Dell W-7205 Series Manuel utilisateur

Dell Networking

W-7205 Controller

Installation Guide

Dell Networking W-7205 Controller |Installation Guide 0511659-03 |April 2015

Wireless Networks®, the registered Aruba the Mobile Edge Company logo, and Aruba Mobility Management

System®. Dell™, the DELL™ logo, and PowerConnect™ are trademarks of Dell Inc.

Originated in the USA. All other trademarks are the property of their respective owners.

Open Source Code

Certain Aruba products include Open Source software code developed by third parties, including software code

subject to the GNU General Public License (GPL), GNU Lesser General Public License (LGPL), or other Open

used can be found at this site:

http://www.arubanetworks.com/open_source

Legal Notice

The use of Aruba Networks, Inc. switching platforms and software, by all individuals or corporations, to terminate

other vendors’ VPN client devices constitutes complete acceptance of liability by that individual or corporation for

this action and indemnifies, in full, Aruba Networks, Inc. from any and all legal actions that might be taken against it

with respect to infringement of copyright on behalf of those vendors.

Dell Networking W-7205 Controller |Installation Guide Contents| 3

Contents

Contents 3

Preface 7

Guide Overview 7

Related Documentation 7

Contacting Dell 7

W-7205 Controller 9

Packaging Checklist 9

W-7205 Components 10

Dual-Media Ports 11

10/100/1000BASE-T (RJ-45) Ports 11

1000BASE-X (SFP) Ports 12

Dual-Media Port LEDs 12

10GBASE-X Ports 13

SFP/SFP+ Modules and DAC Cables 14

USB Interface 15

Serial Console Port 15

Serial Console Port Adapter 16

Micro-USB Console Port 16

Micro-USB Driver 16

Management Port 16

Power, Status, and Peered LEDs 17

LCD Panel 17

LCD Menu 17

Disabling the LCD Screen 18

CPU Module 19

Power Supply 19

4|Contents Dell Networking W-7205 Controller |Installation Guide

Grounding Point 19

Installation 21

Precautions 21

Selecting a Location 22

Rack Mounting - Standard/Front 22

Required Tools and Equipment 22

Installation Steps 23

Rack Mount Installation- Mid 23

Required Tools and Equipment 24

Installation Steps 24

Table or Shelf Installation 25

Required Tools and Equipment 25

Installation Steps 25

Wall Mounting 25

Required Tools and Equipment 26

Installation Steps 26

Connecting and Disconnecting the AC Power Cord 27

Connecting the AC Power Cord 27

Disconnecting the AC Power Cord 28

Installing an SFP/SFP+ Module 28

Connecting an LC Fiber Optic Cable 28

Disconnecting an LC Fiber Optic Cable 29

Removing an SFP/SFP+ Module 29

Specifications, Safety, and Compliance 31

W-7205 Specifications 31

Physical 31

Power Supply Specifications 31

Operating Specifications 31

Storage Specifications 31

Safety and Regulatory Compliance 31

Regulatory Model Name 32

Electromagnetic Interference 32

United States 32

Canada 32

Europe 33

Japan VCCI 33

Taiwan (BSMI) 33

South Korea 33

EU Regulatory Conformance 33

Battery Statements 33

Proper Disposal of Dell Equipment 34

Waste of Electrical and Electronic Equipment 34

China RoHS 34

European Union RoHS 34

India RoHS 35

Dell Networking W-7205 Controller |Installation Guide Contents| 5

Dell Networking W-7205 Controller |Installation Guide Preface| 7

Preface

This document describes the hardware features of the Dell Networking W-7205 Controller. It provides a detailed

overview of the physical and performance characteristics of the controller and explains how to install the controller

and its accessories.

Guide Overview

lW-7205 Controller on page 9 provides a detailed hardware overview of the W-7205 controller and its

components.

lInstallation on page 21 describes how to install the W-7205 controller and its components.

lSpecifications, Safety, and Compliance on page 31 provides the W-7205 controller’s technical specifications and

safety and regulatory compliance information.

Related Documentation

Refer to the latest

Dell Networking W-Series ArubaOS User Guide

and

Dell Networking W-Series ArubaOS CLI

Reference Guide

for complete management of the controller.

Contacting Dell

Web Site Support

Main Website dell.com

Contact Information dell.com/contactdell

Support Website dell.com/support

Documentation Website dell.com/support/manuals

Table 1: Contact Information

Dell Networking W-7205 Controller |Installation Guide W-7205 Controller| 9

Chapter 1

W-7205 Controller

The W-7205 Controller is a wireless LAN controller that connects, controls, and intelligently integrates wireless

Access Points (APs) and Air Monitors (AMs) into a wired LAN system.

There are two models of the W-7205 controller that do not differ physically or functionally from each other.

lW-7205-US: For the United States of America

lW-7205-RW: For the rest of the world

The W-7205 controller has the following port specification:

Model Ports Number of APs

Supported

Number of Users

Supported

W-7205 l4 x dual-media (10/100/1000BASE-T and 1000BASE-X)

l2 x 10GBASE-X

256 8192

Table 2: W-7205 Controller Port Specification

NOTE: The W-7205 controller requires Dell Networking W-Series ArubaOS 6.4.3.1 or later version.

Packaging Checklist

NOTE: Inform your supplier if there are any incorrect, missing, or damaged parts. If possible, retain the carton, including the original

packing materials. Use these materials to repack and return the unit to the supplier, if needed.

Item Quantity

W-7205 Controller 1

Standard Mounting Brackets 2

M6 x 15 mm Phillips Pan Head Screws 4

M4 x 8 mm Phillips Flat Head Screws 8

M6 x 7 mm Grounding Screws 2

M6 Cage Nut 4

M6 Clip Nut 4

AC Power Cord Retaining Clip 1

Table 3: Package Contents

10 |W-7205 Controller Dell Networking W-7205 Controller |Installation Guide

Item Quantity

Power Cable 1

Micro-USB Cable 1

Rubber Feet 4

Installation Guide (this document, printed) 1

Quick Start Guide (Printed) 1

Dell Safety, Environment, and Regulatory Information (printed) 1

Dell Warranty and Support Information (printed) 1

Dell Software License Agreement (printed) 1

Table 3: Package Contents

NOTE: Optional accessories are available for use with the Dell W-7205 controller and are sold separately. Contact your Dell sales

representative for details and assistance.

W-7205 Components

This section introduces the different components of the W-7205 controller, and specifies their locations in the

controller. Figure 1 shows the front panel of the W-7205 controller and Figure 2 shows the back panel of the W-

7205 controller.

Figure 1 Front Panel of the W-7205 Controller

Figure 2 Back Panel of the W-7205 Controller
