset resolution

1680 x 1050 at 60 Hz

Video Supported Modes

Video display capabilities (DVI HD playback)

480i/480p/576i/576p/720p/1080i/1080p (Supports HDCP)

Preset Display Modes

For quick adjustments of different modes, the monitor has default setting modes as shown in the following table:

Display Mode

Horizontal Frequency (kHz)

Vertical Frequency (Hz)

Pixel Clock

(MHz)

Sync Polarity

(Horizontal/Vertical)

VESA, 720 x 400

31.5

70.0

28.3

-/+

VESA, 640 x 480

31.5

60.0

25.2

-/-

VESA, 640 x 480

37.5

75.0

31.5

-/-

VESA, 800 x 600

37.9

60.0

40.0

+/+

VESA, 800 x 600

46.9

75.0

49.5

+/+

VESA, 1024 x 768

48.4

60.0

65.0

-/-

VESA, 1024 x 768

60.0

75.0

78.8

+/+

VESA, 1152 x 864

67.5

75.0

108

+/+

VESA, 1280 x 1024

64.0

60.0

108

+/+

VESA, 1280 x 1024

80.0

75.0

135.0

+/+

VESA1680x1050

65.3

146.3

-/+

VESA, 1680 x 1050

64.7

59.9

119

+/-

Electrical

Video input signals

Analog RGB, 0.7 Volts +/-5%, positive polarity at 75 ohm input impedance

Digital DVI-D TMDS, 600mV for each differential line, positive polarity at 50 ohm input

impedance

Synchronization input signals

Separate horizontal and vertical synchronizations, polarity-free TTL level, SOG (Composite

SYNC on green)

AC input voltage / frequency / current

100 to 240 VAC / 50 or 60 Hz +3 Hz / 1.5A

Inrush current

120V:30A (Max.)

240V:60A (Max.)

Physical Characteristics

The following table shows the physical characteristics of monitor:

Connector type

15-pin D-subminiature, blue connector; DVI-D, white connector

Signal cable type

Digital: Detachable, DVI-D, Solid pins, shipped detached from the monitor

Analog: Detachable, D-Sub, 15pins, shipped attached to the monitor

Dimensions (with stand):

Height

15.39 inches (390.98 mm)

Width

18.62 inches (473.05 mm)

Depth

5.80 inches (147.36 mm)

Dimensions: (without stand)



Great user manuals database on UserManuals.info



Cleaning Your Monitor

lTo clean your antistatic screen, slightly dampen a soft, clean cloth with water. If possible, use a special screen-cleaning tissue or solution suitable for

the antistatic coating. Do not use benzene, thinner, ammonia, abrasive cleaners, or compressed air.

lUse a slightly-dampened,warmclothtocleantheplastics.Avoidusingdetergentofanykindassomedetergentsleaveamilkyfilmontheplastics.

lIf you notice a white powder when you unpack your monitor, wipe it off with a cloth. This white powder occurs during the shipping of the monitor.

lHandleyourmonitorwithcareasdarker-colored monitor may scratch and show white scuff marks more than lighter-coloredmonitor.

lTo help maintain the best image quality on your monitor, use a dynamically changing screen saver and power off your monitor when not in use.





Back to Contents Page

Height

12.56 inches (319.2 mm)

Width

18.62 inches (473.05 mm)

Depth

2.59 inches (65.9 mm)

Stand dimensions:



Height

11.69 inches (297.03 mm)

Width

10.42 inches (264.84 mm)

Depth

5.8 inches (147.36 mm)

Weight with packaging

17.73 lbs (8.05 kg)

Weight with stand assembly and cables

15.49 lbs (7.03 kg)

Weight without stand assembly

(For wall mount or VESA mount considerations -no cables)

11.45 lbs (5.20 kg)

Weight of stand assembly

2.89 lbs (1.31 kg)

Environmental

Refer to the operation conditions given below to use the monitor correctly.

Temperature:



Operating

5°to35°C(41°to95°F)

Nonoperating

Storage: -20°to60°C(-4°to140°F)

Shipping: -20°to60°C(-4°to140°F)

Humidity:

Operating

10% to 80% (noncondensing)

Nonoperating

Storage: 5% to 90% (noncondensing)

Shipping: 5% to 90%(noncondensing)

Altitude:

Operating

3,657.6m (12,000 ft) max

Nonoperating

12,192 m (40,000 ft) max

Thermal dissipation

256.08 BTU/hour (maximum)

129.75 BTU/hour (typical)

CAUTION: Read and follow the safety instructionsbeforecleaningthemonitor.

CAUTION:Beforecleaningthemonitor,unplugthemonitorpowercablefromtheelectricaloutlet.

Great user manuals database on UserManuals.info

Back to Contents Page



Appendix

Dell™SP2008WFPFlatPanelMonitor

Safety Instructions

FCC Notice (U.S. Only) and Other Regulatory Information

Contacting Dell



CAUTION: Safety Instructions

For safety instructions, see the Product Information Guide.

FCC Notice (U.S. Only) and Other Regulatory Information

For FCC Notice and other regulatory information, see the regulatory compliance website located at www.dell.com/regulatory_compliance.

Contacting Dell

For customers in the United States, call 800-WWW-DELL (800-999-3355).

Dell provides several online and telephone-based support and service options. Availability varies by country and product, and some services may not be

available in your area. To contact Dell for sales, technical support, or customer service issues:

Back to Contents Page

CAUTION: Use of controls, adjustments, or procedures other than those specified in this documentation may result in exposure to shock,

electrical hazards, and/or mechanical hazards.

NOTE: If you do not have an active Internet connection, you can find contact information on your purchase invoice, packing slip, bill,

or Dell product catalog.

Visit support.dell.com.

Verify your country or region in the Choose A Country/Region drop-downmenuatthebottomofthepage.

Click Contact Us on the left side of the page.

Select the appropriate service or support link based on your need.

Choose the method of contacting Dell that is convenient for you.

Great user manuals database on UserManuals.info

Back to Contents Page

Setting Up Your Monitor

Dell™SP2008WFPFlatPanelMonitor

IfyouhaveaDell™desktoporaDell™portablecomputerwithinternetaccess

1. Go to http://support.dell.com,enteryourservicetag,anddownloadthelatestdriverforyourgraphicscard.

2. After installing the drivers for your Graphics Adapter, attempt to set the resolution to 1680x1050 again.

Back to Contents Page

NOTE:

Ifyouareunabletosettheresolutionto1680x1050,pleasecontactDell™toinquireaboutaGraphicsAdapterthatsupportstheseresolutions.

Table des matières

Autres manuels Dell Moniteur

Dell

Dell P7524QT Manuel utilisateur

Dell

Dell P2418HZ Manuel utilisateur

Dell

Dell 2709W - UltraSharp - Widescreen LCD Monitor Manuel utilisateur

Dell

Dell S2340T Touch Manuel de la liste des pièces

Dell

Dell P3221D Manuel utilisateur

Dell

Dell P2421DC Instructions d'utilisation

Dell

Dell P1911 Instructions d'utilisation

Dell

Dell S2721Q Manuel utilisateur

Dell

Dell TORINITRON P1130 Manuel utilisateur

Dell

Dell S2721HN Manuel utilisateur

Dell

Dell SP190SFP Manuel utilisateur

Dell

Dell SE2417HG Manuel utilisateur

Dell

Dell SP2309W Manuel utilisateur

Dell

Dell E2209Wf Manuel utilisateur

Dell

Dell UltraSharp U2424HB Manuel utilisateur

Dell

Dell ST2320L Manuel utilisateur

Dell

Dell E773mm Manuel utilisateur

Dell

Dell UltraScan 15TX Manuel utilisateur

Dell

Dell 1900FP - UltraSharp - 19" LCD Monitor Manuel utilisateur

Dell

Dell E1715S Instructions d'installation

Dell

Dell E2015HV Manuel utilisateur

Dell

Dell U4320Q Manuel utilisateur

Dell

Dell M783c Manuel utilisateur

Dell

Dell P3424WEB Manuel utilisateur

Manuels Moniteur populaires d'autres marques

Linear Acoustic

Linear Acoustic LQ-1000 Manuel utilisateur

AOC

AOC I2579V Manuel utilisateur

Gateway

Gateway FPD1520 Manuel utilisateur

Furuno

Furuno Mu 120c Manuel utilisateur

Asus

Asus VB171D - 17" LCD Monitor Manuel utilisateur

Philips

Philips 107C64 Manuel utilisateur

EverFocus

EverFocus EN-7517E Manuel utilisateur

Panasonic

Panasonic TH152UX1 - 152" PLASMA TV Manuel utilisateur

LG 50PM1M - - 50" Plasma Panel Manuel utilisateur

Bosch

Bosch DDU 9 Manuel utilisateur

Acer

Acer A231HL Manuel utilisateur

Philips

Philips 86BDL4152T Manuel utilisateur

NEC

NEC AccuSync LCD5V Manuel utilisateur

Emay

Emay SleepO2 Manuel utilisateur

IBM

IBM 6360 Instructions d'installation

LG M1950D-PZ Manuel utilisateur

Sceptre

Sceptre D40 Manuel utilisateur

Hunt Electronic

Hunt Electronic HCD-15AH Manuel utilisateur
