Dell P2011H Manuel utilisateur

Dell™P2011HMonitorUser'sGuide

Notes, Notices, and Cautions



Information in this document is subject to change without notice.

©2010DellInc.Allrightsreserved.

Reproduction of these materials in any manner whatsoever without the written permission of Dell Inc. is strictly forbidden.

Trademarks used in this text: Dell and the DELLlogoaretrademarksofDellInc;Microsoft and Windows are either trademarks or registered trademarks of Microsoft Corporation in

the United States and/or other countries, Intel is a registered trademark of Intel Corporation in the U.S. and other countries; and ATI is a trademark of Advanced Micro Devices,

Inc. ENERGY STAR is a registered trademark of the U.S. Environmental Protection Agency. As an ENERGY STAR partner, Dell Inc. has determined that this product meets the

ENERGY STAR guidelines for energy efficiency.

Other trademarks and trade names may be used in this document to refer to either the entities claiming the marks and names or their products. Dell Inc. disclaims any

proprietary interest in trademarks and trade names other than its own.

Model P2011Ht.

July 2010 Rev. A01

About Your Monitor

Setting Up the Monitor

Operating the Monitor

Troubleshooting

Appendix



NOTE: A NOTE indicates important information that helps you make better use of your monitor.

CAUTION: A CAUTION indicates either potential damage to hardware or loss of data and tells you how to avoid the problem.

WARNING: A WARNING indicates a potential for property damage, personal injury or death.

Back to Contents Page



About Your Monitor

Dell™P2011HMonitorUser'sGuide

Package Contents

Your monitor ships with the components shown below. Ensure that you have received all the components and contact Dell if something is missing.

Package Contents

Product Features

Identifying Parts and Controls

Monitor Specifications

Plug and Play Capability

Universal Serial Bus (USB) Interface

LCD Monitor Quality and Pixel Policy

Maintenance Guidelines

NOTE: Some items may be optional and may not ship with your Monitor. Some features or media may not be available in certain countries.

NOTE: To set up with anyother stand, please refer to the respective stand setup guide for setup instructions.



lMonitor

lStand

lPower Cable

lVGA Cable



Product Features

The Dell™Professional P2011H flat panel display has an active matrix, thin-film transistor (TFT), liquid crystal display (LCD), and LED backlight. The monitor

features include:

■50.80cm(20inches)viewableareadisplay(Measureddiagonally).1600 X 900 resolution, plus full-screen support for lower resolutions.

■Tilt, swivel, vertical extension and rotate adjustment capability.

■Removable pedestal and Video Electronics Standards Association (VESA™) 100 mm mounting holes for flexible mounting solutions.

■Plug and play capability if supported by your system.

■On-Screen Display (OSD) adjustments for ease of set-up and screen optimization.

■Software and documentation media includes an information file (INF), Image color Matching File (ICM), PowerNap software application and product

documentation.

■Energy Saver feature for Energy Star compliance.

■Security lock slot.

■Asset Management Capability.

■Capability to switch from wide aspect to standard aspect ratio while maintaining the image quality.

■EPEAT Gold Rating.

■Halogen Reduced.

■Arsenic-Free glass and Mercury Free for Panel only.

■High Dynamic Contrast Ratio (DCR).

■0.5 W standby power when in sleep mode.^

■Energy Gauge shows the energy level being consumed by the monitor in real time.

■PowerNap Software included (comes in the CD attached with the monitor).

^Based on measurement of standby power consumption using VGA input.

Identifying Parts and Controls

Front View

lDVI Cable

lUSB up stream cable (enables the USB ports on the monitor)

lDrivers and Documentation media

lQuick Setup Guide

lProduct and Safety Information Guide

Back View



Front View

Front panel controls

Label

Description

Preset Modes (default, but configurable)

Brightness & Contrast (default, but configurable)

Exit

Power button (with power light indicator)

Back view

Back view with monitor stand

Label

Description

Use

VESA mounting holes (100 mm x 100 mm -

behind attached VESA Plate)

Wall mount monitor using VESA-compatible wall mount kit (100 mm x 100 mm)

Regulatory label

Lists the regulatory approvals.

Stand release button

Release stand from monitor.

Security lock slot

Secures monitor with security cable lock



Dell Soundbar mounting brackets

Attaches the optional Dell Soundbar.

Barcode serial number label

Refer to this label if you need to contact Dell for technical support.

USB downstream ports

Connect your USB devices.

Side View

Bottom View



Cable management slot

Use to organize cables by placing them through the slot.



Leftview



Right view

Bottom view

Bottom view with monitor stand

Label

Description

Use

AC power cord connector

Connect the power cable

DC power connector for Dell Soundbar.

Connect the power cord for the soundbar (optional)

DVI connector

Connect your computer DVI cable

VGA connector

Connect your computer VGA cable

USB upstream port

Connect the USB cable that came with your monitor to the monitor and the

computer. Once this cable is connected,you can use the USB connectors on

the side and bottom of the monitor.

Stand lock feature

To lock the Stand to the Monitor

Monitor Specifications

Flat Panel Specifications

Model

P2011H

Screen type

Active matrix -TFT LCD

Panel type

*[P2011H] color gamut (typical) is based on CIE1976 (79%) and CIE1931 (68%) test standards.

Screen dimensions

50.8 cm (20-inch viewable image size)

Preset display area:

462.8 (H) x 272.0(V) mm

Horizontal

462.8 mm (18.22 inches)

Vertical

272.0mm (10.71 inches)

Pixel pitch

0.277 mm

Viewing angle

160°(vertical)typ,170°(horizontal)typ

Luminance output

250 cd/m ²(typ)

Contrast ratio

1000 to 1 (typ)

Dynamic contrast ratio

Up to 2,000,000 : 1 (typ)

Faceplate coating

Antiglare with hard-coating 3H

Backlight

LED edgelight system

Response Time

5 ms typical

Color depth

16.7 million colors

Color gamut (Typical)

79%* (CIE1976 )

Resolution Specifications

Model

P2011H

Video Supported Modes

Horizontal scan range

30 kHz to 83 kHz (automatic)

Vertical scan range

56Hzto75Hz(automatic)

Maximum resolution

1600 X 900 at 60 Hz

Model

P2011H

Video display capabilities (DVI playback)

480p, 576p, 720p, 1080p and 1080i

Preset Display Modes

Display Mode

Horizontal Frequency

(kHz)

Vertical Frequency

(Hz)

Pixel Clock

(MHz)

Sync Polarity

(Horizontal/Vertical)

720 x 400

31.5

70.0

28.3

-/+

640 x 480

31.5

60.0

25.2

-/-

640 x 480

37.5

75.0

31.5

-/-

800 x 600

37.9

60.0

40.0

+/+

800 x 600

46.9

75.0

49.5

+/+

1024 x 768

48.4

60.0

65.0

-/-

1024 x 768

60.0

75.0

78.8

+/+

1152 x 864

67.5

75.0

108.0

+/+

1280 x 1024

64.0

60.0

108.0

+/+

1280 x 1024

80.0

75.0

135.0

+/+

1600 x 900

60.0

97.8

+/-

Electrical Specifications

Model

P2011H

Video input signals

Analog RGB, 0.7 Volts +/-5%, positive polarity at 75 ohm input impedance

Digital DVI-

D TMDS, 600mV for each differential line, positive polarity at 50 ohm input

impedance

Synchronization input signals

Separate horizontal and vertical synchronizations, polarity-free TTL level, SOG

(Composite SYNC on green)

AC input voltage/frequency/current

100 to 240 VAC/50 or 60 Hz +3 Hz/1.5 A (Max.)

Inrush current

120V:30A (Max.)

240V:60A (Max.)

Physical Characteristics

Model

P2011H

Connector type

15-pin D-subminiature, blue connector; DVI-D, white

connector

Signal cable type

Digital: Detachable, DVI-D, Solid pins, shipped

detached from the monitor

Analog: Detachable, D-Sub, 15 pins, shipped attached

to the monitor

Dimensions (with stand)

Height (extended)

435.85 mm (17.16 inches)

Height (compressed)

315.85 mm (12.44 inches)

Width

481.17 mm (18.94 inches)

Depth

171.92 mm (6.77 inches)

Dimensions (without stand)

Height

287.57 mm (11.32 inches)

Width

481.17 mm (18.94 inches)

Depth

61.50 mm (2.42 inches)

Stand dimensions

Height (extended)

360.60 mm (14.20 inches)

Height (compressed)

240.60 mm (9.47 inches)

Width

249.92 mm (9.84 inches)

Depth

171.92 mm (6.77 inches)

Weight

Weight with packaging

5.56 kg (12.23 lb)

Weight with stand assembly and cables

4.56 kg (10.03 lb)

Weight without stand assembly

(For wall mount or VESA mount

considerations - no cables)

2.70 kg (5.94 lb)

Weight of stand assembly

1.70 kg (3.74 lb)

Environmental Characteristics

Model

P2011H

Temperature

Operating

0°to40°C

Non-operating

Storage: -20°to60°C(-4°to140°F)

Shipping: -20°to60°C(-4°to140°F)

Humidity

Operating

10% to 80% (non-condensing)



Non-operating

Storage: 5% to 90% (non-condensing)

Shipping: 5% to 90% (non-condensing)

Altitude

Operating

4,850 m (15,902 ft) max

Non-operating

12,192 m (40,000 ft) max

Thermal dissipation

153.65 BTU/hour (maximum)

85.36 BTU/hour (typical)

Power Management Modes

IfyouhaveVESA'sDPM™compliancedisplaycardorsoftwareinstalledinyourPC,themonitorcanautomaticallyreduceitspowerconsumptionwhennotinuse.Thisis

referred to as Power Save Mode

*. If the computer detects input from keyboard, mouse, or other input devices, the monitor automatically resumes functioning. The

following table shows the power consumption and signaling of this automatic power saving feature:

The OSD will only function in the normal operation mode. When any button is pressed in Active-off mode, the following message will be displayed:

VESA Modes

Horizontal Sync

Vertical Sync

Video

Power Indicator

Power Consumption

Normal operation

Active

Blue

20 W (typical)/45 W (maximum)**

Active-off mode

Inactive

Blanked

Amber (Breathing)

Less than 0.5 W

Switch off

Off

Less than 0.5 W
