Dell™ Latitude™ C/Port II APR

System Information Guide

Guide d'information sur le système

Guia de Informações do Sistema

Guía de información del sistema

Model PRX

www.dell.com | support.dell.com

Dell™ Latitude™ C/Port II APR

System Information Guide

Notes, Notices, and Cautions

NOTE: A NOTE indicates important information that helps you make better use of your computer.

NOTICE: A NOTICE indicates either potential damage to hardware or loss of data and tells you

how to avoid the problem.

CAUTION: A CAUTION indicates a potential for property damage, personal injury,

or death.

____________________

Information in this document is subject to change without notice.

Reproduction in any manner whatsoever without the written permission of Dell Computer Corporation is strictly

forbidden.

Trademarks used in this text: Dell, the DELL logo, and Latitude are trademarks of Dell Computer Corporation; 3Com

is a trademark of 3Com Corporation; Microsoft, Windows, and Windows NT are registered trademarks of Microsoft

Corporation.

Other trademarks and trade names may be used in this document to refer to either the entities claiming the marks and

names or their products. Dell Computer Corporation disclaims any proprietary interest in trademarks and trade names

other than its own.

This product incorporates copyright protection technology that is protected by method claims of certain U.S. patents

and other intellectual property rights owned by Macrovision Corporation and other rights owners. Use of this copyright

protection technology must be authorized by Macrovision Corporation, and is intended for home and other limited

viewing uses only unless otherwise authorized by Macrovision Corporation. Reverse engineering or disassembly is

prohibited.

January 2002 P/N 3G480 Rev. A03

Dell Latitude C/Port II APR System Information Guide 3

Dell™ Latitude™ C/Port II APR

System Information Guide

This document contains getting started, safety, regulatory, and warranty

information about your Dell Latitude C/Port II Advanced Port Replicator

(APR) as well as information about other Dell documents that are available

and how to obtain them.

Safety Instructions

The following information defines the meaning of additional symbols used

only in the Safety Instructions section.

Caution: General (Safety Instructions, continued)

Risk of explosion Aircraft

Risk of fire Use of this feature may be prohibited

on aircraft

Risk of electric shock

• When setting up the docking station for work, place it

on a level surface.

• Do not attempt to service the docking station yourself

unless you are an authorized service technician. Always

follow installation instructions closely.

4Dell Latitude C/Port II APR System Information Guide

www.dell.com | support.dell.com

Caution: Power (Safety Instructions, continued)

• If you use an extension power cable with your AC

adapter, ensure that the total ampere rating of the

products plugged in to the extension power cable does

not exceed the ampere rating of the extension cable.

• Do not push objects into air vents or openings of your

computer. Doing so can cause fire or electric shock by

shorting out interior components.

• Place the AC adapter in a ventilated area, such as a desk

top or on the floor, when you use it to run the computer

or to charge the battery. Do not cover the AC adapter

with papers or other items that will reduce cooling; also,

do not use the AC adapter inside a carrying case.

• Do not use your computer in a wet environment, for

example, near a bath tub, sink, or swimming pool or in a

wet basement.

• To help avoid the potential hazard of electric shock, do

not connect or disconnect any cables or perform

maintenance or reconfiguration of this product during

an electrical storm. Do not use your computer during

an electrical storm unless all cables have been

disconnected and the computer is operating on battery

power.

• Before you clean your docking station, remove power.

Clean your computer with a soft cloth dampened with

water. Do not use liquid or aerosol cleaners, which may

contain flammable substances.

• Use only the Dell-provided AC adapter approved for

use with this docking station. Use of another AC

adapter may cause a fire or explosion.

Dell Latitude C/Port II APR System Information Guide 5

• Before you connect the docking station to an electrical

outlet, check the AC adapter voltage rating to ensure

that the required voltage and frequency match the

available power source.

• To remove power from the computer, turn it off,

remove the battery pack, and disconnect the AC

adapter from the electrical outlet.

• To help prevent electric shock, plug the AC adapter and

peripheral power cables into properly grounded power

sources. These power cables may be equipped with

three-prong plugs to provide an earth grounding

connection. Do not use adapter plugs or remove the

grounding prong from the power cable plug. If you use a

power extension cable, use the appropriate type, two-

prong or three-prong, to mate with the AC adapter

power cable.

• Be sure that nothing rests on your AC adapter’s power

cable and that the cable is not located where it can be

tripped over or stepped on.

• If you are using a multiple-outlet power strip, use

caution when plugging the AC adapter’s power cable

into the power strip. Some power strips may allow you

to insert the plug incorrectly. Incorrect insertion of the

power plug could result in permanent damage to your

computer, as well as risk of electric shock and/or fire.

Ensure that the ground prong of the power plug is

inserted into the mating ground contact of the power

strip.

6Dell Latitude C/Port II APR System Information Guide

www.dell.com | support.dell.com

Other Documents Available

• Documentation updates, which are sometimes included with your docking

device to describe changes to your docking device or software. Always read

these updates before consulting any other documentation because the

updates often contain the latest information.

• Documentation included with any options you purchase separately from

your docking device. This documentation includes information that you

need to configure and install these options in your docking device.

Getting Help

Dell provides a number of tools to help you if your docking device does not

perform as expected. For information on these help tools, see the “Getting

Help” section in the computer’s User’s Guide.

Docking Device Overview

NOTE: Alert your network administrator before you connect the docking device to

a network.

You must attach an AC adapter to the docking device before you dock the

computer to the docking device and turn on the computer. The AC adapter

powers the docking device and the computer at the same time. Any battery

installed in the computer charges while you use the docking device.

NOTICE: Always use the Dell PA-6 AC adapter that came with the docking device.

If you use any other commercially available AC adapter—or the AC adapter from

older models of Dell computers—you may damage the docking device or the

computer.

Dell Latitude C/Port II APR System Information Guide 7

I/O Panel of the Docking Device

The “External I/O Connectors” table shows the icons for each of the

connectors on the back of the APR and indicates the type of external

device(s) that you can attach to each connector.

External I/O Connectors

Connector

Icon

Connector Description

One or two USB devices, such as a USB mouse, connect to

the dual USB connector.

An external PS/2-style keyboard or external numeric keypad

connects to the PS/2 keyboard connector.

An external PS/2-compatible mouse connects to the PS/2

mouse connector.

A serial device, such as a serial mouse or external modem,

connects to the serial port connector.

A network interface cable connects to the NIC connector.

PS/2-keyboard

connector

serial

connector

USB

connectors (2)

parallel

connector

PS/2-mouse

connector

video

connector

network

connector

AC adapter

connector

8Dell Latitude C/Port II APR System Information Guide

www.dell.com | support.dell.com

Audio Connectors and Infrared Sensor

A parallel device, such as a printer, connects to the parallel

port connector.

An external monitor connects to the video connector.

The AC adapter that came with the APR connects to the AC

adapter connector.

External I/O Connectors

infrared sensor audio line-out connector
