Dell E2318H Instructions d'utilisation

Simplified Service Manual

LCD Monitor

E2318H

Simplified Service Manual

Service Manual Versions and Revision

No.

Version

Release Date

Revision

1.0

2.0

2017/02/16

2021/02/26

Initial Release

ErP lot 5 additional requirements

Simplified Service Manual

1. IMPORTANT SAFETY NOTICE ............................................................................................................................................................... 4

2. EXPLODED VIEW DIAGRAM WITH LIST OF ITEMS ...................................................................................................................................... 4

3. WIRING CONNECTIVITY DIAGRAM........................................................................................................................................................ 5

4. LIST OF TOOLS /EQUIPMENT .............................................................................................................................................................. 5

5. DISASSEMBLY AND ASSEMBLY PROCEDURES .......................................................................................................................................... 6

6. TROUBLE SHOOTING INSTRUCTIONS ..................................................................................................................................................... 8

Simplified Service Manual

1. Important Safety notice

2. Exploded view diagram with list of items

Simplified Service Manual

3. Wiring connectivity diagram

4. List of tools / equipment

1. Philips-head screwdriver

2. Hex-head screwdriver

Simplified Service Manual

5. Disassembly and Assembly Procedures

key pad board* 1

FINAL ASSY *1

(SCREW ,P,CROSS M3*6,ZN-

CC)*3

Power board* 1

CHASSIS ASSY

STAND ASSY

B A G, PL A ST I C ,L 160xW

220* T 0. 05mm( PR I NT E D) *1

BACK COVER

ASSY*1

V E SA cover* 1

F ront bezel *1

OSD button*1

FRONT BEZEL ASSY

LE23QU DISASSEMBLY BLOCK

MY L AR FOR CHASSIS*1

R ear-l ogo cover* 1

(SCREW,F,CROSS,T.T-2*3,BL K)* 3

Power button*1

Panel ASSY

DELL Logo

Panel *1

L abel l ef t* 1

BACK COVER*

Label mid*1

(SCREW,I,CROSS,M4*10,BLK-NL )*4

FFC-CABLE*1

(SCREW ,P,CROSS M3*6,ZN-CC)*2

( B OL T , #4-40x 11. 8,Ni F OR

D-SUB/DVI CONN.RO )* 2

I/F BOARD*1

MYLAR FOR PANEL*1

(T ape A CE 85* 20) *1

(Tape A CE W40* L 25)* 1

KEYPAD WIRE*1

LIGHT BAR*1

V E S A C OV E R

ASSY

Chassis*1

BRACKET*1

RELEASE BUTTON*1

SCREW,F,CROSS,T3*4.2,Zn-Cc,BLK,HF*1

(FOI L ,AL ,DOUB L E

COND,80x50xT 0.07mm)*2

Simplified Service Manual

LE23QU ASSEMBLY BLOCK

(SCREW ,P,CROSS

M3* 6,ZN-CC)* 3

FFC-CABLE*1

(

SCREW ,P,CROSS M3*6,ZN-CC

)

(B OL T , #4-40x11. 8,Ni FOR D-SUB /DV I

CONN.RO )*

PANEL ASSY *1

BACK COVER ASSY *1

keypad board* 1

Chassis*1

I /F board

Power board*1

panel * 1

CHASSIS ASSY *1

V E SA COV E R * 1

Rear DELL Logo*1

F ront bezel * 1

FRONT BEZEL ASSY *1

FI NAL ASSY *1

OSD button * 1

(SCREW,I,CROSS,M4*10,BLK-NL )*4

STAND ASSY *1

Power button * 1

DE L L L ogo * 1

L abel l ef t* 1

MY LAR FOR CHASSIS*1

MYLAR FOR PANEL*1

(SCREW,F,CROSS,T.T-2*3,BL

K)*3

L abel mi d* 1

LIGHT BAR*1

KEYPAD WIRE*1

(T ape A CE W40* L 25)* 1

(T ape A CE 85* 20)* 1

B A G, PL A ST I C,L 160xW

220* T 0.05mm(PR INT E D) *1

VESA COVER ASSY

BRACKET*1

RELEASE BUTTON*1

SCREW,F,CROSS,T3*4.2,Zn-Cc,BLK,HF*1

(FOIL,AL,DOUBLE

COND,80x50xT 0.07mm)*2

Simplified Service Manual
