Dell S2723HC Manuel utilisateur

Monitor Model: S2723HC

Regulatory Model: S2723HCt

Dell S2723HC Monitor

User’s Guide

NOTE: A NOTE indicates important information that helps you make better

use of your monitor.

CAUTION: A CAUTION indicates potential damage to hardware or loss of

data if instructions are not followed.

WARNING: A WARNING indicates a potential for property damage,

personal injury, or death.

trademarks of Dell Inc. or its subsidiaries. Other trademarks may be trademarks of their respective owners.

2022 – 03

Rev. A00

| 3

Contents

Safety instructions.......................... 5

About your monitor ......................... 6

Package contents . . . . . . . . . . . . . . . . . . . . . . 6

Product features . . . . . . . . . . . . . . . . . . . . . . .7

Identifying parts and controls . . . . . . . . . . . . . . . .8

Front view . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8

Back view . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9

Bottom view . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10

Monitor specifications . . . . . . . . . . . . . . . . . . . 11

Resolution specifications . . . . . . . . . . . . . . . . . . . . . . 12

Preset display modes . . . . . . . . . . . . . . . . . . . . . . . . 13

Electrical specifications. . . . . . . . . . . . . . . . . . . . . . . 13

Speaker Specifications . . . . . . . . . . . . . . . . . . . . . . . 15

Physical characteristics. . . . . . . . . . . . . . . . . . . . . . . 15

Environmental characteristics . . . . . . . . . . . . . . . . . . . 16

Pin assignments . . . . . . . . . . . . . . . . . . . . . . . . . . . 17

Plug-and-play . . . . . . . . . . . . . . . . . . . . . . . 20

LCD monitor quality and pixel policy . . . . . . . . . . . 20

Ergonomics. . . . . . . . . . . . . . . . . . . . . . . . . 21

Handling and moving your display . . . . . . . . . . . . . 22

Maintenance Guidelines . . . . . . . . . . . . . . . . . . 24

Damage to Monitor Through Incorrect Cleaning Methods. . . . . 24

Setting up the monitor ...................... 25

Connecting the stand . . . . . . . . . . . . . . . . . . . 25

Using the tilt, swivel, and vertical extension . . . . . . . 27

Contents | 3

4| Contents

Tilt, Swivel, and Vertical Extension . . . . . . . . . . . . . . . . . 27

Rotating the display . . . . . . . . . . . . . . . . . . . . 28

Configuring the display settings on your computer after

rotation . . . . . . . . . . . . . . . . . . . . . . . . . . . 28

Connecting your monitor . . . . . . . . . . . . . . . . . 29

Organizing your cables. . . . . . . . . . . . . . . . . . . 31

Securing your monitor using Kensington lock (optional) . 31

Removing the monitor stand . . . . . . . . . . . . . . . 32

Wall mounting (optional) . . . . . . . . . . . . . . . . . 33

Operating the monitor ...................... 34

Power on the monitor . . . . . . . . . . . . . . . . . . . 34

Using the front panel controls . . . . . . . . . . . . . . . 34

Using the OSD lock function . . . . . . . . . . . . . . . 36

Front-panel button . . . . . . . . . . . . . . . . . . . . . 38

Using the On-Screen Display (OSD) menu . . . . . . . . 39

Accessing the menu system . . . . . . . . . . . . . . . . . . . . 39

OSD warning messages . . . . . . . . . . . . . . . . . . . . . . .50

Setting the maximum resolution . . . . . . . . . . . . . . . . . . 53

Troubleshooting ........................... 54

Self-test . . . . . . . . . . . . . . . . . . . . . . . . . . 54

Built-in diagnostics . . . . . . . . . . . . . . . . . . . . 55

Common problems . . . . . . . . . . . . . . . . . . . . . 56

Product specific problems. . . . . . . . . . . . . . . . . 58

Universal Serial Bus (USB) specific problems . . . . . . 60

Appendix..................................61

FCC notices (U.S. only) and other regulatory information 61

Contacting Dell. . . . . . . . . . . . . . . . . . . . . . . 61

EU product database for energy label and product

information sheet . . . . . . . . . . . . . . . . . . . . . 61

Safety instructions | 5

Safety instructions

CAUTION: Use of controls, adjustments, or procedures other than those

specified in this documentation may result in exposure to shock, electrical

hazards, and/or mechanical hazards.

• Place the monitor on a solid surface and handle it carefully. The screen is fragile

and can be damaged if dropped or hit sharply.

• Always be sure that your monitor is electrically rated to operate with the AC

power available in your location.

• Keep the monitor in room temperature. Excessive cold or hot conditions can have

an adverse effect on the liquid crystal of the display.

• Do not subject the monitor to severe vibration or high impact conditions. For

example, do not place the monitor inside a car trunk.

• Unplug the monitor when it is going to be left unused for an extended period of

time.

• To avoid electric shock, do not attempt to remove any cover or touch the inside

of the monitor.

For information on safety instructions, see the Safety, Environmental, and Regulatory

Information (SERI) document that is shipped with your monitor.

6| About your monitor

About your monitor

Package contents

Your monitor ships with the components shown below. Ensure that you have received

all the components and see Contacting Dell if anything is missing.

NOTE: Some components may be optional and may not ship with your

monitor. Somefeatures may not be available in certain countries.

Display

Stand riser

Stand base

Power cable (varies by country)

USB 3.2 Gen 1 Type-C cable (C to

About your monitor | 7

• Quick Start Guide

• Safety, Environmental, and

Regulatory Information

Product features

The Dell S2723HC monitor has an active matrix, Thin-Film Transistor (TFT), Liquid

Crystal Display (LCD), and LED backlight. The monitor features include:

• 68.6 cm (27 in.) active area display (measured diagonally). 1920 x 1080 (16:9)

resolution, plus full-screen support for lower resolutions.

• Speakers (2 x 3 W).

• Removable pedestal and Video Electronics Standards Association (VESA™) 100

mm mounting holes for flexible mounting solutions.

• Ultra-thin bezel minimizes the bezel gap in multi-monitor usage, enabling easier

set up with an elegant viewing experience.

• Extensive digital connectivity with HDMI helps future-proof your monitor.

• Plug-and-play capability if supported by your computer.

• On-Screen Display (OSD) adjustments for ease of set-up and screen

optimization.

• Supports AMD FreeSync™ technology. AMD Freesync™ certified range from 48

Hz - 75 Hz.

• Color gamut of 99% sRGB.

• Digital connectivity with USB Type-C and HDMI.

• Use a USB Type-C cable to provide power (up to 65 W) to compatible notebook

while receiving video and data signal.

• Tilt, swivel, pivot and height adjustment capabilities.

• Power and OSD buttons lock.

• Security-lock slot.

• ≤ 0.3 W in off Mode.

• Optimize eye comfort with a flicker-free screen.

• Premium Panel Exchange for peace of mind.

• Optimize eye comfort with a flicker-free screen minimizes hazard blue light

emission.

• The Monitor use Low Blue Light panel and compliance with TUV Rheinland

(Hardware Solution) at factory reset/default setting model.

8| About your monitor

• Decreases the level of hazard blue light emitted from the screen to make viewing

more comfortable for your eyes.

• The Monitor adopts Flicker-Free technology, which clears the eye visible flicker,

brings comfort viewing experience and preventing users suffer from eye strain

and fatigue.

* PC system that supports DPBS is in Dell website.

WARNING: The possible long-term effects of blue light emission from the

monitor may cause damage to the eyes, including eye fatigue or digital eye

strain.

Identifying parts and controls

Front view

1 2

Label Description Use

1Function buttons For more information, see Operating the Monitor.

2Power on/off button

(with LED indicator)

To turn the monitor on or off.

About your monitor | 9

Back view

Label Description Use

1VESA mounting holes (100 mm

x 100 mm-behind attached

VESA cover)

Wall mount monitor using VESA-compatible

wall mount kit (100 mm x 100 mm).

2Regulatory label Lists the regulatory approvals.

3Stand release button Releases stand from monitor.

4Barcode, serial number, and

Service Tag label

Refer to this label if you need to contact

Dell for technical support. The Service Tag

is a unique alphanumeric identifier that

enables Dell service technicians to identify

the hardware components in your display

and access warranty information.

5Cable management slot Use to organize cables by placing them

through the slot.

10 | About your monitor

Bottom view

1 2 3 456 788

Label Description Use

1Security-lock slot Secures monitor with security cable lock (sold

separately).

2Power connector Connect the power cable (shipped with your

monitor).

3HDMI port Connect your computer with the HDMI cable.

4USB-C port

(Video + Data)

Connect to your computer using the USB-C cable.

The USB-C port offers the fastest transfer rate

(USB 3.2Gen 1). The alternate mode with DP 1.2

supports the maximum resolution of 1920 x 1080

at 75 Hz and PD 20 V/3.25 A, 15 V/3 A, 9 V/3 A,

5 V/3 A.

NOTE: USB-C is not supported on Windows

versions that are prior to Windows 10.

5Audio line-out port Connect speakers to playback audio through

HDMI or USB-C audio channels.

Only two-channel audio is supported.

NOTE: The audio line-out port does not support

headphones.

6USB 3.2 downstream

port

Connect the USB-C cable that comes with your

monitor to the computer. Once this cable is

connected, you can use the USB downstream

connectors on your monitor.

Port supports 0.9 A.

7USB 3.2 downstream

port

Connect the USB-C cable that comes with your

monitor to the computer. Once this cable is

connected, you can use the USB downstream

connectors on your monitor.

Port supports Battery Charging 2 A.

8Built-in speakers To output the sound from audio input.
