Dell P2217 Manuel utilisateur

Product Announcement:

This product is certificated to meet RoHS

Directive and Lead-Free produced definition.

Using approved critical components only is

recommended when the situation to replace

defective parts. Vender assumes no liability

express or implied, arising out of any unauthorized

modification of design or replacing non-RoHS

parts. Service providers assume all liability.

Qualified Repairability:

Proper service and repair is important to the safe,

reliable operation of all series products. The

service providers recommended by vender should

be aware of notices listed in this service manual in

order to minimize the risk of personal injury when

perform service procedures. Furthermore, the

possible existed improper repairing method may

damage equipment or products. It is recommended

that service engineers should have repairing

knowledge, experience, as well as appropriate

product training per new model before performing

the service procedures.

NOTICE:

! To avoid electrical shocks, the products should be

connected to an authorized power cord, and turn

off the master power switch each time before

removing the AC power cord.

! To prevent the product away from water or

expose in extremely high humility environment.

! To ensure the continued reliability of this

product, use only original manufacturer’s

specified parts.

! To ensure following safety repairing behavior, put

the replaced part on the components side of

PWBA, not solder side.

! To ensure using a proper screwdriver, follow the

torque and force listed in assembly and

disassembly procedures to unscrew screws.

! Using Lead-Free solder to well mounted the

parts.

! The fusion point of Lead-Free solder requested in

the degree of 220°C.

1. Important Safety Notice

2. Exploded view diagram with list of items

3. Wiring Connectivity Diagram

PANEL

CRT1

HDMI1DP1

Power board

KB1

FK BD

USB Side Board

USB1 USB2 USB3

Interface board

4. Disassembly and Assembly Procedures

4.1 Disassembly Procedures:

Remove the monitor stand base:

1. Place the monitor on a soft cloth or cushion.

2. Press and hold the stand-release button.

3. Lift the stand up and away from the monitor.

Use a Philips-head screwdriver to remove 4pcs

screws for unlocking mechanisms. Remove DP cap.

(No.1~4 screw size=M4x10; Torque=12±0.5kgfxcm)

Turn over the LCD monitor to let the screen faced

up, place a cloth on the panel where you are working

on to protect the panel. Continually, then wedge your

fingers between the front bezel and the panel for

unlocking mechanisms.

Turn over the LCD monitor to let the screen faced

down and then turn on the rear cover carefully.

Disconnect the USB FFC cable from the connector

of the interface board, and then remove the rear

cover.

top side

bottom side

Tear off two pieces of the aluminium foils and PVC

tape for unfixing the bracket chassis base.

Use a proper tool to release the function key cable

from the connector, then pull the function key cable

high for unsticking two positions with glue and

release the function key cable.

Use a Philips-head screwdriver to remove one screw

for unlocking the USB board unit, then release the

USB board unit and put it aside.

(No.1 screw size=M3x6, Torque=4±0.5kgfxcm)

aluminium foil

Necessary repair and test equipment:

1. Philips-head screwdriver

2. Hex-head screwdriver

4. Disassembly and Assembly Procedures

S11

S12

Unplug the panel power cable from the connector of

the panel module, then release the cable from the

panel by tearing off the adhesive tape.

Move up the bracket chassis module , tear off the

adhesive tape for release the LVDS cable, then push

the ear lock, and remove the LVDS cables from the

connectors of LCD panel module.

Take away the and then put

the bracket chassis module on a protective cushion.

bracket chassis module

(Note: you must stick a piece of mylar when you

change a new panel.)

Lift up the panel module with the bracket for

removing the front bezel with function key board,

and then release the function key board from the

hooks of the front bezel. Put the panel with bracket

chassis on a protect cushion.

S13

S10

Use a Hex-head screwdriver to remove two screws

for unlocking the D-Sub connector.

(No.1~2 screws size=M3x8, Torque=6±0.5kgfxcm)

( No.3~4 screw size=M3x8, Torque=6~7kgfxcm)

Use a Philips-head screwdriver to remove

screws for unlocking the AC power outlet.

two

Turn over the bracket chassis. Use a Philips-head

screwdriver to remove six screws for unlocking the

circuit board, release all the cables from the hooks.

(No.1 screw size=M4x8, Torque=6±0.5kgfxcm;

No.2~6 screw size=M3x7.5, Torque=6±0.5kgfxcm)

4. Disassembly and Assembly Procedures

Remove the interface board and power board from

the bracket chassis module carefully, and disconnect

all the cables.

S14

4. Disassembly and Assembly Procedures

4.2 Assembly Procedures: Turn over the bracket chassis module.

Use a Philips-head screwdriver to tighten two screws

for locking the AC power outlet.

Use a Hex-

head screwdriver to tighten two Hex Nuts for locking

the D-Sub connector.

(No.1~2 screw size=M3x8, Torque=6±0.5kgfxcm)

(No.3~4 screw size=M3x8, Torque=6~7kgfxcm;

Panel preparation: Examine the panel surface

according to inspection criteria. Turn over the panel

to place the screen faced down, then Use a Jp to

stick a piece of mylar on the specific position as the

picture below shown.(Note: you must stick a piece of

mylar when you change a new panel.)

mylar

Turn over a power board and put the power board

into the bracket chassis, locate the panel power

cable into the hook of the bracket chassis.

Place a bracket chassis base on a protective

cushion.

Take a interface board, connect a LVDS cable to the

connector of the interface board, then connect the

cable of the power board to CN2202 of the interface

board. Turn over the interface board and locate it into

the bracket. Use a Philips-head screwdriver to tighten

six screws for locking the power board and interface

board.

(No.1 screw size=M4x8, Torque=6±0.5kgfxcm;

No.2~6 screw size=M3x7.5, Torque=6±0.5kgfxcm)

Cn2202

Put the bracket chassis module on the back of LCD

module.

4. Disassembly and Assembly Procedures

S10

Put the panel module with the bracket into the front

bezel carefully to avoid pressing the function key

cable, then adjust position of the bracket chassis

module till the both parts firmly attached.

Push the earing-lock, connect LVDS cable to the

connector of panel module, then fix the cable with

the double-faced tape which sticked on the back of

the cable.

S11

S12

Use a proper tool to connect the function key cable

to the connector of the board. Fix the function key

cable by two adhesive tapes which taped on the

back of the cable as the positions of No.1 2.~

Connect the panel power cable to the connector of

the panel module, then tear off the adhesive tape

which sticked on the back of cable, fix the cable to

the panel.

Use a Jip to fix the bracket chassis base module and

panel module, then stick two pieces of aluminium foil

to fix the bracket chassis base on the positions of

the panel as the picture below shown.

aluminum foil

S13

aluminum foil

Take a function key board and a front bezel, then

locate the function keyboard into the hooks of the

front bezel for the two parts firmly attached as the

picture below shown. Put the front bezel on a protect

cushion for later assembling.

Take a USB board, a USB hub and a connect cable.

Connect the cable to the USB board, then locate the

USB board into the USB hub.

S14

4. Disassembly and Assembly Procedures

Use a Philips-head screwdriver to tighten four

screws for locking mechanisms, then

stick one

piece of label on the specific positions as the

picture below shown

(No.1~4 screw size=M4x10; Torque=12 0.5kgfxcm)±

Move the assembled rear cover close to the

panel unit, then connect the USB FFC cable to

the connector of interface board. Put down the

rear cover and push the rear cover on the

positions marked as the picture below shown for

mechanisms engagement.

S17

S16

Put down a rear cover on a protect cushion. Stick

a piece of aluminum foil on one side of the USB

hub, then locate the USB unit into the hook of the

rear cover, then use a Philips-head screwdriver to

tighten one screw for locking the USB board with the

USB hub with the middle bezel.

(No.1 screw size=M3x6, Torque=4±0.5kgfxcm)

S15

L c

rovide power supply

and a video signal to the monitor

ift up the monitor, heck the DELL logo if it is firmly

attached to the front bezel. P

, then turn on the

monitor for functionality check.

S19

Stick one piece of label on the specific positions as

the picture below shown. Fit the two tabs on the

upper part of the stand into the grooves on the back

of the monitor, and then press the stand so that the

monitor mounting area snaps onto the stand.

S18

5. Trouble Shooting Instructions

WARNING: Before you begin any of the procedures in this section, follow the

Safety instructions.

Self-test

Your monitor provides a self-test feature that allows you to check if your monitor is

functioning properly. If your monitor and computer are properly connected but the

monitor screen remains dark, run the monitor self-test by performing the following

steps:

1. Turn off both your computer and the monitor.

2. Disconnect all video cables from the monitor. This way, the computer doesn’t

have to be involved.

3. Turn on the monitor.

If the monitor is working correctly, it detects that there is no signal and one of the

following message appears. While in self-test mode, the power LED remains white.

Dell

P1917S/P1917SWh

No VGA Cable

The display will go into Power Save Mode in 4 minutes.

www.dell.com/support/monitors

Dell

P2017H

No VGA Cable

The display will go into Power Save Mode in 4 minutes.

www.dell.com/support/monitors

Dell P2217/P2217Wh

No VGA Cable

The display will go into Power Save Mode in 4 minutes.

www.dell.com/support/monitors

Table des matières

Autres manuels Dell Moniteur

Dell

Dell E2209WFP Manuel utilisateur

Dell

Dell P2016 Manuel utilisateur

Dell

Dell S1909WFP Manuel utilisateur

Dell

Dell E2723 Manuel utilisateur

Dell

Dell P2722HB Instructions d'utilisation

Dell

Dell D2421DS Manuel utilisateur

Dell

Dell P2415Q Manuel utilisateur

Dell

Dell S2422HZ Manuel utilisateur

Dell

Dell D1901N Manuel utilisateur

Dell

Dell E1715S Instructions d'installation

Dell

Dell E1916HV Instructions d'utilisation

Dell

Dell P2421D Instructions d'utilisation

Dell

Dell 2209WA - UltraSharp - 22" LCD Monitor Manuel utilisateur

Dell

Dell E178WFP - 17" LCD Monitor Manuel utilisateur

Dell

Dell M783c Manuel utilisateur

Dell

Dell S2722DGM Manuel utilisateur

Dell

Dell C5522QT Manuel utilisateur

Dell

Dell S3222HN Manuel utilisateur

Dell

Dell ST2010-BLK Manuel utilisateur

Dell

Dell 1707FP - UltraSharp - 17" LCD Monitor Manuel utilisateur

Dell

Dell 1504FP - UltraSharp - 15" LCD Monitor Manuel utilisateur

Dell

Dell P2312H Manuel utilisateur

Dell

Dell 2405FPW - UltraSharp - 24" LCD Monitor Instructions d'utilisation

Dell

Dell S2309WFP Manuel utilisateur

Manuels Moniteur populaires d'autres marques

Linear Acoustic

Linear Acoustic LQ-1000 Manuel utilisateur

AOC

AOC I2579V Manuel utilisateur

Gateway

Gateway FPD1520 Manuel utilisateur

Furuno

Furuno Mu 120c Manuel utilisateur

Asus

Asus VB171D - 17" LCD Monitor Manuel utilisateur

Philips

Philips 107C64 Manuel utilisateur

EverFocus

EverFocus EN-7517E Manuel utilisateur

Panasonic

Panasonic TH152UX1 - 152" PLASMA TV Manuel utilisateur

LG 50PM1M - - 50" Plasma Panel Manuel utilisateur

Bosch

Bosch DDU 9 Manuel utilisateur

Acer

Acer A231HL Manuel utilisateur

Philips

Philips 86BDL4152T Manuel utilisateur

NEC

NEC AccuSync LCD5V Manuel utilisateur

Emay

Emay SleepO2 Manuel utilisateur

IBM

IBM 6360 Instructions d'installation

LG M1950D-PZ Manuel utilisateur

Sceptre

Sceptre D40 Manuel utilisateur

Hunt Electronic

Hunt Electronic HCD-15AH Manuel utilisateur
