Dell SE2219H Manuel utilisateur

Monitor Model: SE2219H/SE2219HX

Regulatory model: SE2219Hf

Dell SE2219H/SE2219HX

User’s Guide

are trademarks of Dell Inc. or its subsidiaries. Other trademarks may be trademarks of their respective

owners.

2018 – 09

Rev. A01

Notes, Cautions and Warnings

NOTE: A NOTE indicates important information that helps you make

better use of your computer.

CAUTION: A CAUTION indicates potential damage to hardware or loss

of data if instructions are not followed.

WARNING: A WARNING indicates a potential for property damage,

personal injury, or death.

Contents

About your monitor 5

Identifying features and controls 7

LCD monitor quality and pixel policy

Setting up the monitor 17

Connecting the stand 17

Package contents

Removing the stand 20

Operating your monitor 22

Turning on the monitor 22

Using the front panel controls 22

Using the On-Screen Display (OSD) menu 24

│

.........................

......................

.....................

Product features

. . . . . . . . . . . . . . . . . . . . . .

Using tilt . . . . . . . . . . . . . . . . . . . . . . . . . .

. . . . . . . . . . . . .

. . . . . . . . . . .

. . . . . . . .

. . . . . . . . . . . . . . . . . . . . .

. . . . . . . . . . . . . . . . . . .

Organizing cables . . . . . . . . . . . . . . . . . . . . .

. . . . . . . . . . . . . . . . . .

Setting up your monitor . . . . . . . . . . . . . . . . . . 40

Connecting your monitor . . . . . . . . . . . . . . . . .

. . . . . . . . . . . . . .

Maintenance guidelines . . . . . . . . . . . . . . . . . .

Plug and play capability

. .

. ..

Monitor sepcifiactions

. .

. .. .

Troubleshooting 43

Appendix 49

Contacting Dell 49

4 │

.................................

...........................

. . . . . . . . . . . . . . . . . . . . . .

Self-test . . . . . . . . . . . . . . . . . . . . . . . . .

Built-in diagnostics

Common problems

. . . . . . . . . . . . . . . . . . . .

. . . . . . . . . . . . .

. . .

FCC notices (U.S. Only) and

other regulatory information

. . . . . . . . . . . .

Contents

Pin assignments . . . . . . . . . . . . . . . . . . . . . .

Product-specific problems

About your m |rotino 5

About your monitor

Package contents

Your monitor ships with the components indicated in the table. Ensure that you

have received all the components and see Contacting Dell if anything is missing.

Monitor

Stand riser

Stand base

Power cable (varies by

country)

VGA cable

(SE2219H)

NOTE: Some items may be optional and may not ship with your

monitor. Some features may not be available in certain countries.

NOTE: To set up with any other stand, see the documentation that

shipped with the stand.

SE2219H/SE2219HX : 54.61 cm (21.5 inch) diagonal viewable area

display(measured diagonally). 1920 x 1080 resolution, with full-screen support for

lower resolutions.

Wide viewing angles of 178 degrees in vertical and horizontal directions.

High dynamic contrast ratio (8,000,000:1).

HDMI connectivity makes it simple and easy to connect with legacy and new

systems.

Plug and play capable if supported by your computer

On-Screen Display (OSD) adjustments is to easy setup and optimize screen.

0.5 W standby power when in the sleep mode.

Optimize eye comfort with a icker-free screen.

Possible long-term eects if blue light emission from the monitor may cause

damage to the eyes, including eye fatigue or digital eye strain. ComfortView feature

is designed to reduce the amount of blue light emitted from the monitor to help

optimize eye comfort.

Security-lock slot.

Arsenic-free glass and mercury-free panel.

BFR/PVC-Reduced (the circuit boards inside your monitor are made using BFR/

PVC-free laminates).

RoHS Compliant.

Energy Saver feature for Energy Star compliance.

| About your monitor

HDMI cable

(SE2219HX)

Quick Setup Guide

Safety and Regulatory

Information

Product features

The Dell SE2219H/SE2219HX at panel display has an active matrix,

Thin-Film Transistor (TFT), Liquid Crystal Display (LCD), anti-static,and LED backlight.

The monitor features include:

About your monito r | 7

Identifying features and controls

Front view

Label Description Use

1Function buttons To access the OSD menu and change

the settings if required. (For more

information, see Using the front panel

controls)

2Power On/Off button

(with LED indicator) To turn the monitor On or Off.

8 | About your monitor

Back view

Label Description Use

1Security-lock slot To secure the monitor using a security

lock (purchased separately).

2Regulatory label, barcode, serial

number, and Service Tag label

List the regulatory approvals. See this

label if you need to contact Dell for

technical support. The Service Tag is a

unique alphanumeric identifier that

enables Dell service technicians to

identify the hardware components in

your computer and access warranty

information.

3Regulatory information (engraved) List the regulatory approvals.

Stand release button Release stand from monitor.

To organize cables.

Side view

Cable-management slot

With monitor stand

Without monitor stand

321

About your monitor | 9

Bottom view, without monitor stand

Label Description Use

1Power port To connect the monitor power cable.

VGA port For connection to your computer using VGA cable.

HDMI port For connection to your computer using HDMI cable.

SE2219H/SE2219HX

1274.84 cm2(197.52 in. 2

10 | About your monitor

Model

Screen type Active matrix-TFT LCD

Panel type In-Plane Switching

Viewable area

Diagonal

Active area:

Horizontal

Vertical

Area

546.1 mm (21.5 in. )

)

Pixel pitch 0.24795 mm

Pixel per inch (PPI) 102

Viewing angle:

Vertical

Horizontal

178° (typical)

Brightness 250 cd/m2

(typical)

Contrast ratio 1,000 to 1 (typical)

8,000,000 to 1 (Dynamic Contrast)

Faceplate coating Anti-glare with 3H hardness

Backlight LED edgelight system

8 ms

5 ms

Color depth 16.7 million colors

Color gamut CIE 1931 (72%)

Dell display manager

compatibility

Yes

Connectivity

Bezel width (edge of

monitor to active area)

6.4 mm (Top)

6.4 mm (Left/Right)

20.5 mm (Bottom)

Security Security-lock slot for cable lock (optional purchase)

Tilt angle -5° to 21°

One VGA port and one HDMI 1.4 (HDCP 1.4) port

with SE2219H/SE2219HX monitors.

267.79 mm (10.54in. )

476.06 mm (18.74 in. )

Response time (Gray to Gray):

Normal mode

Fast mode

SE2219H/SE2219HX

Monitor specications
