Dell S2340T Touch Manuel utilisateur

Dell™ S2340T Monitor

User Guide

Setting the display resolution to 1920 x 1080 (maximum)

Information in this document is subject to change without notice.

Reproduction of these materials in any manner whatsoever without the written permission of Dell Inc. is strictly forbidden.

Trademarks used in this text: Dell and the DELL logo are trademarks of Dell Inc; Microsoft and Windows are either trademarks or registered trademarks of Microsoft Corporation in the United States and/or

other countries, Intel is a registered trademark of Intel Corporation in the U.S. and other countries; and ATI is a trademark of Advanced Micro Devices, Inc. ENERGY STAR is a registered trademark of the

U.S. Environmental Protection Agency. As an ENERGY STAR partner, Dell Inc. has determined that this product meets the ENERGY STAR guidelines for energy efficiency.

Other trademarks and trade names may be used in this document to refer to either the entities claiming the marks and names or their products. Dell Inc. disclaims any proprietary interest in

trademarks and trade names other than its own.

Model S2340Tt

October 2012 Rev. A01

Dell™ S2340T Monitor User's Guide

About Your Monitor

Setting Up the Monitor

Operating the Monitor

Dell Display Manager User's Guide (only for HDMI/DisplayPort)

Troubleshooting

Appendix

Notes, Cautions, and Warnings

NOTE: A NOTE indicates important information that helps you make better use of your computer.

CAUTION: A CAUTION indicates either potential damage to hardware or loss of data and tells you how to avoid the problem.

WARNING: A WARNING indicates a potential for property damage, personal injury, or death.

Information in this document is subject to change without notice.

Reproduction of these materials in any manner whatsoever without the written permission of Dell Inc. is strictly forbidden.

Trademarks used in this text: Dell and the DELL logo are trademarks of Dell Inc; Microsoft and Windows are either trademarks or registered trademarks of Microsoft Corporation in the United

States and/or other countries, Intel is a registered trademark of Intel Corporation in the U.S. and other countries; and ATI is a trademark of Advanced Micro Devices, Inc. ENERGY STAR is a

registered trademark of the U.S. Environmental Protection Agency. As an ENERGY STAR partner, Dell Inc. has determined that this product meets the ENERGY STAR guidelines for energy

efficiency.

Other trademarks and trade names may be used in this document to refer to either the entities claiming the marks and names or their products. Dell Inc. disclaims any proprietary interest in

trademarks and trade names other than its own.

Model S2340Tt

October 2012 Rev. A01

Back to Contents Page

Setting Up Your Monitor

Dell™ S2340T Monitor

Setting the display resolution to 1920 x 1080 (maximum)

For maximum display performance with Microsoft® Windows® operating systems, set the display resolution to 1920 x 1080 pixels by performing the following steps:

In Windows® 7 or Windows® 8:

1. Right-click on the desktop and click Personalization.

2. Click Change Display Settings.

3. Move the slider-bar to the right by pressing and holding the left-mouse button and adjust the screen resolution to 1920 x 1080.

4. Click OK.

If you do not see 1920 x 1080 as an option, you may need to update your graphics driver. Please choose the scenario below that best describes the computer system you are

using, and follow the provided directions:

1: If you have a Dell™ desktop or a Dell™ portable computer with internet access.

2: If you have a non Dell™ desktop, portable computer, or graphics card.

Back to Contents Page

About Your Monitor

Dell™ S2340T Monitor User's Guide

Package Contents

Product Features

Identifying Parts and Controls

Monitor Specifications

Touch Specifications

Camera - MIC Specifications

Plug and Play Capability

Universal Serial Bus (USB) Interface

LCD Monitor Quality and Pixel Policy

Maintenance Guidelines

Package Contents

Your monitor ships with the components shown below. Ensure that you have received all the components and contact Dell if something is missing.

NOTE: Some items may be optional and may not ship with your Monitor. Some features or media may not be available in certain countries.

NOTE: To set up with any other stand, please refer to the respective stand setup guide for setup instructions.

Monitor with stand

Power cable

Power adapter

HDMI cable

DisplayPort cable

USB upstream cable (enables the USB ports on the monitor)

Cloth

Velcro strap

Drivers and Documentation media

Quick Setup Guide

Product and Safety Information Guide

Product Features

The S2340T flat panel display has an active matrix, Thin-Film Transistor (TFT), Liquid Crystal Display (LCD). The monitor features include:

■23-inch (58.42 cm) viewable area display (Measured diagonally). 1920 x 1080 resolution, and full-screen support for lower resolutions.

■Wide viewing angle to allow viewing from a sitting or standing position, or while moving from side-to-side.

■Tilt and touch usage scenario adjustment capability.

■Plug and play capability (if supported by your system).

■On-Screen Display (OSD) adjustments for ease of set-up and screen optimization.

■Software and documentation media includes an information file (INF), Image color Matching File (ICM), Dell Display Manager software

application and product documentation.

■Energy Saver feature for Energy Star compliance.

■Image Enhance feature.

■EPEAT Silver Rating.

■BFR/PVC-reduced.

■Arsenic-free glass and Mercury-free panel.

■Mega Dynamic Contrast (when turned on).

■Dell Display Manager software included (comes in the CD shipped with the monitor).

■TCO 6.0 certified displays.

■Webcam with the resolution of FHD 1080p (1920x1080) and digital dual Mic input.

■USB audio input selected from OSD munu.

■Integrated Gigabit USB Dock Ethernet (10/100/1000Mbit).

■Audio output with two channels of 5W speaker and stereo headphone jack.

■External Mic input jack.

■Minimum PC configuration: CPU 2nd Generation Intel® Core™ i5-2467M processor, Memory size 4GB Dual Channel DDR3 1333MHz, USB port

2.0, access to CD-ROM, HDMI and DP, Harddisk size minimum empty space 10GB.

■Recommended PC configuration: CPU 2nd Generation Intel® Core™ i7 series processor, Memory size 4GB Dual Channel DDR3 1333MHz, USB

port 3.0, access to DVD-ROM, HDMI and DP, Harddisk size empty space 40GB.

Identifying Parts and Controls

Front View

Front View Side panel controls

Label Description

1Webcam with MIC (Only for USB device)

2Preset Modes (default, but configurable)

3Brightness & Contrast (default, but configurable)

4Menu

5Exit

6Power

7Light Indicates

Back and Bottom View

Label Description Use

1DC power cord connector Connect the power cord.

2HDMI connector Connect to devices with HDMI output (or equivalent) such as PC, notebooks, DVD player or

set-up box.

3DisplayPort connector Connect to devices with DisplayPort output (or equivalent).

4USB downstream ports Connect your USB devices. You must connect the USB cable (provided) to the computer

and the monitor to use these ports.

5USB upstream port Connect to devices with USB Host. Once this cable is connected, you can use the docking

features and available USB ports on the side and back.

6RJ45 connector Support Ethernet connection 10/100/1000 Mbps.

7Security Lock Secures monitor with security cable lock.

8Barcode serial number label Required when contacting Dell for technical support.

9Regulatory label Lists the regulatory approvals.

Side View

Left view Right view

Label Description

1Speaker

2Microphone input (Only for USB device)

3Headphone out (Only for USB device)

4USB downstream ports
